SKILLWISE - JOB
CONTROL LANGUAGE

Course Outline
Introduction - Job Control Language
JOB Statements
EXEC Statements
DD Statements
GDG and some commonly used utilities
Commonly Occurring Abend Codes
Q & A
3

What is JCL ?
• What is a JCL?
– Job Control Language - means of communication between an application
program and the computer's operating system (the IBM OS 390 MVS
Operating System).
• What Can I Do With JCL?
– Submit a job to the operating system
– Request resources needed to run the job
– Control the system’s processing of the job
• What is needed to Write JCL?
– Access to the IBM mainframe computer
– A valid TSO user ID
4

What is a Job?
• Job is something that you want to accomplish with the aid
of a mainframe
• Examples
 Copy a data set
 Execute a program
 Process multiple job steps.
5

Functions of JCL
• It identifies your Job to the system.
• It describes the Job’s requirements.
• It directs the execution of the program(s)
• It describes the devices(readers,printers etc.) and
resources(datasets) needed by the program(s).
• JCL statements provide information that the operating
system needs to execute a job
6

JCL Statement Format
• Job Control Language (JCL) is very precise.
• It has specific rules of grammar and syntax that must be
followed.
• Must not contain any irregularities.
• The JCL will be rejected if it contains typographical
errors (including extra or missing spaces or commas),
fields in the wrong order, etc.
• JCL and JES2 statements (except for comments) must not
contain lower case letters.
7

JCL Statement Types
• JOB STATEMENT :
Provides accounting information as well as job name to
each job.
• EXEC STATEMENT:
Calls specified program or procedure for execution.
• DD STATEMENT:
Provides details about the various resources used by the
program.
8

JCL Statement Types
• COMMENT STATEMENT:
The comment statement contains comments. It is used
primarily to document a program and its resource
requirements.
• DELIMITER STATEMENT:
The delimiter statement signifies the end of a job step or
end of data.
• NULL STATEMENT:
The null statement signifies the end of a job.
9

JCL Statement Fields
 Each Job Statement is logically divided into:
 Identifier Field
 Name Field
 Operation Field
 Parameter Field
 Comment Field
10

JCL Statement Fields(contd..)
//L110 JOB (00124,'MONTHLY STATISTICS'),
// CLASS=P,MSGCLASS=P,REGION=0M
//LST11008 EXEC PGM=TEST
//LST11018 EXEC LST11018,ENV=IPHP,UNITCT=CART,CTL=IPHP,
// UNITDA=PRODDA
//SYSIN DD *
//SYSPRINT DD SYSOUT=*
11
Identifier
field
Name
field
Operation
field
Parameter
field

– Identifier Field
 Indicates to the system that a statement is a JCL
statement rather than data.
 The identifier field is located in columns 1, 2 and 3
 Indicates if it is a JCL statement , delimiter statement or a
comment statement
 // indicates it is a JCL statement
 /* indicates it is a delimiter statement
 //* indicates it is a Comment statement
12
//JOB1 JOB (A189), ‘C RANADE’,CLASS=A,PRTY=6

– Name Field
 The name field associates a name with the JCL statement
so that the system can refer to it.
 For JCL statements, code the name as follows:
 The name must begin in column 3.
 The name is 1 through 8 alphanumeric or special ($,
#, @) characters.
 The first character must be an alphabet or special
character ($, #, @).
 The name must be followed by at least one blank.
13

- Operation Field
 The operation field specifies the statement function.
 Code the operation field as follows:
The operation field follows the name field.
The operation field must be preceded and followed
by at least one blank.
The Operation field is required and begins anywhere
in columns 4 through 15.
14

– Parameter Field
• The parameter field, also sometimes referred to as the
operand field
• The Operand Field provides details and instructions
necessary for the system to perform the job. It is composed of
one or more parameters, separated by commas.
• There are positional parameters, which appear in a specific
order, and keyword parameters, which are of the form
KEYWORD=VALUE.
15 //JOB1 JOB (A189), ‘C RANADE’,CLASS=A,PRTY=6

– Comments Field
 The comments field contains any information you seem
helpful when you code the control statement. Code the
comments field as follows:
 The comments field follows the parameter field.
 The comments field must be preceded by at least
one blank and ends in column 71.
 You can code comments after the parameter field
even though you continue the parameter field on
a subsequent statement
16
//STEP001 EXEC PGM=PROGRAM1 => NEW PGM
//INPUT1 DD DSN=INFILE,DISP=SHR
//REPORT1 DD SYSOUT=*

JOB statement
• The Job statement names a job, supplies accounting
and billing information, and supplies options to
control processing of the job.
• The JOB statement is always your first JCL
statement. It signals the beginning of a job and the
end of any previous job and assigns a name to your
job.
//L116 JOB (00124,‘PROGRAMMER NAME'),
// CLASS=J,MSGCLASS=Z,REGION=0M,MSGLEVEL=(0,0),
// NOTIFY=SYSID,TIME=(2,30),TYPRUN=SCAN,RESTART=STEP2
• The JOB card requires
– the Job name, which appears on the header page of your output,
– the word JOB in the Operation field,
– the accounting information for your job,
– the programmer's name.
17

