Naval arch fuel consumptn
•Download as PPT, PDF•
2 likes•1,497 views
The document discusses the relationships between a ship's speed, displacement, distance traveled, and fuel consumption. It states that daily fuel consumption varies as the cube of ship speed, as the 2/3 power of displacement, and as the square of speed multiplied by distance for a voyage. Examples are provided to demonstrate calculating new fuel consumption with changes in speed, displacement or distance. Specific fuel consumption is also defined as the fuel used per kilowatt hour of power.
Report
Share
Report
Share
![AKD;Rev0;Feb02 SP-SMA 2
SPEED ANDSPEED AND
FUEL CONSUMPTIONFUEL CONSUMPTION
Recommended
The Cylinder Liner of Diesel Engines
The cylinder liner forms the cylindrical space in the engine where the piston reciprocates. It is manufactured separately from the cylinder block using an alloy that has better wear resistance at high temperatures. This allows for replacement of just the liner if it wears. The liner is cooled, often with tangential bore cooling, to maintain an optimal temperature for lubrication and reducing thermal stresses. Proper lubrication and minimizing abrasive particles are important to reduce liner wear over the life of the engine.
Stern Tube and Shafting Arrangements
The stern tube is a hollow tube running through the bottom of a ship that contains the propeller shaft. It connects the main engine to the propeller and supports the large weight of the propeller. Stern tubes are designed to keep water from leaking into the ship while allowing the propeller shaft to rotate freely. They contain bearings lubricated with oil or water to reduce friction and prevent leakage between the stern tube and propeller shaft. Modern systems aim to improve lubrication and reduce contamination of lubricants with water for more efficient propulsion.
Ship Motion and Stresses
Static forces on a ship include internal forces from structural weight and cargo and external static forces from hydrostatic pressure. Dynamic forces result from ship motion at sea, wind and waves, and operating machinery. A ship has six degrees of freedom of motion: rolling, surging, pitching, swaying, heaving, and yawing. Ship motion introduces dynamic forces that cause stresses on the ship's structure. Methods to reduce rolling include bilge keels, passive tanks, controlled passive tanks, active tanks, and fin stabilizers.
Lect 9 ship propellers (new)
1. Ship propellers work by sucking in water and accelerating it out in a slipstream, using the change in momentum to generate thrust.
2. Screw propellers have key parts like the blade, hub, tip circle, and define characteristics like pitch. Pitch is the theoretical distance traveled per revolution.
3. Propellers can be fixed pitch or variable pitch (controllable), with the latter allowing control of thrust without changing engine power.
NAVAL ARCHITECTURE- GEOMETRY OF SHIP
This document provides an overview of topics related to ship geometry and hydrostatic calculations. It will cover ship lines, displacement calculations, stability concepts, buoyancy principles, and coefficients used in ship design like block coefficient and waterplane area coefficient. Methods for calculating areas, volumes, and centroids like Simpson's rules and trapezoidal rule will be explained. Key terms involved in floatation and stability like center of gravity, center of buoyancy, and reserve buoyancy will also be introduced.
Indicators
An engine indicator is used to record indicator diagrams from engines, which represent the work done per cycle. There are two types of indicators: mechanical indicators record diagrams on paper up to 150 rpm, while pressure indicators measure only maximum combustion pressures without limit. An indicator consists of a small cylinder connected to the engine that records pressure variations during the cycle as diagrams. Different types of diagrams like power, compression and light spring can detect various engine faults.
Marine Fresh Water Generators
Fresh water generators produce fresh water for domestic and auxiliary use aboard ships by distilling or desalinating sea water. They are essential aboard ships where fresh water consumption can be over 30 tonnes per day. There are two main methods - distillation and reverse osmosis. Distillation involves boiling sea water under vacuum to evaporate it, then condensing the vapor to produce fresh water. Reverse osmosis uses semipermeable membranes to filter out salt and other ions. Fresh water generators recover waste heat from sources like the main engine to economically produce fresh water as needed.
101103077-Tanker-Pipeline-Systems.ppt
The document discusses different types of tanker pipeline systems used to load and discharge cargo tanks, including direct line, ring main, and free flow systems. A direct line system is relatively fast and cheaper but less versatile, while a ring main system is more versatile but more expensive and difficult to maintain. A free flow system provides the fastest loading and discharge but poorer segregation between cargo grades. Safety valves are used to prevent undue pressure rises in vessels.
Recommended
The Cylinder Liner of Diesel Engines
The cylinder liner forms the cylindrical space in the engine where the piston reciprocates. It is manufactured separately from the cylinder block using an alloy that has better wear resistance at high temperatures. This allows for replacement of just the liner if it wears. The liner is cooled, often with tangential bore cooling, to maintain an optimal temperature for lubrication and reducing thermal stresses. Proper lubrication and minimizing abrasive particles are important to reduce liner wear over the life of the engine.
Stern Tube and Shafting Arrangements
The stern tube is a hollow tube running through the bottom of a ship that contains the propeller shaft. It connects the main engine to the propeller and supports the large weight of the propeller. Stern tubes are designed to keep water from leaking into the ship while allowing the propeller shaft to rotate freely. They contain bearings lubricated with oil or water to reduce friction and prevent leakage between the stern tube and propeller shaft. Modern systems aim to improve lubrication and reduce contamination of lubricants with water for more efficient propulsion.
Ship Motion and Stresses
Static forces on a ship include internal forces from structural weight and cargo and external static forces from hydrostatic pressure. Dynamic forces result from ship motion at sea, wind and waves, and operating machinery. A ship has six degrees of freedom of motion: rolling, surging, pitching, swaying, heaving, and yawing. Ship motion introduces dynamic forces that cause stresses on the ship's structure. Methods to reduce rolling include bilge keels, passive tanks, controlled passive tanks, active tanks, and fin stabilizers.
Lect 9 ship propellers (new)
1. Ship propellers work by sucking in water and accelerating it out in a slipstream, using the change in momentum to generate thrust.
2. Screw propellers have key parts like the blade, hub, tip circle, and define characteristics like pitch. Pitch is the theoretical distance traveled per revolution.
3. Propellers can be fixed pitch or variable pitch (controllable), with the latter allowing control of thrust without changing engine power.
NAVAL ARCHITECTURE- GEOMETRY OF SHIP
This document provides an overview of topics related to ship geometry and hydrostatic calculations. It will cover ship lines, displacement calculations, stability concepts, buoyancy principles, and coefficients used in ship design like block coefficient and waterplane area coefficient. Methods for calculating areas, volumes, and centroids like Simpson's rules and trapezoidal rule will be explained. Key terms involved in floatation and stability like center of gravity, center of buoyancy, and reserve buoyancy will also be introduced.
Indicators
An engine indicator is used to record indicator diagrams from engines, which represent the work done per cycle. There are two types of indicators: mechanical indicators record diagrams on paper up to 150 rpm, while pressure indicators measure only maximum combustion pressures without limit. An indicator consists of a small cylinder connected to the engine that records pressure variations during the cycle as diagrams. Different types of diagrams like power, compression and light spring can detect various engine faults.
Marine Fresh Water Generators
Fresh water generators produce fresh water for domestic and auxiliary use aboard ships by distilling or desalinating sea water. They are essential aboard ships where fresh water consumption can be over 30 tonnes per day. There are two main methods - distillation and reverse osmosis. Distillation involves boiling sea water under vacuum to evaporate it, then condensing the vapor to produce fresh water. Reverse osmosis uses semipermeable membranes to filter out salt and other ions. Fresh water generators recover waste heat from sources like the main engine to economically produce fresh water as needed.
101103077-Tanker-Pipeline-Systems.ppt
The document discusses different types of tanker pipeline systems used to load and discharge cargo tanks, including direct line, ring main, and free flow systems. A direct line system is relatively fast and cheaper but less versatile, while a ring main system is more versatile but more expensive and difficult to maintain. A free flow system provides the fastest loading and discharge but poorer segregation between cargo grades. Safety valves are used to prevent undue pressure rises in vessels.
Ship Construction by Jayan Pillai
1. The document provides information on ship construction, including definitions of key ship design terminology and descriptions of basic ship types and designs.
2. It discusses the three main stages of initial ship design - concept, preliminary, and contract design. Key ship dimensions and specifications that are determined at each stage are outlined.
