1. BUILDING RESPONSIVE APPLICATIONS
USING XPAGES
Feb. 16, 2016

2. Courtney Carter
@Teamstudio
Howard Greenberg
@TLCC
Paul Della-Nebbia
@PaulDN
Martin Donnelly
@TweeterDonnelly
Brian Gleeson
@BGleesonIE

3. Asking Questions
Use the “Questions” pane to ask questions.

4. Teamstudio provides products that help
organizations with customized business
applications implement best practices, work
more efficiently, and prepare for the future.
AboutTeamstudio

5. Develop and manage your Notes applications
faster, better, and more easily.

6. Reveal true business usage with Usage Auditor.
http://www.teamstudio.com/solutions/notestools/usage-auditor

7. BUILDING RESPONSIVE APPLICATIONS
USING XPAGES

8. 1
#XPages
Your Hosts Today:
Howard Greenberg
TLCC
@TLCCLtd
Building Responsive
Applications Using XPages
Paul Della-Nebbia
TLCC
@PaulDN

9. How can TLCC Help YOU!
2
• Private classes at
your location or
virtual
•XPages Development
•Support Existing Apps
•Administration
• Let us help you
become an expert
XPages developer!
• Delivered via Notes
• XPages
• Development
• Admin
• User
Self-
Paced
Courses
Mentoring
Instructor-
Led
Classes
Application
Development
and
Consulting
Free
Demo
Courses!

10. Upcoming and Recorded Webinars
3
www.tlcc.com/xpages-webinar
View Previous Webinars
(use url above)
• March – Optimus XPages : An Explosion of Techniques and Best
Practices with John Jardin
• April – Getting Started with the Domino API with Paul Withers and
Jesse Gallagher

11. Asking Questions – Q and A at the end
4
Use the Orange Arrow button to
expand the GoToWebinar panel
Then ask your questions in the
Questions pane!
We will answer your questions
verbally at the end of the
webinar

12. 5
#XPages
Brian Gleeson
IBM
@BGleesonIE
Building Responsive Applications Using
XPages
Martin Donnelly
IBM
@TweeterDonnelly

13. Building Responsive
XPages Applications
Brian Gleeson, IBM Ireland
Martin Donnelly, IBM Ireland

14. Please Note:
• IBM’s statements regarding its plans, directions, and intent are subject to change or withdrawal without notice at IBM’s
sole discretion.
• Information regarding potential future products is intended to outline our general product direction and it should not be
relied on in making a purchasing decision.
• The information mentioned regarding potential future products is not a commitment, promise, or legal obligation to deliver
any material, code or functionality. Information about potential future products may not be incorporated into any contract.
• The development, release, and timing of any future features or functionality described for our products remains at our sole
discretion.
• Performance is based on measurements and projections using standard IBM benchmarks in a controlled environment.
The actual throughput or performance that any user will experience will vary depending upon many factors, including
considerations such as the amount of multiprogramming in the user’s job stream, the I/O configuration, the storage
configuration, and the workload processed. Therefore, no assurance can be given that an individual user will achieve
results similar to those stated here.

15. Agenda
• Introductions
• Bootstrap 3
• Bootstrap 4
• Demos
• Tips & Tricks
• Wrap Up

16. Speakers
Brian Gleeson
Software Engineer, IBM XPages
@BGleesonIE
Martin Donnelly
Software Architect, IBM XPages
@TweeterDonnelly

17. Introduction
Frank Adams
XPages Developer
Greenwell
-------------------------
Blogger
Active on StackOverflow
ExtLib consumer

18. Responsive Web Design

19. Bootstrap 3

20. Bootstrap 3 Release History
Jun 2014 Oct Jan 2015 Mar Jun Aug Nov Feb 2016
3.2 3.3.0 3.3.2 3.3.4 3.3.5 3.3.6
v10 v12 v13 v14v11 v15
Bootstrap Release 9.0.1 ExtLib Release
v7 v9v8
3.2
ExtLib
9.0.1 v16
3.3.6
3.3.1

21. Bootstrap 3 Release History
3.2
3.3.0
[370]
3.3.1
[60]
3.3.2
[150]
3.3.4
[140]
3.3.5
[160]
3.3.6
[100]
3.2 3.3.6
Around 1000 issues & pull requests closed

22. Bootstrap 3 Upgrade
• 100s of CSS/Javascript bugs fixed & enhancements
• Carousel performance improved (v3.3.0)
• Accessibility enhancements
 CSS/JS fixes
 Documentation examples
• Glyphicons v1.9 update (v3.3.2)
 50+ icons added
• Normalize.css v3.0.3 update
 Provides consistency across browsers

