USB PD Introduction
•
0 likes•1,811 views
USB PD (Universal Serial Bus Power Delivery) is a specification that enables flexible power delivery and data transfer over a single USB cable. It allows devices to negotiate the power they require through communication with the power source. This increases power levels above existing USB standards, up to 100W. It also allows power to flow in either direction and devices to draw only the power needed for a given application in order to optimize power management across multiple devices.
