2. Assignment: Vector - Scalar Cornell Notes
SC.912.P.12.1 Distinguish between scalar and vector quantiti
Scale
4: Extra Credit Extension: Design an
experiment using an everyday physical
activity that will provide data, develop
graphs to analyze vector and scalar
quantities (One page with data chart and
graph. 5-points)
3: I can describe the differences
between vectors and scalars and
when to use them.
2: I can describe the differences
between vectors and scalars
1: I can define vectors and scalars
with help from the textbook.
4. What is a Scalar Quantity?
Only has magnitude
Requires 2 things:
1. A value
2. Appropriate units
5. What is a Vector Quantity?
Has magnitude (size, amount) & direction
Requires 3 things:
1. A value
2. Appropriate units
3. A direction!
6. Exit Slip: On index card, write your name.
Draw the t-chart and sort the measurements using your
chart
Scalar Vectors
30
mph
30
mph
50o
C50o
C120
lbs
120
lbs
5
Blocks
East
5
Blocks
East
Falls 5
degrees
Falls 5
degrees
2.5
m/s
North
2.5
m/s
North
3pm3pm
7.
8. More about Vectors
A vector is represented on paper by an arrow
1. the length represents magnitude
2. the arrow faces the direction of motion
3. a vector can be “picked up” and moved on
the paper as long as the length and
direction
its pointing does not change
9. Graphical Representation of a Vector
The goal is to draw a mini version of the vectors to give
you an accurate picture of the magnitude and
direction. To do so, you must:
1. Pick a scale to represent the vectors. Make it simple
yet appropriate.
2. Draw the tip of the vector as an arrow pointing in
the appropriate direction.
3. Use a ruler & protractor to draw arrows for
accuracy. The angle is always measured from the
horizontal or vertical.
10. Understanding Vector Directions
To accurately draw a given vector, start at the second direction
and move the given degrees to the first direction.
N
S
EW
30° N of E
Start on the East
origin and turn 30° to
the North
11. Graphical Representation Practice
5.0 m/s East
(suggested scale: 1 cm = 1 m/s)
300 Newtons 60° South of East
(suggested scale: 1 cm = 100 N)
0.40 m 25° East of North
(suggested scale: 5 cm = 0.1 m)
12. Graphical Addition of Vectors (cont.)
5 Km
3 Km
Scale: 1 Km = 1 cm
Resultant Vector (red) = 6 cm,
therefore its 6 km.
13. Vector Addition Example #1
Use a graphical representation to solve the
following: A hiker walks 1 km west, then 2
km south, then 3 km west. What is the sum of
his distance traveled using a graphical
representation?
15. Vector Addition Example #2
Use a graphical representation to solve the
following: Another hiker walks 2 km south
and 4 km west. What is the sum of her
distance traveled using a graphical
representation? How does it compare to hiker
#1?
17. Assignment: Vector - Scalar Cornell Notes
SC.912.P.12.1 Distinguish between scalar and vector quantiti
Scale
4: Extra Credit Extension: Design an
experiment using an everyday physical
activity that will provide data, develop
graphs to analyze vector and scalar
quantities (One page with data chart and
graph. 5-points)
3: I can describe the differences
between vectors and scalars and
when to use them.
2: I can describe the differences
between vectors and scalars
1: I can define vectors and scalars
with help from the textbook.
19. Acceleration
Speed is the rate of change of position.
Acceleration is the rate of change of velocity.
What form of measurement is acceleration, scalar
or vector?
Hint:
20. Acceleration
• Acceleration is a vector which measures the change in
the velocity of an object.
• It has magnitude and direction.
• This means acceleration could be any of the following
three…
1. a change in speed, the magnitude of the
velocity (from 34 km/h to 67 km/h)
2. a change in direction (from East to North-
East)
3. a change in both speed and direction (from
34km/h East to 12 km/h West)
24. Negative Acceleration
In physics, acceleration is not always an
increase in velocity. It can also be a decrease
in velocity.
Even though you might have heard people use
the word deceleration to describe an object
slowing down, this isn’t really proper physics.
25. Negative Acceleration
• We usually visualize speeding up as positive,
and slowing down as negative.
• A positive velocity means it’s going in the
positive direction (like forwards), and a
negative direction is backwards.
