2. Unit 03: Digital memories and logic families
Digital memories:
SRAM, DRAM, ROM, EPROM
Digital logic families:
PAL,PLA, CPLD, FPGA
Unit 3_Module4 Matoshri College of Engineering & Research Center Nashik 2
3. Module4 :- PLA
(Programmable Logic Array)
Unit 3_Module4 Matoshri College of Engineering & Research Center Nashik 3
1. Introduction.
2. Block Diagram of PLA.
3. Basic Structure of PLA.
4. Advantages & Disadvantage of PLA.
5. Comparison of PAL & PLA.
8. Advantages of PLA
PLA basic design required less time.
Design can also be quickly tested.
Design layout is much simpler .
They can be produce in large volume.
Unit 3_Module4 Matoshri College of Engineering & Research Center Nashik 8
9. Disadvantages of PLA
The product term count restrict the application of PLA.
It is not easy to use.
It is difficult to manufacture,test and programmed.
Unit 3_Module4 Matoshri College of Engineering & Research Center Nashik 9
10. Application.
PLA is used as counter.
PLA is used as Decoder.
PLA is used to provide control over datapath.
In programmed input/output PLA used as bus interface.
Unit 3_Module4
Matoshri College of Engineering & Research Center
Nashik 10
11. SR.NO PLA PAL
1 Both AND & OR array are
programmed
OR array is fixed AND array is
programmed
2 It is costly and complex They are simple.
3 AND array can be programmed to
get desired minterms
AND array can be programmed to get
desired Maxterm
4 Any Boolean function in SOP form
can be implemented using PLA
Any Boolean function in SOP form can
be implemented using PAL
Unit 3_Module4 Matoshri College of Engineering & Research Center Nashik 11
12. Module 4
Unit 3_Module4 Matoshri College of Engineering & Research Center Nashik 12
1. Introduction.
2. Block Diagram of PLA.
3. Basic Structure of PLA.
4. Advantages & Disadvantage of PLA.
5. Comparison of PAL & PLA
13. Thank you
Mr. C. R. Shinde
Electrical Engineering Department
Matoshri College of Engineering & Research centre, Nashik
If you have any query, ask me anytime on…… … .. . . .
cshinde58@gmail.com
chandrakant.shinde@matoshri.edu.in
9970031353
Unit 3_Module4
Matoshri College of Engineering & Research Center
Nashik 13
