TAPVC A CASE STUDY
- 2. CASE STUDY TAPVC REPAIR JAYA BABU S STAFF NURSE CHICU
- 3. PATIENT PROFILE • 50 DAY OLD BABY • FIRST CHILD ,FULL TERM NORMAL DELIVERY • BIRTH WEIGHT -2.7 Kg • H/o bronchopneumonia at the age of 1 month • Based on investigations and clinical symptoms detected to have SUPRACARDIAC TAPVC • Underwent TAPVC rerouting
- 5. TAPVC TOTAL ANOMALOUS PULMORAY VENOUS CONNECTION NO DIRECT CONNECTION BETWEEN ANY PULMOARY VEIN AND LEFT ATRIUM ALL THE PULMONARY VEINS CONNECT TO RIGHT ATRIUM OR ONE OF ITS TRIBUTARIES
- 6. TYPES SUPRACARDIAC 45% CARDIAC 25% INFRACARDIAC 25% MIXED 5%
- 7. SUPRACARDIAC TAPVC PULMONARY VEINS CONVERGE BEHIND THE LEFT ATRIUM COMMON ANOMALOUS VERTICAL VEIN LEFT INNOMINATE VEIN
- 9. CARDIAC TAPVC The pulmonary venous confluence drains into the coronary sinus
- 10. INFRACARDIAC TAPVC The pulmonary venous confluence drains into a descending vertical vein through the diaphragm into the portal vein or ductus venosus.
- 11. MIXED TAPVC It can involve any or all components of the previous three types.
- 12. PATHOPHYSIOLOGY • COMPLETE LA PV DISCONNECTION • PV BLOOD GOING INTO RA • AN INTRAATRIAL COMMUNICATION USUALLY ASD OR PFO • DEGREE OF CYANOSIS DEPEND ON AMOUNT OF PULMONARY BLOOD FLOW
- 13. PATHOPHYSIOLOGY….. INCREASED PULMONARY BLOOD FLOW PULMONARY HYPERTENSION MUSCULARITY OF THE PULMONARY ARTERIOLES LABILE PULMONARY VASCULAR RESISTANCE
- 14. OBSTRUCTION TO PULMONARY VENOUS DRAINAGE SUPRACARDIAC 65% CARDIAC 17-20% INFRACARDAIC 100% SUPRACARDIAC STENOSIS OF THE LEFT VERTICAL VEIN COMPRESSION OF VERTICAL VEIN BETWEEN PULMONARY ARTERY AND LEFT MAIN BRONCHUS ANATOMIC VISE
- 15. OBSTRUCTED TAPVC … AT THE JUNCTION WHERE THE COMMON VEIN JOINS THE CORONARY SINUS AT THE ORIFICE OF THE CORONARY SINUS
- 16. OBSTRUCTED TAPVC … STENOSIS WHERE IT ENTERS PORTAL OR HEPATIC VEIN OR DUCTUS VENOSUS COMPRESSION PASSING THROUGH THE DIAPHRAGM HIGH RESISTANCE PATHWAYS IMPOSED BY FLOW THROUGH HEPATIC MICROVESSELS
- 17. CLINICAL MANIFESTATIONS UNOBSTRUCTED TYPE ASYMPTAMATIC ONLY MILD CYANOSIS FAILURE TO THRIVE DYSPHONIA SLIGHT HEPATOMEGALY CARDIOMEGALY SYSTOLIC EJECTION MURMUR SNOWMAN SIGN IN C-XRAY
- 18. OBSTRUCTED TYPE SYMPTAMATIC WITHIN FEW HOURS AFTER BIRTH • MARKED RESPIRATORY DISTRESS WITH CYANOSIS • FEATURES OF PULMONARY OEDEMA • PROGRESS TO CARDIOGENIC SHOCK • XRAY SHOWS MARKED VENOUS CONGESTION WITH A GROUND GLASS APPEARANCE AND NO CARDIOMEGALY
- 19. Medical management UNOBSTRUCTED TYPE • COMPENSATING RIGHT HEART FAILURE – INOTROPIC SUPPORT – DIURESIS • OBSTRUCTED TYPE LIMITED ROLE INTUBATION AND HYPERVENTILATION CORRECTION OF ACIDOSIS OBSTRUCTED TAPVC IS A TRUE SURGICAL EMERGENCY!!!!!!!!!
- 20. Interrupt the connections with the systemic venous circulation An unobstructed communication between the pulmonary venous confluence and the left atrium close the atrial septal defect SURGERY
- 21. SC TAPVC SURGICAL TECHNIQUE
- 23. POSTOPERATIVE COMPLICATIONS • PULMONARY OEDEMA • PULMONARY HYPERTENSIVE CRISES • PHRENIC NERVE DAMAGE EARLY COMPLICATIONS • PULMONARY VENOUS OBSTRUCTION • ANASTOMOTIC STRICTURE • PULMONARY VEIN STENOSIS LATE COMPLICATIONS
- 24. KEY POINTS IN POSTOPERATIVE CARE Maintain adequate cardiac output Keep the left atrial pressure as low as possible Prevention and management of PAH crises
- 25. PA PRESSURE MONITORING • PAP should be than less than 2/3 rd of the systemic pressure • In PAH CRISIS, PAP becomes suprasystemic.
- 26. Rapid increase in PVR PAP exceeds systemic blood pressure (BP). Decrease in pulmonary blood flow Decreased cardiac output, hypoxia, PAH CRISIS
- 27. RECOGNITION OF PAH CRISIS TACHYCARDIA High PAP ABRUPT DESATURATION HYPOTENSION BRADYCARDIA
- 28. Correct metabolic acidosis. PREVENTI ON Hyperventilate sedation Attenuate noxious stimuli Support cardiac output. 100% oxygen. pulmonary vasodilators.
- 29. POSTOPERATIVE COURSE • SURGERY: Primary sutureless repair by right lateral approach. • Received in ICU with stented sternum and PA line in situ. • On ventilator with FiO2 80% – SIMV 32/TV-30/PEEP-4 – Ph-7.45 / Pao2-99.4 / Paco2-34.4 Lactate-0.9 • Stable hemodynamic – ABP:109/71 PAP:35/23(29) CVP:7 • Sedated with Morphine • Milrinone 0.5mcg/kg/mt
- 30. POSTOPERATIVE COURSE Contd… • Lasix infusion 2mg/kg/day • Sternum closed after 24 hours • Extubated next day and put on NIV • Post extubation maintained stable hemodynamics and PAP within normal range • Milrinone tapered off • On th 4th POD ,PAP :69/38(50) ABP:54/32(41) – Spo2-93% ABG:7.35/ 68/44 – Lactate: 2.1 – PERIPHERAL TEMP: 28.6 ,Urine Output –Nil for 3 hours • Management: – Reintubated – Noradrenaline and Dopamine infusion started – Sildenafil infusion started in PA Line – PD started
- 31. • Improved clinically – ABP Improved – PAP:24/20(22) – Spo2 :100% – Urine output 10ml/hr • PD discontinued after 48 hours • Supports were tapered off. • Extubated again 48 hours of ventilation • Put on NIV and O2 mask alternatively.. • Improving clinically
- 32. • THE POSTOPERATIVE PERIOD IS CHALLENGING….
Editor's Notes
- Infracardiac TAPVC: The common pulmonary vein drains through the diaphragm into the portal vein or ductus venosus. Reprinted with permission from Ref. [12].
