This document provides an overview and tutorials for using MyBatis with Spring Boot. It introduces the mybatis-spring-boot-starter dependency, and covers setting up MyBatis mappers using annotation and XML styles. It also demonstrates MyBatis configuration in Spring Boot, database migrations with Flyway, and MyBatis testing. Additional sections explain concepts like repositories, Java configuration, and using QueryDSL with MyBatis.

1. Spring Boot with MyBatis
KESTI 개발팀

2. Spring Boot with MyBatis
• mybatis-spring-boot-starter 소개
• MyBatis Tutorials
• setup
• mappers
• testing
• Bonus Tutorials
• Flyway
• QueryDSL
2016-10-12KESTI 개발팀 세미나 2

3. MyBatis for Spring Boot
• MyBatis 를 Spring Boot Application 에서 사용하기 위한
라이브러리
• 홈페이지 : http://www.mybatis.org/mybatis-spring-boot/
• 소스 : https://github.com/mybatis/mybatis-spring-boot
• 예제 :
• KESTI SpringBoot-MyBatis Tutorials
• Spring Boot 에서 Java Config를 통해 myBatis 연동하기
2016-10-12KESTI 개발팀 세미나 3

4. MyBatis Tutorials
2016-10-12KESTI 개발팀 세미나 4

5. Tutorial Overview
1. mybatis-spring-boot-starter 프로젝트 구성
2. Mapper – Annotation / XML 방식
3. MyBatis 설정 방법
4. Flyway 를 이용한 database migration 방법
5. MyBatis 단위 테스트
2016-10-12KESTI 개발팀 세미나 5

6. 1. 프로젝트 구성
<dependencies>
<dependency>
<groupId>kr.kesti.kesti4j</groupId>
<artifactId>kesti4j-data-java6</artifactId>
</dependency>
<dependency>
<groupId>org.mybatis.spring.boot</groupId>
<artifactId>mybatis-spring-boot-starter</artifactId>
<version>1.0.1</version>
</dependency>
<dependency>
<groupId>com.h2database</groupId>
<artifactId>h2</artifactId>
</dependency>
</dependencies>
2016-10-12KESTI 개발팀 세미나 6

7. Project Structures
configuration
data handling source
Spring Boot Application
Flyway database migration
MyBatis configuration & XML Mappers
환경설정 정보
Test 코드
2016-10-12KESTI 개발팀 세미나 7

8. XML Mapper
<?xml version="1.0" encoding="UTF-8" ?>
<!DOCTYPE mapper
PUBLIC "-//mybatis.org//DTD Mapper 3.0//EN"
"http://mybatis.org/dtd/mybatis-3-mapper.dtd">
<mapper namespace="kr.kesti.mybatis.examples.domain.models">
<select id="selectActorByFirstname" parameterType="String" resultType="Actor">
SELECT * FROM Actors WHERE firstname = #{firstname} limit 1
</select>
<insert id="insertActor" useGeneratedKeys="true" keyProperty="id">
insert into Actors(firstname, lastname)
values( #{firstname}, #{lastname} )
</insert>
<!-- Oracle, PostgreSQL 은 SEQUENCE -->
<!--
<insert id="insertActorBySequence">
<selectKey keyProperty="id" resultType="int" order="BEFORE" statementType="PREPARED">
SELECT SEQ_ID.nextval FROM DUAL
</selectKey>
INSERT INTO Autors (id, firstname, lastname)
VALUES (#{id}, #{firstname}, #{lastname})
</insert>
-->
</mapper>
2016-10-12KESTI 개발팀 세미나 8

9. Annotated Mapper
/**
* Actor 를 위한 MyBatis Mapper 입니다.
*/
public interface ActorMapper {
@Select("SELECT * FROM Actors WHERE firstname = #{firstname}")
Actor findByFirstname(@Param("firstname") String firstname);
@Select("SELECT * FROM Actors")
List<Actor> findAll();
@Delete("DELETE FROM Actors WHERE id=#{id}")
void deleteById(@Param("id") Integer id);
}
/**
* MyBatis 를 Spring boot 에서 사용하기 위한 환경설정
*/
@Configuration
@EnableAutoConfiguration
@ComponentScan(basePackageClasses = { ActorRepository.class })
@MapperScan(basePackageClasses = { ActorMapper.class })
public class MyBatisConfiguration extends AbstractFlywayMyBatisConfiguration {
2016-10-12KESTI 개발팀 세미나 9
XML Mapper
보다 좋은점은?

