This document provides an overview of the Spring framework. Some key points: - Spring promotes loose coupling and separation of concerns through its lightweight container and use of dependency injection. - It simplifies configuration for aspects like transactions through declarative programming without needing full J2EE. - The inversion of control container resolves and "injects" dependencies into components. - Spring supports aspects through its aspect-oriented programming features which allow cross-cutting concerns to be implemented as aspects. - It provides transaction management, DAO support, and metadata support to further simplify programming tasks.

2.  “Lightweight Container”
◦ Very loosely coupled
◦ Components widely reusable and separately packaged
 Created by Rod Johnson
◦ Based on “Expert one-on-one J2EE Design and
Development”
◦ Currently on version 1.1.1

3.  Wiring of components (Dependency Injection)
◦ Promotes/simplifies decoupling, design to interfaces, TDD
 Declarative programming without J2EE
◦ Easily configured aspects, esp. transaction support
 Simplify use of popular technologies
◦ Abstractions insulate application from specifics, eliminate
redundant code, and handle common error conditions
◦ Underlying technology specifics still accessible (closures)

4.  Conversion of checked exceptions to unchecked
◦ (Or is this a reason not to use it?)
 Not an all-or-nothing solution
◦ Extremely modular and flexible
 Well designed
◦ Easy to extend
◦ Many reusable classes

7.  Inversion of Control (IoC)
 “Hollywood Principle”
◦ Don't call me, I'll call you
 “Container” resolves (injects) dependencies of
components by setting implementation object (push)
 As opposed to component instantiating or Service
Locator pattern where component locates
implementation (pull)
 Martin Fowler calls Dependency Injection

8.  Variations on dependency injection
◦ Interface based (Avalon)
◦ Constructor-based (PicoContainer, Spring)
◦ Setter-based (Spring)
 BeanFactory provides configuration framework to
initialize and “wire” JavaBeans
◦ org.springframework.beans and org.springframework.context
 Typically use the XmlBeanFactory, employing XML
configuration files

9.  BeanFactory configured components need have no
Spring dependencies
◦ Simple JavaBeans
 Beans are singletons by default
 Properties may be simple values or references to
other beans
 Built-in support for defining Lists, Maps, Sets, and
Properties collection types.
◦ Custom PropertyEditors may be defined to
convert string values to other, arbitrary types.

10.  Property and constructor based IoC
<bean id="exampleBean" class="examples.ExampleBean">
<property name="beanOne"><ref bean="anotherExampleBean"/></property>
<property name="beanTwo"><ref bean="yetAnotherBean"/></property>
<property name="integerProperty">1</property>
</bean>
<bean id="anotherExampleBean" class="examples.AnotherBean"/>
<bean id="yetAnotherBean" class="examples.YetAnotherBean"/>
<bean id="exampleBean" class="examples.ExampleBean">
<constructor-arg><ref bean="anotherExampleBean"/></constructor-arg>
<constructor-arg><ref bean="yetAnotherBean"/></constructor-arg>
<constructor-arg><value>1</value></constructor-arg>
</bean>
<bean id="anotherExampleBean" class="examples.AnotherBean"/>
<bean id="yetAnotherBean" class="examples.YetAnotherBean"/>

11.  Direct instantiation
◦ <bean id=“beanId” class=“className”>
 BeanFactory instantiation
◦ Same syntax but class is subclass of BeanFactory
◦ getObject() called to obtain Bean
 Static Factory
◦ <bean id=“beanId” class=“className" factory-method="
staticCreationMethod“>
 Instance Factory Method
◦ <bean id=“beanId” factory-bean=“existingBeanId" factory-
method=“nonStaticCreationMethod">

12.  Beans may be singletons or “prototypes”
◦ Attribute singleton=“false” causes instantiation with each
getBean() lookup
◦ Singleton is default
 XmlBeanFactory pre-instantiates singletons
◦ May be overridden on per-instance basis by lazy-
init=“true”
 Beans may also be marked abstract, allowing
reuse of attribute values through inheritance

13.  Beans may be auto-wired (rather than using <ref>)
◦ Per-bean attribute autowire
◦ Explicit settings override
 autowire=“name”
◦ Bean identifier matches property name
 autowire=“type”
◦ Type matches other defined bean
 autowire=”constructor”
◦ Match constructor argument types
 autowire=”autodetect”
◦ Attempt by constructor, otherwise “type”

14.  Ensures properties are defined
◦ Per-bean attribute dependency-check
◦ None required by default
◦ Verifies autowiring succeeded
 “simple”
◦ all but collaborators
 “object”
◦ collaborators only
 “all”
◦ Collaborators, primitive types, and collections

