Exploration Lan Switching Chapter2
•Download as PPT, PDF•
2 likes•718 views
The document discusses configuring and securing a switch for use in a network. It describes summarizing Ethernet operations, switch forwarding methods, and configuring a switch through the Cisco IOS including security features like passwords, SSH, and port security. The objectives are to understand Ethernet, how switches forward frames, and configure a switch for a voice, video and data network with basic security.
Report
Share
Report
Share
Recommended
Lan Switching[1]
The document discusses LAN switching as a technology to increase the efficiency of local area networks and solve bandwidth problems. It covers key features of switches like full duplex operation, flow control, static and dynamic switching, cut-through versus store-and-forward switching, and address resolution. It also discusses switch architectures, topologies, virtual LAN capabilities, shopping guidelines, and compares switching to other solutions like upgrading to faster networking technologies or using bridges and routers.
Routing Protocols and Concepts: Ch5 - Routing Information Protocol (RIP v1)
Routing Information Protocol Version 1 (RIPv1) history and characteristics.
RIP v1 message format.
RIP Request / Response Process.
IP Address Classes and Classful Routing.
RIP v1 Configuration, Router RIP command, Network command, Show IP Route, debug IP RIP and Show ip protocols.
Passive Interfaces, Boundary Routers and Automatic Summarization.
Advantages and Disadvantages of automatic summarization.
Processing RIP Updates, Default Route and RIPv1
Lan switching technologies
This chapter begins an examination of the flow of traffic in a modern network. It
examines some of the current network design models and the way LAN switches
build forwarding tables and use the MAC address information to efficiently
switch data between hosts.
Routers.ppt
Routers connect different computer networks and forward data packets between them by reading the address information in each packet to determine the ultimate destination. A router contains a routing table with information about connected networks and uses this to determine the best path for packets to travel through multiple networks to reach their destination. There are two main types of routers: core routers connect different cities while edge routers connect users and hosts to networks.
Layer 2 & layer 3 switching
The document compares Layer 2 and Layer 3 switching. Layer 2 switching uses MAC addresses to forward frames within a broadcast domain, while Layer 3 switching uses IP addresses to forward packets, allowing for greater scalability and security. Some benefits of Layer 2 switching include hardware-based bridging and high speeds, while benefits of Layer 3 switching include scalability, security, QoS, and lower latency.
Managing Redundant Links & Inter-VLAN Routing
This document discusses managing redundant links and spanning tree protocols. It describes spanning tree protocol (STP) operations including electing a root bridge, path cost calculations, port states and BPDU timers. It also covers spanning tree in VLAN environments, such as per-VLAN STP (PVST), and techniques for scaling STP, including modifying root selection, path costs, port priorities and timers. Other topics include Fast EtherChannel, PortFast and UplinkFast for improving convergence times.
CCNA- part 8 switch
The document discusses the differences between hubs, switches, bridges and routers. Hubs operate at the physical layer using broadcasting, while switches are intelligent devices that operate at the data link layer using MAC addresses to reduce broadcasting. Spanning tree protocol is used to prevent loops when there are redundant links between switches by blocking certain ports.
How to configure a router
1) A router connects two or more networks and allows communication between them. It routes traffic between different subnets like a local network and the internet.
2) Proper configuration of a router is needed for networking and internet access. This involves settings like IP addresses, default gateways, and DNS servers for the router and connected devices.
3) Configuring a router typically involves accessing a web-based administrative panel to set up the WAN connection, local network, wireless access point, security, and other options like DHCP server settings.
Recommended
Lan Switching[1]
The document discusses LAN switching as a technology to increase the efficiency of local area networks and solve bandwidth problems. It covers key features of switches like full duplex operation, flow control, static and dynamic switching, cut-through versus store-and-forward switching, and address resolution. It also discusses switch architectures, topologies, virtual LAN capabilities, shopping guidelines, and compares switching to other solutions like upgrading to faster networking technologies or using bridges and routers.
Routing Protocols and Concepts: Ch5 - Routing Information Protocol (RIP v1)
Routing Information Protocol Version 1 (RIPv1) history and characteristics.
RIP v1 message format.
RIP Request / Response Process.
IP Address Classes and Classful Routing.
RIP v1 Configuration, Router RIP command, Network command, Show IP Route, debug IP RIP and Show ip protocols.
Passive Interfaces, Boundary Routers and Automatic Summarization.
Advantages and Disadvantages of automatic summarization.
Processing RIP Updates, Default Route and RIPv1
Lan switching technologies
This chapter begins an examination of the flow of traffic in a modern network. It
examines some of the current network design models and the way LAN switches
build forwarding tables and use the MAC address information to efficiently
switch data between hosts.
Routers.ppt
Routers connect different computer networks and forward data packets between them by reading the address information in each packet to determine the ultimate destination. A router contains a routing table with information about connected networks and uses this to determine the best path for packets to travel through multiple networks to reach their destination. There are two main types of routers: core routers connect different cities while edge routers connect users and hosts to networks.
Layer 2 & layer 3 switching
The document compares Layer 2 and Layer 3 switching. Layer 2 switching uses MAC addresses to forward frames within a broadcast domain, while Layer 3 switching uses IP addresses to forward packets, allowing for greater scalability and security. Some benefits of Layer 2 switching include hardware-based bridging and high speeds, while benefits of Layer 3 switching include scalability, security, QoS, and lower latency.
Managing Redundant Links & Inter-VLAN Routing
This document discusses managing redundant links and spanning tree protocols. It describes spanning tree protocol (STP) operations including electing a root bridge, path cost calculations, port states and BPDU timers. It also covers spanning tree in VLAN environments, such as per-VLAN STP (PVST), and techniques for scaling STP, including modifying root selection, path costs, port priorities and timers. Other topics include Fast EtherChannel, PortFast and UplinkFast for improving convergence times.
CCNA- part 8 switch
The document discusses the differences between hubs, switches, bridges and routers. Hubs operate at the physical layer using broadcasting, while switches are intelligent devices that operate at the data link layer using MAC addresses to reduce broadcasting. Spanning tree protocol is used to prevent loops when there are redundant links between switches by blocking certain ports.
How to configure a router
1) A router connects two or more networks and allows communication between them. It routes traffic between different subnets like a local network and the internet.
