Mainframe jcl exec and dd statements part - 3janaki ram
EXEC STATEMENT(EXEC)
EXEC Statement is used to identify program name or procedure name.
Maximum we can code 255 EXEC statements in a JOB.
In EXEC statement has two kinds of parameters
Position parameter Keyword parameter
PGM TIME , COND
PROC REGION , PARM
If you not mention any thing default it takes PROC
PGM
This is a positional parameter which must be coded after EXEC with one blank. This parameter indicates the name of program (or) procedure name
Syntax
//STEPNAME EXEC PGM=REPORT (OR)
PROC = PROCEDURE NAME
PARM
It is keyword parameter and it is mainly used for passing the data to another program.
To pass input to Application program
To invoke complier option.
This is a keyword parameter at activity / step level must be coded with exec operand after PGM parameter.
This parameter allows MAX(100) characters.
To receive PARM parameter data, Cobol program must be coded with “Procedure Division Using Parameter ” option.
These parameters must be declared in the linkage section.
DATA DESCRIPTOR STATEMENT ( DD STMT)
It is used to identify files( input and output ) used in JCL
DD name act as a bridge b/w Cobol program and execution JCL
In DD statement has two kinds of parameters.
Position Parameter Keyword Parameter
* DSN,DISP
DATA SPACE,UNIT
DUMMY DCB,VOLUME
*
Position parameter at DD level used with SYSIN to pass data to Cobol programs this is known as In stream data any number of records can be passed to the program.
In stream data is used to pass values from JCL to Cobol dynamically.
To accept the values in Cobol program, we should have equivalent accept verbs.
Syntax
//SYSIN DD * ------- Entry of in stream data
100
200
/* ---------------------- End of in stream data
DATA
We can pass any thing to another program including special character
Syntax
//SYSIN DD DATA
100
/*
200
/*
DUMMY
All files are treated as End of the file
Syntax
//SYSIN DD DUMMY
NOTE
There is no input to the application all input files treated as End of the file.
DSN
Through DSN we can refer temporary / permanent file
Is a physical space or file where the records will be stored.
DISP
DISP parameter is used to identify the mode of the file.
DISP= ( STATUS, NORMAL , ABNORMAL )
TERMINATION TERMINATION
NEW DELETE DELETE
OLD KEEP KEEP
SHR CATLG CATLG
MOD UNCATLG UNCATLG
NEW Creating the data set first time
OLD Already created accessing the data set all resources are allocated exclusively . No other user can until is released by the current user. If dataset is not existing this creates.
SHR The data set can be accessed by multiple users at a time.
MOD Appending the records to the existing record
NOTE If the dataset is not existing , then MOD is assumed as NEW and writes records to the dataset.
This presentation covers the basic DB2 objects description. Covers the basic administration using IBM utilities. Their complete phase wise operation and termination recoveries. Also have talked about the most frequently used DB2 catalog tables, what's the need for them in DB2. And finally have shown some SPUFI panels and their usage.
CICS is the power of mainframe. It has all the capabilities to handle online transactions. The ppt covers highly useful CICS concepts to refresh your CICS knowledge quickly.
Maintec Technologies provides affordable access to latest Mainframe infrastructure for development, training, additional short term capacity increases and outsourcing needs. Leverage our Mainframe infrastructure, without investing the time, expense and manpower it would take to build your own!.
JCL
Job Control Language (JCL) is a name for scripting languages used On IBM mainframe operating systems to instruct the system on how to run a batch job or start a subsystem.
JCL acts as an interface between application programming and MVS Operating system.
Jcl is used for compilation and execution of batch programs.
Apart from the above functionalities JCL can also be used for,
1. Controlling the jobs.
2. Create GDG’S.
3. Allocate PDS,PS file with IBM Utilities.
4. Create Procs.
5. Sort the files.
JCL Coding Sheet
1,2,3----------Column Numbers----------72,73------------80
//JOBNAME JOB PARAMETERS------COMMENTS
// EXEC
// DD
//* ------------ Comment (* in 3rd column indicates line in comment)
//------------ End of JCL
Where // ----- Identification Field
job name------- Naming field
JOB,EXEC,DD - Statement / Operation
NOTE
If we want to continue parameters in the next line end the last parameter with “,” and continue next parameter only in 4-16 columns.
There are three statements in JCL.
JOB
EXEC
DD
JOB Statement:
Job statement is used to identify job name and job related parameters
JOBCARD = job name + job related parameters.
Syntax
//JOBNAME JOB ACCOUNT INFORMATION,’USERNAME’,CLASS=A-Z/0-9,
// NOTIFY =&SYSUID/RACF ID,MSGCLASS,
// MSGLEVEL=(X,Y),PRTY=0-15,
// TIME=(M,S),REGION=MB/KB,TYPRUN=SCAN/
// HOLD/COPY,COND=(RC,OPERATOR,STEPNAME)
// COND=ONLY OR COND=EVEN,RESTART=STEPNAME
JOBNAME
It is required to identify this job from other jobs in the SPOOL
1 to 8 characters minimum 1 character and maximum is 8 character.
1st character must be alphabet.
Other characters can be alphabets or numeric or $,&,#.
Example
Job names for personal or lab sessions
Userid + 1 / 2 chars
KC03P83$ ------- Userid is KC03P83
KC03P84&--------Userid is KCO3P84
ACCOUNTING INFORMATION
It is a keyword parameter and codes it after JOB statement.
It is used for billing purpose, in real time when we submit any job it is going to take some CPU time. Based on the CPU time there will be some amount involved where this amount has to go will be decided by A/C information parameters.
Examples
(8012T)
(80121I)
(8012M)
USERNAME
It is used to identify the user who has written the JCL.
It can be maximum of 20 characters.
Note Both A/C information and user name are positional parameters and the remaining job
card parameters are keyword parameters.
EX1: //KC03P83A JOB (487A),’JANAKI RAM’
EX2: //KC03P84& JOB (488T),’SOMISETTY’
NOTIFY
To which user id the job has to be notification after successful or unsuccessful completion.
Successful completion means MAXCC = 0 (or) 04 unsuccessful completion means MAXCC > 04.
If it is not coded,then user has to check the status of the job from the spo