3. Ship types covered include liquid cargo ships, dry cargo ships, passenger ships, offshore vessels, fishing vessels, and naval vessels. The evolution of cargo ship designs over time is summarized.
Shell and deck plating
The shell plating forms the watertight skin of the ship and contributes to its longitudinal strength and resistance to vertical shear forces. It consists of curved and flat steel plates butt welded together. Stiffening members are welded to the shell plating. Bottom and side shell plating is thickest amidships, where bending stresses are highest, and tapers toward the ends. The sheer strake along the main deck has greater thickness than other side shell strakes. Bilge keels help dampen rolling motion without adding drag. Weather decks are cambered to drain water, while internal decks may be horizontal. Deck plating thickness is also greatest amidships.
Ship Construction (Structure Part)
The keel forms the backbone of the ship and contributes to longitudinal strength. Common keel types include the flat plate keel and bar keel. The hull uses frames, plate floors, and a keel plate to strengthen the structure. A double bottom creates extra strength and space for piping and tanks. Machinery is mounted on reinforced seats with the engine connected to brackets and lugs. The stern frame supports the rudder and propeller shaft. Additional structures like panting beams further reinforce the hull.
Ship Rudder
This document discusses ship rudders, including:
- Rudders are fitted at the aft end of ships to provide directional control and derive benefit from increased water velocity from the propeller.
- There are three main types of rudders - balanced, unbalanced, and semi-balanced. Balanced rudders have a portion of blade area forward of the stock to reduce torque on the steering gear.
- Size, shape, and type of rudder is governed by the ship's stern shape, required rudder area, steering gear capacity, and service conditions.
- Special rudders like spade rudders, Flettner/Becker rudders, Borg
Purifier and carifier
THE PURIFIER: Is correct size gravity disc or dam ring which is responsible for creating an interface between the oil and water.
THE CLARAFIER: Is clarifiers are settling tanks built with mechanical means for continuous removal of solids being deposited by sedimentation.
Propeller and Rudder
This document discusses ship propulsion systems. It begins by defining key terms related to propeller horsepower, including:
- Brake Horsepower (BHP): Power output at the engine shaft before reduction gears.
- Shaft Horsepower (SHP): Power output after the reduction gears.
- Delivered Horsepower (DHP): Power delivered to the propeller.
- Thrust Horsepower (THP): Power created by the screw/propeller after losses.
It then discusses propeller types, key parts like the hub and blades, and terminology such as diameter, pitch, revolutions per minute, and whether a propeller is right-handed or left-handed. The
Marine Incinerator
This document provides information about shipboard incinerators. It defines an incinerator as machinery used to burn various wastes generated on ships, such as oily rags and galley waste. It describes typical incinerator features like refractory lining and automatic controls. It provides details on normal incinerator operation procedures, the types of wastes that can be incinerated according to IMO regulations, and emission standards for type approval testing. The document also outlines safety requirements for incinerator design, operation, controls, and fire protection in waste storage spaces.
Ship survey presentation
The document discusses the various types of surveys conducted by Nippon Kaiji Kyokai (ClassNK), a ship classification society, including annual surveys, intermediate surveys, special surveys, and docking surveys. The purpose of the different surveys is to inspect the hull, machinery, equipment and overall condition of ships to confirm they meet classification standards and safety requirements. The document provides details on the scope and requirements of each type of survey.
Ship Rudders
Rudders are used in ships to achieve a change in direction from the current path. This ppt is gives details of the types of rudders used
Ship terms
This document defines various ship terms and their meanings. It provides definitions for over 100 common ship terms beginning with letters A through C, including terms like abaft, access holes, accommodation ladder, aft, after, angle clip, anode, aperture, assemble, athwartship, and auxiliaries. Each term is defined concisely, with some terms having short example sentences or diagrams to further illustrate the meaning.
Hull form geometry
This document provides an introduction to ship hull geometry and lines plans. It discusses how a ship's complicated 3D hull shape is represented graphically through a lines drawing using projections onto three orthogonal planes called the body plan, half-breadth plan, and sheer/profile plan. It also defines key hull geometry terms like length between perpendiculars, shear, deadrise, and form coefficients that describe hull dimensions and shape characteristics. The document emphasizes that understanding basic hull geometry and terminology is important groundwork for further naval architecture studies.
Preliminary ship-design
This document provides guidelines for preliminary ship design parameter estimation. It discusses selecting main parameters like length, breadth, depth and draft based on owner requirements and stability constraints. Empirical formulas are presented for estimating parameters like displacement, dimensions, form coefficients, block coefficients, and initial stability values. Statistical data analysis and extrapolating from similar ship designs can also help in the first estimates. The relationships between parameters and their influence on ship performance aspects are outlined.
Aircraft design project 2
This document summarizes a student aircraft design project to design a cargo plane. The objectives are to design a cargo plane to carry 600,000 kg over 4,000 km with a cruise speed of 850 km/h. The preliminary design was completed and included collecting comparative data, selecting parameters, estimating weights, selecting engines and airfoils, and creating a wing layout. Structural analysis was performed on the wing and fuselage.
Procedure for Inspection Pistons and Cylinder Liners
This cylinder liner and piston condition monitoring procedure holds guidelines for inspections, and trouble shooting. It has been prepared in order to give engineers with limited experience a better understanding of what they are observing and how they should interpret what they observe.
Many of the examples may be considered superfluous by experienced engineers, nevertheless, every piece of information is useful for everyone.
This guideline provides technical, safety and health instructions for safely conducting “Inspection through Scavenge Ports” tasks being conducted onboard. This guideline does not and can not cover every possible unique condition, hazard or situation that may arise during subject tasks. This site specific, product specific hazards and situations must be addressed by senior engineers using the appropriate principles and considerations.
Marine Steering Gear and SOLAS Requirements
Marine Steering Gear and SOLAS Requirements by Mohd. Hanif Dewan, Chief Engineer and Maritime Lecturer & Trainer, Bangladesh.
Ship Loads and stresses
The ship at sea or lying in still water is constantly being subjected to a wide variety of stresses and strains, which result from the action of forces from outside and within the ship.
Incinerator and MARPOL Requirements
The document discusses the MARPOL regulations governing shipboard incinerators. MARPOL Annex VI regulates incinerator emissions. Incinerators installed after 2000 must be certified to meet the specifications in MEPC Resolution 76(40), have an operations manual, and be operated by trained crew according to the manual. The regulations prohibit burning certain waste and require minimum flue gas temperatures. Incinerators are used to dispose of waste oil, garbage, and sewage, and the document describes standard incinerator features and operating procedures.
Hull form geometry
This chapter introduces key concepts in hull geometry needed for naval architecture. It discusses how a ship's complicated 3D hull shape is represented graphically through lines drawings, including body, half-breadth, and sheer plans. The chapter also covers how lines plans are converted into numerical tables of offsets and defines important hull geometry terms like length between perpendiculars, block and prismatic coefficients, and rise of floor. Mastering the representation and terminology of hull geometry forms a crucial foundation for further naval architecture studies.
Tank Atmosphere - Tanker Vessels
This document discusses cargo tank atmospheres on oil and chemical tankers. It notes that cargo tanks are enclosed spaces that can accumulate dangerous gases if not properly ventilated. The main hazards associated with tank atmospheres are fires and health issues caused by oxygen depletion, toxic gases, or flammable vapors. Inert gas systems are used to control tank atmospheres and remove oxygen, preventing fires. Key operations like loading, discharging, and tank cleaning require maintaining a safe inert atmosphere through controlled introduction of inert gas to dilute tank contents. Atmosphere monitoring equipment is used to check oxygen, hydrocarbon, and toxic gas levels during operations.
ship design and construction.pdf
The document provides information about ship design and construction. It defines common ship terms like hull, superstructure, machinery, stern, bow, amidships, beam, deck, engine room, propeller shaft, bulbous bow, hold. It describes the roles of the naval architect, navigating officer and marine engineer in ship design. It explains the two main parts of a ship are the hull and machinery. It provides details about locations on a ship like stern, bow, amidships and common directional terms. It also describes ship types and general arrangements depending on intended cargo and trade.