2) Proper configuration of a router is needed for networking and internet access. This involves settings like IP addresses, default gateways, and DNS servers for the router and connected devices.
3) Configuring a router typically involves accessing a web-based administrative panel to set up the WAN connection, local network, wireless access point, security, and other options like DHCP server settings.
CCNA- part 9 vlan
VLAN allows logical separation of broadcast domains by tagging Ethernet frames with VLAN IDs. It divides a physical network into virtual LANs to improve security, manageability and flexibility. VLAN configuration involves assigning ports to VLANs either statically by port number or dynamically by MAC address. Frame tagging standards like IEEE 802.1Q are used to identify VLANs on trunk links that carry traffic for multiple VLANs between switches.
Лекц 9
VLAN allows logical segmentation of networks even if they are physically connected. It divides a physical broadcast domain into multiple broadcast domains to reduce broadcast traffic and increase security. VLAN uses tagging to identify which VLAN a frame belongs to and switches use filtering tables to determine how to handle each frame. Routers are needed to route between VLANs since they are separate broadcast domains.
8. internal components of router
The document discusses the internal components of a router, including RAM, NVRAM, Flash, and ROM. RAM stores temporary configuration files and routing tables, while NVRAM stores backup configuration files. Flash holds the Cisco IOS operating system, and ROM contains the POST and bootstrap programs. Interfaces provide network connections for packets. When booted, the router loads the IOS from Flash into RAM, along with configuration files from NVRAM and routing tables. Status commands like "show version" and "show running-config" display information about the router's components, configuration, and protocols.
Ccna day2-140715152313-phpapp02
Cisco IOS is the operating system that controls routing and switching functions on Cisco networking devices. It allows routers and switches to function by running configuration files that control traffic flow. Understanding Cisco IOS is essential for network administrators to properly configure and manage Cisco devices on their networks.
Link State Protocol
The document describes the design of a link state routing protocol, including the representation of routers and networks as processes identified by IDs, the various packet types used in the protocol, and the data structures and state machines used to store routing and neighbor information and implement the protocol. It also discusses implementation requirements, issues, and how the protocol uses UDP to allow communication between routing processes on the same machine using ports.
LAN Switching and Wireless: Ch3 - Virtual Local Area Networks (VLANs)
This document provides information about LAN switching and wireless networking. It defines VLANs and their benefits, describes different types of VLANs including data, default, native and management VLANs. It also discusses VLAN port membership modes, intra-VLAN and inter-VLAN communication, trunking, trunking modes and common problems with trunks. Contact information is provided at the end for the author, Abdelkhalik Mosa, with links to LinkedIn, Twitter and Facebook.
20088 1 ccna3 3.1-06 switch configurations
This document discusses switch configuration, including:
- Switches contain a CPU, RAM, and operating system and perform a power-on self-test when powered on.
- The system LED indicates power and status, port LEDs show port status and mode.
- Switches can be configured through the console port or remotely via IP address assignment and HTTP.
- Basic configurations include hostname, passwords, management VLAN IP address, and port settings. Backups can be saved to a TFTP server.
Router configuration
Basic idea about router. Router configuration. This is our team project. From this slide we can learn what is router configuration and application of router. We also learn the security of router.
network Switch
thourighly explained working and types of network switches a very good ready to present presentation aesthetically pleasing as well best for university or college use click like if u lyk it thanks
Cisco router basic
Routing is the method by which network devices direct messages across networks to arrive at the correct destination. Routers use routing tables containing information about locally-connected networks and remote networks to determine the best path to send packets. The routing table includes details like the destination, mask, gateway, and cost for each route.
VLAN Virtual Area Network ,Switch,Ethernet ,VIkram Snehi
A VLAN allows computers on different physical LAN segments to communicate as if they were on the same LAN. VLANs logically segment LANs into different broadcast domains by using frame tagging to identify which VLAN a frame belongs to. There are two main types of VLAN configurations - static, where ports are manually assigned to VLANs, and dynamic, where assignments are made via network management software based on device MAC addresses.
Vlans
This document provides an overview of VLAN concepts, configuration, and troubleshooting. It discusses VLAN types and tagging, communicating between VLANs, verifying and saving VLAN configurations, deleting VLANs, and troubleshooting issues such as preventing broadcast storms, establishing trunk links, propagating VLAN changes with VTP, and dropped packets or loops.
Cisco router modes
This document provides an overview of the different working modes of a router and how to configure them. It discusses the following modes: user mode, privilege mode, global configuration mode, interface configuration mode, line configuration mode, and sub-interface mode. It also provides examples of how to set the router name and clock, configure passwords, and set interfaces in these different modes. The document is intended for training purposes and reproducing or distributing it without authorization is prohibited.
Vlan
VLANs logically segment LANs into broadcast domains by using switches to assign ports and their attached devices to VLAN groups based on their MAC address, IP subnet, or switch port. This allows devices that are physically located on different floors or buildings to belong to the same logical LAN segment while preventing Layer 2 broadcasts from crossing VLAN boundaries. VLAN trunk links between switches allow multiple VLANs to be transmitted over the same physical link.
Router and routing
A router is a networking device that connects different networks and selects the best path to forward packets between them. It operates at the network layer and uses routing tables to determine the best path. Major router vendors include Cisco, Juniper, and Huawei. Routers have different types of ports including LAN ports to connect to local networks, WAN ports to connect between routers, and administrative ports for management. Routers also run an operating system like Cisco IOS to perform routing functions.
Lab 6.4.1 InterVLAN routing
This document provides instructions for configuring basic inter-VLAN routing between VLANs on switches and a router. It includes:
- Configuring VLANs, trunk ports, and IP addresses on switches to segment traffic into VLANs 10, 20, 30, and 99.
- Assigning switch ports, PCs, and a server to the appropriate VLANs and IP subnets.
- Clearing the configuration on a router and preparing it to route between the VLANs.
Destroying Router Security - NNC5ed
PDF version slides from our talk at Navaja Negra & Conecta CON 5th Edition: Destroying Router Security.
