Introducing PyTorch and build Feed Forward Neural Network at Facebook Developer Circles Jakarta meetup

1. Machine Learning
With

2. Hi, I’m Riza

3. Agenda
• Introduction PyTorch
• Getting Started with PyTorch
• Handling Datasets
• Build Simple Neural network with PyTorch

4. Introduction

5. Scientific computing package to replace NumPy to use
the power of GPU.
A deep learning research platform that provide
maximum flexibility and speed

6. A complete Python rewrite of Machine Learning library
called Torch, written in Lua
Chainer — Deep learning library, huge in NLP
community, big inspiration to PyTorch Team
HIPS Autograd - Automatic differentiation library,
become on of big feature of PyTorch
In need of dynamic execution

7. January 2017
PyTorch was born 🍼
July 2017
Kaggle Data Science Bowl won using PyTorch 🎉
August 2017
PyTorch 0.2 🚢
September 2017
fast.ai switch to PyTorch 🚀
October 2017
SalesForce releases QRNN 🖖
November 2017
Uber releases Pyro 🚗
December 2017
PyTorch 0.3 release! 🛳
2017 in review

9. Killer Features
Just Python
On Steroid
Dynamic computation allows flexibility
of input
Best suited for research and
prototyping

10. Summary
• PyTorch is Python machine learning library focus
on research purposes
• Released on January 2017, used by tech
companies and universities
• Dynamic and pythonic way to do machine
learning

11. Getting Started

12. Installa7on
$ pip install pytorch torchvision -c pytorch # macos
$ pip install pytorch-cpu torchvision-cpu -c pytorch # linux
More: https://pytorch.org/get-started/locally/

13. Tensors
Scalar
Rank: 0
Dimension: ()
3.14Scalar

14. Tensors
Scalar
import torch
pi = torch.tensor(3.14)
print(x) # tensor(3.1400)

15. Tensors
Vector
Rank: 1
Dimension: (3,)
[3, 4, 8]Vector

16. Tensors
Vector
import torch
vector = torch.Tensor(3,)
print(vector)
# tensor([ 0.0000e+00, 3.6893e+19, -7.6570e-25])

17. Tensors
Matrix
Rank: 2
Dimension: (2, 3)
[[1, 2, 3],
[4, 5, 6]]Matrix

18. Tensors
Matrix
import torch
matrix = torch.Tensor(2, 3)
print(matrix)
# tensor([[0.0000e+00, 1.5846e+29, 2.8179e+26],
# [1.0845e-19, 4.2981e+21, 6.3828e+28]])

19. Tensors
Tensor
Rank: 3
Dimension: (2, 2, 3)
[[[1, 2, 3],
[4, 5, 6]], [[7, 8, 9],
[10, 11, 12]]]Tensor

20. Tensors
Tensor
import torch
tensor = torch.Tensor(2, 2, 3)
print(tensor)
# tensor([[[ 0.0000e+00, 3.6893e+19, 0.0000e+00],
# [ 3.6893e+19, 4.2039e-45, 3.6893e+19]],
# [[ 1.6986e+06, -2.8643e-42, 4.2981e+21],
# [ 6.3828e+28, 3.8016e-39, 2.7551e-40]]])

21. Operators
import torch
x = torch.Tensor(5, 3)
# Randomize Tensor
y = torch.rand(5, 3)
# Add
print(x + y) # or
print(torch.add(x, y))
# Matrix Multiplication
a = torch.randn(2, 3)
b = torch.randn(3, 3)
print(torch.mm(a, b))
https://pytorch.org/docs/stable/tensors.html

22. Working With
import torch
a = torch.ones(5)
print(a) # tensor([1., 1., 1., 1., 1.])
b = a.numpy()
print(b) # [1. 1. 1. 1. 1.]
import numpy as np
a = np.ones(5)
b = torch.from_numpy(a)
np.add(a, 1, out=a)
print(a) "#[2. 2. 2. 2. 2.]
print(b)
#tensor([2., 2., 2., 2., 2.], dtype=torch.float64)

23. Working With GPU
import torch
x = torch.Tensor(5, 3)
y = torch.rand(5, 3)
if torch.cuda.is_available():
x = x.cuda()
y = y.cuda()
x + y

24. Summary
• Tensor is like rubiks or multidimentional array
• Scalar, Vector, Matrix and Tensor is the same
with different dimension
• We can use torch.Tensor() to create a
tensor.

