This document outlines Tietec's telecommunication infrastructure services for various clients in Egypt and other countries. The services include site acquisition, construction works, and telecom installation. Specifically, it discusses projects for Ericsson in Egypt involving GSM sites for Vodafone and Etisalat, a CDMA project for Quicktel in Egypt involving Sofisat sites, GSM sites for Alcatel-Lucent in Egypt for Mobinil and Etisalat, and CDMA projects for ZTE and Telecom Egypt in Egypt. It also mentions turnkey projects for Huawei in Mali and Libya. The services provided include site searches, permitting, construction of towers, shelters, and installations.

1. éTelecommunication Infrastructure Services
A- Vodafone & Etisalat GSM Sites – for Ericsson Company, Egypt.
-The site acquisition service consists of the following components:
Site Search and Negotiation
- A suitable site location(s) (minimum three alternatives) is acquired that satisfies the
search criteria specified in both the nominal cell plan. A preliminary agreement is
then signed with the owner.
RF Survey and Preliminary Site Design (Cad Drawings)
- Providing a clear presentation of the site to the customer to be evaluated including
photos to describe the site and any obstructions around it, proposed shelter and structure locations drawn u
AutoCAD program, and power source availability.
Line Of Sight Verification and Report
- Providing a full report using the Path Loss Program after undergoing surveys, this decides the MW link
connect the site to the whole network.

2. Final Cad Drawings and Structural Analysis Report

4. - Submitting final AutoCAD designs for the image of the site (RF antenna information is obtained from th
acceptance report, MW dish information is obtained from
The LOS report and finally shelter and structure locations are obtained from the
Structural analysis report by a certified civil consultant, who evaluates the durability
Of the building.
Lease Contract Negotiation and Signature
- Negotiating the final contract terms with the owner to sign it.
Issuing the required Permits
- Providing all needed permits to construct the site, which include but are not limited to environmental,
environmental health safety, municipality, antiquities, roads and traffic, agricultural, and civil aviation per
Securing a permanent power source
- Getting permanent power meter and permits for the site.
I.Construction Works of Greenfield and Roof Top Sites:
Our scope of work in the Construction area includes necessary design for individual site, supply and
installation of all Civil Works material in accordance with our customers' specifications.

5. Note: Safety Tools and procedures are applied during all processes under the inspection of our safety
and quality control supervisor.
Our construction works service consists of the following Subjects:
Civil Works
- Site Levelling and Clearance
- Excavation and Concrete Works
- Soil Replacement and Backfilling as per the customer's specifications
Tower, Stub Tower and GRD Erection
- Manufacturing the Steel Grillage, this will carry the Loads.
- Tower footprint is taken off to start erecting the tower using hot dipped galvanized
Steel works and stainless steel auxiliaries.
- Whilst using the most practical size of cable tray throughout the installation, Consideration is given to fu
expansion as well as minimizing the visual impact.
Shelter and RF (Feeder and Antenna) Installation
Supply and Installation of the Shelter with its internal fittings to be in accordance with the Proposed Shelte
and as follows:
- Support Structures
- Navigational Lights
- RF Installations
RF to be extended from the surge protection on the Shelter feeder access panel By means of jumpers, coile
tied to the wire tray above each BTS position ,
Ready for the BTS Rack installations by others,
- Earth System
- Air-conditioners and Controllers
- Alarms and IDF
- AC Distribution Board and Circuits
- Site Security Light
- DC Rectifier
- Fire Protection System and Handheld Extinguisher
- Transmission System
IV. Construction of Special Projects
Our scope of work in the Special Projects area includes the necessary design for individual site, and the
supply and installation of upgrading material in accordance with our customers' specifications.
Our construction works service includes the following Projects:
3G and RRH Sites Upgrades
- Installation of RRU units and Battery units.
- Installation of new RRU Brackets and Battery Brackets.
- Replacement of all 2G antenna and installation of 3G antenna with new feeder entry
glands and their needed Brackets.

