3. Concept of Earthing Systems
All the people living or working in residential,
commercial and industrial places, particularly the
person who are close with electrical systems and
machineries, should essentially be protected against
possible electrification.
4. What Is Earthing? The process of connecting
metallic bodies of all the
electrical apparatus and
equipment to huge mass of
earth by a wire having
negligible resistance is
called Earthing.
5. Grounding
There are two kinds of grounding:
• 1. Electrical circuit or system grounding
• 2. Electrical equipment grounding
6. Electrical System
Grounding • One conductor of the
circuit is intentionally
grounded to earth
• Protects circuit from
lightning, or other high
voltage contact
7. Equipment Grounding
• All metal frames & enclosures of equipment are
grounded by a permanent connection or bond
8. Qualities Of Good Earthing
• Must be of low electrical
resistance
• Must be of good corrosion
resistance
• Must be able to dissipate
high fault current repeatedly
9. Effects of Amount of AC
Current3 ma- painful shock which cause
indirect accidents
10ma- muscle contraction...”no
let go” danger
30ma- lung paralysis- usually
temporary
50ma- possible ventricular
fibrillation (heart dysfunction,
usually fatal)
100 ma-4amps- certain
ventricular fibrillation(heart fail),
fatal
4 amps- heart paralysis, severe
burns
