1. AUTOMATION TRAINING
PLC is a digital computer that includes equipment, factory
assembly line, light fittings, fun riding, etc, and a programmable
Logic Controller. PLC is used in all types of industries in many
systems. These controllers are designed for different systems,
extended temperature areas, analog inputs, and outputs,
resistance to vibration and immunity to electrical noise.
PLC PROGRAMMING TRAINING
 Non-Volatile memory is driven into PLC to automate the
process of the sector.
 Modern PLCs provide advanced movement management,
process management, relay management, and sophisticated
networking features.
 PLC controls input, choice, and output to automate a
computer or process, and monitors distinct values such as
values.
 With PLC systems, SCADA is used as a remote control and
tracking system that works over communication channels
with coded signals.
PLC AND SCADA
Industrial automation is the use of different control systems such
as PLC's /SCADA, used to manage different sector activities
without important human involvement and to provide automatic
control efficiency. Control strategies in sectors use a set of

2. techniques that are introduced to deliver the required
performance or output, making the automation system most
important to companies. The use of' smart' machinery in
factories to carry out production procedures with minimal
human interference is industry automation in manufacturing. It
includes the use of several control mechanisms to allow working
machinery to perform duties of velocity, endurance, and
accuracy on its own, with little human interference.
SCADA system components:
1.Transmission data
2. HMI
3.RTU
4.MTU
While industrial automation is not without its detractors in
manufacturing such as an unsubstantiated statement that it will
lead to mass unemployment, its future looks bright.
SCADA TRAINING
 SCADA represents monitoring and acquisition of data.
 SCADA is an industrial process control and infrastructure
process control system.

3.  SCADA is a pure software packet positioned at the top of
hardware.
which is interacted with in most cases via a Programmable
Logic Controller PLC or other commercial
hardware modules. It is not a specific technology, but a
type of application. SCADA allows a user to gather and
return the control from one or more remote installations.
Advantages of SCADA
 Long-range surveillance
 Long-range training
 Protection against vandalism-alarm
 Data management
 Automated real-time control operations
 Reliability robustness
 Rich functionality
SCADA systems normally execute a distributed database,
known as a tag database, that includes tags or points. A point
reflects a single system-monitored input or output value. Two
kinds of tags are:
1. System-defined Tags: it reflects the value of the system in
the SCADA represented by dollar singing $
2. User-defined tags: the user or programmer defines this tag.

4. PLC SCADA COURSE
For a multitude of industrial automation apps, plc training PLCs
are developing and continue to be the best choice. Greater
flexibility and convenience of programming, scalability, more
memory, lower dimensions, high-speed Ethernet and integrated
wireless are changing characteristics of the programmable logic
controller. In automation training automation is plc scada In the
competitive globe, each sector is challenged to work for
survival. The primary advantage and benefit of automation are
that it enables them to save energy, material and human effort.
Automation, on the other side, enables them to improve quality,
accuracy.

5. PLC AND SCADA PROGRAMMING
SCADA is an industrial control system composed of the fol
lowing parts: SCADA is an industrial control unit.
Remote Terminal Units (RTU) connecting sensors
monitoring a physical process and converting sensor
signals to digital data. They are equipped with telemetry
hardware and integrated controls.
PLCs are often used in place of RTUs. Their integrated con
trol capabilities are versatile and flexible.
Telemetry hardware capable of sending digital data to the
monitoring system and getting digital controls from the
Monitoring system. Industrial automation training is that
Data acquisition server Human-machine interface
Supervisory computer system which acquires data, sends
command, etc.
AUTOMATION IN LIVEWIRE
You need to know more about automation to construct a career
in the field of automation. You must, therefore, be helped by the
one who is a automation specialist. LIVEWIRE is the Thrissur
organization for automation instruction. So take the chance to
take a step towards your future.