Authors:
- José Antonio Rodríguez García
- Álvaro Folgado Rueda
- Iván Sanz de Castro
vlan
The document discusses VLAN configuration for a group project. It defines VLAN as a broadcast domain within a switch that divides a broadcast domain into multiple broadcast domains. It provides details on LANs, creating VLANs, VLAN types (static and dynamic), and commands used for VLAN configuration like show vlan brief, vlan database, and switchport access vlan. Benefits of VLAN discussed are broadcast control, security, and performance.
Inter VLAN Routing
Inter-VLAN routing is the process of forwarding network traffic from one VLAN to another VLAN using a
router.
VLANs divide broadcast domains in a LAN environment. Whenever hosts in one VLAN need to
communicate with hosts in another VLAN, the traffic must be routed between them. This is known as
inter-VLAN routing. On Catalyst switches it is accomplished by creating Layer 3 interfaces (Switch virtual
interfaces (SVI)).
Lan & vlan
This document provides an overview of local area networks (LANs) and virtual LANs (VLANs). It defines LAN as a network covering a small area like a home, office or campus to connect computers in close proximity. The document discusses common LAN topologies like bus, ring and star. It then introduces VLAN as a way to logically segment devices within a LAN even if they share the same infrastructure. The document explains how VLANs work using tags and trunking between switches. It outlines benefits of VLANs like improved security, flexibility and traffic management compared to traditional LANs.
Default and On demand routing - Advance Computer Networks
Routing is the process of selecting best paths in a network. In the past, the term routing was also used to mean forwarding network traffic among networks. However this latter function is much better described as simply forwarding. Routing is performed for many kinds of networks, including the telephone network (circuit switching), electronic data networks (such as the Internet), and transportation networks.
In packet switching networks, routing directs packet forwarding (the transit of logically addressed network packets from their source toward their ultimate destination) through intermediate nodes. Intermediate nodes are typically network hardware devices such as routers, bridges, gateways, firewalls, or switches. General-purpose computers can also forward packets and perform routing, though they are not specialized hardware and may suffer from limited performance. The routing process usually directs forwarding on the basis of routing tables which maintain a record of the routes to various network destinations. Thus, constructing routing tables, which are held in the router's memory, is very important for efficient routing. Most routing algorithms use only one network path at a time. Multipath routing techniques enable the use of multiple alternative paths.
Image processing detect faces( معالجة الصور (كشف الأوجه)
Image processing detect faces( معالجة الصور (كشف الأوجه)
is mini project about face detect
More Related Content
What's hot
CCNA- part 9 vlan
VLAN allows logical separation of broadcast domains by tagging Ethernet frames with VLAN IDs. It divides a physical network into virtual LANs to improve security, manageability and flexibility. VLAN configuration involves assigning ports to VLANs either statically by port number or dynamically by MAC address. Frame tagging standards like IEEE 802.1Q are used to identify VLANs on trunk links that carry traffic for multiple VLANs between switches.
Лекц 9
VLAN allows logical segmentation of networks even if they are physically connected. It divides a physical broadcast domain into multiple broadcast domains to reduce broadcast traffic and increase security. VLAN uses tagging to identify which VLAN a frame belongs to and switches use filtering tables to determine how to handle each frame. Routers are needed to route between VLANs since they are separate broadcast domains.
8. internal components of router
The document discusses the internal components of a router, including RAM, NVRAM, Flash, and ROM. RAM stores temporary configuration files and routing tables, while NVRAM stores backup configuration files. Flash holds the Cisco IOS operating system, and ROM contains the POST and bootstrap programs. Interfaces provide network connections for packets. When booted, the router loads the IOS from Flash into RAM, along with configuration files from NVRAM and routing tables. Status commands like "show version" and "show running-config" display information about the router's components, configuration, and protocols.
Ccna day2-140715152313-phpapp02
Cisco IOS is the operating system that controls routing and switching functions on Cisco networking devices. It allows routers and switches to function by running configuration files that control traffic flow. Understanding Cisco IOS is essential for network administrators to properly configure and manage Cisco devices on their networks.
Link State Protocol
The document describes the design of a link state routing protocol, including the representation of routers and networks as processes identified by IDs, the various packet types used in the protocol, and the data structures and state machines used to store routing and neighbor information and implement the protocol. It also discusses implementation requirements, issues, and how the protocol uses UDP to allow communication between routing processes on the same machine using ports.
LAN Switching and Wireless: Ch3 - Virtual Local Area Networks (VLANs)
This document provides information about LAN switching and wireless networking. It defines VLANs and their benefits, describes different types of VLANs including data, default, native and management VLANs. It also discusses VLAN port membership modes, intra-VLAN and inter-VLAN communication, trunking, trunking modes and common problems with trunks. Contact information is provided at the end for the author, Abdelkhalik Mosa, with links to LinkedIn, Twitter and Facebook.
20088 1 ccna3 3.1-06 switch configurations
This document discusses switch configuration, including:
- Switches contain a CPU, RAM, and operating system and perform a power-on self-test when powered on.
- The system LED indicates power and status, port LEDs show port status and mode.
- Switches can be configured through the console port or remotely via IP address assignment and HTTP.
- Basic configurations include hostname, passwords, management VLAN IP address, and port settings. Backups can be saved to a TFTP server.
Router configuration
Basic idea about router. Router configuration. This is our team project. From this slide we can learn what is router configuration and application of router. We also learn the security of router.
network Switch
thourighly explained working and types of network switches a very good ready to present presentation aesthetically pleasing as well best for university or college use click like if u lyk it thanks
Cisco router basic
Routing is the method by which network devices direct messages across networks to arrive at the correct destination. Routers use routing tables containing information about locally-connected networks and remote networks to determine the best path to send packets. The routing table includes details like the destination, mask, gateway, and cost for each route.
VLAN Virtual Area Network ,Switch,Ethernet ,VIkram Snehi
A VLAN allows computers on different physical LAN segments to communicate as if they were on the same LAN. VLANs logically segment LANs into different broadcast domains by using frame tagging to identify which VLAN a frame belongs to. There are two main types of VLAN configurations - static, where ports are manually assigned to VLANs, and dynamic, where assignments are made via network management software based on device MAC addresses.
Vlans
This document provides an overview of VLAN concepts, configuration, and troubleshooting. It discusses VLAN types and tagging, communicating between VLANs, verifying and saving VLAN configurations, deleting VLANs, and troubleshooting issues such as preventing broadcast storms, establishing trunk links, propagating VLAN changes with VTP, and dropped packets or loops.