PERFORMANCE STANDARDS FOR AUTOPILOT
1. The document outlines 23 performance standards that autopilot and heading control systems installed on ships must meet according to the International Maritime Organization (IMO).
2. The standards require systems to reliably maintain a preset heading under various operating conditions, incorporate controls to adjust for weather and steering performance, and allow for easy and safe operation.
3. Systems must also ensure the ship's heading can only be altered intentionally by crew, integrate properly with navigation systems, and include alarms and indications for failures or off-heading situations.
Want To Pursue A Career In Naval Architecture?
Take your first step at International Maritime Academy, a leading maritime institute that offers marine education in Chennai, including naval architecture & ship building courses.
More Related Content
What's hot
Ship Construction by Jayan Pillai
1. The document provides information on ship construction, including definitions of key ship design terminology and descriptions of basic ship types and designs.
2. It discusses the three main stages of initial ship design - concept, preliminary, and contract design. Key ship dimensions and specifications that are determined at each stage are outlined.
3. Ship types covered include liquid cargo ships, dry cargo ships, passenger ships, offshore vessels, fishing vessels, and naval vessels. The evolution of cargo ship designs over time is summarized.
Shell and deck plating
The shell plating forms the watertight skin of the ship and contributes to its longitudinal strength and resistance to vertical shear forces. It consists of curved and flat steel plates butt welded together. Stiffening members are welded to the shell plating. Bottom and side shell plating is thickest amidships, where bending stresses are highest, and tapers toward the ends. The sheer strake along the main deck has greater thickness than other side shell strakes. Bilge keels help dampen rolling motion without adding drag. Weather decks are cambered to drain water, while internal decks may be horizontal. Deck plating thickness is also greatest amidships.
Ship Construction (Structure Part)
The keel forms the backbone of the ship and contributes to longitudinal strength. Common keel types include the flat plate keel and bar keel. The hull uses frames, plate floors, and a keel plate to strengthen the structure. A double bottom creates extra strength and space for piping and tanks. Machinery is mounted on reinforced seats with the engine connected to brackets and lugs. The stern frame supports the rudder and propeller shaft. Additional structures like panting beams further reinforce the hull.
Ship Rudder
This document discusses ship rudders, including:
- Rudders are fitted at the aft end of ships to provide directional control and derive benefit from increased water velocity from the propeller.
- There are three main types of rudders - balanced, unbalanced, and semi-balanced. Balanced rudders have a portion of blade area forward of the stock to reduce torque on the steering gear.
- Size, shape, and type of rudder is governed by the ship's stern shape, required rudder area, steering gear capacity, and service conditions.
- Special rudders like spade rudders, Flettner/Becker rudders, Borg
Purifier and carifier
THE PURIFIER: Is correct size gravity disc or dam ring which is responsible for creating an interface between the oil and water.
THE CLARAFIER: Is clarifiers are settling tanks built with mechanical means for continuous removal of solids being deposited by sedimentation.
Propeller and Rudder
This document discusses ship propulsion systems. It begins by defining key terms related to propeller horsepower, including:
- Brake Horsepower (BHP): Power output at the engine shaft before reduction gears.
- Shaft Horsepower (SHP): Power output after the reduction gears.
- Delivered Horsepower (DHP): Power delivered to the propeller.
- Thrust Horsepower (THP): Power created by the screw/propeller after losses.
It then discusses propeller types, key parts like the hub and blades, and terminology such as diameter, pitch, revolutions per minute, and whether a propeller is right-handed or left-handed. The
Marine Incinerator
This document provides information about shipboard incinerators. It defines an incinerator as machinery used to burn various wastes generated on ships, such as oily rags and galley waste. It describes typical incinerator features like refractory lining and automatic controls. It provides details on normal incinerator operation procedures, the types of wastes that can be incinerated according to IMO regulations, and emission standards for type approval testing. The document also outlines safety requirements for incinerator design, operation, controls, and fire protection in waste storage spaces.
Ship survey presentation
The document discusses the various types of surveys conducted by Nippon Kaiji Kyokai (ClassNK), a ship classification society, including annual surveys, intermediate surveys, special surveys, and docking surveys. The purpose of the different surveys is to inspect the hull, machinery, equipment and overall condition of ships to confirm they meet classification standards and safety requirements. The document provides details on the scope and requirements of each type of survey.
Ship Rudders
Rudders are used in ships to achieve a change in direction from the current path. This ppt is gives details of the types of rudders used
Ship terms
This document defines various ship terms and their meanings. It provides definitions for over 100 common ship terms beginning with letters A through C, including terms like abaft, access holes, accommodation ladder, aft, after, angle clip, anode, aperture, assemble, athwartship, and auxiliaries. Each term is defined concisely, with some terms having short example sentences or diagrams to further illustrate the meaning.
Hull form geometry
This document provides an introduction to ship hull geometry and lines plans. It discusses how a ship's complicated 3D hull shape is represented graphically through a lines drawing using projections onto three orthogonal planes called the body plan, half-breadth plan, and sheer/profile plan. It also defines key hull geometry terms like length between perpendiculars, shear, deadrise, and form coefficients that describe hull dimensions and shape characteristics. The document emphasizes that understanding basic hull geometry and terminology is important groundwork for further naval architecture studies.
Preliminary ship-design
This document provides guidelines for preliminary ship design parameter estimation. It discusses selecting main parameters like length, breadth, depth and draft based on owner requirements and stability constraints. Empirical formulas are presented for estimating parameters like displacement, dimensions, form coefficients, block coefficients, and initial stability values. Statistical data analysis and extrapolating from similar ship designs can also help in the first estimates. The relationships between parameters and their influence on ship performance aspects are outlined.
Aircraft design project 2
This document summarizes a student aircraft design project to design a cargo plane. The objectives are to design a cargo plane to carry 600,000 kg over 4,000 km with a cruise speed of 850 km/h. The preliminary design was completed and included collecting comparative data, selecting parameters, estimating weights, selecting engines and airfoils, and creating a wing layout. Structural analysis was performed on the wing and fuselage.
Procedure for Inspection Pistons and Cylinder Liners
This cylinder liner and piston condition monitoring procedure holds guidelines for inspections, and trouble shooting. It has been prepared in order to give engineers with limited experience a better understanding of what they are observing and how they should interpret what they observe.
Many of the examples may be considered superfluous by experienced engineers, nevertheless, every piece of information is useful for everyone.
This guideline provides technical, safety and health instructions for safely conducting “Inspection through Scavenge Ports” tasks being conducted onboard. This guideline does not and can not cover every possible unique condition, hazard or situation that may arise during subject tasks. This site specific, product specific hazards and situations must be addressed by senior engineers using the appropriate principles and considerations.
Marine Steering Gear and SOLAS Requirements
Marine Steering Gear and SOLAS Requirements by Mohd. Hanif Dewan, Chief Engineer and Maritime Lecturer & Trainer, Bangladesh.
Ship Loads and stresses
The ship at sea or lying in still water is constantly being subjected to a wide variety of stresses and strains, which result from the action of forces from outside and within the ship.
Incinerator and MARPOL Requirements
The document discusses the MARPOL regulations governing shipboard incinerators. MARPOL Annex VI regulates incinerator emissions. Incinerators installed after 2000 must be certified to meet the specifications in MEPC Resolution 76(40), have an operations manual, and be operated by trained crew according to the manual. The regulations prohibit burning certain waste and require minimum flue gas temperatures. Incinerators are used to dispose of waste oil, garbage, and sewage, and the document describes standard incinerator features and operating procedures.
Hull form geometry
This chapter introduces key concepts in hull geometry needed for naval architecture. It discusses how a ship's complicated 3D hull shape is represented graphically through lines drawings, including body, half-breadth, and sheer plans. The chapter also covers how lines plans are converted into numerical tables of offsets and defines important hull geometry terms like length between perpendiculars, block and prismatic coefficients, and rise of floor. Mastering the representation and terminology of hull geometry forms a crucial foundation for further naval architecture studies.
