The document describes an improved SIFT feature extraction and matching algorithm based on the MSER algorithm. It first uses MSER instead of DOG to detect maximally stable elliptical regions, increasing stability and reducing the number of features. It then divides each elliptical region into fan-shaped subregions instead of square subregions, and constructs a new SIFT descriptor using Gaussian-weighted gradient information. Experimental results showed the new algorithm has affine invariance while maintaining other properties of SIFT, making it faster and better suited for real-time image processing.
This project is to retrieve the similar geographic images from the dataset based on the features extracted.
Retrieval is the process of collecting the relevant images from the dataset which contains more number of
images. Initially the preprocessing step is performed in order to remove noise occurred in input image with
the help of Gaussian filter. As the second step, Gray Level Co-occurrence Matrix (GLCM), Scale Invariant
Feature Transform (SIFT), and Moment Invariant Feature algorithms are implemented to extract the
features from the images. After this process, the relevant geographic images are retrieved from the dataset
by using Euclidean distance. In this, the dataset consists of totally 40 images. From that the images which
are all related to the input image are retrieved by using Euclidean distance. The approach of SIFT is to
perform reliable recognition, it is important that the feature extracted from the training image be
detectable even under changes in image scale, noise and illumination. The GLCM calculates how often a
pixel with gray level value occurs. While the focus is on image retrieval, our project is effectively used in
the applications such as detection and classification.