10. Repository / DAO
/**
* {@link Actor} 를 위한 Repository (DAO) 입니다.
*/
@Slf4j
@Repository
public class ActorRepository {
@Autowired ActorMapper mapper;
@Autowired SqlSessionTemplate session;
public Actor findByFirstname(@NonNull String firstname) {
return mapper.findByFirstname(firstname);
}
public Actor findByFirstnameWithXmlMapper(@NonNull String firstname) {
return session.selectOne("selectActorByFirstname", firstname);
}
public List<Actor> findAll() {
return mapper.findAll();
}
public int insertActor(@NonNull Actor actor) {
return session.insert("insertActor", actor);
}
public void deleteById(@NonNull Integer id) {
mapper.deleteById(id);
}
}
2016-10-12KESTI 개발팀 세미나 10

11. MyBatis JavaConfig
@Configuration
@EnableAutoConfiguration
@ComponentScan(basePackageClasses = { ActorRepository.class })
@MapperScan(basePackageClasses = { ActorMapper.class })
public class MyBatisConfiguration extends AbstractFlywayMyBatisConfiguration {
// datasource 용 properties (application.properties 에서 자동으로 정보를 읽어옴)
@Inject DataSourceProperties dataSourceProperties;
// mybatis 용 properties (application.properties 에서 자동으로 정보를 읽어옴)
@Inject MybatisProperties mybatisProperties;
@Override
protected DatabaseSetting getDatabaseSetting() {
return DatabaseSetting.builder()
.driverClass(dataSourceProperties.getDriverClassName())
.jdbcUrl(dataSourceProperties.getUrl())
.build();
}
@Override
protected String getMyBatisConfigPath() {
return mybatisProperties.getConfig();
}
@Override
protected String getMyBatisMapperPath() {
return mybatisProperties.getMapperLocations()[0];
}
}
2016-10-12KESTI 개발팀 세미나 11
XML Config
와 장단점
비교

12. Spring Boot application.properties
### DataSource
spring.datasource.driver-class-name=org.h2.Driver
spring.datasource.jdbc-url=jdbc:h2:mem
spring.datasource.username=sa
spring.datasource.password=
### MyBatis
mybatis.config=mybatis/mybatis-config.xml
mybatis.mapper-locations=mybatis/mappers/**/*Mapper.xml
mybatis.executor-type=simple
### Logging
logging.level.root=info
logging.level.kr.kesti.mybatis.examples=debug
2016-10-12KESTI 개발팀 세미나 12

13. Database Setup by Flyway
/**
* Flyway 를 이용한 DB Migration 을 수행하도록 합니다.
*
* @param dataSource DataSource
* @return {@link Flyway} 인스턴스
*/
@Bean(initMethod = "migrate")
protected Flyway flyway(DataSource dataSource) {
Flyway flyway = new Flyway();
flyway.setDataSource(dataSource);
if (cleanDatabaseForTest()) {
flyway.clean();
}
return flyway;
}
CREATE TABLE Actors (
id SERIAL PRIMARY KEY,
firstname VARCHAR(64),
lastname VARCHAR(64)
);
INSERT INTO Actors (firstname, lastname) VALUES
('Sunghyouk', 'Bae');
INSERT INTO Actors (firstname, lastname) VALUES ('Misook',
'Kwon');
INSERT INTO Actors (firstname, lastname) VALUES ('Jehyoung',
'Bae');
INSERT INTO Actors (firstname, lastname) VALUES ('Jinseok',
'Kwon');
INSERT INTO Actors (firstname, lastname) VALUES ('Kildong',
'Hong');
2016-10-12KESTI 개발팀 세미나 13

14. Configuration Test
@Slf4j
@RunWith(SpringJUnit4ClassRunner.class)
@SpringApplicationConfiguration(classes = { MyBatisConfiguration.class })
public class MyBatisConfigurationTest {
@Inject ActorMapper actorMapper;
@Inject ActorRepository actorRepository;
@Inject private SqlSessionFactory sf;
@Test
public void testConfiguration() {
assertThat(actorMapper).isNotNull();
assertThat(actorRepository).isNotNull();
assertThat(sf).isNotNull();
}
}
2016-10-12KESTI 개발팀 세미나 14