Positional Parameters
on the Job Card
 Positional parameter must precede the keyword
parameters.
Job Accounting information parameter
 identifies the account number which will be billed
for the CPU time utilized on the mainframe
Syntax
(account-number,additional-accounting-information)
//JOB1 JOB (A189,DEPT1)

on the Job Card
 Programmer-Name parameter
Name
Information related to the job being submitted
The PROGRAMMER name can be a maximum of 20
characters.
//JOB1 JOB (A189),SUNIL

Keyword Parameters
on the Job Card
• Must follow positional parameter
• Can be coded in any order
 CLASS
 PRTY
 MSGCLASS
 MSGLEVEL
 REGION
 TYPRUN
20

CLASS parameter
 The CLASS parameter is used to assign your job to a job
processing class. The CLASS parameter specifies the class in
which the job will be run and it depends on the characteristics
of Job.
 CLASS=n where n varies from A-Z or from 0-9.
 If one does not specify the CLASS parameter the installation
establishes a default CLASS.
21
//JOB1 JOB (A189),SUNIL,CLASS=K

PRTY parameter
 The PRTY parameter is related to the CLASS parameter
 It assigns priority to jobs which belong to the same class
 PRTY=priority
 Priority is a number between 0 to 14, or 0 to 15
 The job with a higher number takes precedence over a job
with a lower number
A job with priority 10 will run before a job with priority 3.
22
//JOB1 JOB (A189),SUNIL,CLASS=8,PRTY=6
//JOB2 JOB (B189),SUNIL,CLASS=8,PRTY=9

 The MSGCLASS Parameter
 The MSGCLASS parameter assigns the job log for a job to a
particular sysout output class. MSGCLASS specifies the
default print class for all output data sets generated by the
job.
 MSGCLASS = n, where n is any value from A – Z or from
0 – 9. If omitted, the default MSGCLASS=A (Printer) is set
by the installation. The job log contains the JOB statement,
the JCL for the job, JCL processing messages, in-stream
and cataloged procedure statements, and JES2 messages
and MVS operator messages, if any.
23
MSGCLASS parameter
//JOB1 JOB (A189),SUNIL,CLASS=8,PRTY=6,MSGCLASS=A

MSGLEVEL Parameter
 The MSGLEVEL parameter is used to controls the
amount of system messages generated for a Job.
 The following job log elements can be controlled:
– Log messages indicating the job name, user name etc
routed to output device
– JCL statements comprising that job are output
– Messages related to execution of the job will be
output
– The output of the program being executed is output
24
MSGLEVEL=(statements, messages)
//JOB1 JOB (A189),MSGLEVEL=(1,1)

• Values for 'statements' in the MSGLEVEL
keyword can be one of these:
– 0 – Print only JOB statements
– 1 – Print all JCL and JES statements & messages
– 2 – Print only input JCL statements
• Values for 'messages' in the MSGLEVEL
keyword can be one of these:
– 0 – will result in only allocation/termination messages being output
if the job terminates abnormally
The system prints only JCL messages. It prints JES and operator
messages only if the job abnormally terminates, and prints SMS
messages only if SMS fails the job.
– 1 – will result in all allocation/termination message being output
regardless of whether the job terminates normally or abnormally
• Default value is (1,1)
25
MSGLEVEL Parameter

The JCL output for a batch job or any piece of work handled by JES2
or JES3 is a collection of three data sets. These three data sets (in the
order they appear in the output) are:
JES JOB LOG (JESMSGLG)
STATEMENT IMAGES (JESJCL)
SYSTEM MESSAGES (JESYSMSG)
Statements
Indicates which job control statements the system is to print in the
statement images portion of the JCL output. This subparameter is
one of the following numbers:
0 : The system prints the JOB statement and all comments and JCL
statements up to the first EXEC statement.
1 : The system prints all JCL statements, JES2 or JES3 control
statements, the procedure statements, and IEF653I messages, which
give the values assigned to symbolic parameters in the procedure
statements.
2 : The system prints only JCL statements and JES2 or JES3 control
statements.
26
MSGLEVEL Parameter

• Messages
Indicates which messages the system is to
print in the system messages portion of the JCL
output.
This subparameter is one of the following
numbers:
0 : The system prints only JCL messages. It
prints JES and operator messages only if the job
abnormally terminates, and prints SMS
messages only if SMS fails the job.
1 : The system prints JCL, JES, operator, and
SMS messages.27
MSGLEVEL Parameter

REGION parameter
• REGION: The REGION parameter specifies the
amount of computer memory allocated for your
job. If the REGION parameter is omitted, the
system uses a default region size set by the
installation.
• Syntax:
– REGION [.procstepname ]={valueK} / {valueM} = 0M
valueK Specifies the required storage in kilobytes
valueM Specifies the required storage in megabytes
– A JOB statement REGION parameter applies to all steps of the job and
overrides any EXEC statement REGION parameters.
• REGION=0K or REGION=0M
The above mentioned parameters allows the
program to request the largest available region
size.29

TYPRUN parameter
• The TYPRUN parameter is used to specify a special type
of job processing, such as whether a job is to be held
until it is released, and whether its execution
is to be suppressed altogether
• Syntax
TYPRUN=HOLD
or
TYPRUN=SCAN
30

TYPRUN parameter
• TYPRUN=HOLD
//JOB1 JOB (A123),’RANADE’,TYPRUN=HOLD
In this example, JOB1 will be held until it is released by
the operator
• TYPRUN=SCAN
//JOB1 JOB (A123),’RANADE’,TYPRUN=SCAN
In this example, the JCL will be checked for syntax
errors
31

