The document summarizes a presentation about optimizing Apache Spark performance when working with data sources like ElasticSearch. It discusses techniques like partition pruning, predicate pushdowns, and joining partitioned datasets to push filters deep into data sources for faster query execution. It also covers Spark's data source API and how to create custom data sources that support these optimization techniques.

1. Power of data. Simplicity of design. Speed of innovation.
IBM Spark
spark.tc
Spark Data Sources API + Spark-ElasticSearch Connector
+ Spark-ElasticSearch In Action
Advanced Apache Spark Meetup
Thanks Rackspace (Space) and Loggly (Food)!!
Feb 15, 2016
Chris Fregly
Principal Data Engineer @ IBM Spark Tech Center
advancedspark.com!
+
Costin Leau
Engineer, Elastic
Urvish Mahida
Data Platform Engineer, Loggly

2. Power of data. Simplicity of design. Speed of innovation.
IBM Spark
spark.tc
spark.tc
Power of data. Simplicity of design. Speed of innovation.
IBM Spark
Who Am I?
2
Streaming Data Engineer
Open Source Committer
Data Solutions Engineer
Apache Contributor
Principal Data Solutions Engineer
IBM Technology Center
Founder
Advanced Apache Meetup
Author
Advanced .
Due 2016

3. Power of data. Simplicity of design. Speed of innovation.
IBM Spark
spark.tc
spark.tc
Power of data. Simplicity of design. Speed of innovation.
IBM Spark
Where Am I?
3
Summit East 2016
New York City
Spark-NYC
(Co-presenting with Databricks)

4. Power of data. Simplicity of design. Speed of innovation.
IBM Spark
spark.tc
spark.tc
Power of data. Simplicity of design. Speed of innovation.
IBM Spark
Advanced Apache Spark Meetup
http://advancedspark.com
Meetup Metrics
Top 5 Most-active Spark Meetup!
~2600 Members in just 6 mos!!
~2600 Docker image downloads
Meetup Mission
Deep-dive into Spark and related open source projects
Surface key patterns and idioms
Focus on distributed systems, scale, and performance
4

5. Power of data. Simplicity of design. Speed of innovation.
IBM Spark
spark.tc
spark.tc
Power of data. Simplicity of design. Speed of innovation.
IBM Spark
Presentation Outline
① Partitions, Pruning, Pushdowns
② Spark Data Sources API
③ DataFrames and DataSets
④ Spark and ElasticSearch In Action
5

6. Power of data. Simplicity of design. Speed of innovation.
IBM Spark
spark.tc
spark.tc
Power of data. Simplicity of design. Speed of innovation.
IBM Spark
Partitions
Partition Based on Data Access Patterns
/genders.parquet/gender=M/…
/gender=F/… <-- Use Case: Access Users by Gender
/gender=U/…
Dynamic Partition Creation (Write)
Dynamically create partitions on write based on column (ie. Gender)
SQL: INSERT TABLE genders PARTITION (gender) SELECT …
DF: gendersDF.write.format("parquet").partitionBy("gender")
.save("/genders.parquet")
Partition Discovery (Read)
Dynamically infer partitions on read based on paths (ie. /gender=F/…)
SQL: SELECT id FROM genders WHERE gender=F
DF: gendersDF.read.format("parquet").load("/genders.parquet/").select($"id").
.where("gender=F")
6

7. Power of data. Simplicity of design. Speed of innovation.
IBM Spark
spark.tc
spark.tc
Power of data. Simplicity of design. Speed of innovation.
IBM Spark
Pruning
Partition Pruning
Filter out rows by partition
SELECT id, gender FROM genders WHERE gender = ‘F’
Column Pruning
Filter out columns by column filter
Extremely useful for columnar storage formats (ie. Parquet)
Skip entire blocks of columns
SELECT id, gender FROM genders
7

8. Power of data. Simplicity of design. Speed of innovation.
IBM Spark
spark.tc
spark.tc
Power of data. Simplicity of design. Speed of innovation.
IBM Spark
Pushdowns
aka. Predicate or Filter Pushdowns
Predicate returns true or false for given function
Filters rows deep into the data source
Reduces number of rows returned
Data Source must implement PrunedFilteredScan
def buildScan(requiredColumns: Array[String],
filters: Array[Filter]): RDD[Row]
8

9. Power of data. Simplicity of design. Speed of innovation.
IBM Spark
spark.tc
spark.tc
Power of data. Simplicity of design. Speed of innovation.
IBM Spark
Filter Collapse and Pushdown
9
Filter Collapse
Filter is Not
Pushed Down
(JSON)
Filter is
Pushed Down
(Parquet)

10. Power of data. Simplicity of design. Speed of innovation.
IBM Spark
spark.tc
spark.tc
Power of data. Simplicity of design. Speed of innovation.
IBM Spark
Join Between Partitioned & Unpartitioned
10
Note: JSON supports partitioning,
We’re not using it here.

