IPSec provides authentication, confidentiality, and key management. It uses Authentication Header (AH) and Encapsulating Security Payload (ESP) to provide integrity, authentication, and encryption for transport and tunnel mode. Combining security associations allows applying multiple protocols like AH followed by ESP. Oakley key exchange negotiates keys securely while addressing man-in-the-middle and clogging attacks.
Recommended
More Related Content
What's hot
What's hot (20)
Similar to ip security
Similar to ip security (20)
Recently uploaded
Recently uploaded (20)
ip security
- 1. IPSecurity
- 2. IP Security..___...____...._____.....______........... Functional Areas Authentication Confidentiality Key Management
- 3. Applications of IP Security..___...___....____........... Provide Secure Connection Across LAN MAN WAN 1
- 4. Applications of IP Security..___...___....____........... Secure Remote Access over the Internet 2
- 5. Applications of IP Security..___...___....____........... Establish Extranet and Intranet connectivity 3
- 6. Applications of IP Security..___...___....____........... Enhancing Electronic commerce security 4
- 7. Applications of IP Security..___...___....____........... Router Applications Router Advertisement (new) Router Advertisement (maintenances) Not forged update
- 8. Benefits of IP Security..___..._____....______........... • IPsec in Router • IPsec in Firewall • Its below transport layer, so no need to change existing security mechanism • Transparent to End-user • IPsec for individual users
- 10. • Access control • Connectionless integrity • Data origin authentication • Rejection of replayed packets • Confidentiality (encryption) • Limited traffic flow confidentiality IP Security Architecture..___..._____...._____........... • RFC 2401: An overview of security architecture • RFC 2402: Packet Authentication Extension • RFC 2406: Packet Encryption Extension • RFC 2408: Key Management capabilities Two security Header Extension Encapsulating Security Payload (ESP) Authentication Header (AH) services
- 11. Security Association…___...._____.....______........... Security Association A one-way relationship between sender & receiver Uniquely identified by: SA Parameters Security Parameters Index (SPI) IP Destination Address Security Protocol Identifier A bit string assigned to this SA. The address of the destination endpoint of the SA. Indicates whether the association is an AH or ESP Security Association. Sequence Number Counter Sequence Counter Overflow Anti-Replay WindowAH Information ESP Information Lifetime of this Security AssociationIP Security Mode Path MTU
- 12. Transport Mode…___....____.....______........... • Provide protection for upper layer protocols. (TCP/UDP/ICMP) • Used for end to end communication • ESP • Encrypts IP payload, • Optionally authenticate IP Payload but not IP header • AH • Authenticate IP payload and selected portion of IP Header
- 13. Tunnel Mode…___......____........_______........... • Provide protection for entire IP packet by encrypting the packet with AH/ESP and an additional IP header • Tunnel mode could be used in Three different configuration. • Gateway to Gateway • One endpoint • Third party Firewall
- 17. Authentication Header…__......___........_____........... • Provides support for Data Integrity and Authentication Ensures that modification to a packet content in transit is not possible. Enables End-System to Authenticate the User or Application Prevents Address Spoofing Attack Guards against reply attack
- 18. Authentication Header…__......___........_____........... Data integrity Authentication Reply Protection MAC Secret shared key Sequence Number
- 19. Authentication Header…__......___........_____........... Fields: • Next Header: Identify the type of header immediately following this header (could be TCP or UDP header, based on application) • Payload Length: Length of authentication header in 32 bit word minus 2 • Reserved: For future use (set to 0) • Security Parameter index: Identifies Security Association Rules • Sequence Number: Monotonically increasing counter value(number of messages Sent using the current SA) • Authentication Data: Contains Integrity Check Value(ICV), Eg. MAC
- 21. Authentication Header…__......___........_____........... ICV (Integrity Check Value) • It’s a Message Authentication Code • First 96 bits are used as MAC as it’s the default size for the authentication data field. • MAC is calculated over • Immutable ip-header fields • Predictable fields upon arrival at the endpoint. • Mutable and unpredictable fields are set to Zero • Authentication Header other than authentication data field. • Entire upper level data
- 22. Internet header length Source Address Version Authentication Header…__......___........_____........... Immutable Fields Mutable but Predictable Fields Destination Address Mutable Fields that are Zeroed Time to live and Header checksum Flow Label
- 23. Authentication Header…__......___........_____........... Anti-Reply Service • Protects against Reply Attack • Based on Sequence Number • Sequence number cycle : 232 – 1 • When this limit is reached, negotiate new SA • Inbound processing when a packet is received
- 24. Authentication Header…__......___........_____........... Transport Mode IP Header TCP Data IP Header AH TCP Data
- 25. Authentication Header…__......___........_____........... Tunnel Mode IP Header TCP Data New IP Header AH Original IP Header TCP Data
- 26. Encapsulating Security Payload.....__......___.......... Fields: • Next Header: Identify the type of header immediately following this header (could be TCP or UDP header, based on application) • Security Parameter index: Identifies Security Association Rules • Sequence Number: Monotonically increasing counter value(number of messages Sent using the current SA) • Payload Data: Transport level data or IP packet • Padding: 0-255 Bytes • Pad Length: number of pad bytes • Authentication Data: Contains Integrity Check Value(ICV)
- 28. Encapsulating Security Payload.....__......___.......... Transport Mode IP Header TCP Data IP Header ESP TCP Data ESP Trailer ESP Authentication Encrypted
- 29. Combining Security Association.....__......___.......... Individual SA can implement either the AH or ESP protocol but not both. Some traffic flow require services provided by both AH & ESP Security Association Bundle: It refers to a sequence of SAs through which traffic must be processed to provide a desired set of IPSec services. The SAs in a bundle may terminate at different or same end-points Security Association Bundle Transport Adjacency: Refers to applying more than one security protocol to the same IP packet, without invoking tunneling. Iterated tunneling: Refers to the application of multiple layers of security protocols effected through IP tunneling. Each tunnel can originate or terminate at a different IPSec site along the path.
- 32. Combining Security Association.....__......___.......... Iterated tunneling with different End Point:
- 33. Combining Security Association.....__......___.......... Case 1: Security is provided between end systems Case 2: Security is provided only between Gateways Case 3: Builds on Case 2 by adding end-to-end security Case 4: Provides support for a remote host
- 35. Combining Security Association.....__......___.......... Authentication Plus Confidentiality Transport mode ESP: Authentication and Encryption apply to the IP payload, IP header is not protected. Tunnel mode ESP: Applies to entire IP packet. Possible Combinations: a: AH in transport mode b: ESP in transport mode c: ESP followed by AH in transport mode d: a, b, c inside an AH or ESP in tunnel mode
- 36. Key Management......_____.........______.......... Manual Automatic Small Static environment Every Where
- 37. Key Management......_____.........______.......... Oakley Key Determination Protocol Refinement over Diffie-Hellman key exchange algorithm Features: Secret keys are created only when needed Requires no pre-existing infracture Weaknesses: Doesn’t provide any info regarding identity of parties Subject to man in the middle attack
- 38. Key Management......_____.........______.......... Man in the Middle Attack CloggingAttack
- 39. Key Management......_____.........______.......... Oakley Features Cookies to thwart clogging attack Enables two parties to negotiate group Use nonces to ensure against reply attack
- 40. Key Management......_____.........______.......... Oakley Authentication Methods Digital Signature Public key Encryption Symmetric key Encryption