6. - Supply and Installation of fiber Cables with their PVC conduits.
- Supply and Installation of upgraded earthing system.
Modernization of Sites Equipments
- Replacement of the 24000 Btu/Hr with an Air conditioning system of 36000 Btu/Hr.
- Replacement of power cable 4 x 16 mm with cable 4 x 25 mm.
- Supply and Installation of a new Electric Distribution Panel with main 63A CB.
Radio Enhancement
- Enhancement with new antenna including the supply and installation of all needed feeder
Cables and feeder entry glands, including all needed cable trays.
TX Enhancement
- Enhancement with new feeder entry glands and feeder entry glands cubes, including supply and installati
needed cable trays.
B- Sofisat (Telecom Egypt) CDMA Project – for Quicktel Company, Egypt.
The Scope of Work and Services includes:
I. Project Management Service
- Offering project management service for Quicktel Company as to supervise all
Subcontractors of the Sofisat Project.
- Managing 6 subcontractors to acquire and complete their sites for 18 months.
- Number of completed sites: 69
II. Site Acquisition – Site Search and Negotiation
RF Survey and Preliminary Site Design (Cad Drawings), Line Of Sight Verification, Final Cad Drawings
Structural Analysis Report,
Lease Contract Negotiation and Signature, and issuing the required Permits.
III. Construction Works of Roof Top and Greenfield Sites
Civil Works, Tower and Stub
Tower Erection, Shelter and RF (Feeder and Antenna) Installation (with internal fittings).
C- Mobinil & Etisalat GSM Sites – for Alcatel-Lucent Company, Egypt.
The Scope of Work and Services includes:
I. Site Acquisition
Site Search and Negotiation, RF Survey and Preliminary Site Design (Cad
Drawings), Line Of Sight Verification, Final Cad Drawings and Structural Analysis Report,
Lease Contract Negotiation and Signature, and issuing the required Permits.

7. II. Construction Works of Greenfield Sites
Civil Works, Tower Erection, and Shelter and RF
(Feeder and Antenna) Installation (with internal fittings: Air-Conditioner, A/C Controller, DC/Ac panel, F
system, DDF, power connections, wiring, feeder cable entry glands,
Switches, power sockets, environmental monitoring system, external light & earth system).
II.Construction Works of Rooftop Sites
Shelter, and Stub Tower (with internal fittings).
D- Telecom Egypt CDMA Phase II Project – for ZTE Corporation, Egypt.
The Scope of Work and Services includes:
I. Construction Works of Green Field Sites
Civil Works, Tower Erection, and Shelter andRF (Feeder and Antenna) Installation (with internal fittings).
II. Construction Works of Rooftop Sites
Shelter, and Stub Tower (with internal fittings).
III. Equipment Installation
BTS Site Survey, Site Preparation, Physical Installation and providing the management system.
E- Optical Fiber Project – for ZTE Corporation, Egypt
The Scope of Work and Services included:
I. Survey & Design Services
ncluding Survey Reports to prepare all installation material.
II. Execution and Installation
of the civil works and the of Fiber Optic Cable's Laying, Splicing and Termination.
III. Testing
for the Fiber Optical Links and submitting a Testing Report.
F- CDMA Project – (ZTE Corporation) for STC (Saudi Telecom Company).
The Scope of Work and Services included:
I. Installation, testing and commissioning for ZTE

8. CDMA Access Products containing BTS and BSC.
G- CDMA – ZTE Corporation (for National Telecommunication Institute).
The Scope of Work and Services included:
I. Installation, testing and commissioning for ZTE
CDMA products containing the MSC, BTS and BSC.
Tietec team looks forward to build business relationships with your company & serve your business
needs in the near future.
H-Mali-Libya-Huawei, Turnkey projects.
The Scope of Work and Services includes:
I. Site Acquisition
Site Search and Negotiation, RF Survey and Preliminary Site Design (Cad
Drawings), Line Of Sight Verification, Final Cad Drawings and Structural Analysis Report,
Lease Contract Negotiation and Signature, and issuing the required Permits.
II. Construction Works of Greenfield Sites
Civil Works, Tower Erection, and Shelter and RF
(Feeder and Antenna) Installation (with internal fittings: Air-Conditioner, A/C Controller, DC/Ac panel, F
system, DDF, power connections, wiring, feeder cable entry glands,
Switches, power sockets, environmental monitoring system, external light & earth system).
III-Construction Works of Rooftop Sites
Shelter, and Stub Tower (with internal fittings).
IV- Telecom Installation
-Installation for BTS cabinets
–Battery Cabinets
-MW Link & commission
-Antenna 2G & 3G.
