This document discusses TCP performance with delayed acknowledgements in wireless networks. It finds that TCP throughput does not always benefit from unrestricted delayed acks, and that there exists an optimal delay window size producing the best throughput for a given topology and flow pattern. Too small a window causes too many acks, while too large a window induces interference and losses from bursty transmissions. The document proposes adaptive delayed ack schemes for ad hoc and hybrid networks to dynamically select appropriate delay window sizes based on path length. It also addresses the issue of unfriendliness between standard and delayed ack TCP.
