GPS satellites are positioned at an altitude of 20,200 km above the Earth's surface, which falls within medium Earth orbits. This height provides global coverage with a smaller number of satellites and allows earth-based transmitters and receivers to use modest sized antennas and lower transmission powers.
Gross tonnage refers to the total enclosed volume of a ship, while net tonnage refers to the cargo-carrying capacity. Both are determined by measuring volumes and applying formulas, and are dimensionless numbers rather than units of mass.
Radar performance can be ascertained using a performance monitor. 10 cm or S-band radar is generally better for long range scanning and in heavy rain due to less clutter.