25. Autograd

26. Differen7a7on
Refresher
y = f(x) = 2xIF THEN
dy
dx
= 2
IF THENy = f(x1, x2,…,xn) [
dy
dx1
,
dy
dx2
, . . . ,
dy
dxn
]
Is the gradient of y w.r.t [x1, x2, …, xn]

27. Autograd
• Calculus chain rule on steroid
• Derivative of function within a function
• Complex functions can be written as many
compositions of simple functions
• Provides auto differentiation on all tensor
operations
• In torch.autograd module

28. Variable
• Crucial data structure, needed for automatic
differentiation
• Wrapper around Tensor
• Records reference to the creator function

29. Variable
import torch
from torch.autograd import Variable
x = Variable(torch.FloatTensor([11.2]),
requires_grad=True)
y = 2 * x
print(x)
# tensor([11.2000], requires_grad=True)
print(y)
# tensor([22.4000], grad_fn=<MulBackward>)
print(x.data) # tensor([11.2000])
print(y.data) # tensor([22.4000])
print(x.grad_fn) # None
print(y.grad_fn)
# <MulBackward object at 0x10ae58e48>
y.backward() # Calculates the gradients
print(x.grad) # tensor([2.])

30. Summary
• Autograd provides auto differentiation on all tensor
operations, inside torch.autograd module
• Variable is wrapper around Tensor that will records
reference to the creator function

31. Handling DataSets

32. Dataset Collection of training examples

33. Epochs
One pass of the entire dataset
through your model

34. Batch
A subset of training examples passed
through your model at a time

35. Itera7on A single pass of a batch

36. Example
1,000 images of dataset
1 epochs
Batch size of 50
Leads to 20 iterations

37. Access Dataset
CIFAR10 dataset via torchvision
import torch
import torchvision
import torchvision.transforms as transforms
import matplotlib.pyplot as plt

38. Access Dataset
Transform the data
transform = transforms.Compose([
transforms.ToTensor(),
transforms.Normalize((0.5, 0.5, 0.5), (0.5, 0.5, 0.5))])

39. Access Dataset
Prepare train data
trainset = torchvision.datasets.CIFAR10(root='./data', train=True,
download=True, transform=transform)
print(len(trainset.train_data)) # 5000
print(trainset.train_labels[1]) # 9 = Truck image

40. Access Dataset
Prepare train loader
trainloader = torch.utils.data.DataLoader(
trainset, batch_size=10, shuffle=True, num_workers=2)

41. Access Dataset
Iterate data and train the model
for i, data in enumerate(trainloader):
data, labels = data
print(type(data)) # <class 'torch.Tensor'>
print(data.size()) # torch.Size([10, 3, 32, 32])
print(type(labels)) # <class 'torch.Tensor'>
print(labels.size()) # torch.Size([10])
# Model training happens here""...

42. Datasets
• COCO — large-scale object detection, segmentation, and
captioning dataset.
• MNIST — handwritten digit database
• Fashion-MNIST — fashion product database
• LSUN — Large-scale Image Dataset
• Much more…
Others

43. Summary
• We can use existing dataset provided by torch and
torchvision such as CIFAR10
• Dataset is training example, epochs is on pass
througout the model, batch is subset of training
model and iteration is a single pass of one batch

44. Neural Network

45. Neural Network
Input Hidden 1 Hidden 2 Output
Layers

46. Neural Network
A Neuron
Output
ip1
ip2
ip3
w1
w2
w3
ip1*w1
ip2*w2
ip3*w3
bias fn()
Output = fn(w1 * ip1 + w2 * ip2 + w3* ip3 + bias)
Input Vector
Weights Vector
Activation Function

47. Ac7va7on Func7ons
Sigmoid
f(x) =
1
1 + e−x

48. Ac7va7on Func7ons
Tanh
f(x) =
ex
− e−x
ex + e−x

49. Ac7va7on Func7ons
Rectified Linear Unit
f(x) = max(x,0)

50. Summary
• Neural net is a collection of neurons that related to
each other consist of input, weight, bias and output.
• To generate an output we need to activate it using
activation function such as Sigmoid, tanh or ReLU.

