The document discusses metrics for measuring system availability and reliability such as MTBF, MTTR, and various "nines" of availability. It notes that while increasing availability is important, reducing recovery time after failures through measures like redundant systems, data replication, and disaster recovery plans is also crucial. The key metrics are recovery time objective (RTO) and recovery point objective (RPO) which specify how long a system can be down and how much data can be lost respectively. The document concludes that the right approach depends on each system's specific requirements and that failures will inevitably occur, so the focus should be on rapid recovery.

1. MTBF / MTTR
Availability or recoverability?
Presented by
Michael Richardson, Energized Work
21 March 2012
ENERGIZED WORK
25 MACKLIN STREET
LONDON WC2B 5NN
+44 (0)20 7691 8933
WWW.ENERGIZEDWORK.COM

2. Michael Richardson
Twitter: @mr_spb
Email: michael@energizedwork.com
#ewtektalk
© 2012 Energized Work - www.energizedwork.com 2

3. So what is
high availability?
• Five nines?
• No single point of failures?
• Multiple data centres?
• Fault tolerance?
• Load balancing?
• Uptime?
© 2012 Energized Work - www.energizedwork.com 3

4. Nines
of availability
9 9
9
9
9
9
9 9
© 2012 Energized Work - www.energizedwork.com 4

5. Nines
of availability
Availability
Downtime per Year
One nine (90%)
36.5 days
Two nines (99%)
3.65 days
Three nines (99.9%)
8.76 hours
Four nines (99.99%)
52.56 minutes
Five nines (99.999%)
5.26 minutes
© 2012 Energized Work - www.energizedwork.com 5

6. Problem with
the nines
• What do they mean?
• Guaranteed or just an SLA?
• Multiplicity (99.9% * 99.9% * 99.9% = 99.7%)
© 2012 Energized Work - www.energizedwork.com 6

7. SLA availability numbers
just aim to provide a level of
confidence in a website’s service
© 2012 Energized Work - www.energizedwork.com 7

8. No single point of failure
(SPOF)
© 2012 Energized Work - www.energizedwork.com 8

9. Two of everything?
© 2012 Energized Work - www.energizedwork.com 9

10. Start with this
Users
Index.html
© 2012 Energized Work - www.energizedwork.com 10

11. End with this
Users
Firewall 1 Firewall 2
Switch 1 Switch 2
WEB1 WEB2 APP1 APP2 DB1 DB2
© 2012 Energized Work - www.energizedwork.com 11

12. Problems with
eliminating SPOF
• It’s expensive
• Where do you draw the line?
• Are failures independent?
• Can you guarantee no SPOF?
• Increased complexity
© 2012 Energized Work - www.energizedwork.com 12

13. Problem:
Data centres fail
© 2012 Energized Work - www.energizedwork.com 13

14. Solution:
Get a second data centre
© 2012 Energized Work - www.energizedwork.com 14

15. Hot – Hot
multisite
• Full range of services available in multiple locations
• Easy to automate failover of sites
• Data consistency is hard
• Capacity planning concerns
+
© 2012 Energized Work - www.energizedwork.com 15

16. Hot – Warm
multisite
• Simpler than hot – hot
• Read / Write ratio dependent
• Synchronously or asynchronously replicate data?
+
© 2012 Energized Work - www.energizedwork.com 16

17. Hot – Cold
multisite
• Easy to setup
• Will it work?
• Can it be trusted?
• Cold site rapidly becomes stale
• Is it actually valuable?
+
© 2012 Energized Work - www.energizedwork.com 17

18. DR multisite
• Fingers crossed you never need it
• How can / should you test it?
• Cloud?
+
© 2012 Energized Work - www.energizedwork.com 18

19. Problems
with multiple sites
• It’s expensive
• Managing more systems
• Managing data consistency
• Managing capacity
• Is it still fail proof?
• Unless you test it, it’s just a plan
© 2012 Energized Work - www.energizedwork.com 19

20. We now have
a complex system
© 2012 Energized Work - www.energizedwork.com 20

21. Complex systems
• More redundancy and automation leads to more complexity
• More complexity often adds more points of failure
© 2012 Energized Work - www.energizedwork.com 21

22. How complex systems fail
- Dr. Richard Cook
• Catastrophe is always just around the corner
• Human operators have dual roles
• Change introduces new forms of failure
© 2012 Energized Work - www.energizedwork.com 22

23. Failure and recovery
© 2012 Energized Work - www.energizedwork.com 23

24. Questions
for the business
• What is the cost of downtime?
• What are the Recovery Time Objectives (RTO)
• What are the Recovery Point Objectives (RPO)?
© 2012 Energized Work - www.energizedwork.com 24

25. Aggressive RTO and RPO
are expensive and have a
performance impact
© 2012 Energized Work - www.energizedwork.com 25

26. RTO / RPO
example
Problem:
• Simple DB
• Business can tolerate up to 15 minutes downtime
• 10-minute window of data loss
© 2012 Energized Work - www.energizedwork.com 26

27. RTO / RPO
example
Possible solution:
• Continuously replicate data to second host
• Continue with nightly backups and also copy DB transaction logs
from the primary host to another system
© 2012 Energized Work - www.energizedwork.com 27

28. So what is more important –
increasing availability
or reducing recovery time?
© 2012 Energized Work - www.energizedwork.com 28

29. MTBF or MTTR?
What about MTTD?
© 2012 Energized Work - www.energizedwork.com 29

30. The answer is:
It depends
© 2012 Energized Work - www.energizedwork.com 30

31. Failure
is inevitable
© 2012 Energized Work - www.energizedwork.com 31

32. Ask anyone
© 2012 Energized Work - www.energizedwork.com 32
