A presentation on "Imagenet classification with deep convolutional neural networks" paper by Geoffrey Hinton

1. Amirkabir University of Technology
Department of Computer Engineering
and Information Technology
Image Classification with
Deep Convolutional
Neural Networks
Sepehr Rasouli

2. Introduction > Methods > Results > Conclusion2
Outline
• Introduction to Image Classification
& Deep Networks
• Proposed Method
• Main Idea
• Data Set
• Architecture
• Techniques
• Comparison & Results
• Conclusion

3. Introduction > Methods > Results > Conclusion3
Image Classification

4. Introduction > Methods > Results > Conclusion4
Why Deep Learning?
•“Shallow” vs. “deep” architectures
Learn a feature hierarchy all the way from pixels to classifier
Hand Designed
Feature
Extraction
Trainable
Classifier
Layer 1 Layer N
Simpler
classifier

5. Introduction > Methods > Results > Conclusion5
Our Method
• Deep Convolutional Neural Network
• 5 convolutional and 3 fully connected layers
• 650,000 neurons, 60 million parameters
• Techniques used for boosting up performance
• ReLU nonlinearity
• Training on Multiple GPUs
• Overlapping max pooling
• Data Augmentation
• Dropout

6. Introduction > Methods > Results > Conclusion6
Overall Architecture
• Trained with stochastic gradient descent on two NVIDIA GPUs for about a
week (5~6 days)
• 650,000 neurons, 60 million parameters, 630 million connections
• The last layer contains 1,000 neurons which produces a distribution over the
1,000 class labels.

7. Introduction > Methods > Results > Conclusion7
Dataset
• ImageNet
§ Over 15 million high-quality labeled images
§ About 22,000 categories
§ Collected from the web, labeled by humans on Amazon's Mechanical
Turk
§ Variable-resolution images
• ILSVRC Competition
§ ImageNet Large-Scale Pascal Visual Object Challenge
§ Annual competition of image classification at large scale
§ Subset of ImageNet
§ 1,000 categories with about 1,000 images each
§ 1.2M images in 1K categories
§ Classification: make 5 guesses about the image label

8. Introduction > Methods > Results > Conclusion8
Rectified Linear Units
𝑥 = 𝑤$ 𝑓 𝑍$ + 𝑤( 𝑓 𝑍(
+𝑤) 𝑓 𝑍)
x is called the total input
to the neuron, and f(x)
is its output
Very bad
(slow to train )
Very good
(quick to train)
f(x) = max(0,x)f(x) = tanh(x)

9. Introduction > Methods > Results > Conclusion9
Rectified Linear Units
• Biological plausibility: One-sided, compared
to the antisymmetry of tanh.
• Sparse activation: For example, in a randomly
initialized network, only about 50% of hidden
units are activated (having a non-zero output).
• Efficient gradient propagation: No vanishing
gradient problem or exploding effect.
• Efficient computation: Only comparison,
addition and multiplication

10. Introduction > Methods > Results > Conclusion10
Training on Multiple GPUs
• Spread across two GPUs
• GTX 580 GPU with 3GB memory
• Particularly well-suited to cross-GPU
parallelization
• Very efficient implementation of CNN on
GPUs

11. Model Top-1 Top-5
Sparse coding [3] 47.1% 28.2%
SIFT + FVs [4] 45.7% 25.7%
CNN 37.5 17.0%
Introduction > Methods > Results > Conclusion11
Results & Comparison
•ILSVRC-2010 test set
ILSVRC-2010 winner
Previous best
published result
Our Method
Comparison of results on ILSRVCs 2010
test set. In italics best results achieved
by others.

12. Introduction > Methods > Results > Conclusion12
Conclusion
• Large, deep convolutional neural networks for large
scale image classification was proposed
• 5 convolutional layers, 3 fully-connected layers
• 650,000 neurons, 60 million parameters
• Several techniques for boosting up performance
• The proposed method won the ILSVRC-2012
• Achieved a winning top-5 error rate of 15.3%,
compared to 26.2% achieved by the second-best entry

13. Introduction > Methods > Results > Conclusion13
Conclusion

14. Introduction > Methods > Results > Conclusion14
References
[1] http://cs.nyu.edu/~fergus/tutorials/
deep_learning_cvpr12/fergus_dl_tutorial_final.pptx
[2] reference : http://web.engr.illinois.edu/
~slazebni/spring14/lec24_cnn.pdf
[3] A. Berg, J. Deng, and L. Fei-Fei. Large scale
visual recognition challenge 2010.
www.imagenet.org/challenges. 2010. [4]
S. Tara, Brian Kingsbury, A.-r. Mohamed and
B. Ramabhadran, "Learning Filter Banks within a Deep
[4] J.Sánchezand F.Perronnin.High-dimensional
signature compression for large-scale image classification.
In Computer Vision and Pattern Recognition(CVPR),
2011IEEEConferenceon,pages1665–1672.IEEE, 2011.

15. Introduction > Methods > Results > Conclusion15
Thank you for your attention
Any Questions?

16. Introduction > Methods > Results > Conclusion16
Results 2012
• ILSVRC-2012 results
Proposed method
Top-5 error rate : 16.422%
Runner-up
Top-5 error rate : 26.172%

17. Introduction > Methods > Results > Conclusion17
Convolutional NNs

18. Introduction > Methods > Results > Conclusion18
Pooling
• Spatial Pooling
• Non-overlapping / overlapping regions
• Sum or max
Max
Sum

19. Introduction > Methods > Results > Conclusion19
Dropout
• Independently set each hidden unit activity to zero with 0.5
probability
• Used in the two globally-connected hidden layers at the net's
output