51. Our First Neural Network

52. Feed Forward NN
The Iris
Classify flower based on it’s structure

53. Feed Forward NN
The Model

54. Feed Forward NN
The Dataset
Table 1
sepal_length_cm sepal_width_cm petal_length_cm petal_width_cm class
5.1 3.5 1.4 0.2 Iris-setosa
4.9 3.0 1.4 0.2 Iris-setosa
7.0 3.2 4.7 1.4 Iris-versicolor
6.4 3.2 4.5 1.5 Iris-versicolor
6.9 3.1 4.9 1.5 Iris-versicolor
6.4 2.8 5.6 2.2 Iris-virginica
6.3 2.8 5.1 1.5 Iris-virginica
6.1 2.6 5.6 1.4 Iris-virginica

55. The Iris
import torch
import torch.nn as nn
import matplotlib.pyplot as plt
from torch.autograd import Variable
from data import iris
Import things

56. The Iris
class IrisNet(nn.Module):
def "__init"__(self, input_size,
hidden1_size, hidden2_size, num_classes):
super(IrisNet, self)."__init"__()
self.layer1 = nn.Linear(input_size, hidden1_size)
self.act1 = nn.ReLU()
self.layer2 = nn.Linear(hidden1_size, hidden2_size)
self.act2 = nn.ReLU()
self.layer3 = nn.Linear(hidden2_size, num_classes)
def forward(self, x):
out = self.layer1(x)
out = self.act1(out)
out = self.layer2(out)
out = self.act2(out)
out = self.layer3(out)
return out
model = IrisNet(4, 100, 50, 3)
print(model)
Create Module and Instance

57. The Iris
batch_size = 60
iris_data_file = 'data/iris.data.txt'
train_ds, test_ds = iris.get_datasets(iris_data_file)
train_loader = torch.utils.data.DataLoader(dataset=train_ds,
batch_size=batch_size, shuffle=True)
test_loader = torch.utils.data.DataLoader(dataset=test_ds,
batch_size=batch_size, shuffle=True)
DataLoader

58. Loss Func7on
Output/Prediction
Actual Result
Loss Function
Loss Score
Input

59. Loss Func7on
In PyTorch
• L1Loss
• MSELoss
• CrossEntropyLoss
• BCELoss
• SoftMarginLoss
• More: https://pytorch.org/docs/stable/nn.html?#loss-functions

60. Loss Func7on
CrossEntropyLoss
Measures the performance of a classification model
whose output is a probability value between 0 and 1.
🍎 🍌 🍍
Prediction 0.02 0.88 0.1 Actual
🍌
Loss Score 0.98 0.12 0.9

61. Op7mizer Func7on
Output/Prediction
Actual Result
Loss Function
Loss Score
Input
Calculate Gradients
Optimizer
Iteration

62. Op7mizer Func7on
In PyTorch
• Socastic Gradient Descend (SGD)
• Adam
• Adadelta
• RMSprop

63. Back to Iris
Let’s Train The Neural Network
net = IrisNet(4, 100, 50, 3)
# Loss Function
criterion = nn.CrossEntropyLoss()
# Optimizer
learning_rate = 0.001
optimizer = torch.optim.SGD(net.parameters(),
lr=learning_rate,
nesterov=True,
momentum=0.9,
dampening=0)

64. Back to Iris
Let’s Train The Neural Network
num_epochs = 500
for epoch in range(num_epochs):
train_correct = 0
train_total = 0
for i, (items, classes) in enumerate(train_loader):
# Convert torch tensor to Variable
items = Variable(items)
classes = Variable(classes)

65. Back to Iris
Let’s Train The Neural Network
net.train() # Training mode
optimizer.zero_grad() # Reset gradients from past operation
outputs = net(items) # Forward pass
loss = criterion(outputs, classes) # Calculate the loss
loss.backward() # Calculate the gradient
optimizer.step() # Adjust weight based on gradients
train_total += classes.size(0)
_, predicted = torch.max(outputs.data, 1)
train_correct += (predicted "== classes.data).sum()
print('Epoch %d/%d, Iteration %d/%d, Loss: %.4f'
%(epoch+1, num_epochs, i+1,
len(train_ds)"//batch_size, loss.data[0]))

