This document proposes a thesis project to develop a transcoder that can efficiently transcode a H.264 bitstream to a VC-1 bitstream. The objective is to implement a H.264 to VC-1 transcoder for progressive compression. Motivation for the project includes the coexistence of different video coding standards like H.264, VC-1, and MPEG-2 in applications such as Blu-ray discs, which creates a need for transcoding between these formats. While there has been work on other types of transcoding, published work on H.264 to VC-1 transcoding is limited. The document discusses various transcoding architectures and argues that a cascaded pixel domain architecture is best suited for the heterogeneous