23. Extlib 9.0.1 v16 + Bootstrap 3.3.6
WARNING!

24. Bootstrap 3 Upgrade
• Only one version of Bootstrap 3
 ExtLib v16 = Bootstrap 3.3.6
• Potential breaking changes
 Bootstrap3.2.0.theme, Bootstrap3.2.0_flat.theme
 Bootstrap3.theme, Bootstrap3_flat.theme
 Resources restructured

25. Bootstrap 3 Upgrade - Themes
• Old themes will map to latest Bootstrap3 theme
• Update application
theme in XSP properties
• Update Bootstrap theme extensions
<theme extends="Bootstrap3.2.0_flat" …
<theme extends="Bootstrap3_flat" …

26. DEMO – Bootstrap 3 Upgrade

27. Bootstrap 3 Upgrade – Resource references

28. Bootstrap 3 – More Info
• Documentation: http://getbootstrap.com/getting-started/
• Supported browsers: http://getbootstrap.com/getting-started/#support
• Wall of browser bugs: http://getbootstrap.com/browser-bugs/
• Purchasable themes: http://themes.getbootstrap.com/
• Stack Overflow: http://stackoverflow.com/questions/tagged/twitter-bootstrap
• Slack Channel: http://bootstrap-slack.herokuapp.com/
• Bootstrap github repo: https://github.com/twbs/bootstrap
• Bootstrap Blog: http://blog.getbootstrap.com/

29. Bootstrap 4

30. Bootstrap 4 αlpha
• Pre-release of Bootstrap V4.0.0
 2 αlpha releases so far
• Added to ExtlibX - http://tinyurl.com/extlibx
 Default Bootstrap 4 αlpha.2 build
 New renderers, theme and plugin
 CSS fixes for XPages controls
• Major version number = major overhaul
 Potential breaking changes

31. Frank is excited!
• Frank sees Bootstrap 4 blog posts
• Lots of new features
• Stay ahead of the curve
• Eager to try it out…

32. DEMO – Bootstrap 4

33. Bootstrap 4 αlpha
3.2 3.3.0 3.3.2 3.3.4 3.3.5 3.3.6
v10 v12 v13 v14v11 v15
Bootstrap 3 Release 9.0.1 ExtLib Release
v7 v9v8
3.2
3.3.1
ExtLib
9.0.1 v16
3.3.6
Jun 2014 Oct Jan 2015 Mar Jun Aug Nov Feb 2016
Bootstrap 4α Release ExtLibX Release
v15
4.α.2
4.α.1 4.α.2
v16
4.α.2

34. Bootstrap 4 Team Quotes
“A few alpha releases while things are still in flux.”
“2 beta releases after features and functionality are locked down
to really test things out.”
“2 release candidates (RCs) to really test things out closer to
production environments.”
“Then, the final release!”
“For the foreseeable future, we’ll be maintaining Bootstrap 3 with
critical bug fixes and documentation improvements.”

35. Bootstrap 4 αlpha
What’s new?
A LOT!
2000+ commits
25,000+ lines changed

36. Bootstrap 4 αlpha - Navbars
• Simplified set of CSS classes
• Fluid by default
• Easily customize background/text colour
.bg-inverse .navbar-dark
.bg-faded .navbar-light
style=“background:red;”
.bg-primary .navbar-dark
• Forms & collapse functionality cleaned up

37. DEMO – Navbars

38. Bootstrap 4 αlpha – Device Sizes
• Additional device size breakpoint
Bootstrap 3 Bootstrap 4
• xs: 0 – 543px
• sm: 544 – 767px
• md: 768 – 991px
• lg: 992 – 1199px
• xl: 1200+ pixels
• xs: 0 – 767px
• sm: 768 – 991px
• md: 992 – 1199px
• lg: 1200+ pixels

39. Bootstrap 4 αlpha - Cards
• New component = Cards
 Replaces panels, thumbnails & wells
• “A card is a flexible and extensible
content container.”
• Customisable headers, footers, backgrounds & display options
• Use card groups, card decks and card columns to arrange content