Cisco router modes
This document provides an overview of the different working modes of a router and how to configure them. It discusses the following modes: user mode, privilege mode, global configuration mode, interface configuration mode, line configuration mode, and sub-interface mode. It also provides examples of how to set the router name and clock, configure passwords, and set interfaces in these different modes. The document is intended for training purposes and reproducing or distributing it without authorization is prohibited.
Vlan
VLANs logically segment LANs into broadcast domains by using switches to assign ports and their attached devices to VLAN groups based on their MAC address, IP subnet, or switch port. This allows devices that are physically located on different floors or buildings to belong to the same logical LAN segment while preventing Layer 2 broadcasts from crossing VLAN boundaries. VLAN trunk links between switches allow multiple VLANs to be transmitted over the same physical link.
Router and routing
A router is a networking device that connects different networks and selects the best path to forward packets between them. It operates at the network layer and uses routing tables to determine the best path. Major router vendors include Cisco, Juniper, and Huawei. Routers have different types of ports including LAN ports to connect to local networks, WAN ports to connect between routers, and administrative ports for management. Routers also run an operating system like Cisco IOS to perform routing functions.
Lab 6.4.1 InterVLAN routing
This document provides instructions for configuring basic inter-VLAN routing between VLANs on switches and a router. It includes:
- Configuring VLANs, trunk ports, and IP addresses on switches to segment traffic into VLANs 10, 20, 30, and 99.
- Assigning switch ports, PCs, and a server to the appropriate VLANs and IP subnets.
- Clearing the configuration on a router and preparing it to route between the VLANs.
Destroying Router Security - NNC5ed
PDF version slides from our talk at Navaja Negra & Conecta CON 5th Edition: Destroying Router Security.
Authors:
- José Antonio Rodríguez García
- Álvaro Folgado Rueda
- Iván Sanz de Castro
vlan
The document discusses VLAN configuration for a group project. It defines VLAN as a broadcast domain within a switch that divides a broadcast domain into multiple broadcast domains. It provides details on LANs, creating VLANs, VLAN types (static and dynamic), and commands used for VLAN configuration like show vlan brief, vlan database, and switchport access vlan. Benefits of VLAN discussed are broadcast control, security, and performance.
Inter VLAN Routing
Inter-VLAN routing is the process of forwarding network traffic from one VLAN to another VLAN using a
router.
VLANs divide broadcast domains in a LAN environment. Whenever hosts in one VLAN need to
communicate with hosts in another VLAN, the traffic must be routed between them. This is known as
inter-VLAN routing. On Catalyst switches it is accomplished by creating Layer 3 interfaces (Switch virtual
interfaces (SVI)).
Lan & vlan
This document provides an overview of local area networks (LANs) and virtual LANs (VLANs). It defines LAN as a network covering a small area like a home, office or campus to connect computers in close proximity. The document discusses common LAN topologies like bus, ring and star. It then introduces VLAN as a way to logically segment devices within a LAN even if they share the same infrastructure. The document explains how VLANs work using tags and trunking between switches. It outlines benefits of VLANs like improved security, flexibility and traffic management compared to traditional LANs.
What's hot (20)
LAN Switching and Wireless: Ch3 - Virtual Local Area Networks (VLANs)
LAN Switching and Wireless: Ch3 - Virtual Local Area Networks (VLANs)
VLAN Virtual Area Network ,Switch,Ethernet ,VIkram Snehi
VLAN Virtual Area Network ,Switch,Ethernet ,VIkram Snehi
Viewers also liked
Default and On demand routing - Advance Computer Networks
Routing is the process of selecting best paths in a network. In the past, the term routing was also used to mean forwarding network traffic among networks. However this latter function is much better described as simply forwarding. Routing is performed for many kinds of networks, including the telephone network (circuit switching), electronic data networks (such as the Internet), and transportation networks.
In packet switching networks, routing directs packet forwarding (the transit of logically addressed network packets from their source toward their ultimate destination) through intermediate nodes. Intermediate nodes are typically network hardware devices such as routers, bridges, gateways, firewalls, or switches. General-purpose computers can also forward packets and perform routing, though they are not specialized hardware and may suffer from limited performance. The routing process usually directs forwarding on the basis of routing tables which maintain a record of the routes to various network destinations. Thus, constructing routing tables, which are held in the router's memory, is very important for efficient routing. Most routing algorithms use only one network path at a time. Multipath routing techniques enable the use of multiple alternative paths.
Image processing detect faces( معالجة الصور (كشف الأوجه)
Image processing detect faces( معالجة الصور (كشف الأوجه)
is mini project about face detect
أنماط الصور الرقمية
This document discusses color modes in Photoshop including bitmap, grayscale, duotone, indexed color, RGB, CMYK, and Lab color. It also covers multichannel color mode and layers. Bitmap uses 1-bit color while grayscale uses 8-bits per pixel for black, white, and shades of gray. Duotone allows using two colors and Lab color represents lightness and color opponent dimensions. The document also briefly discusses type tools, vertical and horizontal type, and shortcuts for entering and committing text.
Digital Photographs
عرض تقديمى عن الصور الرقمية، مكونات الكاميرا الرقمية ، و إنتاج و مميزات الصور الرقمية
ARP
ARP enables hosts on a network to dynamically map IP addresses to physical hardware addresses. Each host maintains an ARP cache containing IP to physical address mappings. When a host needs to send data to another host, it first checks its ARP cache for the mapping. If no mapping exists, the host broadcasts an ARP request containing the target IP address. The host with that IP address responds with its physical address, which the requesting host adds to its ARP cache. This process allows hosts to dynamically learn each other's physical addresses as needed for packet transmission.
شبكات و أمن المعلومات 2
شبكات الإتصالات - تقنيات الشبكات - الانترنت و الانران و الاكسترانت - مكونات الشبكة
LAN Switching and Wireless: Ch7 - Basic Wireless Concepts and Configuration
Chapter 7 : CCNA Cisco Academy: LAN Switching and Wireless.
This chapter discusses the basic wireless concepts:
- Comparison between WLAN and LAN.
- The difference between wireless PAN, LAN, MAN and WAN.