15. Repository Test
@Slf4j
@RunWith(SpringJUnit4ClassRunner.class)
@SpringApplicationConfiguration(classes = { MyBatisConfiguration.class })
public class ActorRepositoryTest {
@Inject ActorRepository actorRepo;
private static final String FIRST_NAME = "Sunghyouk";
@Test
public void testConfiguration() {
assertThat(actorRepo).isNotNull();
}
@Test
public void testFindByFirstname() {
Actor actor = actorRepo.findByFirstname(FIRST_NAME);
assertThat(actor).isNotNull();
}
@Test
public void testFindByFirstnameWithXmlMapper() {
Actor actor = actorRepo.findByFirstnameWithXmlMapper(FIRST_NAME);
assertThat(actor).isNotNull();
}
@Test
public void testFindAll() {
List<Actor> actors = actorRepo.findAll();
assertThat(actors.size()).isGreaterThan(0);
}
@Test
public void testInsertActor() {
String firstname = "mybatis";
Actor actor = Actor.of(null, firstname, "kesti");
int rowCount = actorRepo.insertActor(actor);
log.debug("rowCount={}", rowCount);
actor = actorRepo.findByFirstname(firstname);
log.debug("actor={}", actor);
assertThat(actor).isNotNull();
assertThat(actor.getFirstname()).isEqualTo(firstname);
actorRepo.deleteById(actor.getId());
}
}
2016-10-12KESTI 개발팀 세미나 15

16. Flyway
Evolve your Database Schema easily and
reliably across all your instances
2016-10-12KESTI 개발팀 세미나 16

17. Code 관리는 git
2016-10-12KESTI 개발팀 세미나 17
DB 형상 관리는?

18. DB Schema Control by Dev Step
2016-10-12KESTI 개발팀 세미나 18

19. DB Schema Version Control
2016-10-12KESTI 개발팀 세미나 19

20. QueryDSL
Unified Queries for Java with Typesafe
2016-10-12KESTI 개발팀 세미나 20

21. QueryDSL 개요
• 질의어를 문자열이 아닌 Java Code로 표현
• Query문 – type check 불가 / 실행 전에는 오류 검출 불가
• Java Code는
• Compile Error를 미리 검출
• Code assistant 활용 100%
• Refactoring 용이
• 다양한 저장소에 대한 일관된 질의어 제작 가능
• Collection, RDBMS, MongoDB, Lucene …
• .NET 의 LINQ 같은 목적 (Langunage-INtegrated Query)
• 참고 : 한글 매뉴얼 (단 3.4.0 기준임. 4.x 는 package 명이
달라졌음)
2016-10-12KESTI 개발팀 세미나 21

22. QueryDSL 적용 범위
JPA (Java Persistence API)
JDO (Java Data Object)
SQL
Lucence
MongoDB
Collections
QueryDSL
RDBMS
ORM
Lucene
(search
engine)
MongoD
B
List / Map
2016-10-12KESTI 개발팀 세미나 22

23. QueryDSL for SQL
• Select
• Join (innerJoin, join, leftJoin, rightJoin, fullJoin)
• group by / having
• order by
• limit / offset / restrict
• subquery
• Window functions
• Common Table Expression (CTE)
• Insert
• Update
• Delete
2016-10-12KESTI 개발팀 세미나 23

24. SELECT with Projections
2016-10-12KESTI 개발팀 세미나 24
QActors $ = QActors.actors;
List<Tuple> rows = query.select($.id, $.firstname, $.lastname)
.from($)
.fetch();
QActors $ = QActors.actors;
List<Actor> actors = query.select(Projections.constructor(Actor.class,
$.id,
$.firstname,
$.lastname))
.from($)
.fetch();

25. SELECT – Filter, GroupBy
2016-10-12KESTI 개발팀 세미나 25
Actor actor = query.select(Projections.constructor(Actor.class,
$.id,
$.firstname,
$.lastname))
.from($)
.where($.lastname.eq("Bae"))
.fetchFirst();
List<Tuple> rows = query.select($.lastname, $.lastname.count().as("cnt"))
.from($)
.groupBy($.lastname)
.fetch();

26. SELECT : Subquery
2016-10-12KESTI 개발팀 세미나 26
QActors $ = QActors.actors;
QActors $2 = new QActors("$2");
SQLQuery<Actor> sq = query.select(Projections.constructor(Actor.class,
$.id,
$.firstname,
$.lastname))
.from($)
.where($.id.eq(SQLExpressions.select($2.id.max()).from($2)));
List<Actor> actors = sq.fetch();

27. CUD
2016-10-12KESTI 개발팀 세미나 27
QActors $ = QActors.actors;
long inserted = query.insert($)
.columns($.firstname, $.lastname)
.values("querydsl", "examples")
.execute();
long updated = query.update($)
.set($.lastname, "updated examples")
.where($.firstname.eq("querydsl"))
.execute();
long deleted = query.delete($)
.where($.firstname.eq("querydsl"))
.execute();