NOTIFY Parameter
• NOTIFY: This parameter notifies TSO session of the
completion of a job. The message to the TSO terminal
indicates whether the job was cancelled or ABENDed.
• On your JCL JOB card, use the NOTIFY parameter as follows:
– //jobname JOB (accounting info,'description',)
// NOTIFY=userid where userid is 1 through 7
alphanumeric characters and must be valid one.
– NOTE: If you are logged on at the time the job completes,
the message will appear immediately. If not, the message
will appear the next time you begin a TSO session.
32
//JOB1 JOB (A123),’RANADE’,NOTIFY=ABCDEFG

TIME parameter
• The TIME parameter specifies the maximum CPU time
allocated for a job. If a job uses less than the amount
specified, then the account is billed only for the time used.
If a job tries to use more time than the maximum specified,
the job will terminate with an S322 ABEND. The TIME
parameter has two positional subparameters, minute and
second.
 TIME=(min,sec) or TIME=min or TIME=(,sec)
 The time parameter on the job card does not override
the step parameter.
33

• TIME=NOLIMIT or TIME=1440 – Indicates that the Job
can use the processor for the unlimited period of time.(
ie : 24 hrs)
• TIME=MAXIMUM – Indicates that the Job can use the
processor for the maximum amount of time ie: 357912
mins.(248.55 days)
34
TIME parameter

• TIME parameter coded on both Job and Exec
//JOB1 JOB (A123),’LITTLE
STEVIE’,TIME=12
//STEP1 EXEC
PGM=PROGRAM1,TIME=4
//STEP2 EXEC
PGM=PROGRAM2,TIME=4
//STEP3 EXEC
PGM=PROGRAM3,TIME=4
35
TIME parameter

RESTART Parameter
• . RESTART :
– It specifies the new starting step for a Job.
• RESTART=STEP2 – starts from the STEP2
• RESTART=Procname. Stepname – starts from the a step within a cataloged
procedure
• RESTART=* - starts from the first step.
• Note: Datasets created in or after restarted step of
previous run may still exist and should be deleted first
• RESTART=Y or RESTART=N
The restart parameter is used to restart a job if it
terminates abnormally. Setting RESTART to Y results
in the job being restarted from scratch. Setting it to N
results in the job being started from the step at which
it is terminated
36

EXEC
• EXEC (execute) statement is used to name the program
to be executed or invokes cataloged or in-stream
procedure that the job is to execute
• The EXEC statement marks the beginning of each step in
a job or a procedure.
• A job can have a maximum of 255 EXEC statements
Syntax
//stepname EXEC PGM=program-name,keyword parameters
37

EXEC(contd..)
38
Example
//STEPNAME EXEC PGM=TEST1
//STEPNAME EXEC PROC

EXEC statement Fields
• Name field:
– It must be unique within the job.
– The stepname must begin in column 3.
– It can contain max of 8 alphanumeric or national
characters
– The first character must be a alphabet.
• Operation Field:
– This field consists of characters EXEC and can start in
any column.
– The word EXEC must be preceded and followed by a
blank.
39

EXEC statement Fields
• Parameter field:
EXEC statement has 2 types of parameter fields.
– Positional Parameter Field
– Keyword Parameter Field.
• Comment field:
The comments field follows the parameter field after at
least one intervening blank.
40

Positional Parameter field
• The two positional parameter of EXEC
statements are:
– PGM
• It refers to a program name
• The program name must be 8 characters long.
– PROC or Procedure name
• It refers to procedure name.
41

PGM Parameter
• PGM parameter:
– It is used to name the program that the system is
to execute.
– Coded as first parameter in EXEC statement.
• The specified program must be a load member of a
partitioned data set (PDS) used as a system library, a
private library, or a temporary library.
• PGM=program-name
– Program name specifies the member name of the
program to be executed.
42

PGM Parameter(Example)
//JOB8 JOB BOB,MSGLEVEL=(2,)
//JOBLIB DD
DSNAME=DEPT12.LIB4,DISP=SHR
//STEP1 EXEC PGM=PROGRAM1
43

PROC Parameter
• Grouping JCL statements together and giving them a
name
• PROC parameter is used to specify that the system is to
call and execute a cataloged or in-stream procedure.
• Syntax
– {PROC=procedure-name} or {procedure-name}
• procedure-name Identifies the procedure to be called and
executed:
• The name on the PROC statement that begins an in-stream
procedure. The in-stream procedure must appear earlier in
this job.
• Not more than 255 job steps can be coded in one
procedure
44

PROC Parameter(Example)
//BK EXEC OPERATE
//SP3 EXEC PROC=PAYWKRS
45

PROC - Types
• Cataloged procedure
Grouping JCL statements together, giving them
a name, and recording the name as a partitioned
data set
• In-Stream Procedure
Grouping JCL statements together and making
them a part of the JCL input stream
46

IN-STREAM PROC
• An in-stream procedure is different in that they
are not members of partitioned datasets.
• They are included in input stream of job itself.
• Rules for coding IN-STREAM PROC’s
– They must begin with PROC statement
– They end with PEND statement
– They must be coded immediately after JOB statement
& before first EXEC statement
– No more than 15 in-stream procedures can be coded
in a Job
47

