1. Surgical Management of
Middle Cerebral Artery Aneurysms
Alexander M. Mason , C. Michael Cawley , Daniel L. Barrow
2/02/59

2. • May grow to 20 mm or larger before detection
• More likely to present with an
intraparenchymal clot
• More likely to cause symptoms of mass
effect than most other intracranial aneurysms
• More challenging to treat with endovascular
techniques than other aneurysms within the
intracranial circulation
MCA aneurysm

3. Anatomy

4. • Sylvian fissure
– deep component
• anterior (sphenoidal) compartment
– M1 segment
• posterior (operculoinsular) compartment
– M2 and M3 segments
– superficial component
Anatomy

5. • M1 (sphenoidal)
– lateral lenticulostriate arteries
• caudate nucleus
– anterior temporal artery
• temporal tip
• M2 (insular)
• M3 (opercular)
• M4 (cortical)
• MCA candelabra : duplication of MCA
Anatomy

6. • Morphology
– Saccular aneurysms : most common
– Fusiform aneurysms
– Blister aneurysms : less common
– Extremely dysmorphic or distal aneurysms are usually
infectious : M4 branches
• Size
– small (<5 mm)
– medium (5 to 10 mm)
– large (11 to 25 mm)
– giant (>25 mm)
Classification

7. Classification
• Location
– MCA bifurcation and trifurcation aneurysm 90%
• Surgical consideration
– Proximal MCA aneurysm
• Superior wall type :
– aneurysms arise at the origins of the
lenticulostriate arteries
– project into the frontal lobe posterosuperiorly
• Inferior wall type :
– aneurysms arise at the origin of the anterior
temporal artery or the temporopolar artery
– project toward the temporal lobe in an anterolateral
projection

8. • Location
– Distal MCA aneurysms
• most uncommon of the MCA aneurysms
• either infectious or, less frequently, traumatic
• often small and can be challenging to identify
Classification

9. Classification
• Etiology
– Saccular Aneurysms(berry)
• at sites of arterial curves or branching
• hemodynamic forces
– Infectious Aneurysms(mycotic)
• most commonly found along the distal branches of the
cerebral arteries
• secondary to infectious emboli
• bacterial endocarditis, idiopathic bacterial or fungal
sources
• neoplastic disease, such as choriocarcinoma and atrial
myxoma

10. • Etiology
– Fusiform Aneurysms
• most frequently seen in the posterior circulation
– Dissecting Aneurysms
• rare
• may be associated with infection, connective tissue diseases
such as Marfan’s syndrome, cystic medial degeneration, and
fibromuscular dysplasia
• present with ischemia or SAH
– Traumatic Aneurysms
• uncommon
• most often associated with the ACA
• most frequently distal on M3 and M4 segments and often
present with
Classification

11. • Because of their propensity to become quite large
before detection, they may occasionally become
symptomatic without SAH
• Seizures in giant aneurysm
• Lack of blood necessitates a lumbar puncture (LP) if
the history is suggestive of an aneurysm rupture
• CT
– SAH
– ICH
Presentation and evaluation

12. • MCA aneurysms are preferentially clipped at
most cerebrovascular centers
– frequently broad-based configuration
– the relatively small caliber of surrounding branches
often precludes the use of stents
– their classic bifurcation location makes recurrence
more likely
Surgical treatment

13. • Cerebrospinal fluid drainage
– indicated in patients with acute hydrocephalus after
aneurysmal SAH
– relaxed brain makes surgery safer in ruptured
aneurysm surgery
– patients with unruptured aneurysms generally do not
have preoperative placement of a lumbar drain
• Position
– head is turned about 30 degrees to the opposite
side with the vertex slightly extended
Preparation

14. Craniotomy
• Pterional incision
• Preserve STA
• Temporalis muscle splitting
with leaving cuff of muscle
• 2 burr holes
– Key hole
– Superior to zygoma

15. • Dura is stripped from the cranium with a Penfield
No. 3
• Pterional craniotomy flap is created with a high-
speed drill with footplate
• The lesser wing of the sphenoid is flattened to
the level of the superior orbital fissure
• Dural tack-up sutures
• Dura is opened in a curvilinear fashion
Craniotomy

16. • Microscope
• Sylvian fissure is opened sharply with an
arachnoid knife or a No. 11 knife blade
• After a 3-4 mm, microscissors are used to
continue to open the superficial arachnoid
over the fissure
• Inside out technique or open opticocarotid
cistern
Fissure dissection

17. Fissure dissection

18. • Unruptured aneurysm or a small, laterally
pointing ruptured aneurysm of the bifurcation
– first distally and then ultimately on the medial surface
(undersurface) of the bifurcation to access the M1
segment, gaining proximal control without opening the
proximal fissure first
• larger or ruptured aneurysm or uncertain
anatomy
– fissure dissection should be wide and include
proximal control, initially at the opticocarotid cistern,
and then working distally until the proximal M1 is
identified
Aneurysm Dissection and Clipping

19. • Sharp dissection,clear aneurysm neck
• Beware small branches adherence to dome
• Temporary clip
• Clips should be applied parallel to the branch
vessels to avoid possible small remnants and to
reestablish normal anatomic flow
Aneurysm Dissection and Clipping

20. • Multilobed aneurysms
– require more than one clip and often imaginative clip
constructs
• Large, multilobulated aneurysms often also
have calcified or atheromatous walls
– closure of clips tricky
– tandem clipping technique
– fenestrated clip through the distal neck and then
completing the proximal neck occlusion with a
nonfenestrated clip
Aneurysm Dissection and Clipping

21. Aneurysm Dissection and Clipping

22. • Giant MCA aneurysms
– visualization of branches or small lenticulostriate
arteries is often poor
– usually calcification or atheroma
– large sacs contain intraluminal thrombus that must be
removed before clip application
• Temporary trapping and opening of the sac
to evacuate the thrombus
• Brain ischemic protection
– modest hypothermia
– induced hypertension
– barbiturates
Aneurysmorrhaphy

23. Temporary Occlusion
• occlusion times of less than 10 minutes are
preferable
• no consensus in the literature regarding specific
cerebroprotective agents

24. Bypass
• Fusiform and giant aneurysms
• STA-MCA bypass
• M2 side to side
