% dig b.example.com a +dnssec +m
;; ->>HEADER<<- opcode: QUERY, status: NOERROR, id: 2887
;; flags: qr rd ra ad; QUERY: 1, ANSWER: 0, AUTHORITY: 4, ADDITIONAL: 1
[..]
;; AUTHORITY SECTION:
example.com. 282 IN SOA ns.example.com. hostmaster.example.com. (
2014051176 ; serial [...]
)
example.com. 282 IN RRSIG SOA 8 2 300 (
20150928042215 20150829032215 23244 example.com.
0VGDuKP1/b6XpaKkckHwp+LWXm7BgzUJ3CV7JFpS9WZp
gsedpIzliQn5IIpxOyaK4z4E6v5r23TizA== )
9MEDN0AJ921I1HB0J9LTG5IFTGV32HQ0.example.com. 282 IN NSEC3 1 0 150 D407600606CC5026 (
9MEDN0AJ921I1HB0J9LTG5IFTGV32HQ2
A NS SOA MX TXT RRSIG DNSKEY NSEC3PARAM
)
9MEDN0AJ921I1HB0J9LTG5IFTGV15HQ0.example.com. 282 IN RRSIG NSEC3 8 3 300 (
20150926212215 20150827211012 23244 example.com.
woQjIEfIsWSB+5G5SH0GOVipkHEksuP94hg2URf88sXb
L7ov6pp4RIroLSrTO5xeQjGWbVdFZQKh/A== )
;; Query time: 0 msec
;; SERVER: 127.0.0.1#53(127.0.0.1)
;; WHEN: Mon Aug 31 11:37:31 CEST 2015
;; MSG SIZE rcvd: 809
SOA
RRSIG!
(Signature)!for!
SOA
hash(a.example.com) hash(c.example.com)
NSEC3!+!narrow!mode
Monday 31 August 15](https://image.slidesharecdn.com/powerdnsslides-150831164523-lva1-app6892/75/PowerDNS-Webinar-14-2048.jpg)
Uploaded byMen and Mice
PowerDNS Webinar
This document provides an overview of PowerDNS, an open-source authoritative DNS server. It discusses PowerDNS' backends for storing zone data like BIND and SQL databases, its DNSSEC signing capabilities, and its support for remote and Lua scripting backends. It also demonstrates configuring PowerDNS to use BIND, MySQL, and remote backends. Finally, it summarizes Men & Mice's generic PowerDNS controller and upcoming training courses.
More Related Content
PowerDNS Webinar
- 1.
- 2. ©!Men!&!Mice!!http://menandmice.com! PowerDNS •Overview!on!the!PowerDNS!DNS!Server!and!information! on!how!to: • manage!a!DNS!zone!via!SQL!backend • manage!a!DNS!zone!via!BIND!backend •remote!zone!backend • DNSSEC!signing!with!PowerDNS • the!Men!&!Mice!Suite!DNS!server!controller!for!PowerDNS Monday 31 August 15
- 3. ©!Men!&!Mice!!http://menandmice.com! What!is!PowerDNS •authoritative!DNS-Server • serves!authoritative!DNS!data • fast!and!feature-rich •modern!architecture • open!source • available!on!many!Unix(ish)!platforms •PowerDNS-Recursor!(will!be!covered!in!a!future!webinar) Monday 31 August 15
- 4.
- 5. ©!Men!&!Mice!!http://menandmice.com! PowerDNS!backends •PowerDNS!backends!store!DNS!zone!data • Traditional!backends:!BIND,!tinydns,!MyDNS • Database:!MySQL,!PostgreSQL,!Oracle,!SQLite,!LMDB,! OpenDBX •GeoIP • LDAP • Lua,!Remote!(JSON/RPC),!Pipe Monday 31 August 15
- 6.
- 7.
- 8.
- 9. ©!Men!&!Mice!!http://menandmice.com! Demo:!Remote!backend •this!demo!shows!how!to!configure!PowerDNS • !to!query!DNS!data!from!an!remote!backend!server!via!JSON/RPC • Remote!Backend!supports •Unix!Pipe • Unix!Sockets • HTTP-Connection • ZeroMQ Monday 31 August 15
- 10.