IN-STREAM PROC(contd..)
//JOB1 JOB (A123),NAME
//INST1 PROC
//DD1 DD DSN=FILE1,DISP=SHR
//DD2 DD DSN=FILE2,DISP=DHR
// PEND
//STEP3 EXEC INST1
The EXEC statements between PROC & PEND statements are
not executed when they are first encountered in the Job Stream,
but they are saved as a procedure so that they can be executed
later. It is executed when the EXEC statement mentioning the
IN-STREAM procedure is encountered.
48

Cataloged procedures
• A cataloged procedure is a set of job control statements
that are grouped together, given a name and then
recorded as a member of a partitioned dataset.
• Rules for coding cataloged proc
 They must begin with PROC statement
 PEND statement is not required
 The procedure name must be unique within the
procedure library.
 Once the procedure has been created and tested, it can
be catalogued and placed inside a system or user defined
library
49

Sample JCL demonstrating the
cataloged procedurePROCEDURE
//CATALOG1 PROC
JOB calling the above PROC
//JOB1 JOB
//PROCLIB DD DSN=USER.TEST.PROCLIB,DISP=SHR
//JOBLIB DD DSN=USER.TEST.JOBLIB,DISP=SHR
//DATA2 EXEC CATALOG1
50

Catalogued vs
In stream procedure• Cataloged procedures are members of PDS and remain
there until they are deleted. In stream procedures are not
members of PDS, and exist only for the duration of the
job
• PROC statement is mandatory in both procedures
• PEND statement cannot not coded in catalogued
procedures
51

Keyword Parameters
of EXEC statement
• Must follow positional parameters.
• Can be coded in any sequence
• The keyword parameter coded in a jobstep
will apply only to that step
• Keyword parameters
– ACCT
– PARM
– ADDRSPC
– DPRTY
– COND
– REGION
– TIME
52

ACCT
• Used to supply accounting information for the job step
that it is used in
• Syntax
ACCT=account-information
• Account information can contain more than one sub
parameter
• Max number of characters that can be included in
accounting information including commas is 142
• Ex
//STEP1 EXEC PGM=PROGRAM1,ACCT=(A123,RR)
53

ADDRSPC
• ADDRSPC –(Address Space) Indicates the type of storage for the
present step.
– This parameter cannot override the specific type of storage coded in
the job statement but can override the system default.
– Syntax=ADDRSPC[procstepname]={VIRT/REAL}
• VIRT - requests virtual storage. The system can page the job
step.
• REAL - requests real storage. The system cannot page the job
step and must place the job step in central storage.
• The system uses the EXEC statement ADDRSPC parameter only
when no ADDRSPC parameter is on the job statement.
– Example
• //CAC1 EXEC PGM=A,ADDRSPC=VIRT
• //CAC2 EXEC PROC=B,ADDRSPC=REAL,REGION=8K
54

DPRTY
• Assign a dispatching priority to the job step to
determine the order in which the tasks are to be
executed
• Syntax
DRPTY=(value1, value2)
value1 => 0-15 specifies the priority of the jobstep
higher the number higher the prioirty
value2 => 0-15
DPRTY=(value1)*(16) + value2
• Exa
//JOB1 JOB (A123),’RANANDE’
//STEP1 EXEC PGM=PROGRAM1,DPRTY(12,9)
Priority in STEP1 is determined as
(12*16) + 9 = 192 + 9 = 201
55

COND Parameter
• COND: This parameter is used to test the return codes
from previous job steps in order to determine if the
present step is to be executed or bypassed.
• Syntax= COND[.procstepname]=(code, relational
operator,[step name])
If the condition is false, then the step will get executed
and if the condition is true, the step will be bypassed.
E.g. COND=(30,LE)
56

Condition Codes
• Condition codes can range from 0 to 4095.
Common condition codes are:
– 0 no errors or warnings detected
– 4 possible error (warning) detected but execution is possible.
– 8 serious error detected, likely to fail.
– 12 severe error detected, execution impossible.
– 16 terminal error, execution cannot continue
• The condition parameter coded on the JOB statement applies
to all the job steps within the job, and it overrides COND parameters
coded on the EXEC statement, if they exist.
• The relational operators that can be used are GT, GE, LT, LE, EQ &
NE.
57

COND – Examples
• Example 1
//JOB1 JOB (A123),’JERRY’,COND=(4,LT)
• Example 2
//JOB1 JOB (A123),’JERRY’,COND=(4,GT)
• Example 3
//JOB1 JOB (A123),’JERRY’,COND=((4,GE)),(9,LT))
58

COND in EXEC statement
• The COND parameter coded on the EXEC statement applies
only to the step that it is coded in. The job step is executed or
bypassed depending upon the condition codes issues by one
or more prior job steps
• Syntax
COND=(comparison-code,condition,stepname,ONLY)
• Stepname : specifies the name of the preceding step whose
return code is to be checked.
• If COND=EVEN executes the Jobstep whether or not the
previous step has abended.
• COND=ONLY is used for steps that perform recovery
processing that should be invoked only in the event of an
abend. It helps to execute the Jobstep only if a previous step
has abended.
59

COND – Examples
• Example 1
//JOB1 JOB (A123),’JERRY’
//STEP2 EXEC PGM=PROGRAM2,COND=(8,EQ,STEP1)
• Example 2
//STEP2 EXEC PGM=PROGRAM2,COND=(0,LT)
• Example 3
//STEP3 EXEC PGM=PROGRAM3,COND=(8,GE),(80,LE STEP1)
60