11. Power of data. Simplicity of design. Speed of innovation.
IBM Spark
spark.tc
spark.tc
Power of data. Simplicity of design. Speed of innovation.
IBM Spark
Join Between Partitioned & Partitioned
11

12. Power of data. Simplicity of design. Speed of innovation.
IBM Spark
spark.tc
spark.tc
Power of data. Simplicity of design. Speed of innovation.
IBM Spark
Cartesian Join vs. Inner Join
12

13. Power of data. Simplicity of design. Speed of innovation.
IBM Spark
spark.tc
spark.tc
Power of data. Simplicity of design. Speed of innovation.
IBM Spark
Broadcast Join vs. Normal Shuffle Join
13

14. Power of data. Simplicity of design. Speed of innovation.
IBM Spark
spark.tc
spark.tc
Power of data. Simplicity of design. Speed of innovation.
IBM Spark
Visualizing the Query Plan
14
Effectiveness
of Filter
Cost-based
Join Optimization
Similar to
MapReduce
Map-side Join
& DistributedCache
Peak Memory for
Joins and Aggs
UnsafeFixedWidthAggregationMap
getPeakMemoryUsedBytes()

15. Power of data. Simplicity of design. Speed of innovation.
IBM Spark
spark.tc
spark.tc
Power of data. Simplicity of design. Speed of innovation.
IBM Spark
Presentation Outline
① Partitions, Pruning, Pushdowns
② Spark Data Sources API
③ DataFrames and DataSets
④ Spark and ElasticSearch In Action
15

16. Power of data. Simplicity of design. Speed of innovation.
IBM Spark
spark.tc
spark.tc
Power of data. Simplicity of design. Speed of innovation.
IBM Spark
Spark Data Sources API
Relations (o.a.s.sql.sources.interfaces.scala)
BaseRelation (abstract class): Provides schema of data
TableScan (impl): Read all data from source
PrunedFilteredScan (impl): Column pruning & predicate pushdowns
InsertableRelation (impl): Insert/overwrite data based on SaveMode
RelationProvider (trait/interface): Handle options, BaseRelation factory
Filters (o.a.s.sql.sources.filters.scala)
Filter (abstract class): Handles all filters supported by this source
EqualTo (impl)
GreaterThan (impl)
StringStartsWith (impl)
16

17. Power of data. Simplicity of design. Speed of innovation.
IBM Spark
spark.tc
spark.tc
Power of data. Simplicity of design. Speed of innovation.
IBM Spark
Native Spark SQL Data Sources
17

18. Power of data. Simplicity of design. Speed of innovation.
IBM Spark
spark.tc
spark.tc
Power of data. Simplicity of design. Speed of innovation.
IBM Spark
JSON Data Source
DataFrame
val ratingsDF = sqlContext.read.format("json")
.load("file:/root/pipeline/datasets/dating/ratings.json.bz2")
-- or –
val ratingsDF = sqlContext.read.json
("file:/root/pipeline/datasets/dating/ratings.json.bz2")
SQL Code
CREATE TABLE genders USING json
OPTIONS
(path "file:/root/pipeline/datasets/dating/genders.json.bz2")
18
json() convenience method

19. Power of data. Simplicity of design. Speed of innovation.
IBM Spark
spark.tc
spark.tc
Power of data. Simplicity of design. Speed of innovation.
IBM Spark
Parquet Data Source
Configuration
spark.sql.parquet.filterPushdown=true
spark.sql.parquet.mergeSchema=false (unless your schema is evolving)
spark.sql.parquet.cacheMetadata=true (requires sqlContext.refreshTable())
spark.sql.parquet.compression.codec=[uncompressed,snappy,gzip,lzo]
DataFrames
val gendersDF = sqlContext.read.format("parquet")
.load("file:/root/pipeline/datasets/dating/genders.parquet")
gendersDF.write.format("parquet").partitionBy("gender")
.save("file:/root/pipeline/datasets/dating/genders.parquet")
SQL
CREATE TABLE genders USING parquet
OPTIONS
(path "file:/root/pipeline/datasets/dating/genders.parquet")
19