Tank Atmosphere - Tanker Vessels
This document discusses cargo tank atmospheres on oil and chemical tankers. It notes that cargo tanks are enclosed spaces that can accumulate dangerous gases if not properly ventilated. The main hazards associated with tank atmospheres are fires and health issues caused by oxygen depletion, toxic gases, or flammable vapors. Inert gas systems are used to control tank atmospheres and remove oxygen, preventing fires. Key operations like loading, discharging, and tank cleaning require maintaining a safe inert atmosphere through controlled introduction of inert gas to dilute tank contents. Atmosphere monitoring equipment is used to check oxygen, hydrocarbon, and toxic gas levels during operations.
ship design and construction.pdf
The document provides information about ship design and construction. It defines common ship terms like hull, superstructure, machinery, stern, bow, amidships, beam, deck, engine room, propeller shaft, bulbous bow, hold. It describes the roles of the naval architect, navigating officer and marine engineer in ship design. It explains the two main parts of a ship are the hull and machinery. It provides details about locations on a ship like stern, bow, amidships and common directional terms. It also describes ship types and general arrangements depending on intended cargo and trade.
What's hot (20)
Procedure for Inspection Pistons and Cylinder Liners
Procedure for Inspection Pistons and Cylinder Liners
Viewers also liked
PERFORMANCE STANDARDS FOR AUTOPILOT
1. The document outlines 23 performance standards that autopilot and heading control systems installed on ships must meet according to the International Maritime Organization (IMO).
2. The standards require systems to reliably maintain a preset heading under various operating conditions, incorporate controls to adjust for weather and steering performance, and allow for easy and safe operation.
3. Systems must also ensure the ship's heading can only be altered intentionally by crew, integrate properly with navigation systems, and include alarms and indications for failures or off-heading situations.
Want To Pursue A Career In Naval Architecture?
Take your first step at International Maritime Academy, a leading maritime institute that offers marine education in Chennai, including naval architecture & ship building courses.
1 introduction to shipping and marine engineering
The document discusses the functions of merchant ships and their role in international trade. It notes that merchant ships were important for transport in the 19th century and different types of cargo ships later developed for specific goods like oil, timber, and cement. Shipping remains the cheapest form of transport for large cargo quantities and is critical for international trade, nation building, and domestic trade in island countries. Various factors influence world trade, including economic resources, market conditions, political frameworks, technological development, and financial situations between countries.
Marine engineering i
This document discusses marine vehicles and their applications and limitations. It begins by introducing how transportation needs have evolved with globalization. It then explains that marine transportation differs from land transportation due to the influence of the sea on politics, economy, culture, and security. Finally, it outlines three main applications of marine vehicles: 1) as links in transportation systems, considering factors like payload, speed, and costs, 2) as mobile naval bases designed around military requirements, and 3) as special purpose vehicles for tasks like research, salvage, dredging, and ferries.
Ship Construction - Rudder Theory
This document summarizes key aspects of rudder theory and design. It discusses how rudders generate force through pressure differences on each side, and how this force has both lift and drag components. It describes different types of rudders based on the position of the center of effort relative to the axis of rotation, including balanced, semi-balanced, and unbalanced rudders. It also discusses rudder construction materials, pintle bearings, and considerations for rudder stock sizing based on the type of rudder.
Software in Naval Architecture and Marine Engineering
This presentation shows the different software that benefit the field of Naval Architecture, Ship Design, Ship Operation and Offshore Engineering
Viewers also liked (6)
Software in Naval Architecture and Marine Engineering
Software in Naval Architecture and Marine Engineering
Similar to Naval arch fuel consumptn
Gate question on rolling contact bearing
1) Ball bearings are rated by manufacturers for a certain life (e.g. 10^6 revolutions) at a given load (e.g. 16KN). The life of a bearing operating at a lower load (e.g. 2KN) can be calculated using the load life formula.
2) Of the bearing types listed (DGBB, ACBB, CRB, SRB), only CRB (cylindrical roller bearing) should not be subjected to thrust (axial) loads.
3) For ball bearings, the relationship between radial load F, fatigue life L (in revolutions), and a constant K is given by the load life formula FL^1/
Air Pollution Prevention - An Introduction
MARPOL Annex-VI
Ship emissions
NOx treatment
Sulphur Cap
ODS
VOCs
Fuel quality measures
Energy Efficiency requirements
IRJET- Study on Different Estimation Methods of Propulsion Power for 60 Mts O...
This document studies different methods to estimate the propulsion power required for a 60-meter offshore supply vessel, including resistance calculation using Guldhammer & Harvald, Holtrop, and Oortmerssen methods. It analyzes the vessel's hull geometry and calculates parameters like resistance, effective power, and total resistance at ship speeds of 10-19 knots using each method. The results are compared to determine the most accurate way to obtain hull resistance and powering requirements for propelling the vessel.
H2P_Energy_Final_Presentation_ENCH_531
The document summarizes a proposed project to build a steam methane reforming plant in Alberta capable of producing 50,000 Nm3 of hydrogen per hour. It details the plant's design requirements, including feedstock needs, operating costs, and economic analysis. The plant would produce hydrogen primarily through steam methane reforming of natural gas, and the document evaluates this process as well as alternatives like dry reforming of methane. It ultimately recommends constructing one to four similar hydrogen production plants in Alberta.
Thermo 5th chap01_p085
The equivalent wind chill temperatures in °F are plotted as a function of wind velocity in the range of 4-100 mph for ambient temperatures of 20, 40, and 60°F using EES. The plots show that equivalent temperature decreases with increasing wind velocity and decreases with decreasing ambient temperature. Wind chill has a greater effect at lower ambient temperatures.
Thermo 5th chap01p085
1. A hydraulic lift uses a piston with a diameter of 210 cm to lift a weight of 2500 kg by applying a force of 25 kg to a smaller piston.
2. The pressure and diameter calculations show that the larger piston needs a diameter of 100 cm to lift the 2500 kg weight.
3. Pascal's principle and pressure calculations allow large weights to be lifted with little effort using hydraulic lifts.
Boiler design-calculation 3
This document discusses the thermal design of a simple boiler. It presents the calculation procedures for boiler design, focusing on heat transfer modes, heat and mass balances, and a worked example. The key points are:
- Heat transfer in boilers occurs via conduction, convection, and radiation. Conduction is not considered in simple calculations.
- Heat and mass balance equations relate the heat input from fuel to the heat output via steam as well as accounting for air and flue gas flows.
- A worked example calculates furnace conditions like flue gas temperature for a methane-fueled boiler, assuming radiation is the only heat transfer mode in the furnace. Tube bank calculations then determine the exit gas
NAME 338 ( Ship Design Project and Presentation )
This document summarizes a design project for a 100 TEU container ship. It includes calculations for stability and trim, resistance and power, engine selection, rudder design, propeller and shaft design, and scantling. Principal particulars of the ship include a length of 74m, breadth of 13m, draught of 3m, and capacity of 100 twenty-foot equivalent units. Calculations show the ship will have a speed of 11 knots powered by a 900kW engine.
Flywheel.pptx
The document discusses flywheels and their use in engines. It provides information on:
- How flywheels store energy from the power stroke of engines and release it to maintain uniform rotation during other strokes when no energy is produced.
- Flywheels do not maintain a constant speed but reduce fluctuations by absorbing and releasing energy as the engine's torque varies each cycle.
- The coefficient of fluctuation of speed and energy are defined to quantify the speed and energy variations a flywheel controls.
- Equations are provided to calculate the mass of flywheel needed based on the engine's output, mean speed, and required limits of speed and energy fluctuations.
Mg 360 deg assessment
This document summarizes Mukes Gupta's presentation on floating liquefied natural gas (FLNG) and compressed natural gas (CNG) transport. It discusses how FLNG and CNG can transport gas from offshore fields by avoiding the need for undersea pipelines. CNG transport involves compressing gas into ships at high pressure, while FLNG involves liquefying gas into ships. CNG has a lower capital cost but can only transport smaller volumes, while FLNG has a higher cost but can transport larger volumes over long distances. The document compares the costs and applications of LNG, CNG, and gas-to-liquids (GTL) technologies for transporting offshore natural gas to markets.
1590701599PTE_526-Natural_Gas_Engineering (1).pptx
This course is all about Natural gas engineering from the Federal University of Technology owerri, it has concise explanations about the different topics in it
Thermo problem set no. 2
This document contains a 16 question multiple choice mechanical engineering review problem set. It covers topics including: specific weight calculations, changes in weight due to elevation, pressure and force calculations for scuba diving, determining height using barometer readings, properties of gas mixtures, heat transfer between materials, gas turbine processes, combustion calculations, and thermodynamic processes including changes in temperature, pressure, volume, entropy and heat/work.