15.  Can define init method called after properties
set
◦ init-method=”<method-name>”
 Can define destroy method as shutdown hook
◦ destroy-method=”<method-name>”
 May alternatively implement InitializingBean
and/or DisposableBean
◦ At cost of Spring dependency

16.  BeanFactoryAware interface provides BeanFactory
for bean
◦ setBeanFactory(BeanFactory)
 BeanNameAware interface provides bean name
◦ setBeanName(String)
 FactoryBean for beans which are themselves
factories
◦ Object getObject()
◦ Boolean isSingleton()
◦ Class getObjectType()

17. InputStream is = new FileInputStream("beans.xml");
XmlBeanFactory factory = new XmlBeanFactory(is);
MyBeanClass bean = (MyBeanClass)factory.getBean(“myBean”);
ApplicationContext ctx = new
ClassPathXmlApplicationContext("beans.xml");
MyBeanClass bean = (MyBeanClass)ctx.getBean(“myBean”);
OR

18.  Extends functionality of BeanFactory
 Pre-instantiates singleton beans
 Detects and registers BeanPostProcessors and
BeanFactoryPostProcessors
 Supports nesting of contexts
 ApplicationListener and ApplicationEvents
◦ Initialized and closed predefined
◦ Custom may be created
 MessageSource provides i18n messaging
◦ <bean id=”messageSource”
class=”...ResourceBundleMessageSource”/>
◦ Contains list of bundle base names

19.  Web applications may use
ContextLoaderListener to initialize Spring
<context-param>
<param-name>contextConfigLocation</param-name>
<param-value>/WEB-INF/daoContext.xml /WEB-INF/applicationContext.xml
</param-value>
</context-param>
<listener>
<listener-class>org.springframework.web.context.ContextLoaderListener</listener-class>
</listener>
web.xml
Automatically done by Spring DispatcherServlet

20.  MethodInvokingFactoryBean
◦ Invokes method on registered beans or any static
methods
◦ Stores return value
 SingletonBeanFactoryLocator and
ContextSingletonBeanFactoryLocator
◦ Useful for sharing BeanFactories
◦ Eliminate duplication of beans in multiple similar
factories or contexts

21.  Defined beans inheriting from
BeanFactoryPostProcessor are detected and invoked
 CustomEditorConfigurer
◦ Registers custom PropertyEditors for converting
configuration string values to specific types
 AutoProxyCreators
◦ Wrap beans in proxies based on various criteria (name,
metadata, etc)
 PropertyResourceConfigurer
 Sets from property file and/or system properties

22. <bean id="propertyConfigurer"
class="org.springframework.beans.factory.config.PropertyPlaceholderConfigurer">
<property name="location"><value>database.properties</value></property>
</bean>
<bean id="dataSource"
class="org.springframework.jdbc.datasource.DriverManagerDataSource">
<property name="driverClassName">
<value>${database.connection.driver_class}</value>
</property>
<property name="url">
<value>${database.connection.url}</value>
</property>
</bean>

24.  Aspect-oriented programming (AOP) provides for
simplified application of cross-cutting concerns
◦ Transaction management
◦ Security
◦ Logging
◦ Auditing
◦ Locking
 AOP sometimes (partially) achieved via Decorators
or Proxies
◦ CORBA Portable Interceptors
◦ Servlet Filters

25.  Aspect - Implementation of a cross-cutting concern.
◦ Spring Advisors or Interceptors
 Joinpoint - Execution point to target
◦ Typically, methods
 Advice - Action taken at a particular joinpoint.
 Pointcut - A set of joinpoints specifying where advice
should be applied (e.g. Regular expression)
 Introduction/Mixin - Adding methods or fields to an
advised class.
 Weaving - Assembling aspects into advised objects.

26.  Generally, applies aspects to beans using
BeanFactory
◦ Uses Dynamic Proxies if interface available otherwise
CGLIB
◦ CGLIB creates derived class which proxies requests
 Bean class may not be final
 Less capable than AspectJ
◦ does not have field interception
◦ only runtime weaving solution is available
◦ Closer integration with AspectJ anticipated

27.  Pointcut applicability to a class may be
evaluated statically or dynamically
 Spring only creates proxies where necessary
public interface Pointcut {
ClassFilter getClassFilter();
MethodMatcher getMethodMatcher();
}
public interface ClassFilter {
boolean matches(Class clazz);
}

28.  Pointcut may be statically or dynamically
evaluated based on isRuntime()
 Abstract class StaticMethodMatcherPointcut
requires override of 1st
method only
public interface MethodMatcher {
boolean matches(Method m, Class targetClass);
boolean isRuntime();
boolean matches(Method m, Class targetClass, Object[] args);
}
Only called if isRuntime() == true