20. Power of data. Simplicity of design. Speed of innovation.
IBM Spark
spark.tc
spark.tc
Power of data. Simplicity of design. Speed of innovation.
IBM Spark
ElasticSearch Data Source
Github
https://github.com/elastic/elasticsearch-hadoop
Maven
org.elasticsearch:elasticsearch-spark_2.10:2.2.0
Code
val esConfig = Map("pushdown" -> "true", "es.nodes" -> "<hostname>",
"es.port" -> "<port>")
df.write.format("org.elasticsearch.spark.sql”).mode(SaveMode.Overwrite)
.options(esConfig).save("<index>/<document-type>")
20

21. Power of data. Simplicity of design. Speed of innovation.
IBM Spark
spark.tc
spark.tc
Power of data. Simplicity of design. Speed of innovation.
IBM Spark
Creating a Custom Data Source
① Study existing implementations
o.a.s.sql.execution.datasources.jdbc.JDBCRelation
② Extend base traits & implement required methods
o.a.s.sql.sources.{BaseRelation,PrunedFilterScan}
Examples
Spark JDBC (o.a.s.sql.execution.datasources.jdbc)
class JDBCRelation extends BaseRelation
with PrunedFilteredScan, InsertableRelation
DataStax Cassandra (o.a.s.sql.cassandra)
class CassandraSourceRelation extends BaseRelation
with PrunedFilteredScan, InsertableRelation!
21

22. Power of data. Simplicity of design. Speed of innovation.
IBM Spark
spark.tc
Power of data. Simplicity of design. Speed of innovation.
IBM Spark
spark.tc
Demo!
Create a Simple Integer Data Source
Predicate (Filter) Pushdowns
https://github.com/fluxcapacitor/pipeline/blob/master/myapps/sql/src/main/scala/
com/advancedspark/sql/source/IntegerDataSource.scala
22

23. Power of data. Simplicity of design. Speed of innovation.
IBM Spark
spark.tc
spark.tc
Power of data. Simplicity of design. Speed of innovation.
IBM Spark
Presentation Outline
① Partitions, Pruning, Pushdowns
② Spark Data Sources API
③ DataFrames and DataSets
④ Spark and ElasticSearch In Action
23

24. Power of data. Simplicity of design. Speed of innovation.
IBM Spark
spark.tc
spark.tc
Power of data. Simplicity of design. Speed of innovation.
IBM Spark
DataFrames and DataSets
DataFrames
Lost compile-time typing from RDD’s
Favored untyped o.a.s.sql.Row
Code could break at runtime
DataSets
Re-introduce compile-time types
Requires Custom Encoders/Serializers
Tip: Use Kryo Serializer for custom Encoder
Check out mapGroups() and flatMapGroups() methods
Operate on grouped data
24

25. Power of data. Simplicity of design. Speed of innovation.
IBM Spark
spark.tc
spark.tc
Power of data. Simplicity of design. Speed of innovation.
IBM Spark
Presentation Outline
① Partitions, Pruning, Pushdowns
② Spark Data Sources API
③ DataFrames and DataSets
④ Spark and ElasticSearch In Action
25

26. Power of data. Simplicity of design. Speed of innovation.
IBM Spark
spark.tc
spark.tc
Power of data. Simplicity of design. Speed of innovation.
IBM Spark
advancedspark.com (github and docker)
End User ->
ElasticSearch ->
Spark ML ->
Data Scientist ->
26
<- Kafka
<- Spark
Streaming
<- Cassandra,
Redis
<- Zeppelin,
iPython

27. Power of data. Simplicity of design. Speed of innovation.
IBM Spark
spark.tc
spark.tc
Power of data. Simplicity of design. Speed of innovation.
IBM Spark
Thank You!!!
Chris Fregly
IBM Spark Tech Center
(http://spark.tc)
San Francisco, California, USA
advancedspark.com
Sign up for the Meetup and Book
Clone, Contribute, Commit on Github
Run All Demos using Docker Image
2600 Docker Downloads!!
Find me on LinkedIn, Twitter, Github, Email, Fax
27
Image derived from http://www.duchess-france.org/

28. Power of data. Simplicity of design. Speed of innovation.
IBM Spark
spark.tc
spark.tc
Power of data. Simplicity of design. Speed of innovation.
IBM Spark
Up Next…
Costin Leau
Developer @ Elastic
(45 mins – 1 hour w/ Q & A)
Urvish Mahida
Data Platform Dev @ Loggly
(30 – 45 mins w/ Q & A)
28