COND – Examples
61
 Example 4
//STEP2 EXEC PGM=PROGRAM2,COND=EVEN
 Example 5
//STEP2 EXEC PGM=PROGRAM2,COND=ONLY

PARM Parameter
• PARM : Passes control information to the job
step when the step is initiated.
• This is useful for passing runtime
information to an application program
• Syntax
PARM[procstepname]= information.
• Information can be of 100 characters.
Examples
//STEP1 EXEC PGM=PROGRAM1,PARM=‘M’
LINKAGE SECTION.
01 PARM-FIELD.
05 PARM-LENGTH PIC S9(04) COMP.
05 PARM-RUN-TYPE PIC X(01).
62

PARM Parameter(Examples)
• The system passes P1,123,P2=5 to the processing
program named APG22.
RUN3 EXEC PGM=APG22,PARM='P1,123,P2=5‘
• The system passes MT5 to the first step of the procedure
named PROC81. If PROC81 contains more steps and
their EXEC statements contain PARM parameters, the
system nullifies those PARM parameters.
ABCDEF EXEC PROC81,PARM=MT5
63

REGION Parameter
• Region
– This parameter is used to specify the amount of central or
virtual storage that the steps requires(inclusive of the
storage for all the programs in the step to be executed.)
• Syntax:
– REGION [.procstepname ]={valueK}
{valueM}
– valueK Specifies the required storage in kilobytes
– valueM Specifies the required storage in megabytes
– A JOB statement REGION parameter applies to all steps of
the job and overrides any EXEC statement REGION
parameters.
64

Examples
• Example
• //MKBOYLE EXEC
PROC=A,ADDRSPC=REAL,REGION=40
K
• //STP6 EXEC
PGM=CONT,REGION=120K
65

Time Parameter
• TIME parameter is used to specify the maximum
amount of time that a job step may use the
processor or to find out through messages how
much processor time a step used.
• You can use the TIME parameter on an EXEC
statement to increase or decrease the amount of
processor time available to a job step over the
default value.
• TIME [.procstepname ]= {([minutes ][,seconds ])}
{1440 }
{NOLIMIT }
{MAXIMUM }
66

Time Parameter(Example)
//STEP1 EXEC PGM=GRYS,TIME=(12,1 )
//FOUR EXEC PGM=JPLUS,TIME=(,3 )
//INT EXEC PGM=CALC,TIME=5
//LONG EXEC PGM=INVANL,TIME=NOLIMIT
67

DD STATEMENT
• DD (data definition) statement is used to convey information
about the data that will be read or written within Job.
• Syntax:
– //ELECSTD DD DSN=PSET.CDRS.SAS.CDRS341.ELECSTD.FLATFILE,
– // DISP=SHR
• The DD statement must immediately follow the EXEC
statement
• The DD statement consists of the characters // in columns 1
and 2 and four fields: name, operation (DD), parameter, and
comments.
• A DD statement is required for each data set.
• Each ddname should be unique within the job step.
• The ddname is 1 through 8 alphanumeric or national ($, #, @)
characters.
• The first character must be alphabetic or national ($, #, @).
• The ddname must be followed by at least one blank.68

DD Statement Fields
• Name field:
Each ddname should be unique within the job step.
• Operation Field:
The operation field consists of the characters DD and must be
preceded and followed by at least one blank. It can begin in
any column.
• Comments Field:
The comments field follows the parameter field after at least
one intervening blank.
• Parameter Field:
A DD statement has two kinds of parameters: positional and
keyword.
69

DDNAME s reserved
for system use
70
JOBLIB
SYSABEND
SYSIN
SYSOUT

of DD statements
• May be coded in the operands field.
• Positional Parameters
– *
– DATA
– DUMMY
71

of DD statements
• * specifies that data follows immediately; no keyword
parameters may follow. The data may not contain any
records beginning with // or /*.
– A cataloged or in-stream procedure cannot contain a
DD * statement.
//JOB1 JOB A100,JOHN
//SYSIN DD *
< Lines of data>
/*
72

of DD statements
• DATA : specifies that data follows immediately;
keyword parameters may follow the DATA positional
parameter.
• DUMMY : specifies that if the file is an output file, the
output is to be discarded. If the file is an input file, it
specifies that there is no data.
• Example
– //MYDS DD DSNAME=REPORT
– //A DD DSNAME=FILE
73

Temporary vs Permanent dataset
• A temporary data set is a data set that you create
and delete within a job. When you use DSNAME
for a temporary data set, code the name as two
ampersands (&&) followed by a character string 1
to 8 characters in length
&&dsname Specifies the name of a temporary data set.
• Example
//JOB1 JOB A123,’JOE HARRY’
//DATA1 DD DSN=&&TEMPDATA
• A permanent data set is not deleted after a job
completion and may be catalogued, if requested.
//JOB1 JOB A123,’JOE HARRY’
//DATA1 DD DSN=USER.TEST.REVENUE.FILE,DISP=SHR
74

DUMMY/NULL FILE
• Data Set Name for Dummy Data Set :
– NULLFILE
– Specifies a dummy data set. NULLFILE has the same
effect as coding the DD DUMMY parameter.
NULLFILE must be coded as a single-word
parameter.
75

Keyword Parameters
of DD statement
• Keyword parameters must follow the positional
parameters if both are coded
76
 Syntax
//ddname DD DSN=data_set_name,
DISP=(status,normal_disposition,abnormal_disposition
)
 DSN
 DISP
 UNIT
 SPACE
 DCB
 VOLUME