29.  Spring predefined pointcuts
◦ In org.springframework.aop.support package
 RegexpMethodPointcut
◦ Union of multiple regular expressions
◦ Uses Jakarta ORO package
 ControlFlowPointcut
◦ Similar to AspectJ cflow
◦ Applied if call stack includes specific class and, optionally,
method
 UnionPointcut
◦ Merges pointcuts

30.  Can have per-class or per-instance Advice
 Spring provides several Advice types
 Around Advice
 AOP Alliance compliant
 Must call invocation.proceed() to call target
public class MyAdvice implements AroundAdvice {
Object invoke(MethodInvocation invocation) {
// change arguments, start transaction, lock, etc.
invocation.proceed();
// change return value, stop transaction, unlock,etc.
}
}

31.  MethodBeforeAdvice
◦ void before(Method m, Object[] args, Object target)
◦ Cannot alter return type
 ThrowsAdvice
◦ Marker interface
◦ Implementors define methods of form:
 afterThrowing([Method], [args], [target], subclassOfThrowable)
 AfterReturningAdvice
◦ void afterReturning(Object returnValue, Method, m,
Object[] args, Object target)
◦ Cannot modify return value

32.  IntroductionInterceptor provides ability to define
mixins
public class RollbackAdvice extends DelegatingIntroductionInterceptor
implements RollbackSupport {
Map map = new HashMap();
void rollback(Date date) {
// rollback to state at given time
}
public Object invoke(MethodInvocation invocation) {
// record change and time of change
}
}

33. <bean id=“meetingTarget" class=“ex.DefaultMeeting“
singleton=“false”>
<property name=“topic">Spring</property>
</bean>
<bean id="myAdvisor" class=“ex.RollbackAdvice"
singleton=”false”>
</bean>
<bean id="debugInterceptor"
class="org.springframework.aop.interceptor.DebugInterceptor">
</bean>

34. <bean id=“meeting"
class="org.springframework.aop.framework.ProxyFactoryBean">
<property name="proxyInterfaces">
<value>ex.Meeting</value>
</property>
<property name="target"><ref local=“meetingTarget"/></property>
<property name="interceptorNames">
<list>
<value>myAdvisor</value>
<value>debugInterceptor</value>
</list>
</property>
</bean>
Advisors applied in order
All methods
using CGLib
if none defined

35.  Autoproxy bean definitions automatically proxy
selected beans.
 BeanNameAutoProxyCreator
◦ Adds listed advisors/interceptors to beans
with names matching regular expression
 DefaultAdvisorAutoProxyCreator
◦ Generic autoproxy infrastructure support
◦ Applies all advisors defined in the context
to all beans, proxying appropriately

36.  Spring supports obtaining meta data Object
attributes at class, method, and field level
◦ Not yet argument level (as JSR-175)
 Currently supports Jakarta Commons Attributes
 Support for JSR-175 in work
 Metadata support provided via Attributes
interface
◦ Amenable to mocking unlike JDK reflection and
Commons static methods

37.  Configuration of autoproxying based on metadata
attributes simplifies configuration
◦ Define custom attribute class
◦ Define Advisor with pointcut based on custom attribute
◦ Add Advisor in ApplicationContext with autoproxy
 Examples
◦ Transaction Attributes
◦ Security Attributes
◦ Pooling
◦ Mapping of controllers to URLs

39.  Spring provides AOP support for declarative
transactions
 Delegates to a PlatformTransactionManager
instance
◦ DataSourceTransactionManager
◦ HibernateTransactionManager
◦ JdoTransactionManager
◦ JtaTransactionManager

40. <bean id="sessionFactory"
class="org.springframework.orm.hibernate.LocalSessionFactoryBean">
<property name="dataSource"><ref bean="dataSource"/></property>
<property name="mappingResources">
<list>
<value>com/../model/*.hbm.xml</value>
</list>
</property>
</bean>
<bean id="transactionManager”
class="org.springframework.orm.hibernate.HibernateTransactionManager">
<property name="sessionFactory">
<ref bean="sessionFactory"/>
</property>
</bean>

41.  Declarative transactional support can be added
to any bean by using
TransactionProxyFactoryBean
 Similar to EJB, transaction attributes may be
defined on a per-method basis
 Also allows definition of pre- and post-
interceptors (e.g. for security)

42. <bean id=“reservationService"
class="org.springframework.transaction.interceptor.TransactionProxyFactoryBean">
<property name="transactionManager">
<ref bean="transactionManager"/>
</property>
<property name="target"><ref local=“reservationServiceTarget"/></property>
<property name="transactionAttributes">
<props>
<prop key=“reserveRoom*">PROPAGATION_REQUIRED</prop>
<prop key="*">PROPAGATION_REQUIRED,readOnly</prop>
</props>
</property>
</bean>
Declarative transaction support for single bean