- Infrared and Radio Frequency (RF).
- Benefits and limitations of the wireless technology.
- Difference between licensed and unlicensed bands.
- Wi-Fi and the key organizations influencing WLAN standards.
- Wireless infrastructure components which are the wireless NIC, Wireless Access Points and wireless routers.
- The Hidden node problem.
- Configuration parameters SSID, network modes and channels.
- Wireless 802.11 typologies: Ad hoc (IBSS), BSS and ESS.
Client and Access Point Association: Beacons, probe, authenticate and associate.
- Threats to Wireless Security- Unauthorized Access: War Drivers, Hackers and employees.
- Man-in-the-Middle Attacks, Denial of Service.
- Wireless Security Protocol Overview: open authentication, WEP authentication.
- Encryption – TKIP and AES.
- Configuring the Wireless Access Point
- Configuring security: personal and enterprise (AAA and EAP ).
- WLAN Troubleshooting: Incorrect Channel Settings, Solving RF Interference, Access Point Misplacement and Authentication and Encryption
Arp
ARP and RARP protocols are used to map IP addresses to MAC addresses on local area networks. ARP requests are broadcast to the network to resolve IP to MAC addresses, and ARP replies provide the requested mapping. Hosts cache ARP entries to avoid frequent address resolution, with entries expiring after 20 minutes. Proxy ARP allows a router to respond to ARP requests on behalf of hosts on different connected networks.
Eigenface For Face Recognition
The document discusses the eigenface approach for face recognition. It provides an overview of eigenfaces, how they are calculated from a training set of faces, and how they can be used to identify faces by projecting faces onto the eigenface space. Major steps include calculating the eigenfaces from a training set, projecting new images into eigenface space to get weight coefficients, and comparing the weights to known individuals' weights or thresholds to classify faces as known or unknown. Advantages are ease of implementation and little preprocessing required, while limitations include sensitivity to head scale and only applicable to frontal views under controlled conditions.
أمن المعلومات 4
أمن المعلومات والجرائم المعلوماتية وكيفية الاصابة والوقاية بالبرمجيات الخبيثة
من فيروسات وأشباة الفيروسات
LAN Switching and Wireless: Ch2 - Basic Switch Concepts and Configuration
This chapter starts with discussing the key elements of ethernet/802.3 networks such as CSMA/CD, communication using unicast, multicast, and broadcast, the ethernet frame, MAC address, duplex settings, half-duplex and full-duplex, switch port settings, auto-MDIX, and the switch MAC table.
After that, there is a discussion about the design considerations for Ethernet networks such as bandwidth, throughput, goodput, collision domains, broadcast domains, LAN segmentation, and network latency.
Switch forwarding modes: store and forward and cut-through and the difference between symmetric and asymmetric switching.
Memory Buffering: port-based memory and shared memory.
The difference between layer 3 switches and routers.
Cisco switch CLI commands, accessing the history, switch boot sequence and recovering from system crash.
Managing the MAC address table, dynamic MAC addresses and static MAC addresses and backing configuration files to a TFTP server.
Configuring switch passwords and password recovery, configuring telnet and SSH.
Common Security Attacks such as MAC address flooding, spoofing attacks, CDP attacks and telnet attacks.
Switch port security, sticky port security and security violation modes: protect, restrict and shutdown and verifying poert security
CCNA Network Devices
This document summarizes network devices and concepts from a CCNA guide. It describes how repeaters, hubs, wireless access points, bridges, switches and routers segment networks and control traffic. It also defines Ethernet, Fast Ethernet and Gigabit Ethernet standards, and explains half and full-duplex communication modes. The summary provides an overview of common network devices and technologies for local area networks.
CCNA Basic Switching and Switch Configuration
This document provides an overview of basic switching concepts and Cisco switch configuration. It explains Ethernet and how switches work to segment networks and reduce collisions. Switches operate at the data link layer and learn MAC addresses to forward frames efficiently. The document discusses switch configuration using commands like hostname, interface, duplex, and port security. It compares switching methods like store-and-forward and cut-through forwarding. The summary reiterates how switches divide collision domains to improve performance over shared-medium Ethernet.
Viewers also liked (18)
Default and On demand routing - Advance Computer Networks
Default and On demand routing - Advance Computer Networks
Image processing detect faces( معالجة الصور (كشف الأوجه)
Image processing detect faces( معالجة الصور (كشف الأوجه)
LAN Switching and Wireless: Ch7 - Basic Wireless Concepts and Configuration
LAN Switching and Wireless: Ch7 - Basic Wireless Concepts and Configuration
LAN Switching and Wireless: Ch2 - Basic Switch Concepts and Configuration
LAN Switching and Wireless: Ch2 - Basic Switch Concepts and Configuration
Similar to Exploration Lan Switching Chapter2
CCNA Exploration 3 - Chapter 2
The document discusses configuring and securing a Cisco switch. It covers summarizing Ethernet operation as defined in IEEE 802.3, explaining switch forwarding methods, and configuring a switch and basic security. Key topics include store and forward switching, symmetric and asymmetric switching, Cisco IOS CLI features like help and command history, and security measures like passwords, SSH, and port security.
CCNA Icnd110 s02l09
This document summarizes key aspects of Ethernet LANs and Cisco switches. It discusses how switches can segment Ethernet networks into multiple sections using forwarding, filtering, and flooding functions. It also explains that while microsegmentation and hierarchies can improve switched Ethernet performance, physical loops must be prevented using Spanning Tree Protocol (STP). Finally, it outlines the startup process for Cisco switches and how the Cisco IOS CLI is used to configure settings like the switch name, passwords, interfaces, and IP addresses to implement a network design.
Introduction to routers
The document introduces Cisco IOS software which controls routing and switching functions on Cisco routers and switches. It describes the purpose of IOS which provides basic routing, switching, security and scalability. It also outlines the command line interface environment and modes, and how to establish connections and configure router interfaces such as Ethernet, serial and ISDN interfaces.
CCNA3 Verson6 Chapter1
This document discusses designing scalable campus wired LANs and selecting network devices. It covers hierarchical LAN designs with access, distribution and core layers. When expanding networks, methods like redundancy, smaller failure domains and link aggregation are used. The document also discusses selecting switches and routers based on requirements, with considerations like port density, forwarding rates, wire speed, PoE and form factors. Basic device configuration and management commands are also outlined.