UNIT-2_Part3_RANKINE CYCLE.pdf
This document describes the Rankine cycle, which is commonly used in steam power plants. It consists of four processes:
1. Constant pressure heat addition in a boiler, heating water to steam.
2. Adiabatic expansion of the steam in a turbine, producing work.
3. Constant pressure heat rejection in a condenser, condensing the steam to water.
4. Adiabatic compression of the water in a pump, returning it to the boiler pressure.
The efficiency of the Rankine cycle depends on the temperature difference between the steam entering and leaving the turbine. Examples are provided to illustrate efficiency calculations for Rankine cycles operating between different pressure and temperature conditions.
Presentation-for-teachers.pptx
Uneven heating of the Earth's surface and its rotation cause global wind patterns and local wind variations. As air rises and falls on the planet, pressure differences drive global wind circulation. Additional localized patterns arise from terrain and other surface factors. Wind speed generally increases with height until turbulence decreases it again near the tropopause. The density of air decreases with increases in altitude and temperature. This document discusses how to calculate the power available in wind and energy production from wind resources using power curves and wind speed data. Key factors in the economics of wind energy projects are the levelized cost of energy and the capacity factor.
Watertaxi 2-2nd Project Presentation-BUET
This document summarizes the design of a water taxi for 95 passengers in Bangladesh. The objectives are to take advantage of Dhaka's circular waterways and ease waterway transportation. Topics covered include the principal particulars, general arrangement, scantling calculations to determine hull dimensions according to ISSA rules, deadweight calculations accounting for passengers and supplies, lightweight calculations, stability and trim calculations to meet IMO regulations. Scantling, deadweight, lightweight, and stability calculations are shown as examples. The design displacement is 117.51 tons with a trim of 0.06 meters forward and 0.05 meters aft.
1. atr42 uso de hoja de carga mecanizada
The document provides instructions for completing a load sheet for an ATR42 aircraft with the following flight details:
- Flight number: SWT7025
- Origin: VLC
- Destination: MAD
- Aircraft registration: EC-JBX
- Ramp fuel: 1700 kg
- Taxi fuel: 50 kg
- Trip fuel: 650 kg
It includes sections to input payload weight distribution across holds and signatures for the loader, load planner, and accepting captain.
Shortsea Norvest 2010 Sea Cargo Ole Saevild
The document discusses Sea-Cargo, an operator of cargo vessels between Norway and the UK. It outlines Sea-Cargo's business structure and operations, as well as some of the structural challenges facing maritime transport, such as land-based infrastructure costs and pilotage fees. It also discusses Sea-Cargo's focus on environmental transport and innovation, including its work on developing liquefied natural gas as an alternative fuel for ships.
sreenath project.ppsx
This document outlines the design of a lag bullet tanker to transport 500 tons of ammonia per day from Udyogamandal Complex to Cochin division. The key requirements are for an inland self-propelled barge carrying liquefied ammonia in 6 insulated bullet tanks. Dimensional restrictions due to bridges require a length of 58m, width of 9.538m, and draft of 1.5m. Estimations determine a displacement of 449.7 tons, requiring a power of 275KW. Stability calculations show adequate GM and GZ curves. Ballast and capacity checks also meet requirements.
Ch.17
1) Sound is a small pressure wave that travels through a medium and requires a medium, unlike light which can travel through a vacuum.
2) The speed of sound in a medium depends on the properties of that medium and changes as those properties change, such as temperature.
3) The speed of sound is highest in gases with a high kR value, such as helium, and increases with increasing temperature in all gases.
Knowledge Management: Estimate Oil API Using logs before Testing or Sampling
This document presents a novel approach to directly estimate API oil gravity from standard wireline logs using a density log vs. N cross plot. Traditionally, density, neutron, and sonic logs are used to determine porosity and lithology. Ratios M, N, and P can also be computed from these logs. The presented method observes clustering of points on a cross plot of density log vs. N that correlate to different API gravities of produced oil. The study calibrated this method using production and sample data from wells across various basins. Results show this cross plot method can reliably estimate API gravity of between 15-40 directly from logs before formation testing.
Similar to Naval arch fuel consumptn (20)
IRJET- Study on Different Estimation Methods of Propulsion Power for 60 Mts O...
IRJET- Study on Different Estimation Methods of Propulsion Power for 60 Mts O...
1590701599PTE_526-Natural_Gas_Engineering (1).pptx
1590701599PTE_526-Natural_Gas_Engineering (1).pptx
Knowledge Management: Estimate Oil API Using logs before Testing or Sampling
Knowledge Management: Estimate Oil API Using logs before Testing or Sampling
More from Dheeraj Kaushal
69116612 imo-ps-s-vdr
1. The purpose of a simplified voyage data recorder (S-VDR) is to securely store information about a vessel's position, movement, status, and command in the event of an incident for use in subsequent investigations.
2. Ships defined in SOLAS Chapter V must be fitted with an S-VDR that continuously records preselected data items relating to ship status, equipment output, and command/control. The data must be time-correlated and stored in a tamper-proof capsule for at least 2 years.
3. An S-VDR must record data items including date, time, position, speed, heading, bridge audio, communications audio, radar data, and AIS data
69116166 iamsar
The document provides information on the International Aeronautical and Maritime Search and Rescue (IAMSAR) Manual. It discusses that IAMSAR is a joint publication of ICAO and IMO that assists states in meeting SAR needs and obligations under international conventions. It has three volumes that deal with specific SAR system duties and can be used independently or together. The document then provides definitions and explanations of key terms related to SAR operations, structures, and coordination.
68902251 imo-ps-roti
This document outlines the International Maritime Organization's (IMO) performance standards for rate of turn indicators (ROTI) installed on ships. The ROTI must be capable of indicating port and starboard turns, have a means to verify operation, and use a center-zero analog dial indicator with positive indications for port and starboard turns. The scale must allow measurement of turns between -30 and 30 degrees per minute and meet accuracy standards for deviations from the actual turn rate under various ship motions and speeds.
68899162 imo-ps-gps
The document outlines 17 performance standards that GPS receiver equipment installed on ships must meet in order to be compliant. The standards require the equipment to:
1) Be capable of receiving and processing GPS signals to provide position, latitude and longitude, in the WGS-84 coordinate system and UTC time within specified accuracies and update rates.
2) Have static and dynamic position accuracy of 100m or less depending on whether differential GPS corrections are applied.
3) Generate and output position, course, speed, and time data at least once per second and interface with other navigation equipment.
4) Provide warnings if performance standards for position dilution or update rates are not met.
68898351 imo-performance-standards-for-echo-sounder
This document outlines the performance standards for echo-sounding equipment set by the International Maritime Organization (IMO). The equipment is intended to provide reliable depth readings between 2-200 meters to aid navigation, especially in shallow waters. It must have at least two depth ranges (20m and 200m scales), record soundings for 15 minutes, and be able to record depth and time for 12 hours. The display must show depth marks no more than 1/10 the range and time marks at most every 5 minutes. Alarms are required for shallow water and any failure affecting safe operation.
Naval arch incline test
This document discusses an inclining test performed on a ship to determine its metacentric height (GM). It provides details of the test, including five shifts of weights totaling 216 tonnes that caused deflections of the ship ranging from 12 to 110 mm. It also shows the calculations to determine that the ship's GM as inclined is 1.68 m. Precautions for an accurate inclining test are noted, such as having a calm environment, securing loose weights, and restricting crew movement during the test.
Ibs
An integrated bridge system (IBS) combines systems like the integrated navigation system (INS) to allow centralized monitoring and control of operations from the bridge like navigation, machinery control, safety, and security. An IBS provides benefits like enhanced decision making and workload reduction. Key components of an IBS include the navigation management system, alarm system, and conning display. Passage planning, position fixing, and track keeping can be automated if principles are followed, but overreliance on automation without watchkeeping can be dangerous. An IBS interconnects INS and other systems, while INS specifically combines navigational data and systems.
Autopilot
The document discusses autopilot systems and steering gear controls on ships. It provides details on:
- How autopilots work to automatically steer the ship and reduce workload in heavy weather by learning a ship's handling characteristics.