- 11. ©!Men!&!Mice!!http://menandmice.com! DNSSEC!NSEC3!“narrow”!mode •DNSSEC!uses!NSEC3!records!to!provide!“authenticated!denial!of! existence” • proof!for!DNS!information!that!does!not!exist! (NODATA!and!NXDOMAIN) • NSEC!records!allow!zone!walking,!NSEC3!was!created!to!solve!the! issue •traditional!NSEC3!signing!uses!hashes!and!makes!zone!walking!hard,! but!not!impossible • PowerDNS!NSEC3!“narrow”!prevents!zone!walking Monday 31 August 15
- 12. ©!Men!&!Mice!!http://menandmice.com! NSEC example.com. 3600 INSOA ... example.com. 3600 IN NS ... a.example.com. 3600 IN A 192.0.2.1 d.example.com. 3600 IN A 192.0.2.2 g.example.com. 3600 IN A 192.0.2.3 example.com. 3600 IN SOA ... example.com. 3600 IN NS ... example.com. 3600 IN NSEC a.example.com. SOA NS NSEC a.example.com. 3600 IN A 192.0.2.1 a.example.com. 3600 IN NSEC d.example.com. A NSEC d.example.com. 3600 IN A 192.0.2.2 d.example.com. 3600 IN NSEC g.example.com. A NSEC g.example.com. 3600 IN A 192.0.2.3 g.example.com. 3600 IN NSEC example.com. A NSEC Monday 31 August 15
- 13. ©!Men!&!Mice!!http://menandmice.com! NSEC3 example.com. 3600 INSOA ... example.com. 3600 IN NS ... a.example.com. 3600 IN A 192.0.2.1 d.example.com. 3600 IN A 192.0.2.2 g.example.com. 3600 IN A 192.0.2.3 example.com. 3600 IN SOA ... example.com. 3600 IN NS ... example.com. 3600 IN NSEC a.example.com. SOA NS NSEC a.example.com. 3600 IN A 192.0.2.1 hash(a.example.com.) 3600 IN NSEC3 hash(d.example.com). ... d.example.com. 3600 IN A 192.0.2.2 hash(d.example.com.) 3600 IN NSEC3 hash(g.example.com.) ... g.example.com. 3600 IN A 192.0.2.3 hash(g.example.com.) 3600 IN NSEC3 hash(example.com.) ... Monday 31 August 15
- 14. ©!Men!&!Mice!!http://menandmice,com! % dig b.example.coma +dnssec +m ;; ->>HEADER<<- opcode: QUERY, status: NOERROR, id: 2887 ;; flags: qr rd ra ad; QUERY: 1, ANSWER: 0, AUTHORITY: 4, ADDITIONAL: 1 [..] ;; AUTHORITY SECTION: example.com. 282 IN SOA ns.example.com. hostmaster.example.com. ( 2014051176 ; serial [...] ) example.com. 282 IN RRSIG SOA 8 2 300 ( 20150928042215 20150829032215 23244 example.com. 0VGDuKP1/b6XpaKkckHwp+LWXm7BgzUJ3CV7JFpS9WZp gsedpIzliQn5IIpxOyaK4z4E6v5r23TizA== ) 9MEDN0AJ921I1HB0J9LTG5IFTGV32HQ0.example.com. 282 IN NSEC3 1 0 150 D407600606CC5026 ( 9MEDN0AJ921I1HB0J9LTG5IFTGV32HQ2 A NS SOA MX TXT RRSIG DNSKEY NSEC3PARAM ) 9MEDN0AJ921I1HB0J9LTG5IFTGV15HQ0.example.com. 282 IN RRSIG NSEC3 8 3 300 ( 20150926212215 20150827211012 23244 example.com. woQjIEfIsWSB+5G5SH0GOVipkHEksuP94hg2URf88sXb L7ov6pp4RIroLSrTO5xeQjGWbVdFZQKh/A== ) ;; Query time: 0 msec ;; SERVER: 127.0.0.1#53(127.0.0.1) ;; WHEN: Mon Aug 31 11:37:31 CEST 2015 ;; MSG SIZE rcvd: 809 SOA RRSIG! (Signature)!for! SOA hash(a.example.com) hash(c.example.com) NSEC3!+!narrow!mode Monday 31 August 15
- 15. ©!Men!&!Mice!!http://menandmice.com! NSEC/NSEC3!mode!usage •when!to!use!NSEC!or!NSEC3!or!NSEC3!narrow-mode: • NSEC:!simple!zones,!zones!with!predictable!content,!zones!with! non-sensitive!data • NSEC3:!zones!where!changes!to!the!content!needs!to!be!protected! for!some!weeks •NSEC3+narrow:!zones!with!sensitive!content!(e.g.!OPENPGPKEY/ SMIMEA!mail!addresses!etc) • NSEC3+narrow!requires!“live-signing”,!the!DNSSEC!keys!must!be!present! on!every!authoritative!server! Monday 31 August 15
- 16.
- 17.
- 18.
- 19.
- 20.
- 21. ©!Men!&!Mice!!http://menandmice.com! Upcoming!webinars • PowerDNS!part!2!-!Master/Slave!and!Supermaster,!Lua-Scripting- Engine,!HTTP-API,!Tools!-!17th!Sep!2015 • keeping!DNS!server!up-and-running!with!“runit” •DNSTAP!-!have!a!deep!look!into!DNS!server!operations!(featuring! Unbound!and!Knot-DNS) • the!DNS!server!in!Windows!2016!Server!-!a!big!leap!forward!(views,! response!rate!limiting,!ACLs!and!more) • an!Update!on!DNSSEC!and!DANE:!new!implementations,!adoption!in! the!market,!new!Internet!standards Monday 31 August 15