Introduction 140318015826-phpapp01
This document provides a summary of a presentation on CCNA (Cisco Certified Network Associate). It includes:
1. An introduction to CCNA, which stands for Cisco Certified Network Associate and provides information about networking, its types and applications. Networking is important for communication and resource sharing.
2. Descriptions of different types of networking including LAN, MAN, and WAN. It also lists common networking devices like LAN cards, bridges, hubs, switches, and routers.
3. Overviews of topics covered in CCNA including subnetting, supernetting, Classless Interdomain Routing (CIDR), the differences between hubs and switches, what routers are used for,
ccna summer training ppt ( Cisco certified network analysis) ppt. by Traun k...
This document provides a summary of a presentation on CCNA (Cisco Certified Network Associate). It was trained by Ravinder Kumar from Gurukul Technical Institute and submitted by Tarun Khaneja with roll number 2110045 and contact number 09034406598. The presentation introduces CCNA and discusses networking types and applications. It also covers networking devices, subnetting, routing protocols like RIP, EIGRP, OSPF, ACLs, VLANs, and inter-VLAN routing. Configuration examples are provided for EIGRP and RIP routing on the same network.
Chapter 05 - Inter-VLAN Routing
Chapter 5: Objectives
---------------------------------------------------------
Describe the three primary options for enabling inter-VLAN routing.
Configure legacy inter-VLAN routing.
Configure router-on-a-stick inter-VLAN routing.
Troubleshoot common inter-VLAN configuration issues.
Troubleshoot common IP addressing issues in an inter-VLAN-routed environment.
Configure inter-VLAN routing using Layer 3 switching.
Troubleshoot inter-VLAN routing in a Layer 3-switched environment.
Yaser Rahmati | یاسر رحمتی
Rahmati Academy | آکادمی رحمتی
www.yaser-rahmati.ir
www.rahmati-academy.ir
KPUCC-Rs instructor ppt_chapter5_final
The document discusses inter-VLAN routing and layer 3 switching. It describes legacy, router-on-a-stick, and multilayer switch approaches to inter-VLAN routing. It also covers configuring and troubleshooting inter-VLAN routing, including using switch virtual interfaces (SVIs) and routed ports for layer 3 switching. The document provides instructions on configuring various inter-VLAN routing options and identifies common configuration issues.
CCNAv5 - S2: Chapter5 Inter Vlan Routing
CCNAv5
S2-Routing and Switching: Inter Vlan Routing
Download here:
ccna5vn.wordpress.com
ccna5vn.blogspot.com
Cehv8:
cehv8vn.blogspot.com
Youtube Channel:
www.youtube.com/user/VuzBlog
ccna project on topic company infrastructure
Prince Gautam submitted a presentation on CCNA that introduces CCNA and networking. It defines CCNA, describes the importance of networking for communication and resource sharing. It also summarizes different types of networking including LAN, MAN, WAN and common networking devices like hubs, switches, routers. The presentation further explains concepts like subnetting, supernetting, routing protocols like RIP, EIGRP, OSPF and basic router configuration.
Chapter 16 : inter-vlan routing
1) Describe the three primary options for enabling inter-VLAN routing.
2) Configure legacy inter-VLAN routing.
3) Configure router-on-a-stick inter-VLAN routing.
4) Troubleshoot common inter-VLAN configuration issues.
5) Troubleshoot common IP addressing issues in an inter-VLAN-routed environment.
6) Configure inter-VLAN routing using Layer 3 switching.
7) Troubleshoot inter-VLAN routing in a Layer 3-switched environment.
Lan to lan vpn
LAN to LAN VPN also known as Site to Site VPN is the most basic and the most simplest of all the VPN’s used on CISCO devices. It helps in connecting networks in different geographical location.
network goal.pptx
nrnrnrnrnrnrnnskkdfdksfdskfldsfjdslkfjdslkfjdslkfjsdlfjsdlkfjdsklfjsdlfdjsfkldsfjdslkfjdslfdsjfkldsfjsdlfjsdlkfjdslfdskfjdslkfjdslfkdsjfldskfjdkkdkdkkdjeeytagdfdafghbfbdfdskfbdskfsddsjfhdksfhsdjkfhdskjfhdskfjhdsf
Cis81 ccna1v5-2-configuring networkoperatingsystem
The document provides an overview of configuring a network operating system using Cisco IOS. It discusses accessing Cisco IOS devices through the console port or remotely using Telnet or SSH. It describes the command line interface and command structure of Cisco IOS, including different modes like privileged EXEC mode, global configuration mode, and interface configuration mode. It also covers setting the hostname, limiting access, saving configurations, and verifying connectivity between devices on the network.
Copyright © 2016 VIT, All Rights Reserved. VIT and its log.docx
Copyright © 2016 VIT, All Rights Reserved. VIT and its logo are trademarks of Victorian Institute of Technolog 1
IT NE 2005
Pratical Assessment
Assignment 3
WEEK - 10
IT NE 2005 Assessments
Copyright © 2016 VIT, All Rights Reserved. VIT and its logo are trademarks of Victorian Institute of Technolog 2
Week 10 Assighment 3
Deadline: Check Moodle
Objective: Securing Company Network
Network Topology
Note: ISR G1 devices have Fast Ethernet interfaces instead of Gigabit Ethernet Interfaces.