- The different control modes and settings used on autopilot control units, including proportional, integral, derivative controls and weather compensation settings.
- Limitations of autopilot use in rough conditions, tight spaces, slow speeds, or during maneuvers.
- Procedures for changing between manual and autopilot steering, testing equipment, and emergency steering protocols.
91121543 roti
This document discusses Rate of Turn Indicator (ROTI), which is required on vessels over 50,000 GT per SOLAS regulations. ROTI assists the officer on watch in planning, executing, and monitoring a vessel's progress along a curved segment of its charted course. It provides the rate of turn to port and starboard in degrees per minute. The document derives the formula for ROT as the change in angle over time divided by the radius of the turn. It provides examples of using ROTI for constant radius and constant rate turns, and discusses wheel over points and planning turns.
91121543 roti (1)
1) ROTI (Rate of Turn Indicator) is an instrument that assists ship officers in planning, executing, and monitoring a vessel's progress along curved segments of its charted course. It indicates the rate of turn (in degrees per minute) to port or starboard.
2) For large vessels, turns must be executed along curved paths rather than sharp corners due to momentum and water friction. ROTI helps determine the radius and rate of turn needed based on factors like vessel size and speed.
3) There are two main turn types - constant radius, where the radius remains fixed and rate of turn varies, and constant rate, where the rate of turn remains fixed and the radius varies. The document provides
ORALS
GPS satellites are positioned at an altitude of 20,200 km above the Earth's surface, which falls within medium Earth orbits. This height provides global coverage with a smaller number of satellites and allows earth-based transmitters and receivers to use modest sized antennas and lower transmission powers.
Gross tonnage refers to the total enclosed volume of a ship, while net tonnage refers to the cargo-carrying capacity. Both are determined by measuring volumes and applying formulas, and are dimensionless numbers rather than units of mass.
Radar performance can be ascertained using a performance monitor. 10 cm or S-band radar is generally better for long range scanning and in heavy rain due to less clutter.
80920328 vdr
VDR is a marine recording device that functions like an aircraft's black box, recording critical ship data and communications to help investigators determine the cause of accidents. A VDR continuously records data from navigational equipment, alarms, and communications for at least 12 hours. This data is stored in a protective capsule that can withstand fire and deep water immersion. Accessing and analyzing VDR data after an incident allows for faster, more accurate investigations that help improve safety. VDR recordings have also assisted ship owners in assessing bridge team performance and identifying areas for improvement.
80918797 gyro-numericals-solved
The document contains several numerical problems related to marine gyrocompasses. It provides solutions to problems involving calculating the tilt and direction of a gyroscope's spin axis (SA) given its initial position and the latitude, passage of time, or a later observed position. One question calculates the percentage change in the moment of inertia (MOI) of a gyroscope rotor if its mass increases by 20% and radius of gyration decreases by 20%.
78998058 chk-lists
This document contains checklists for various emergency situations that may occur on ships, such as general emergencies, abandoning ship, search and rescue, rescuing crew from a disabled vessel, flooding, fire, stranding or grounding, collision, main engine failure, steering failure, rudder failure, and checklists for navigation in coastal and ocean waters. The checklists provide step-by-step instructions for crew to follow to ensure passenger and crew safety, assess damage, send distress signals, and follow proper emergency procedures in a variety of emergency situations at sea.
78239585 orals-met
1. Atmospheric pressure is the pressure exerted by the weight of the earth's atmosphere. It is measured in hectopascals (hPa), with 1 hPa equal to 1 millibar.
2. Pressure gradient refers to the rate of change of pressure over distance and indicates how strongly winds will blow between areas of high and low pressure.
3. Dew point temperature is the temperature at which air becomes saturated with water vapor and fog can form. It is an important measurement for mariners to consider when deciding whether to ventilate cargo holds.
78238898 imo-ps-bnwas
1. The document outlines International Maritime Organization performance standards for Bridge Navigational Watch Alarm Systems (BNWAS).
2. BNWAS monitors bridge activity and detects if the Officer of the Watch becomes incapacitated, alerting others. It has automatic, manual on, and manual off operational modes.
3. The system remains dormant for 3-12 minutes before initiating visual alerts. If not reset, it issues audible alarms to the bridge and then remotely to summon help. Resetting cancels alerts and restarts the dormant period.
75347365 em-log
1. An electromagnetic (EM) log works by inducing an electromotive force in sea water moving through the Earth's magnetic field using a solenoid, with the induced voltage proportional to water velocity.
2. The solenoid is housed in a streamlined flow sensor that extends below the ship's hull. Electrodes on either side of the sensor measure the voltage induced in the strip of sea water moving across the magnetic field.
3. This voltage corresponds to ship speed and is amplified and used to drive indicators showing speed in the wheelhouse. The EM log thus non-intrusively measures ship speed through water.
75346996 a-is
AIS aims to automatically identify vessels using electronic communication without human intervention. It works by having each vessel broadcast its identification and position using a transponder. Vessels are assigned time slots to transmit this data to avoid interference on the shared VHF channel. The time slots are precisely synchronized using GPS time signals. This allows many vessels to broadcast on the same frequency without interfering with each other. Vessels can then receive the identification and position of all other vessels within range, aiding navigation safety.
74784234 gyro-compass
1) A marine gyrocompass uses a freely-spinning gyroscope to determine direction based on the principles of angular momentum and the earth's constant rotation.
2) A gyroscope has three degrees of freedom - it can spin about its axis and tilt or turn in horizontal and vertical planes. The earth acts like a giant free gyroscope due to its mass, high-speed rotation, and lack of friction in space.
3) The gyroscope's angular momentum and inertia cause it to resist changes to its axis of spin, allowing it to maintain a fixed direction in space independent of the ship's movements. This gyroscopic property is used to determine true north.
74009510 imo-ps-ecdis-rpnm
1. The document outlines performance standards for route planning, monitoring, and voyage recording functions of Electronic Chart Display and Information Systems (ECDIS).
2. It describes that ECDIS should allow for simple and reliable route planning including straight and curved segments as well as adjustments to planned routes. It should monitor the ship's position along the selected route and provide alarms if deviations occur.
3. For voyage recording, ECDIS should store minimum navigation elements from the past 12 hours including ship track, time, position and headings as well as the ENC database information used for reconstruction and verification purposes. It should also record the complete voyage track with time marks not exceeding 4 hours.
More from Dheeraj Kaushal (20)
68898351 imo-performance-standards-for-echo-sounder
68898351 imo-performance-standards-for-echo-sounder
Recently uploaded
Mending Clothing to Support Sustainable Fashion_CIMaR 2024.pdf
Ozturkcan, S., Berndt, A., & Angelakis, A. (2024). Mending clothing to support sustainable fashion. Presented at the 31st Annual Conference by the Consortium for International Marketing Research (CIMaR), 10-13 Jun 2024, University of Gävle, Sweden.
The debris of the ‘last major merger’ is dynamically young
The Milky Way’s (MW) inner stellar halo contains an [Fe/H]-rich component with highly eccentric orbits, often referred to as the
‘last major merger.’ Hypotheses for the origin of this component include Gaia-Sausage/Enceladus (GSE), where the progenitor
collided with the MW proto-disc 8–11 Gyr ago, and the Virgo Radial Merger (VRM), where the progenitor collided with the
MW disc within the last 3 Gyr. These two scenarios make different predictions about observable structure in local phase space,
because the morphology of debris depends on how long it has had to phase mix. The recently identified phase-space folds in Gaia
DR3 have positive caustic velocities, making them fundamentally different than the phase-mixed chevrons found in simulations
at late times. Roughly 20 per cent of the stars in the prograde local stellar halo are associated with the observed caustics. Based
on a simple phase-mixing model, the observed number of caustics are consistent with a merger that occurred 1–2 Gyr ago.
We also compare the observed phase-space distribution to FIRE-2 Latte simulations of GSE-like mergers, using a quantitative
measurement of phase mixing (2D causticality). The observed local phase-space distribution best matches the simulated data
1–2 Gyr after collision, and certainly not later than 3 Gyr. This is further evidence that the progenitor of the ‘last major merger’
did not collide with the MW proto-disc at early times, as is thought for the GSE, but instead collided with the MW disc within
the last few Gyr, consistent with the body of work surrounding the VRM.