40. DEMO – eXpo App

41. Bootstrap 4 αlpha – Fonts & Icons
• Responsive Fonts
 Default font-size:
 All other font-size CSS uses REM (Root EM), e.g.
font-size: 1.5rem; // = 24px by default
 Change font sizes per device, e.g.
@media (min-width: 544px) {html { font-size: 14px; }} //sm
@media (min-width: 768px) {html { font-size: 12px; }} //md
@media (min-width: 992px) {html { font-size: 11px; }} //lg
@media (min-width: 1200px) {html { font-size: 10px; }} //xl
html { font-size: 16px; }

42. DEMO – Responsive Fonts

43. Bootstrap 4 αlpha – Fonts & Icons
• Glyphicon Fonts removed!
• Problematic for ExtLib
 Halflings are not open source
 Used extensively in XPages Bootstrap theme
• Bootstrap 3 to the rescue

44. Bootstrap 4 αlpha - Pagers
• New pagination CSS classes
Bootstrap 3
• Added simple pager
<div>
<ul class="pagination">
<li class="page-item active"><a class="page-link" href="#">1</a></li>
<li class="page-item"><a class="page-link" href="#">2</a></li>
</ul>
</div>
<div>
<ul class="pagination">
<li class=“active"> <a href="#">1</a></li>
<li><a href="#">2</a></li>
</ul>
</div>
<div>
<ul class="pager">
<li><a href="#">Previous</a></li>
<li><a href="#">Next</a></li>
</ul>
</div>
Bootstrap 4

45. • .btn-outline, .btn-secondary added
• pull-left, pull-right replaced by pull-*-right & pull-*-left
pull-xs-right, pull-sm-left, pull-md-right etc.
• hidden utility classes replaced
hidden-sm-down, hidden-md-up, hidden-lg-down
• margin & padding utility classes added
{margin or padding}-{sides}-{size}
m-t-0, m-b-1, m-l-2, m-r-3, m-x-4, m-y-auto
p-t-auto, p-b-4, p-l-3, p-r-2, p-x-1, p-y-0
Bootstrap 4 αlpha – Other changes

46. Bootstrap 4 αlpha – Other changes
• Table additions
 table-inverse
 table-head-inverse
 table-sm
 table-reflow
• img-responsive replaced by img-fluid
• Custom forms option available
 Based on WTF Forms
 http://wtfforms.com/
• 30% smaller footprint

47. ExtLibX

48. Bootstrap 4 αlpha – ExtlibX
• New Bootstrap4 plugin
com.ibm.xsp.extlibx.theme.bootstrap4_ 9.0.1.v00_16_20160119-2239.jar
• New Bootstrap4.theme

49. Bootstrap 4 αlpha – Implemented so far
• New Bootstrap plugin
 Plugin infrastructure + Bootstrap4.theme
 Bootstrap 4 αlpha.2 resources
 XPages specific CSS & JS resources
 Navbar Renderer
 2x Application Layout Renderers
 Pager Renderer
 Dashboard Renderer
 Navigator Renderer
 Data View Renderer
• What’s missing? https://github.com/OpenNTF/XPagesExtLibX/issues

50. Bootstrap 4 αlpha – ExtlibX
• How does Frank get it?
 Download release: http://tinyurl.com/extlibx
 Or from github: https://github.com/OpenNTF/XPagesExtLibX
 Install update site
 Or install new ExtLib v16

51. Bootstrap 4 αlpha – ExtlibX
• How can Frank contribute?
 Fork repository - https://github.com/OpenNTF/XPagesExtLibX
 Clone locally – git clone
 Write some code!
 Do some testing
 Submit pull request

52. DEMO – Frank’s Contribution

53. Overview of ExtLibX Integration
• Pull requests are merged into main ExtLibX repository
Community Repo
o
ExtLib
Repo
IBM XPages
Product
Stream
ExtLibX
Repo
Forks
Submissions
Bluewash
Community Repo
Frank’s
Repo

54. Frank’s Tips & Tricks

55. Frank’s Tips & Tricks
• Bootstrap Grid system
 Containers > Rows > Columns
 Container class: container-fluid or container
 12 columns per row
col-xs-12, col-sm-6, col-md-4, col-lg-3, col-xl-2
 Nested rows supported
 Offsets supported: col-md-offset-2, col-lg-offset-4 etc.

