Moving from C#/.NET to Hadoop/MongoDB
- 1. Moving from C#/.NET to Hadoop/MongoDB Robert Vandehey December 4, 2012
- 2. We power the Discovery, Delivery and Display of Digital Entertainment 4 © 2012 Rovi Corporation. Company confidential.
- 3. Global Reach 137M+ 47M+ Viewers use our guide technologies Storefronts with entertainment services through service provider offerings powered by Rovi Entertainment Store 266M+ Consumer electronic (CE) devices Data coverage: have our CE guide technologies 4.5M+ TV shows, movies, sports and celebrities 40M+ Households reached globally by Rovi Advertising Network 3.3M+ Album releases and 32M music tracks 600M+ Devices certified for high quality DivX video playback 500K+ Movie titles 7 © 2012 Rovi Corporation. Company confidential.
- 6. 11 © 2012 Rovi Corporation. Company confidential.
- 7. The Problem 13 © 2012 Rovi Corporation. Company confidential.
- 8. ETL/Cache Loading Data Takes Too Long Node 1 MemcacheD MemcacheD DB (Scratch Cluster DSG DB Server Server(s)) WSP ETL Server Backup & MemcacheD Server(s) Restore MemcacheD Transform CI Cache MemcacheD DSG Extract Database CI Table Loading Database Loading Database Database Process Process MemcacheD MemcacheDB Node 2 Cluster DB Server MemcacheDB Backup & Restore MemcacheDB CI Database Page 16
- 9. The Solution 17 © 2012 Rovi Corporation. Company confidential.
- 10. Hadoop/MongoDB 18 Copyright ®2012 Rovi Corporation. Company confidential.
- 11. Network Diagram 20 Copyright ®2012 Rovi Corporation. Company confidential.
- 12. Mongo Sharding 21 Copyright ®2012 Rovi Corporation. Company confidential.
- 13. Challenges 23 © 2012 Rovi Corporation. Company confidential.
- 14. Challenges • Transition existing Windows/.NET team to Linux/Java – Environment setup. Technology framework choices – Coding differences – Cultural differences – Platform differences – Easier than expected to transition team from .NET to Java – No religious battles • Backwards compatibility of CXF web services to Microsoft .NET web services • Managing new releases of Hadoop • BCP took too long – Converted to base tables. Used Pig to join the data • Writes to Mongo are very fast. Updates are slower and saturated disks – Implemented Diff process (MD5 calc) to allow Hadoop to do the work and minimize writes to Mongo 24 © 2012 Rovi Corporation. Company confidential.
- 15. Lessons Learned 25 © 2012 Rovi Corporation. Company confidential.
- 16. Lessons Learned • General – Current versions of Hadoop CDH4 and MongoDB 2.0 are actually very stable products • We purchased enterprise support agreements from both Cloudera and 10gen – Create a developers VM image – Deploy early and often even if not ready for real customers – Use the same setup in test and production environments • Sharding caused differences • SQL – Get raw tables without any transformation or joins • Let Hadoop do the processing for you • Hadoop – Do as much work as you can in Hadoop – Take the time to create small datasets to iterate fast – Take the time to learn and use Pig • It is very fast and provides tons of functionality that you don’t need to code in Java – Don’t create Runners - Use Oozie workflows – Measure, benchmark and track performance – Use Hadoop counters 26 © 2012 Rovi Corporation. Company confidential.
- 17. Lessons Learned - 2 • MongoDB – RAM, RAM, RAM!!! – Many writes from Hadoop can easily overwhelm MongoDB • Single database lock • Drive bandwidth saturation – Can be expanded through sharding • Do as much as possible to minimize writes • Measure where your application is blocking and optimize – Don’t shard unless you have to – if you do shard, preconfigure your shard key • You need a good shard key – Use Replica sets. They are easy to setup and work good. • Make sure repllog is large enough. – Use MongoDB Monitoring Service (MMS) – It’s free – Mongo queries are fast! 27 © 2012 Rovi Corporation. Company confidential.
- 18. Mongo Query – returns 90 rows from a database of 9 million in 44ms 28 © 2012 Rovi Corporation. Company confidential.
- 19. Q&A 31 © 2012 Rovi Corporation. Company confidential.
- 20. Follow-up Information • Email: robert.vandehey@rovicorp.com • LinkedIn: http://www.linkedin.com/in/bvandehey • Twitter: @bvandehey • Rovi Cloud Services: http://developer.rovicorp.com/ 32 © 2012 Rovi Corporation. Company confidential.
- 21. Thank You 33 © 2012 Rovi Corporation. Company confidential.
Editor's Notes
- This is the new Data Load Process. It makes it look easy…
- …The reality it is quite complex. This is just one of our workflows. The orange/tan-ish boxes are Java map/reduce processes. The pink boxes are pig processes. The white boxes are BCP processes. The green boxes are MongoDB collections.
- Here is our sharding scheme. We actually have 6 more servers than is shown because we decided to have multiple replicas at each remote site.
