2. Structural Traps
TERMS TO KNOW BEFORE UNDERSTANDING
TRAPS
Porous rock
Permeable rock
Source rock
Reservoir rock
Migration path(primary migration and
secondary migration)
Seal rock/Cap rock/Roof rock
3. Structural Traps
Porous rock:
A rock which contains pores in it
Permeable rock:
A rock which contains interconnected pores
Source rock:
The rock which generates Hydrocarbons
Reservoir rock:
Porous and permeable rock unit which holds
Hydrocarbons
4. Structural Traps
Seal rock:
An impermeable rock that acts as a barrier to the passage
of further upward migration of Hydrocarbons, migrating
in the subsurface.
Common seals are:
– Shale
– Evaporites
Seal overlies the reservoir rock to form a trap.
Also known as roof rock and cap rock.
5. Structural Traps
Primary Migration:
The migration/movement of Hydrocarbons from the
source rock to reservoir rock is called primary migration.
Secondary Migration:
The movement of Hydrocarbons within the reservoir rock
is called secondary migration.
6. Structural Traps
What is a Trap?
Any arrangement of strata that permits the accumulation
of hydrocarbons in commercial quantities is a trap.
7. Structural Traps
A trap is the place where oil and gas are barred from
further movement(Levorsen,1967).
Checks the flow of Hydrocarbons
8. Structural Traps
A structural trap is a geological trap that forms as a result
of changes in structure of the subsurface due to tectonic,
gravitational and compactional processes i.e. Folding,
faulting etc.
9. Types of Structural Traps
Anticlinal traps
Fault related traps
Salt dome traps
10. Structural Traps
Anticlinal Trap:
If a permeable rock like sandstone or limestone is
located between impermeable rock layers like shale
and the rocks are folded into an anticline, oil and gas
can move upward in the permeable reservoir rocks,
and accumulate in the upper region of the anticline.
13. Structural Traps
Fault-Related Traps:
If faulting can shift permeable and impermeable rocks
so that the permeable rocks always have impermeable
rocks above them, then an oil trap can form.
Both normal and reverse faults can form this type
of oil trap
17. Structural Traps
Salt Dome Traps:
salt that has moved up through the Earth,
punching through and bending rock along the
way.
Oil can come to rest right up against the
impermeable salt, which makes salt an effective
trap rock