28. CUD Batch Execution
2016-10-12KESTI 개발팀 세미나 28
QActors $ = QActors.actors;
int COUNT = 100;
// INSERT
SQLInsertClause insertClause = query.insert($);
for (int i = 0; i < COUNT; i++) {
insertClause.set($.firstname, "firstname-" + i)
.set($.lastname, "lastname-" + i)
.addBatch();
}
long insertedCount = insertClause.execute();
// UPDATE
SQLUpdateClause updateClause = query.update($);
for (int i = 0; i < COUNT; i++) {
updateClause.set($.firstname, "updated-firstname-" + i)
.where($.lastname.eq("lastname-" + i))
.addBatch();
}
long updatedCount = updateClause.execute();
// DELETE
SQLDeleteClause deleteClause = query.delete($);
for (int i = 0; i < COUNT; i++) {
deleteClause.where($.firstname.eq("updated-firstname-" + i))
.addBatch();
}
long deletedCount = deleteClause.execute();

29. QueryDSL Dependency
2016-10-12KESTI 개발팀 세미나 29
<dependency>
<groupId>com.querydsl</groupId>
<artifactId>querydsl-sql</artifactId>
<version>${com.querydsl.version}</version>
</dependency>
<dependency>
<groupId>com.querydsl</groupId>
<artifactId>querydsl-sql-spring</artifactId>
<version>${com.querydsl.version}</version>
</dependency>
<dependency>
<groupId>com.querydsl</groupId>
<artifactId>querydsl-sql-codegen</artifactId>
<version>${com.querydsl.version}</version>
</dependency>
<dependency>
<groupId>com.querydsl</groupId>
<artifactId>querydsl-spatial</artifactId>
<version>${com.querydsl.version}</version>
</dependency>
<dependency>
<groupId>com.querydsl</groupId>
<artifactId>querydsl-sql-spatial</artifactId>
<version>${com.querydsl.version}</version>
</dependency>

30. QueryDSL APT
2016-10-12KESTI 개발팀 세미나 30
<plugin>
<groupId>com.querydsl</groupId>
<artifactId>querydsl-maven-plugin</artifactId>
<version>${com.querydsl.version}</version>
<executions>
<execution>
<goals>
<goal>export</goal>
</goals>
</execution>
</executions>
<configuration>
<jdbcDriver>org.postgresql.Driver</jdbcDriver>
<jdbcUrl>jdbc:postgresql://localhost/querydsl</jdbcUrl>
<jdbcUser>root</jdbcUser>
<jdbcPassword>root</jdbcPassword>
<packageName>kesti4j.data.querydsl.models</packageName>
<sourceFolder>${project.basedir}/target/generated-sources/java</sourceFolder>
<targetFolder>${project.basedir}/target/generated-sources/java</targetFolder>
<spatial>true</spatial>
</configuration>
<dependencies>
<dependency>
<groupId>org.postgresql</groupId>
<artifactId>postgresql</artifactId>
<version>9.4-1206-jdbc42</version>
</dependency>
</dependencies>
</plugin>

31. QueryDSL Generated Code
2016-10-12KESTI 개발팀 세미나 31
/**
* QActors is a Querydsl query type for QActors
*/
@Generated("com.querydsl.sql.codegen.MetaDataSerializer")
public class QActors extends RelationalPathSpatial<QActors> {
private static final long serialVersionUID = 822224394;
public static final QActors actors = new QActors("actors");
public final StringPath firstname = createString("firstname");
public final NumberPath<Integer> id = createNumber("id", Integer.class);
public final StringPath lastname = createString("lastname");
public final com.querydsl.sql.PrimaryKey<QActors> actorsPkey = createPrimaryKey(id);
public QActors(String variable) {
super(QActors.class, forVariable(variable), "public", "actors");
addMetadata();
}
public QActors(String variable, String schema, String table) {
super(QActors.class, forVariable(variable), schema, table);
addMetadata();
}
public QActors(Path<? extends QActors> path) {
super(path.getType(), path.getMetadata(), "public", "actors");
addMetadata();
}
public QActors(PathMetadata metadata) {
super(QActors.class, metadata, "public", "actors");
addMetadata();
}
public void addMetadata() {
addMetadata(firstname, ColumnMetadata.named("firstname").withIndex(2).ofType(Types.VARCHAR).withSize(64));
addMetadata(id, ColumnMetadata.named("id").withIndex(1).ofType(Types.INTEGER).withSize(10).notNull());
addMetadata(lastname, ColumnMetadata.named("lastname").withIndex(3).ofType(Types.VARCHAR).withSize(64));
}
}