43. <bean id="autoproxy"
class="org...DefaultAdvisorAutoProxyCreator">
</bean>
<bean id="transactionAdvisor"
class="org...TransactionAttributeSourceAdvisor"
autowire="constructor" >
</bean>
<bean id="transactionInterceptor"
class="org...TransactionInterceptor"
autowire="byType">
</bean>
<bean id="transactionAttributeSource"
class="org...AttributesTransactionAttributeSource"
autowire="constructor">
</bean>
<bean id="attributes"
class="org...CommonsAttributes"
/>
Caches metadata
from classes
Generic autoproxy
support
Applies transaction
using transactionManager
Invokes interceptor
based on attributes

45.  DAO support provides pluggable framework for
persistence
 Currently supports JDBC, Hibernate, JDO, and
iBatis
 Defines consistent exception hierarchy (based
on RuntimeException)
 Provides abstract “Support” classes for each
technology
◦ Template methods define specific queries

46. public class ReservationDaoImpl extends HibernateDaoSupport
implements ReservationDao {
public Reservation getReservation (Long orderId) {
return (Reservation)getHibernateTemplate().load(Reservation .class,
orderId);
}
public void saveReservation (Reservation r) {
getHibernateTemplate().saveOrUpdate(r);
}
public void remove(Reservation Reservation) {
getHibernateTemplate().delete(r);
}

47. public Reservation[] findReservations(Room room) {
List list = getHibernateTemplate().find(
"from Reservation reservation “ +
“ where reservation.resource =? “ +
“ order by reservation.start",
instrument);
return (Reservation[]) list.toArray(new Reservation[list.size()]);

48. public Reservation[] findReservations(final DateRange range) {
final HibernateTemplate template = getHibernateTemplate();
List list = (List) template.execute(new HibernateCallback() {
public Object doInHibernate(Session session) {
Query query = session.createQuery(
"from Reservation r “ +
“ where r.start > :rangeStart and r.start < :rangeEnd “);
query.setDate("rangeStart", range.getStartDate()
query.setDate("rangeEnd", range.getEndDate())
return query.list();
}
});
return (Reservation[]) list.toArray(new Reservation[list.size()]);
}
}

49. <bean id="sessionFactory"
class="org.springframework.orm.hibernate.LocalSessionFactoryBean">
<property name="dataSource"><ref bean="dataSource"/></property>
<property name="mappingResources">
<list>
<value>com/jensenp/Reservation/Room.hbm.xml</value>
<value>com/jensenp/Reservation/Reservation.hbm.xml</value>
<value>com/jensenp/Reservation/Resource.hbm.xml</value>
</list>
</property>
<property name="hibernateProperties">
<props>
<prop key="hibernate.dialect">${hibernate.dialect}</prop>
<prop key="hibernate.hbm2ddl.auto">${hibernate.hbm2ddl.auto}
</prop>
<prop key="hibernate.show_sql">${hibernate.show_sql}</prop>
</props>
</property>
</bean>
<bean id=“reservationDao"
class="com.jensenp.Reservation.ReservationDaoImpl">
<property name="sessionFactory"><ref bean="sessionFactory"/>
</property>
</bean>

50.  JDBCTemplate provides
◦ Translation of SQLExceptions to more meaningful Spring
Runtime exceptions
◦ Integrates thread-specific transactions
 MappingSQLQuery simplifies mapping of
ResultSets to Java objects

52.  The DispatcherServlet is the Spring Front
Controller
 Initializes WebApplicationContext
 Uses /WEB-INF/[servlet-name]-servlet.xml by
default
 WebApplicationContext is bound into
ServletContext

53.  HandlerMapping
◦ Routing of requests to handlers
 HandlerAdapter
◦ Adapts to handler interface. Default utilizes Controllers
 HandlerExceptionResolver
◦ Maps exceptions to error pages
◦ Similar to standard Servlet, but more flexible
 ViewResolver
◦ Maps symbolic name to view

54.  MultipartResolver
◦ Handling of file upload
 LocaleResolver
◦ Default uses HTTP accept header, cookie, or session

55.  Controller interface defines one method
◦ ModelAndView handleRequest(HttpServletRequest req,
HttpServletResponse resp) throws Exception
 ModelAndView consists of a view identifier and
a Map of model data

56.  CommandControllers bind parameters to data
objects
 AbstractCommandController
 AbstractFormController
 SimpleFormController
 WizardFormController