56. DEMO – Grid System

57. Frank’s Tips & Tricks
• Media Queries
@media screen and (min-width : 992px) { body{ background-color: blue;}}
@media screen and (min-width : 1200px){ body{ background-color: red;}}
@media screen and (max-width : 991px) { body{ background-color: green;}}
• xs: 0 – 543px
• sm: 544 – 767px
• md: 768 – 991px
• lg: 992 – 1199px
• xl: 1200+ pixels
• xs: 0 – 767px
• sm: 768 – 991px
• md: 992 – 1199px
• lg: 1200+ pixels
Bootstrap 3 Bootstrap 4

58. DEMO – Media Queries

59. Frank’s Tips & Tricks
• Bootlint
 Examines rendered HTML
 Flags common Bootstrap usage mistakes
 Only supports Bootstrap 3 (for now)
• How to use?
 Pass URL to http://www.bootlint.com/
 Include bootlint in page/app using CDN
https://github.com/twbs/bootlint#in-the-browser
 Use Node.js to run on command line
https://github.com/twbs/bootlint#on-the-command-line

60. DEMO – Bootlint

61. Frank’s Tips & Tricks
• Browser dev tools
 Firefox – Firebug + User Agent Switcher
 Chrome – Built-in Tooling
 Safari – Built-in Web Inspector & Responsive Design Mode
 Online emulators & emulator tools

62. Frank’s Tips & Tricks
• Custom Bootstrap build
 http://getbootstrap.com/customize/
 Customise content
 Customise settings/properties
 Click “compile and download”
• Git repo custom build
 Fork Bootstrap
 Change content/settings/variables
 Setup build tools
 Build using node & grunt

63. Wrap Up

64. Summary
• Bootstrap 3 Upgrade
 3.2 3.3.6
 Refactoring work + warning
• Bootstrap 4 αlpha
 Changes & new features
• ExtLibX incubator for Bootstrap 4
 Implemented support so far
 How to contribute (a.k.a. Be like Frank)
• Frank’s Tips

65. What has Frank learned?
• Bootstrap 3.3.6 Upgrade + refactoring work
Auto theme loading
May need some manual changes
• Bootstrap 4 αlpha Lots of new features/changes
Use ExtLibX incubator for Bootstrap 4
Make a contribution
• Frank’s Tips Grid System & Media Queries
Bootlint & Browser Tools
Custom Builds

66. Other Resources
• XPages Goes Responsive Videos
 Part 1: https://www.youtube.com/watch?v=XdWYmPLmIrk
 Part 2: https://www.youtube.com/watch?v=P24PsLXO5_o
• Check ExtLib readme docs, v10 – v15
 http://extlib.openntf.org
• ExtLibX Github Repository:
 https://github.com/OpenNTF/XPagesExtLibX
• TLCC – XPages Courses & Training
 http://www.tlcc.com
• IBM Social Business User Community
 http://www.ibm.com/socialug

68. Notices and Disclaimers
Copyright © 2015 by International Business Machines Corporation (IBM). No part of this document may be reproduced or transmitted in any form without
written permission from IBM.
U.S. Government Users Restricted Rights - Use, duplication or disclosure restricted by GSA ADP Schedule Contract with IBM.
Information in these presentations (including information relating to products that have not yet been announced by IBM) has been reviewed for accuracy as of
the date of initial publication and could include unintentional technical or typographical errors. IBM shall have no responsibility to update this information. THIS
DOCUMENT IS DISTRIBUTED "AS IS" WITHOUT ANY WARRANTY, EITHER EXPRESS OR IMPLIED. IN NO EVENT SHALL IBM BE LIABLE FOR ANY
DAMAGE ARISING FROM THE USE OF THIS INFORMATION, INCLUDING BUT NOT LIMITED TO, LOSS OF DATA, BUSINESS INTERRUPTION, LOSS OF
PROFIT OR LOSS OF OPPORTUNITY. IBM products and services are warranted according to the terms and conditions of the agreements under which they
are provided.
Any statements regarding IBM's future direction, intent or product plans are subject to change or withdrawal without notice.
Performance data contained herein was generally obtained in a controlled, isolated environments. Customer examples are presented as illustrations of how
those customers have used IBM products and the results they may have achieved. Actual performance, cost, savings or other results in other operating
environments may vary.
References in this document to IBM products, programs, or services does not imply that IBM intends to make such products, programs or services available in
all countries in which IBM operates or does business.
Workshops, sessions and associated materials may have been prepared by independent session speakers, and do not necessarily reflect the views of IBM. All
materials and discussions are provided for informational purposes only, and are neither intended to, nor shall constitute legal or other guidance or advice to any
individual participant or their specific situation.
It is the customer’s responsibility to insure its own compliance with legal requirements and to obtain advice of competent legal counsel as to the identification
and interpretation of any relevant laws and regulatory requirements that may affect the customer’s business and any actions the customer may need to take to
comply with such laws. IBM does not provide legal advice or represent or warrant that its services or products will ensure that the customer is in compliance
with any law

