This document provides a learning guide with 10 questions to help prepare for the load chart and rigging assessment for a Level A CraneSafe certification for mobile hydraulic cranes under 80 tonnes. It includes the questions, answers which explain how the answers were determined, and relevant load chart information to answer the questions without needing the full crane manual or load chart package. The guide notes that operators must correctly answer at least 7 of the 10 questions to demonstrate competency in load charts and rigging. It also contains tables with load chart information and operating instructions for the Tadano RT GR-600XL-1 60 ton hydraulic rough terrain crane.