IT NE 2005 Assessments
Copyright © 2016 VIT, All Rights Reserved. VIT and its logo are trademarks of Victorian Institute of Technolog 3
Addressing Table
Device Interface IP Address Subnet Mask Default Gateway Switch Port
R1-S0000 F0/0 209.165.200.225 255.255.255.248 N/A ASA G0/0
S0/0 (DCE) 10.1.1.1 255.255.255.252 N/A N/A
Loopback 1 172.20.1.1 255.255.255.0 N/A N/A
R2-S0000 S0/0 10.1.1.2 255.255.255.252 N/A N/A
S0/1 (DCE) 10.2.2.2 255.255.255.252 N/A N/A
R3-S0000 F0/1 172.16.3.1 255.255.255.0 N/A S3 G0/0
S0/0 10.2.2.1 255.255.255.252 N/A N/A
S1-S0000 VLAN 1 192.168.2.11 255.255.255.0 192.168.2.1 N/A
S2-S0000 VLAN 1 192.168.1.11 255.255.255.0 192.168.1.1 N/A
S3-S0000 VLAN 1 172.16.3.11 255.255.255.0 172.16.3.1 N/A
ASA VLAN 1 (G0/1) 192.168.1.1 255.255.255.0 N/A S2 G0/0
VLAN 2 (G0/0) 209.165.200.226 255.255.255.248 N/A R1 F0/0
VLAN 2 (G0/2) 192.168.2.1 255.255.255.0 N/A S1 G0/0
PC-A NIC 192.168.2.3 255.255.255.0 192.168.2.1 S1 G0/1
PC-B NIC 192.168.1.3 255.255.255.0 192.168.1.1 S2 G0/1
PC-C NIC 172.16.3.3 255.255.255.0 172.16.3.1 S3 G0/1
In this lab, you will perform the following tasks:
Part 2: Configure Basic Device Settings
Part 3: Configure Secure Router Administrative Access
• Configure encrypted passwords and a login banner.
• Configure the EXEC timeout value on console and VTY lines.
• Configure login failure rates and VTY login enhancements.
• Configure Secure Shell (SSH) access and disable Telnet.
IT NE 2005 Assessments
Copyright © 2016 VIT, All Rights Reserved. VIT and its logo are trademarks of Victorian Institute of Technolog 4
• Configure local authentication, authorization, and accounting (AAA) user authentication.
• Secure the router against login attacks, and secure the IOS image and the configuration file.
• Configure a router NTP server and router NTP clients.
• Configure router syslog reporting and a syslog server on a local host.
Part 4: Configure a Zone-Based Policy Firewall and Intrusion Prevention System
• Configure a Zone-Based Policy Firewall (ZPF) on an ISR using the CLI.
• Configure an intrusion prevention system (IPS) on an ISR using the CLI.
Part 5: Secure Network Switches
• Configure passwords and a login banner.
• Configure management VLAN access.
• Secure access ports.
• Protect against Spanning Tree Protocol (STP) attacks.
• Configure port security and disable unused ports.
Part 6: Config.
Chapter 03 - VLANs
Chapter 3: Objectives
---------------------------------------------------
Explain the purpose of VLANs in a switched network.
Analyze how a switch forwards frames based on VLAN configuration in a multi-switched environment.
Configure a switch port to be assigned to a VLAN based on requirements.
Configure a trunk port on a LAN switch.
Configure Dynamic Trunk Protocol (DTP).
Troubleshoot VLAN and trunk configurations in a switched network.
Configure security features to mitigate attacks in a VLAN-segmented environment.
Explain security best practices for a VLAN-segmented environment.
Yaser Rahmati | یاسر رحمتی
Rahmati Academy | آکادمی رحمتی
www.yaser-rahmati.ir
www.rahmati-academy.ir
CCNAv5 - S2: Chapter3 Vlans
CCNAv5
S2-Routing and Switching: VLANS
Download here:
ccna5vn.wordpress.com
ccna5vn.blogspot.com
Cehv8:
cehv8vn.blogspot.com
Youtube Channel:
www.youtube.com/user/VuzBlog
KPUCC-Rs instructor ppt_chapter3_final
This document discusses VLANs and their implementation in Cisco switches. It covers VLAN segmentation and types of VLANs, how switches use 802.1Q tagging to identify VLAN traffic on trunk links between switches, and best practices for VLAN security and design including mitigating VLAN hopping and double-tagging attacks. Configuration topics include creating VLANs, assigning ports, configuring trunks, and troubleshooting. The objectives are to explain VLAN purposes, switch forwarding based on VLANs, and configure and secure VLAN environments.
CCNA (R & S) Module 04 - Scaling Networks - Chapter 1
This document discusses designing and scaling campus wired LANs. It covers hierarchical network designs with access, distribution and core layers. Selecting the proper network devices is important, including switches with sufficient port density, forwarding rates and wire speeds. Switches and routers require configuration, management and troubleshooting using commands like show ip route, show interfaces and show mac-address-table. Designing networks with redundancy, smaller failure domains and link aggregation allows networks to scale effectively.
Similar to Exploration Lan Switching Chapter2 (20)
ccna summer training ppt ( Cisco certified network analysis) ppt. by Traun k...
ccna summer training ppt ( Cisco certified network analysis) ppt. by Traun k...
Cis81 ccna1v5-2-configuring networkoperatingsystem
Cis81 ccna1v5-2-configuring networkoperatingsystem
Copyright © 2016 VIT, All Rights Reserved. VIT and its log.docx
Copyright © 2016 VIT, All Rights Reserved. VIT and its log.docx
CCNA (R & S) Module 04 - Scaling Networks - Chapter 1
CCNA (R & S) Module 04 - Scaling Networks - Chapter 1
Recently uploaded
Your Skill Boost Masterclass: Strategies for Effective Upskilling
Your Skill Boost Masterclass: Strategies for Effective UpskillingExcellence Foundation for South Sudan
Strategies for Effective Upskilling is a presentation by Chinwendu Peace in a Your Skill Boost Masterclass organisation by the Excellence Foundation for South Sudan on 08th and 09th June 2024 from 1 PM to 3 PM on each day.clinical examination of hip joint (1).pdf
described clinical examination all orthopeadic conditions .
Advanced Java[Extra Concepts, Not Difficult].docx
This is part 2 of my Java Learning Journey. This contains Hashing, ArrayList, LinkedList, Date and Time Classes, Calendar Class and more.
Top five deadliest dog breeds in America
Thinking of getting a dog? Be aware that breeds like Pit Bulls, Rottweilers, and German Shepherds can be loyal and dangerous. Proper training and socialization are crucial to preventing aggressive behaviors. Ensure safety by understanding their needs and always supervising interactions. Stay safe, and enjoy your furry friends!
ANATOMY AND BIOMECHANICS OF HIP JOINT.pdf
it describes the bony anatomy including the femoral head , acetabulum, labrum . also discusses the capsule , ligaments . muscle that act on the hip joint and the range of motion are outlined. factors affecting hip joint stability and weight transmission through the joint are summarized.