69. Notices and Disclaimers cont.
Information concerning non-IBM products was obtained from the suppliers of those products, their published announcements or other publicly available sources.
IBM has not tested those products in connection with this publication and cannot confirm the accuracy of performance, compatibility or any other claims related
to non-IBM products. Questions on the capabilities of non-IBM products should be addressed to the suppliers of those products. IBM does not warrant the
quality of any third-party products, or the ability of any such third-party products to interoperate with IBM’s products. IBM EXPRESSLY DISCLAIMS ALL
WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR
A PARTICULAR PURPOSE.
The provision of the information contained herein is not intended to, and does not, grant any right or license under any IBM patents, copyrights, trademarks or
other intellectual property right.
•IBM, the IBM logo, ibm.com, Aspera®, Bluemix, Blueworks Live, CICS, Clearcase, Cognos®, DOORS®, Emptoris®, Enterprise Document Management
System™, FASP®, FileNet®, Global Business Services ®, Global Technology Services ®, IBM ExperienceOne™, IBM SmartCloud®, IBM Social Business®,
Information on Demand, ILOG, Maximo®, MQIntegrator®, MQSeries®, Netcool®, OMEGAMON, OpenPower, PureAnalytics™, PureApplication®,
pureCluster™, PureCoverage®, PureData®, PureExperience®, PureFlex®, pureQuery®, pureScale®, PureSystems®, QRadar®, Rational®, Rhapsody®,
Smarter Commerce®, SoDA, SPSS, Sterling Commerce®, StoredIQ, Tealeaf®, Tivoli®, Trusteer®, Unica®, urban{code}®, Watson, WebSphere®, Worklight®,
X-Force® and System z® Z/OS, are trademarks of International Business Machines Corporation, registered in many jurisdictions worldwide. Other product and
service names might be trademarks of IBM or other companies. A current list of IBM trademarks is available on the Web at "Copyright and trademark
information" at: www.ibm.com/legal/copytrade.shtml.

70. Addendum Slides

71. Bootstrap 3 – New themes
• Purchase themes
 http://themes.getbootstrap.com/
 Added components
 Examples included
 Source & build tools included
 Customisable variables
 Documentation
 Free updates
 Multiple use license

72. Bootstrap 4 αlpha - Infrastructure
• Normalize 3.0.3 update
 Reboot.css adds Bootstrap resets
• All Javascript re-written in ECMAScript6
• SASS replaces LESS
• 30% smaller footprint

73. • Internet Explorer 8 support dropped
• iOS6 support dropped
Chrome Firefox IE MS Edge Opera Safari
Mac Supported Supported N/A N/A Supported Supported
Windows Supported Supported 9+ Supported Supported Supported Not supported
Chrome Firefox Opera Safari Android Browser & WebView
Android Supported Supported Not supported N/A Android v5.0+ supported
iOS Supported N/A Not supported Supported N/A
Mobile devices
Generally Bootstrap supports the latest versions of each major platform’s default browsers.
Desktop browsers
Similarly, the latest versions of most desktop browsers are supported.
Bootstrap 4 αlpha – Browser Support

74. DEMO – XGallery

75. Your Feedback Is Important!
Fill out session surveys at:
https://www.connectsurveys.com
or through IBM Event Connect.

76. Questions????
6
Use the Orange Arrow button to
expand the GoToWebinar panel
Then ask your questions in the
Questions panel!
Remember, we will answer your
questions verbally

77. #XPages
@BGleesonIE
@TweeterDonnelly
@TLCCLtd
@Teamstudio
@PaulDN
Upcoming Events:
 UCS.UG, Hamburg, Germany – March 10
 Inform 2016 in Sydney, Australia – March 10 to 11
 Engage, Eindhoven, the Netherlands – Mar. 23 to 24
 EntwicklerCamp, Gelsenkirchen, Germany – April 11 to 13
 MWLUG, Austin, TX – August 17 to 19
Question and Answer Time!
7
Teamstudio Questions?
contactus@teamstudio.com
978-712-0924
TLCC Questions?
howardg@tlcc.com paul@tlcc.com
888-241-8522 or 561-953-0095
Howard Greenberg
Courtney CarterMartin Donnelly
Paul Della-Nebbia
Brian Gleeson