66. Back to Iris
Let’s Train The Neural Network
net.eval() # Put the network into evaluation mode
train_loss.append(loss.data[0])
train_accuracy.append((100 * train_correct / train_total))
# Record the testing loss
test_items = torch.FloatTensor(test_ds.data.values[:, 0:4])
test_classes = torch.LongTensor(test_ds.data.values[:, 4])
outputs = net(Variable(test_items))
loss = criterion(outputs, Variable(test_classes))
test_loss.append(loss.data[0])
# Record the testing accuracy
_, predicted = torch.max(outputs.data, 1)
total = test_classes.size(0)
correct = (predicted "== test_classes).sum()
test_accuracy.append((100 * correct / total))

67. Back to Iris
Let’s Train The Neural Network
import torch
import torch.nn as nn
import matplotlib.pyplot as plt
from torch.autograd import Variable
from data import iris
# Create the module
class IrisNet(nn.Module):
def "__init"__(self, input_size, hidden1_size, hidden2_size, num_classes):
super(IrisNet, self)."__init"__()
self.layer1 = nn.Linear(input_size, hidden1_size)
self.act1 = nn.ReLU()
self.layer2 = nn.Linear(hidden1_size, hidden2_size)
self.act2 = nn.ReLU()
self.layer3 = nn.Linear(hidden2_size, num_classes)
def forward(self, x):
out = self.layer1(x)
out = self.act1(out)
out = self.layer2(out)
out = self.act2(out)
out = self.layer3(out)
return out
# Create a model instance
model = IrisNet(4, 100, 50, 3)
print(model)
# Create the DataLoader
batch_size = 60
iris_data_file = 'data/iris.data.txt'
train_ds, test_ds = iris.get_datasets(iris_data_file)
print('# instances in training set: ', len(train_ds))
print('# instances in testing/validation set: ', len(test_ds))
train_loader = torch.utils.data.DataLoader(dataset=train_ds, batch_size=batch_size, shuffle=True)
test_loader = torch.utils.data.DataLoader(dataset=test_ds, batch_size=batch_size, shuffle=True)
# Model
net = IrisNet(4, 100, 50, 3)
# Loss Function
criterion = nn.CrossEntropyLoss()
# Optimizer
learning_rate = 0.001
optimizer = torch.optim.SGD(net.parameters(),
lr=learning_rate,
nesterov=True,
momentum=0.9,
dampening=0)
# Training iteration
num_epochs = 500
train_loss = []
test_loss = []
train_accuracy = []
test_accuracy = []
for epoch in range(num_epochs):
train_correct = 0
train_total = 0
for i, (items, classes) in enumerate(train_loader):
# Convert torch tensor to Variable
items = Variable(items)
classes = Variable(classes)
net.train() # Training mode
optimizer.zero_grad() # Reset gradients from past operation
outputs = net(items) # Forward pass
loss = criterion(outputs, classes) # Calculate the loss
loss.backward() # Calculate the gradient
optimizer.step() # Adjust weight/parameter based on gradients
train_total += classes.size(0)
_, predicted = torch.max(outputs.data, 1)
train_correct += (predicted "== classes.data).sum()
print('Epoch %d/%d, Iteration %d/%d, Loss: %.4f'
%(epoch+1, num_epochs, i+1, len(train_ds)"//batch_size, loss.data[0]))
net.eval() # Put the network into evaluation mode
train_loss.append(loss.data[0])
train_accuracy.append((100 * train_correct / train_total))
# Record the testing loss
test_items = torch.FloatTensor(test_ds.data.values[:, 0:4])
test_classes = torch.LongTensor(test_ds.data.values[:, 4])
outputs = net(Variable(test_items))
loss = criterion(outputs, Variable(test_classes))
test_loss.append(loss.data[0])
# Record the testing accuracy
_, predicted = torch.max(outputs.data, 1)
total = test_classes.size(0)
correct = (predicted "== test_classes).sum()
test_accuracy.append((100 * correct / total))

69. Summary
• Created feed forward neural network to predict a
type of flower
• Start from read the dataset and dataloader
• Choose a loss function and optimizer
• Train and evaluation

70. What’s Next?!
• pytorch.org/tutorials
• course.fast.ai
• coursera.org/learn/machine-learning
• kaggle.com/datasets

71. That’s All From me
github.com/rizafahmi
slideshare.net/rizafahmi
rizafahmi@gmail.com
twi8er.com/rizafahmi22
facebook.com/rizafahmi
