Today Micron announced the production of 8GB DDR4 NVDIMM, the company’s first commercially available solution in the persistent memory category. Persistent memory delivers a unique balance of latency, bandwidth, capacity and cost, delivering ultra-fast DRAM-like access to critical data and allowing system designers to better manage overall costs. With persistent memory, system architects are no longer forced to sacrifice latency and bandwidth when accessing critical data that must be preserved. Watch the video presentation: http://wp.me/p3RLHQ-eII Sign up for our insideHPC Newsletter: http://insidehpc.com/newsletter

1. ©2015 Micron Technology, Inc. | Micron Confidential1
©2015 Micron Technology, Inc. All rights reserved. Information, products, and/or specifications are subject to change without notice. All information is provided on an “AS IS” basis without warranties of any kind.
Statements regarding products, including regarding their features, availability, functionality, or compatibility, are provided for informational purposes only and do not modify the warranty, if any, applicable to any
product. Drawings may not be to scale. Micron, the Micron logo, and all other Micron trademarks are the property of Micron Technology, Inc. All other trademarks are the property of their respective owners.
Persistent Memory & NVDIMM

2. ©2015 Micron Technology, Inc.2
Who We Are
 Micron is a global leader in advanced
memory systems and solutions
focused on enabling the world’s most
leading-edge technologies for
computing, consumer, networking,
embedded and mobile products

3. ©2015 Micron Technology, Inc.3
DRAM
NAND
Package
Technology
New
Memory
Technology
Leading-Edge Technology
Images are not to scale
Hybrid
Memory Cube
• Multiple paths under active development for
storage class memory enablement
• Continued strong progress for 20nm yield
• 1Xnm development underway in Asia and
1Y/1Znm in US
• 16nm TLC NAND in production
• 1st generation 3D NAND on track for
production
• 3D package technology continues to mature,
currently manufacturing HMC generation 2
1Xnm DRAM
3D NAND
3D XPoint™
Memory

4. ©2015 Micron Technology, Inc.4
What Are We Announcing?
 On November 10, Micron is announcing
production of the company’s first commercially
available Persistent Memory solution, a DDR4
NVDIMM.
– Combines DRAM Performance with NAND Flash
– Accelerates Application Performance by Delivering
Faster Access to Large Data Sets While Removing
Bottlenecks
– Provides a new choice in architecture that allows
customers to store data close to the processor

5. ©2015 Micron Technology, Inc.5
Persistent System Memory
 Persistent memory is a new addition
to the compute/storage hierarchy
that provides non-volatile, low-
latency memory close to the
processor.
Lower
Latency
Higher
Bandwidth
Higher
Endurance
Lower Cost
Per Bit
CPU
Cache
DRAM
DDR
HDD
SSD
PCIe, SAS
SSD
SATA

6. ©2015 Micron Technology, Inc.6
 Persistent memory accelerates
application performance
– Removes constricting I/O bottlenecks
– Greater flexibility in data management
 Non-volatile memory on the DRAM
bus significantly optimizes data
movement, delivering faster access
 Will provide a bridge to future storage
class memory solutions such as 3D
XPoint™ technology.
Persistent System Memory
Lower Cost
Per Bit
CPU
Cache
DRAM
DDR
SSD
PCIe, SAS
SSD
SATA
HDD
NVDIMM
DRAM NAND
Storage Class
Memory 3D XPoint™
Lower
Latency
Higher
Bandwidth
Higher
Endurance

7. ©2015 Micron Technology, Inc.7
Understanding the Performance Gap: Latency
 Translating latency into a real world example…
How long would it take to locate and retrieve a key ingredient – like a tomato - to
make a pizza using locations based on DRAM, PCIe SSD or 10K HDD?
DRAM
…walking to
your fridge to
get a tomato…
6 seconds
PCIe SSD
…driving to a
country produce
stand to get a
fresh tomato…
2.2 hours
10K HDD
…growing and
ripening a
tomato in your
garden….
46 days

8. ©2015 Micron Technology, Inc.8
The Impact of Persistent Memory
• A growing number of applications
— Require frequent access to large data sets
— Are sensitive to down time
— Have performance limitations due to I/O bottlenecks
• Extends life of SSD
and improves
performance for
write-intensive
apps
• >100x lower write
latency versus PCIe SSD
w/ unlimited endurance
• Scalable unified RAID
performance for SSDs
and HDDs
Case #1: Write Caching
For MLC SSDs
Case #2: Low Write Latency
Persistent Storage
Case #3: Unified Open Software-
Defined Server RAID

9. ©2015 Micron Technology, Inc.9
Persistent Memory & NVDIMM
• NVDIMM is the persistent memory solution
available today.
• Micron’s NVDIMM is capable of delivering
the performance levels of DRAM combined
with the persistent reliability of NAND:
— Combines NAND Flash, DRAM, and a
power source into a memory
subsystem
— Delivers DRAM read/write performance
and backs up its data if power is
interrupted
Ultracapacitor
Module
Self-contained energy
source for backup
operation during
power failure
NVDIMM
Controller
Flash management,
high-speed DMA, Status
Onboard DRAM & NAND
DRAM performance and
Flash non-volatility

10. ©2015 Micron Technology, Inc.10
Persistent
Memory
Storage Class
Memory
3D XPoint™
Memory
NVDIMM
Why Micron
• Committed to the development of persistent memory
technology
• Delivering on the promise of persistent memory with a
DDR4 NVDIMM solution
• Leading the way on future persistent memory
development, spearheading R&D efforts on promising
new technologies such as 3D XPoint™ technology, which
will be available in 2016 and beyond.

11. ©2015 Micron Technology, Inc.11
NVDIMM – More Details
Micron will be offering three DDR4 NVDIMM products:
1. 8GB DDR4 NVDIMM w/legacy firmware
• RDIMM architecture
• DDR4-2133
• Single rank x4 configuration
• In production now
• Backup power source: PowerGEM or persistent 12V routed to DRAM slot
2. 8GB DDR4 NVDIMM w/JEDEC firmware
• RDIMM architecture
• DDR4-2133
• Single rank x4 configuration
• Engineering samples available now; Production in early 2016
• Backup power source: PowerGEM or persistent 12V routed to DRAM slot
3. PowerGEM (ultracapacitor) for 8GB NVDIMM
• Back-up time: ~40 seconds (the time required for the NVDIMM controller to copy the DRAM content to NAND when power is lost)
• Back-up power source: tethered ultracapacitor
• 2 ½” Drive bay form factor

12. ©2015 Micron Technology, Inc. | Micron Confidential12

13. ©2015 Micron Technology, Inc.13
Understanding the Performance Gap: Bandwidth
 Translating bandwidth into a real world example…
How long would it take to commute to work if using different routes based on
DRAM, PCIe SSD and 10k HDD?
DRAM
… speeding
on a 256 lane
autobahn…
PCIe SSD
…driving a
16 lane
highway…
10K HDD
…puttering
along a 2 lane
alley….
