Measurement Uncertainty (1).ppt
- 2. Topics Covered Brief overview of concepts and terms of probability and statistics Measurement uncertainty Detection and quantification limits Miscellaneous
- 3. Target Audience(s) Project planners and managers Radiochemists and technicians Computer programmers Data validators and assessors Metrologists?
- 4. Measurement Uncertainty We use the Guide to the Expression of Uncertainty in Measurement (ISO- GUM). International guidance – years of development and review by seven international organizations Strongly recommended by NIST Best way to ensure consistency among labs in the U.S. and the rest of the world
- 5. Measurement Model Define the measurand – the quantity subject to measurement Determine a mathematical model, with input quantities, X1,X2,…,XN, and (at least) one output quantity,Y. The values determined for the input quantities are called input estimates and are denoted by x1,x2,…,xN. The value calculated for the output quantity is called the output estimate and denoted by y.
- 6. Standard Uncertainty The standard uncertainty of a measured value is the uncertainty expressed as an estimated standard deviation – i.e., the one- sigma uncertainty. The standard uncertainty of an input estimate, xi, is denoted by u(xi). The standard uncertainty of the output estimate, y, determined by uncertainty propagation, is called the combined standard uncertainty, and is denoted by uc(y).
- 7. Type A Evaluation Statistical evaluation of uncertainty involving a series of observations Always has an associated number of degrees of freedom Examples include simple averages and least-squares estimates Not “random uncertainty”
- 8. Type B Evaluation Any evaluation that is not a Type A evaluation is a Type B evaluation. Not “systematic uncertainty” Examples: Calculating Poisson counting uncertainty (error) as the square root of the observed count Using professional judgment combined with assumed rectangular or triangular distributions Obtaining standard uncertainties in any manner from standard certificates or reference books
- 9. Covariance Correlations among input estimates affect the combined standard uncertainty of the output estimate. The estimated covariance of two input estimates, xi and xj, is denoted by u(xi,xj).
- 10. Uncertainty Propagation “Law of Propagation of Uncertainty,” or, more simply, the “uncertainty propagation formula” Standard uncertainties and covariances of input estimates are combined mathematically to produce the combined standard uncertainty of the output quantity.
- 11. Expanded Uncertainty Multiply the combined standard uncertainty, uc(y), by a number k, called the coverage factor to obtain the expanded uncertainty, U. The probability (or one’s degree of belief) that the interval y +- U will contain the value of the measurand is called either the coverage probability or the level of confidence.
- 12. Recommendations Follow ISO-GUM in terminology and methods. Consider all sources of uncertainty and evaluate and propagate all that are considered to be potentially significant in the final result. Do not ignore subsampling uncertainty just because it may be hard to evaluate.
- 13. Recommendations - Continued Report all results – even if zero or negative Report either the combined standard uncertainty or the expanded uncertainty. Explain the uncertainty – in particular state the coverage factor for an expanded uncertainty. Round the reported uncertainty to either 1 or 2 figures (suggest 2) and round the result to match.
- 14. Detection and Quantification There are several standards on the subject of detection limits. We try to follow the principles that are common to all. We follow IUPAC (more or less) for quantification limits.
- 15. Detection A detection decision is based on the critical value (critical level, decision level) of the response variable (e.g., instrument signal, either gross or net). The minimum detectable concentration (MDC) is the smallest (true) analyte concentration that ensures a specified high probability of detection.
- 16. “A Priori” vs. “A Posteriori” Avoid the “a priori” vs. “a posteriori” distinction. We recognize: Many labs report a sample-specific estimate of the MDC Many experts insist it should not be done We take no firm position except to state that the sample-specific MDC has few valid uses and is often misused.
- 17. Misuse of the MDC We state that no version of the MDC should be used in deciding whether an analyte is present in a laboratory sample. The MDC cannot be determined unless the detection criterion has already been specified.
- 18. Quantification Limits We cite IUPAC’s guidance for defining quantification limits. The minimum quantifiable concentration (MQC) is the analyte concentration that gives a relative standard deviation of 1/k, for some specified number k (usually 10).
- 19. The MQC We hoped to unify the approaches to uncertainty and to detection and quantification limits. ISO-GUM in effect treats all error components as random variables. Is this approach consistent with IUPAC’s approach to quantification limits? We proceeded as if the answer were yes.
- 20. The MQC - Continued Our MQC is based on an overall standard deviation that represents all sources of measurement error – not just “random errors.” This standard deviation differs from the combined standard uncertainty, a random variable whose value changes with each measurement.
- 21. Use of the MQC The MQC is almost unknown among radiochemists but should be a useful performance characteristic. The MDC is well-known and is sometimes used for purposes that would be better served by the MQC. E.g., choosing a procedure to measure Ra-226 in soil.
- 22. Other Topics Effects of nonlinearity on uncertainty propagation Laboratory subsampling – based on Pierre Gy’s sampling theory Tests for normality Example calculations
- 23. Other Topics - Continued Detection decisions based on low- background Poisson counting or few degrees of freedom Expressions for the critical net count in the pure Poisson case Well-known (so-called “Currie’s equation”) Not so well-known (Nicholson, Stapleton)
- 24. Concerns & Questions Overkill? Is anything important missing? E.g., a table of “typical” uncertainties More real-world examples of good uncertainty evaluation How can the examples be improved? Contradictory standards on detection limits