CACJapan - GROUP Presentation 1- Wk 4.pdf
Macroeconomics- Movie Location
This will be used as part of your Personal Professional Portfolio once graded.
Objective:
Prepare a presentation or a paper using research, basic comparative analysis, data organization and application of economic information. You will make an informed assessment of an economic climate outside of the United States to accomplish an entertainment industry objective.
Natural birth techniques - Mrs.Akanksha Trivedi Rama University
Natural birth techniques - Mrs.Akanksha Trivedi Rama UniversityAkanksha trivedi rama nursing college kanpur.
Natural birth techniques are various type such as/ water birth , alexender method, hypnosis, bradley method, lamaze method etcDigital Artifact 1 - 10VCD Environments Unit
Digital Artifact 1 - 10VCD Environments Unit - NGV Pavilion Concept Design
How to Manage Your Lost Opportunities in Odoo 17 CRM
Odoo 17 CRM allows us to track why we lose sales opportunities with "Lost Reasons." This helps analyze our sales process and identify areas for improvement. Here's how to configure lost reasons in Odoo 17 CRM
How to Add Chatter in the odoo 17 ERP Module
In Odoo, the chatter is like a chat tool that helps you work together on records. You can leave notes and track things, making it easier to talk with your team and partners. Inside chatter, all communication history, activity, and changes will be displayed.
How to Build a Module in Odoo 17 Using the Scaffold Method
Odoo provides an option for creating a module by using a single line command. By using this command the user can make a whole structure of a module. It is very easy for a beginner to make a module. There is no need to make each file manually. This slide will show how to create a module using the scaffold method.
Pollock and Snow "DEIA in the Scholarly Landscape, Session One: Setting Expec...
Pollock and Snow "DEIA in the Scholarly Landscape, Session One: Setting Expec...National Information Standards Organization (NISO)
This presentation was provided by Steph Pollock of The American Psychological Association’s Journals Program, and Damita Snow, of The American Society of Civil Engineers (ASCE), for the initial session of NISO's 2024 Training Series "DEIA in the Scholarly Landscape." Session One: 'Setting Expectations: a DEIA Primer,' was held June 6, 2024.ISO/IEC 27001, ISO/IEC 42001, and GDPR: Best Practices for Implementation and...
Denis is a dynamic and results-driven Chief Information Officer (CIO) with a distinguished career spanning information systems analysis and technical project management. With a proven track record of spearheading the design and delivery of cutting-edge Information Management solutions, he has consistently elevated business operations, streamlined reporting functions, and maximized process efficiency.
Certified as an ISO/IEC 27001: Information Security Management Systems (ISMS) Lead Implementer, Data Protection Officer, and Cyber Risks Analyst, Denis brings a heightened focus on data security, privacy, and cyber resilience to every endeavor.
His expertise extends across a diverse spectrum of reporting, database, and web development applications, underpinned by an exceptional grasp of data storage and virtualization technologies. His proficiency in application testing, database administration, and data cleansing ensures seamless execution of complex projects.
What sets Denis apart is his comprehensive understanding of Business and Systems Analysis technologies, honed through involvement in all phases of the Software Development Lifecycle (SDLC). From meticulous requirements gathering to precise analysis, innovative design, rigorous development, thorough testing, and successful implementation, he has consistently delivered exceptional results.
Throughout his career, he has taken on multifaceted roles, from leading technical project management teams to owning solutions that drive operational excellence. His conscientious and proactive approach is unwavering, whether he is working independently or collaboratively within a team. His ability to connect with colleagues on a personal level underscores his commitment to fostering a harmonious and productive workplace environment.
Date: May 29, 2024
Tags: Information Security, ISO/IEC 27001, ISO/IEC 42001, Artificial Intelligence, GDPR
-------------------------------------------------------------------------------
Find out more about ISO training and certification services
Training: ISO/IEC 27001 Information Security Management System - EN | PECB
ISO/IEC 42001 Artificial Intelligence Management System - EN | PECB
General Data Protection Regulation (GDPR) - Training Courses - EN | PECB
Webinars: https://pecb.com/webinars
Article: https://pecb.com/article
-------------------------------------------------------------------------------
For more information about PECB:
Website: https://pecb.com/
LinkedIn: https://www.linkedin.com/company/pecb/
Facebook: https://www.facebook.com/PECBInternational/
Slideshare: http://www.slideshare.net/PECBCERTIFICATION
A Survey of Techniques for Maximizing LLM Performance.pptx
A Survey of Techniques for Maximizing LLM Performance
The History of Stoke Newington Street Names
Presented at the Stoke Newington Literary Festival on 9th June 2024
www.StokeNewingtonHistory.com
Azure Interview Questions and Answers PDF By ScholarHat
Azure Interview Questions and Answers PDF By ScholarHat
Recently uploaded (20)
Your Skill Boost Masterclass: Strategies for Effective Upskilling
Your Skill Boost Masterclass: Strategies for Effective Upskilling
Natural birth techniques - Mrs.Akanksha Trivedi Rama University
Natural birth techniques - Mrs.Akanksha Trivedi Rama University
How to Manage Your Lost Opportunities in Odoo 17 CRM
How to Manage Your Lost Opportunities in Odoo 17 CRM
How to Build a Module in Odoo 17 Using the Scaffold Method
How to Build a Module in Odoo 17 Using the Scaffold Method
Film vocab for eal 3 students: Australia the movie
Film vocab for eal 3 students: Australia the movie
Pollock and Snow "DEIA in the Scholarly Landscape, Session One: Setting Expec...
Pollock and Snow "DEIA in the Scholarly Landscape, Session One: Setting Expec...
ISO/IEC 27001, ISO/IEC 42001, and GDPR: Best Practices for Implementation and...
ISO/IEC 27001, ISO/IEC 42001, and GDPR: Best Practices for Implementation and...
A Survey of Techniques for Maximizing LLM Performance.pptx
A Survey of Techniques for Maximizing LLM Performance.pptx
Azure Interview Questions and Answers PDF By ScholarHat
Azure Interview Questions and Answers PDF By ScholarHat
Exploration Lan Switching Chapter2
- 1. Configure a Switch LAN Switching and Wireless – Chapter 2
