Guiding a successful SharePoint implementation<br />Randy Williams<br />Enterprise Trainer & Evangelist<br />randy.william...
About your speaker<br />20 years in IT<br />developer, consultant, trainer, author<br />At AvePoint<br />Evangelist, Archi...
Today’s agenda<br />Part 1 (2:00 - 3:10)<br />Introduction & Overview<br />The Need to Plan<br />Defining the Business Sol...
Challenges deploying SharePoint<br />It’s a business solution<br />Delivering ROI<br />Cultural changes<br />Managing the ...
The need to plan<br />
Yes, you really need a plan<br />It’s still a project<br />SharePoint is one of the trickiest types of projects<br />Many ...
How can SharePoint Fail?<br />Lack of growth planning<br />Lack of governance model<br />Lack of governance board<br />Lac...
Defining the solution<br />
What are your business goals?<br />Identify pain points and opportunities<br />Do not assume SharePoint is the solution<br...
User Personas<br />Because users won’t just “figure it out”<br />Identify specific use cases that SharePoint can address<b...
Organizing all requirements<br />Project Requirements<br />
Addressing the gap<br />What about requirements that cannot be met by SharePoint?<br />Is SharePoint the right solution?<b...
Design and deliver governance<br />
Governance is the set of policies, roles, responsibilities, and processes that guides, directs, and controls how an organi...
Accountability<br />
Accuracy<br />
Restrictions<br />
Appropriateness<br />
Compliance<br />
SharePoint Governance issues<br />
Storage<br />
Information Architecture<br />
Proliferation <br />
Lifecycle Management<br />
Group management<br />
WITH GREAT POWER THERE MUST ALSO COME - - GREAT RESPONSIBILITY!<br />
People<br />Governance System<br />
Policy<br />
Process<br />Manual Enforcement<br />Automated Enforcement<br />Semi-automated<br />
Technical governance<br />Define Your Requirements<br />Align Management Requirements with Controls and Scopes<br />Align ...
Ready for a break?<br />Q&A<br />
Architecting the Solution<br />
Logical design of SharePoint<br />Farm<br />Web Application<br />Service Application<br />Zone<br />Content DB<br />Site c...
Server roles<br />Web front end (WFE)<br />IIS server that receives all direct HTTP requests from users<br />Application s...
Scaling web front end<br />Very scalable role using load balancing<br />Active/active design<br />Can use either NLB (buil...
Scaling application server<br />Very scalable using SharePoint<br />Active/active design<br />Load balancing is built into...
Scaling database server<br />Add multiple database servers<br />Clustering is an active/passive design <br />only a high a...
How can I decide where/how to distribute services across my farm?<br />Answer: Perform adequate testing to determine the r...
Single server farm<br />All roles on one machine<br />Only advised for development or test environments<br />No fault tole...
Two server farm<br />Very common for small to some medium-sized organizations<br />In general, can support up to 2000 user...
Three server farm<br />Each server has its own role<br />Usually used with heavier search component<br />All application s...
Small high-availability farm<br />Four server farm with all roles redundant<br />Database server can either beclustered or...
Medium server farm<br />Comes in many flavors and sizes<br />Scale each role as needed<br />Delivers high availability and...
Large farm<br />Yes, SharePoint is uber scalable<br />
Storage Capacity Planning<br />Content databases<br />Documents x Versions x Average Size = data size<br />10KB x [List It...
Remote BLOB Storage (RBS)<br />Store documents outside of content database<br />Save on storage costs<br />Best in file-he...
Authentication<br />SharePoint supports two modes<br />Classic<br />Same as with SharePoint 2007<br />Works with all forms...
Office 365<br />
What’s in the Box?<br />http://office365.microsoft.com/<br />
Microsoft’s Promise<br />99.9% uptime<br />Certified<br />Multiple datacenters<br />Geo-redundant<br />Shorter release cyc...
Data Centers<br />$2.3B+ investment – geo redundant - environmentally sustainable<br />
Missing Features Today<br />Business Connectivity Services<br />FAST Search<br />Performance Point Services<br />Project S...
Latest Costs (per user/per month)<br />Professional and Small Business(less than 50 users)<br />P$6	 – Exchange, Lync, Sha...
SharePoint 2010 Enterprise<br />Lync 2010<br />Exchange 2010 <br />Office 2010 Professional<br />Sample Comparison<br />10...
Software: Windows Server 2008 R2, SQL Server 2008 R2, SharePoint Server 2010, Office 2010 Professional…</li></ul>Cost?<br />
To learn more about Office 365<br />Webcast recorded on 2 Aug 2011<br />Download from http://www.avepoint.com/sharepointun...
How to address training<br />
Recommendations<br />Users will not “figure it out”<br />Training should not be product-centric<br />Task-oriented <br />f...
Training resources<br />www.point8020.com<br />www.avantustraining.com<br />http://sharepoint.microsoft.com/en-us/resource...
Register today and learn about these exciting topics:<br /><ul><li>Office 365: Does it Work in a Leap Year?
To BLOB or Not to Blob?  Storage Optimization Demystified
Without Boundaries:  Building SharePoint for Real Global Collaboration