EWOCS-I: The catalog of X-ray sources in Westerlund 1 from the Extended Weste...
Context. With a mass exceeding several 104 M⊙ and a rich and dense population of massive stars, supermassive young star clusters
represent the most massive star-forming environment that is dominated by the feedback from massive stars and gravitational interactions
among stars.
Aims. In this paper we present the Extended Westerlund 1 and 2 Open Clusters Survey (EWOCS) project, which aims to investigate
the influence of the starburst environment on the formation of stars and planets, and on the evolution of both low and high mass stars.
The primary targets of this project are Westerlund 1 and 2, the closest supermassive star clusters to the Sun.
Methods. The project is based primarily on recent observations conducted with the Chandra and JWST observatories. Specifically,
the Chandra survey of Westerlund 1 consists of 36 new ACIS-I observations, nearly co-pointed, for a total exposure time of 1 Msec.
Additionally, we included 8 archival Chandra/ACIS-S observations. This paper presents the resulting catalog of X-ray sources within
and around Westerlund 1. Sources were detected by combining various existing methods, and photon extraction and source validation
were carried out using the ACIS-Extract software.
Results. The EWOCS X-ray catalog comprises 5963 validated sources out of the 9420 initially provided to ACIS-Extract, reaching a
photon flux threshold of approximately 2 × 10−8 photons cm−2
s
−1
. The X-ray sources exhibit a highly concentrated spatial distribution,
with 1075 sources located within the central 1 arcmin. We have successfully detected X-ray emissions from 126 out of the 166 known
massive stars of the cluster, and we have collected over 71 000 photons from the magnetar CXO J164710.20-455217.
ESA/ACT Science Coffee: Diego Blas - Gravitational wave detection with orbita...
ESA/ACT Science Coffee: Diego Blas - Gravitational wave detection with orbita...Advanced-Concepts-Team
Presentation in the Science Coffee of the Advanced Concepts Team of the European Space Agency on the 07.06.2024.
Speaker: Diego Blas (IFAE/ICREA)
Title: Gravitational wave detection with orbital motion of Moon and artificial
Abstract:
In this talk I will describe some recent ideas to find gravitational waves from supermassive black holes or of primordial origin by studying their secular effect on the orbital motion of the Moon or satellites that are laser ranged.Compexometric titration/Chelatorphy titration/chelating titration
Classification
Metal ion ion indicators
Masking and demasking reagents
Estimation of Magnisium sulphate
Calcium gluconate
Complexometric Titration/ chelatometry titration/chelating titration, introduction, Types-
1.Direct Titration
2.Back Titration
3.Replacement Titration
4.Indirect Titration
Masking agent, Demasking agents
formation of complex
comparition between masking and demasking agents,
Indicators/Metal ion indicators/ Metallochromic indicators/pM indicators,
Visual Technique,PM indicators (metallochromic), Indicators of pH, Redox Indicators
Instrumental Techniques-Photometry
Potentiometry
Miscellaneous methods.
Complex titration with EDTA.
11.1 Role of physical biological in deterioration of grains.pdf
Storagedeteriorationisanyformoflossinquantityandqualityofbio-materials.
Themajorcausesofdeteriorationinstorage
•Physical
•Biological
•Mechanical
•Chemical
Storageonlypreservesquality.Itneverimprovesquality.
Itisadvisabletostartstoragewithqualityfoodproduct.Productwithinitialpoorqualityquicklydepreciates
ESR spectroscopy in liquid food and beverages.pptx
With increasing population, people need to rely on packaged food stuffs. Packaging of food materials requires the preservation of food. There are various methods for the treatment of food to preserve them and irradiation treatment of food is one of them. It is the most common and the most harmless method for the food preservation as it does not alter the necessary micronutrients of food materials. Although irradiated food doesn’t cause any harm to the human health but still the quality assessment of food is required to provide consumers with necessary information about the food. ESR spectroscopy is the most sophisticated way to investigate the quality of the food and the free radicals induced during the processing of the food. ESR spin trapping technique is useful for the detection of highly unstable radicals in the food. The antioxidant capability of liquid food and beverages in mainly performed by spin trapping technique.
The cost of acquiring information by natural selection
This is a short talk that I gave at the Banff International Research Station workshop on Modeling and Theory in Population Biology. The idea is to try to understand how the burden of natural selection relates to the amount of information that selection puts into the genome.
It's based on the first part of this research paper:
The cost of information acquisition by natural selection
Ryan Seamus McGee, Olivia Kosterlitz, Artem Kaznatcheev, Benjamin Kerr, Carl T. Bergstrom
bioRxiv 2022.07.02.498577; doi: https://doi.org/10.1101/2022.07.02.498577
Randomised Optimisation Algorithms in DAPHNE
Slides from talk:
Aleš Zamuda: Randomised Optimisation Algorithms in DAPHNE .
Austrian-Slovenian HPC Meeting 2024 – ASHPC24, Seeblickhotel Grundlsee in Austria, 10–13 June 2024
https://ashpc.eu/
Travis Hills of MN is Making Clean Water Accessible to All Through High Flux ...
By harnessing the power of High Flux Vacuum Membrane Distillation, Travis Hills from MN envisions a future where clean and safe drinking water is accessible to all, regardless of geographical location or economic status.
Authoring a personal GPT for your research and practice: How we created the Q...
Thematic analysis in qualitative research is a time-consuming and systematic task, typically done using teams. Team members must ground their activities on common understandings of the major concepts underlying the thematic analysis, and define criteria for its development. However, conceptual misunderstandings, equivocations, and lack of adherence to criteria are challenges to the quality and speed of this process. Given the distributed and uncertain nature of this process, we wondered if the tasks in thematic analysis could be supported by readily available artificial intelligence chatbots. Our early efforts point to potential benefits: not just saving time in the coding process but better adherence to criteria and grounding, by increasing triangulation between humans and artificial intelligence. This tutorial will provide a description and demonstration of the process we followed, as two academic researchers, to develop a custom ChatGPT to assist with qualitative coding in the thematic data analysis process of immersive learning accounts in a survey of the academic literature: QUAL-E Immersive Learning Thematic Analysis Helper. In the hands-on time, participants will try out QUAL-E and develop their ideas for their own qualitative coding ChatGPT. Participants that have the paid ChatGPT Plus subscription can create a draft of their assistants. The organizers will provide course materials and slide deck that participants will be able to utilize to continue development of their custom GPT. The paid subscription to ChatGPT Plus is not required to participate in this workshop, just for trying out personal GPTs during it.
Applied Science: Thermodynamics, Laws & Methodology.pdf
When I was asked to give a companion lecture in support of ‘The Philosophy of Science’ (https://shorturl.at/4pUXz) I decided not to walk through the detail of the many methodologies in order of use. Instead, I chose to employ a long standing, and ongoing, scientific development as an exemplar. And so, I chose the ever evolving story of Thermodynamics as a scientific investigation at its best.
Conducted over a period of >200 years, Thermodynamics R&D, and application, benefitted from the highest levels of professionalism, collaboration, and technical thoroughness. New layers of application, methodology, and practice were made possible by the progressive advance of technology. In turn, this has seen measurement and modelling accuracy continually improved at a micro and macro level.
Perhaps most importantly, Thermodynamics rapidly became a primary tool in the advance of applied science/engineering/technology, spanning micro-tech, to aerospace and cosmology. I can think of no better a story to illustrate the breadth of scientific methodologies and applications at their best.
Farming systems analysis: what have we learnt?.pptx
Presentation given at the official farewell of Prof Ken Gillet at Wageningen on 13 June 2024
(June 12, 2024) Webinar: Development of PET theranostics targeting the molecu...
(June 12, 2024) Webinar: Development of PET theranostics targeting the molecu...Scintica Instrumentation
Targeting Hsp90 and its pathogen Orthologs with Tethered Inhibitors as a Diagnostic and Therapeutic Strategy for cancer and infectious diseases with Dr. Timothy Haystead.Sexuality - Issues, Attitude and Behaviour - Applied Social Psychology - Psyc...