DISP Parameter
• Used to instruct the system as to the current status
of a data set
• It also indicates the steps to be taken with the
dataset upon successful or unsuccessful execution
of a Job
• Syntax DISP=(status,normal-disposition,abnormal-
disposition)
• status - indicates current status of dataset
– NEW – the dataset does not exist and should be created
– OLD – the dataset exists and should be allocated for exclusive use
– SHR – the dataset exists and should be allocated for shared use
– MOD – the dataset is allocated for exclusive use and is positioned at the end
of the data, so additional records may be added after last record
77

DISP Parameter
• normal-disposition –
specifies how the dataset is to disposed
upon normal execution of job
– DELETE – the dataset is deleted . If the dataset was retrieved from
catalog, it is also uncataloged
– KEEP – the dataset is retained
– CATLG – the dataset is retained and catalog entry is made
– UNCATLG – the dataset is retained but it’s catalog entry remove
– PASS – Normal disposition only. The dataset is retained for use by
a later job step
78

DISP Parameter
• abnormal-disposition –
specifies how the dataset is to be disposed
upon abnormal execution of job
– DELETE – the dataset is deleted . If the dataset was retrieved from
catalog, it is also uncataloged
– KEEP – the dataset is retained
– CATLG – the dataset is retained and catalog entry is made
– UNCATLG – the dataset is retained but it’s catalog entry remove
79

DISP Parameter
• Default values for DISP parameter
If status subparameter is omitted MVS assumes it as
NEW
If normal-disposition subparameter is omitted the
default depends on the status subparameter
If status subparameter is NEW the normal
disposition subparameter is DELETE else KEEP
If abnormal disposition subparameter is omitted it
takes whatever value specified in normal disposition
subparameter
80

DISP Parameter
 DISP=SHR
Allocates an existing dataset for shared access, normal and
abnormal disposition parameter default is KEEP
• DISP=OLD
Allocates an existing dataset for exclusive access, normal and
abnormal disposition default set to KEEP
• DISP=MOD
If dataset exists, extend it else create it. The access is exclusive,
normal and abnormal disposition default is set to KEEP
• DISP=(NEW,CATLG)
Allocates a new dataset and catalogs it, abnormal disposition
set to CATLG
81

DISP Parameter
• DISP=(OLD,DELETE)
Allocates and existing dataset and deletes it , abnormal
disposition set to DELETE
• DISP=(,KEEP,DELETE)
Allocates a new dataset and keeps it if job step ends
normally, if job step ends abnormally the dataset is
deleted
• DISP=(NEW,CATLG,DELETE)
The dataset is created, cataloged if the job step ends
normally and deletes it if job step ends abnormally
82

UNIT Parameter
• UNIT : specifies whether the dataset is to reside on disk
or tape; device can be DISK for disk datasets, TAPE for
cartridge tape datasets, or REEL for reel (round) tape
datasets.
• UNIT= [device_address]
//JOB1 JOB A123,’NAME’
//STEP1 EXEC PGM=PGM1
//DATA1 DD DSN=FILE1,
// UNIT=S04
• UNIT= [device_type]
// UNIT=3390
83

UNIT Parameter
 UNIT=[device_group_name]
// UNIT=SYSDA
• UNIT=[AFF=ddname]
//JOB1 JOB D13,KIRAN
//NAME1 DD DSN=DATA1,
// UNIT=CART
//NAME2 DD DSN=DATA2,
// UNIT=AFF=NAME1
84

UNIT Parameter
• UNIT=[device,DEFER]
//JOB4 JOB S123,’NAME5’
//STEP2 EXEC=PGM4
//NAME DD DSN=DATA3,
// UNIT=(TAPE,,DEFER)
85

VOLUME Parameter
• VOL parameter
– Specifies the volume on which the dataset resides; name is either
a disk pack or a tape name.
– This parameter can be omitted for an existing catalogued data
set.
• VOL=SER
– This is used to request specific volumes
• //JOB1 JOB D12,’GIREESH’
• //STEP1 EXEC PGM=PGM1
• //NAME1 DD DSN=DATA1,
• // VOL=SER=23456
• VOL=REF subparameter
– This is used to specify a volume which has been previously
defined within same Job, but not in current step
– VOL=REF=*.referback
86

VOLUME Parameter
//JOB1 JOB C123,’JANNET’
//DD1 DD DSN=DATA1,
// VOL=SER=VOL1
//DD2 DD DSN=DATA2,
// VOL=REF=*.STEP1.DD1
87

SPACE Parameter
• Space parameter:
– Used to specify the storage requirements on direct access devices
– Syntax SPACE=
(CYL,(primary,secondary,directory),RLSE)
– =
(TRK,(primary,secondary,directory),RLSE)
– =
(BLK,(primary,secondary,directory),RLSE)
– Primary – specifies how many units of space to allocate for
the dataset’s primary extents.
– Secondary – if the file requires space more than what is
allocated in primary extent, secondary extents can be used
to allocate upto 15 times the primary extents
– Directory – this is used only for partitioned datasets
• this is used to record the names and locations of members
created within partitioned datasets
• It should be a number that specifies how many 256-byte blocks
are to be contained in the directory of a PDS88

