4. 4
OUTPUT SIGNAL TYPES
Discrete
ON or OFF
YES or NO
Analog
Speed control
Position information
MIN MAX
Electrical Interface
SignalSignal
5. 5
OPERATING VOLTAGE
Direct Current (DC)
Current flows in only
ONE direction
Safe, easy-to-handle
power source
Alternating Current (AC)
Current changes direction 60
times a second
Readily available
Electrical Interface
PowerPower
6. 6
A DISCRETE
SENSOR IS A SWITCH
Electronics
Sensing Side
Front-end
Electronics
Power Wires
Switch
Electrical Interface
8. 8
TYPES OF DISCRETE ELECTRICAL
OUTPUTS
Sensors of today use Solid-State outputs, not
mechanical relays
Today Yesterday
PNP, 3-wire Relay
NPN, 3-wire
AC/DC, 2-wire
Electrical Interface
9. 9
THE NPN & PNP OUTPUT
Functions similar to a switch,
But current only flows in one direction
PNP
Transistor Mechanical
Switch
Electrical Interface
10. 10
THE DIFFERENT TRANSISTORS
What direction do you want current to flow?
NPN
Also called Sinking
Electrical Interface
PNP
Also called Sourcing
+--+
11. 11
PNP, 3-WIRE
1
4
+
PNP Output
3 -
Load
Standard diagram form
As shown in our catalog
The Sensor
The Load
Connector
Pins
Electrical Interface
14. 14
1 ~
3 ~
Load
THE 2-WIRE AC/DC OUTPUT
Functions similar to a switch,
But with a small leak
Sensors Power
Supply from leakage current
Output Signal
Triac
Electrical Interface
15. 15
QUICK REFERENCE:
WIRING PNP & NPN
N P N
P N P
+
-
Load
First side of load
Second side of load
Switched side
Positive
Negative
Sensor is PNP
Electrical Interface
16. 16
IF GIVEN A CHOICE, WHICH DISCRETE
SENSOR TYPE SHOULD I CHOOSE?
PNP or NPN, 3-wire
- Fewer interface
problems
- Largest selection
- Lowest unit costs
AC/DC, 2-wire
- Many interface issues
- Smaller selection
- Susceptible to noise
1st CHOICE
2nd CHOICE
1
4
+
3 -
Load
1 ~
3 ~
Load
Electrical Interface
17. 17
NORMALLY OPEN (NO)
VS.
NORMALLY CLOSED (NC)
Identifies the non-active state (target not present) of
the sensor
Electronics
+
-
Normally Open
Is it off (open)?
Is it on (closed)?
Electrical Interface
18. 18
NORMALLY OPEN (NO)
VS.
NORMALLY CLOSED (NC)
Identifies the non-active state (target not present) of
the sensor
Electronics
+
-
Is it off (open)?
Is it on (closed)?
Electronics
+
-
Normally
Closed
Electrical Interface
19. 19
ANALOG OUTPUTS
Unlike a discrete output with two defined states,
analog signals have an infinite number of states.
Discrete
Analog
On
Off
Voltage
Time
Max
Min
Voltage
Time
Electrical Interface
20. 20
ANALOG USES
To provide absolute measurement or position
information
Measurement
Position
Electrical Interface
21. 21
ANALOG APPLICATIONS!
Spool diameter
Rotational position
Liquid level
Sort parts
Determine part orientation
Measure vibration
Measure straightness
Hydraulic or pneumatic
cylinder position
Expanding
possibilities
Expanding
possibilities
Electrical Interface
23. 23
ANALOG INFORMATION
The many forms for representing measurement or
position information
10
0
10
-10
5
-5
20
0
20
4
Voltage
Current
Digital Pulse
Electrical Interface
24. 24
ANALOG VOLTAGE
Information contained in varying voltage
Maximum Voltage
0 10
987654321
Measurement
Half VoltageNo Voltage
0 10
987654321
Measurement
0 10
987654321
Measurement
Water Analogy Volt Meter
Electrical Interface
25. 25
ANALOG CURRENT
Information contained in varying Current
0 10
987654321
Measurement
0 10
987654321
Measurement
0 10
987654321
Measurement
Maximum CurrentHalf CurrentNo Current
Water Analogy Current Meter
Electrical Interface
26. 26
DIGITAL PULSE
Information contained in digital pulse timing
100.00
Maximum measurementHalf wayMinimum measurement
50.000.00Pulse Width
Meter
Start/Stop
Electrical Interface
27. 27
ELECTRICAL INTERFACE REVIEW
Operating voltage: Sensor Power
DC: Safest
AC: Most available
Output signal types
Discrete
PNP, 3-wire
NPN, 3-wire
AC/DC 2-wire
Analog
Voltage
Current
Digital pulse
Electrical Interface
PowerPower
SignalSignal