A proprietary approach developed by bringing together the best of learning theories from Psychology, design principles from the world of visualization, and pedagogical methods from over a decade of training experience, that enables you to: Learn better, faster!
Recently uploaded (20)
Mending Clothing to Support Sustainable Fashion_CIMaR 2024.pdf
Mending Clothing to Support Sustainable Fashion_CIMaR 2024.pdf
Juaristi, Jon. - El canon espanol. El legado de la cultura española a la civi...
Juaristi, Jon. - El canon espanol. El legado de la cultura española a la civi...
The debris of the ‘last major merger’ is dynamically young
The debris of the ‘last major merger’ is dynamically young
EWOCS-I: The catalog of X-ray sources in Westerlund 1 from the Extended Weste...
EWOCS-I: The catalog of X-ray sources in Westerlund 1 from the Extended Weste...
ESA/ACT Science Coffee: Diego Blas - Gravitational wave detection with orbita...
ESA/ACT Science Coffee: Diego Blas - Gravitational wave detection with orbita...
Compexometric titration/Chelatorphy titration/chelating titration
Compexometric titration/Chelatorphy titration/chelating titration
aziz sancar nobel prize winner: from mardin to nobel
aziz sancar nobel prize winner: from mardin to nobel
11.1 Role of physical biological in deterioration of grains.pdf
11.1 Role of physical biological in deterioration of grains.pdf
ESR spectroscopy in liquid food and beverages.pptx
ESR spectroscopy in liquid food and beverages.pptx
Basics of crystallography, crystal systems, classes and different forms
Basics of crystallography, crystal systems, classes and different forms
The cost of acquiring information by natural selection
The cost of acquiring information by natural selection
Travis Hills of MN is Making Clean Water Accessible to All Through High Flux ...
Travis Hills of MN is Making Clean Water Accessible to All Through High Flux ...
Authoring a personal GPT for your research and practice: How we created the Q...
Authoring a personal GPT for your research and practice: How we created the Q...
Applied Science: Thermodynamics, Laws & Methodology.pdf
Applied Science: Thermodynamics, Laws & Methodology.pdf
Farming systems analysis: what have we learnt?.pptx
Farming systems analysis: what have we learnt?.pptx
(June 12, 2024) Webinar: Development of PET theranostics targeting the molecu...
(June 12, 2024) Webinar: Development of PET theranostics targeting the molecu...
Sexuality - Issues, Attitude and Behaviour - Applied Social Psychology - Psyc...
Sexuality - Issues, Attitude and Behaviour - Applied Social Psychology - Psyc...
Naval arch fuel consumptn
- 2. AKD;Rev0;Feb02 SP-SMA 2 SPEED ANDSPEED AND FUEL CONSUMPTIONFUEL CONSUMPTION [Ref.1]
- 3. AKD;Rev0;Feb02 SP-SMA 3 SPEED ANDSPEED AND FUEL CONSUMPTIONFUEL CONSUMPTION o At moderate speeds, the daily Fuel Consumption in tonnes varies approximately as the following: (Ship Speed)3 o FC = k V3 where 1. FC = Daily fuel consumption in tonnes 2. V = Ship speed in knots 3. k = A constant
- 4. AKD;Rev0;Feb02 SP-SMA 4 SPEED ANDSPEED AND FUEL CONSUMPTIONFUEL CONSUMPTION o FC = k V3 o So, from the above relation, old and new fuel consumptions can be written as the following: 3 3 .. .. old new V V nconsumptiodailyold nconsumptiodailynew =
- 5. AKD;Rev0;Feb02 SP-SMA 5 SPEED ANDSPEED AND FUEL CONUMPTIONFUEL CONUMPTION o Exercise: oA ship burns 40 tonnes of fuel per day at 12 knots, calculate her daily fuel consumption at 11 knots o(ANS: 30.8 tonnes per day)
- 6. AKD;Rev0;Feb02 SP-SMA 6 DISPLACEMENT ANDDISPLACEMENT AND FUEL CONSUMPTIONFUEL CONSUMPTION o If displacement of a ship be altered then fuel consumption per day in tonnes will vary as the following: (Displacement)2/3 o FC = k ∆2/3 where 1. FC = Daily fuel consumption in tonnes 2. ∆ = Ship’s displacement in tonnes 3. k = A constant
- 7. AKD;Rev0;Feb02 SP-SMA 7 DISPLACEMENT ANDDISPLACEMENT AND FUEL CONSUMPTIONFUEL CONSUMPTION o FC = k ∆2/3 o So, from the above relation, old and new fuel consumptions can be written as the following: 3/2 3/2 .. .. old new nconsumptiodailyold nconsumptiodailynew ∆ ∆ =
- 8. AKD;Rev0;Feb02 SP-SMA 8 DISPLACEMENT ANDDISPLACEMENT AND FUEL CONSUMPTIONFUEL CONSUMPTION o Exercise: oA ship when displacing 16,000 tonnes burns 25 tonnes of fuel oil per day at a certain speed, calculate her daily consumption at this same speed after discharging 3500 tonnes o(ANS: 21.2 tonnes per day)
- 9. AKD;Rev0;Feb02 SP-SMA 9 DISTANCE ANDDISTANCE AND FUEL CONSUMPTIONFUEL CONSUMPTION o The total fuel consumption in tonnes for a passage/voyage varies as the following: (Ship Speed)2 x Distance o TFC = k V2 x D where 1. TFC = Total fuel consumption in tonnes 2. V = Ship speed in knots 3. D = The cruising distance in nautical miles 4. k = A constant
- 10. AKD;Rev0;Feb02 SP-SMA 10 DISTANCE ANDDISTANCE AND FUEL CONSUMPTIONFUEL CONSUMPTION o TFC = k V2 x D o So, from the above relation, old and new fuel consumptions can be written as the following: oldold newnew xDV xDV nconsumptiototalold nconsumptiototalnew 2 2 .. .. =
- 11. AKD;Rev0;Feb02 SP-SMA 11 DISTANCE ANDDISTANCE AND FUEL CONSUMPTIONFUEL CONSUMPTION o Exercise: oA ship burns 120 tonnes of fuel oil on a passage of 2400 miles at 10 knots. At what speed can she steam 3000 miles on 180 tonnes of fuel oil o(ANS: 10.95 knots)
- 12. AKD;Rev0;Feb02 SP-SMA 12 DISTANCE ANDDISTANCE AND FUEL CONSUMPTIONFUEL CONSUMPTION o The total fuel consumption in tonnes for a passage/voyage varies as the following: (Ship Speed)2 (For same distance) o TFC = k V2 where 1. TFC = Total fuel consumption in tonnes 2. V = Ship speed in knots 3. k = A constant
- 13. AKD;Rev0;Feb02 SP-SMA 13 DISTANCE ANDDISTANCE AND FUEL CONSUMPTIONFUEL CONSUMPTION o TFC = k V2 o So, from the above relation, old and new fuel consumptions can be written as the following: 2 2 .. .. old new V V nconsumptiototalold nconsumptiototalnew =
- 14. AKD;Rev0;Feb02 SP-SMA 14 DISTANCE ANDDISTANCE AND FUEL CONSUMPTIONFUEL CONSUMPTION o Exercise: o On increasing the speed of a vessel by 1.5 knots it is found that the daily consumption of fuel is increased by 25 tonnes and the percentage increase in fuel consumption for a voyage of 2250 nautical miles is 20. Estimate (a) the original daily fuel consumption and (b) the original speed of the ship o (ANS: 79.91 tonnes/day and 15.79 knots)
- 15. AKD;Rev0;Feb02 SP-SMA 15 SPECIFIC FUELSPECIFIC FUEL CONSUMPTIONCONSUMPTION o SFC is the fuel consumption per kW per hour o Normal SFC: 180 – 185 gm/kW/h 1000x1000 PowerxSFC tonnesinnConsumptioFuelHourly = 1000x1000 24xPowerxSFC tonnesinnConsumptioFuelDaily =
- 16. AKD;Rev0;Feb02 SP-SMA 16 BIBLIOGRAPHYBIBLIOGRAPHY REFERENCESREFERENCES 1. E. A. Stokoe, Reed’s Naval Architecture for Marine Engineers, 3rd ed. (1973) 2. W. A. Fisher, Engineering for Nautical Students, 4th ed. (1973)