SPACE Parameter
• RLSE –
specifies that any unused space is to be released when
the job step is finished with the data set.
– This parameter is optional; it should be coded for
sequential data sets only.
Example
– SPACE=(TRK,(20,5),RLSE)
– The maximum space that could be allocated is: 20 +
5(15) = 95 tracks.
89

DCB Parameter
• The DCB parameter contains the information necessary to complete the
data control block.
• Syntax
DCB=(RECFM=format,LRECL=record-length,
BLKSIZE=block-size)
//DD1A DD DSNAME=EVER,
// DISP=(NEW,KEEP),
// UNIT=SYSDA,
//
DCB=(RECFM=FB,LRECL=326,BLKSIZE=23472),
// SPACE =(TRK,(20,5),RLSE)
90

DCB Parameter
• Important subparameters of DCB parameter:
• BLKSIZE : specifies the number of bytes (characters) per
block,where b is a multiple of the LRECL.
• LRECL : specifies the logical record length (n) for fixed
or variable length records; omit LRECL for records of
undefined length.
91

DCB Parameter
• RECFM : specifies the record format. Common values
for RECFM are
– U for undefined-length records,
– V or VB for variable-length or variable-blocked
records,
– F or FB for fixed-length or fixed-blocked records, and
– FA, FBA, or VBA for fixed, fixed-blocked, or variable-
blocked records with a printer control character as the
first byte of data.
92

SYSOUT Parameter
• SYSOUT :
– Specifies one character output class associated with
SYSOUT dataset
– Syntax SYSOUT=class
– If SYSOUT=* then output class specified in
MSGCLASS parameter of JOB statement is used
– Routes the system output to the class associated with
output device indicated
– class can be any alphanumeric character from A – Z,
0 – 9 or *
93

JOBLIB DD Statement
• JOBLIB statement:
– Identifies a private library that the system is to search for
the program named in each EXEC statement PGM
parameter in the job.
– Only if the system does not find the program in the private
library, does it search system libraries.
– Syntax //JOBLIB DD parameter [,parameter ]...[comments
]
• We can concatenate job libraries
• Do not include a JOBLIB DD statement in an in-stream or
cataloged procedure.
94

JOBLIB DD Statement
//JOB1 JOB A123,’BHASKAR’
//JOBLIB DD DSN=M1.TEST.LOADLIB,
// DISP=SHR
===============================================
=
//L140 JOB (00124,'PURGE PGM'),
//
CLASS=N,MSGCLASS=P,TIME=1440,REGION=6M
//JOBLIB DD DSN=IPHP.BT.PGMLIB,DISP=SHR
// DD DSN=IPHP.OL.PGMLIB,DISP=SHR
// DD DSN=SYS5.PROSERV.EXITS,DISP=SHR
// DD DSN=S00P.BT.PGMLIB,DISP=SHR
// DD DSN=S00P.OL.PGMLIB,DISP=SHR
95

STEPLIB DD Statement
• Use the STEPLIB DD statement to
– Syntax //STEPLIB DD parameter [,parameter
]...[comments ]
– Overriding a JOBLIB
• If the system lib is defined in a STEPLIB DD statement then
the system will ignore the JOBLIB DD statement for that
step.
96

STEPLIB DD Statement
//PAYROLL JOB BAKER,MSGLEVEL=1
//JOBLIB DD
DSNAME=LIB5.GROUP4,DISP=(OLD,PASS)
//STEP1 EXEC PROC=SNZ12
//STEP2 EXEC PGM=SNAP1
//STEPLIB DD
DSNAME=LIBRARYP,DISP=(OLD,PASS),
// UNIT=335
,VOLUME=SER=55566
//STEP3 EXEC PGM=A153
//STEP4 EXEC PGM=SNAP11
//STEPLIB DD DSNAME=*.STEP2.STEPLIB,
// DISP=(OLD,KEEP)
97

Concatenating Data Sets
• Datasets can be concatenated and perceived together as
one file by coding each applicable dataset name one after
another
• Rules for coding
– Up to 255 sequential datasets and 16 PDS files can be
concatenated together
– The LRECL value must be same for all the datasets.
– All datasets concatenated together must have the same type of
record format
– All datasets concatenated together must exist in the same type of
device
– The dataset which has the largest bulksize must be given first.
98

Concatenating Data Sets
 If tape datasets are concatenated datasets together, then
block size of the first dataset must be larger than or
equal to, that of the subsequent dataset
 A PS cannot be concatenated with PDS.
Sample JCL
//JOB1 JOB 001,’AL’
//STEP1 EXEC PFM=CONCAT1
//DATA1 DD DSN=FILE1
// DD DSN=FILE2
// DD DSN=FILE3
– Here the files FILE1,FILE2 & FILE3 are concatenated
together.
99

Referring Back of Datasets
• A referback is a reference to an earlier DD statement in
the job or in a catalogued or in-stream procedure called
by a job step.
• A referback is in the form of *.ddname or
*.stepname.ddname or
*stepname.procstepname.ddname.
//INPUT DD DSN=*.STEP1.OUTPUT
//OUTPUT DD DSN=CLASS.FILE,DCB=*STEP1.OUT1
100

JCLLIB statement
• JCLLIB statement is used to identify the names of the
private libraries that the system uses for the job.
• Syntax
• //[name ]JCLLIB ORDER=(library [,library
]...)[comments ]
• The private libraries that you specify on the JCLLIB
statement must comply with following rules:
– The private library must be cataloged.
– The private library must be accessible to the job.
• JCLLIB statement should be coded after JOB statement
and before first exec statement.
• //JCLLIB DD DSN=MMA2.PROCLIB,DISP=SHR
101

Utilities
• IEBGENER
Copy sequential files
• IEBCOPY
Copy partitioned data sets
Compress partitioned data sets
• IEFBR14
Null program commonly used for creation, deletion or
updating a dataset with out having to execute any
specific datasets
102

GDG – Generation Data Groups
• These are groups of datasets that are related to each
other chronologically and functionally
• Index
– NAME
– LIMIT
– EMPTY/NOEMPTY
– SCRATCH/NOSCRATH
103

How to define a GDG index
//JOB1 JOB (A123),’TEST JOB’
//STEP1 EXEC PGM=IDCAMS
//SYSIN DD *
DEFINE GDG(NAME(FINANCES.MONTHLY)-
LIMIT(5) -
NOEMPTY -
SCRATCH)
/*
//
104

How to define a GDG index
//SYSIN DD *
DEFINE GDG(NAME(FINANCES.MONTHLY)-
LIMIT(5) -
NOEMPTY -
SCRATCH)
/*
//
105

Creating a GDG dataset
//JOB1 JOB (A123),’CREATE GDG DATASET’
//STEP1 EXEC PGM=ABCDEF
//INFILE DD DSN=TEST.FILE1,DISP=SHR
//OUTFILE DD DSN=FINANCES.MONTHLY(+1),
// DISP=(NEW,CATLG,DELETE),
// UNIT=SYSDA,
// SPACE=(CYL,(100,50),RLSE),
// DCB=(MODEL.DCB,RECFM=FB,
// LRECL=80,BLKSIZE=800)
106

Deleting a GDG
Deleting a GDG dataset
//STEP1 EXEC PGM=IEFBR14
//DEL1 DD DSN=FINANCES.MONTHLY(0),
// DISP=(OLD,DELETE,DELETE)
Deleting a GDG INDEX
//SYSIN DD *
DELETE(FINANCES.MONTHLY)GDG
/*
107

Deleting a GDG
Deleting a GDG INDEX Using FORCE
//SYSIN DD *
DELETE(FINANCES.MONTHLY)GDG FORCE
/*
108

Utilities – SORT
//SORT1 JOB (A123),’TEST SORT JOB’
//STEP1 EXEC PGM=SORT
//SYSOUT DD SYSOUT=*
//SORTIN DD DSN=TEST.FILE,
// DISP=SHR
//SORTOUT DD DSN=TEST.FILE.SORTED,
// UNIT=SYSDA
// DCB=(RECFM=F,LECL=80,BLKSIZE=800)
//SORTWK01 DD UNIT=SYSDA,
// SPACE =(CYL,(100,50),RLSE),
//SORTWK02 DD UNIT=SYSDA,
// SPACE =(CYL,(100,50),RLSE),
//SYSIN DD *
SORT FIELDS=(2,5,CH,A)
/*
//
109

Utilities – SORT
 TO COPY ALL THE RECORDS FROM INPUT FILE TO OUTPUT FILE
SORT FIELDS=COPY
 TO COPY THOSE RECORDS WHICH SATISFY A PARTICULAR
CONDITION.
INCLUDE COND=(38,10,CH,EQ,C'57071509',OR,36,10,CH,EQ,C' 57105779')
 TO OMIT THOSE RECORDS WHICH SATISFY A PARTICULAR
CONDITION.
OMIT COND=(19,1,CH,EQ,C'S',OR,19,1,CH,EQ,C'S')
 TO SKIP CERTAIN NO OF RECORDS
SORT FIELDS=COPY,SKIPREC=1000
 TO STOP AFTER COPYING CERTAIN NO OF RECORDS
SORT FIELDS=COPY,STOPAFT=5000
110

Utilities – SORT
 SKIPREC AND STOPREC CAN BE USED IN COMBINATION
SORT FIELDS=COPY,SKIPREC=1000,STOPAFT=5000
111

Utilities – MERGE
//SORTIN01 DD DSN=TEST.FILE1,DISP=SHR
//OUTFILE DD DSN=TEST.FILE.SORTED,
// UNIT=SYSDA,
//SYSIN DD *
MERGE FIELDS=(2,5,CH,A)
/*
//
112

Common Abend Codes
Code Description
SOC4 Subscript being out of range
SOC7 Caused by bad data, which the program was unable
to detect
S222 Caused by the job being cancelled by the operator
SB37 Caused by lack of sufficient secondary space
SE37 Caused by lack of space for PDS
SD37 Caused by lack of sufficient primary space
113

Utilities – MERGE
// UNIT=SYSDA,
//SYSIN DD *
MERGE FIELDS=(2,5,CH,A)
/*
//
114

Utilities – MERGE
// UNIT=SYSDA,
//SYSIN DD *
MERGE FIELDS=(2,5,A,CH)
/*
//
115

Utilities – MERGE
// UNIT=SYSDA,
//SYSIN DD *
MERGE FIELDS=(2,5,A,CH)
/*
//
116

Skillwise JCL

Recommended

Recommended

More Related Content

What's hot

What's hot (20)

Viewers also liked

Viewers also liked (15)

Similar to Skillwise JCL

Similar to Skillwise JCL (20)

More from Skillwise Group

More from Skillwise Group (20)

Recently uploaded

Recently uploaded (20)

Skillwise JCL
