By- Vinay Kumar
 Introduction
 Injection
 Aspect Dependency Oriented Programming
 Bean Factory
 Wiring Objects
 Spring MVC

 Spring DAO
Introduction
 Spring Framework
 is a J2EE Framework
 that provides a lightweight container
 for dependency injection
 and Aspect oriented Programming (AOP)

Now what was that, again?
DI or IOC
 Dependency injection or Inversion of control
 Alternative to Service Locator

Locate your own dependencies

Let the framework do the dirty job for you
AOP
 Aspect oriented programming
 Cross cutting concerns
 Transaction, Security and Logging requirements
BeanFactory






Interface BeanFactory
BeanFactory creates beans
getBean() method
Implementation classes like the XmlBeanFactory
Methods:
 getBean()
 isSingleton()
 getType()

 getAliases()
 containsBean()

This is how a BeanFactory looks like
Using BeanFactory
public static void main (String args []){
BeanFactory factory = new XmlBeanFactory (new
FileInputStream (“bean-config.xml”));
MyBean mybean = (MyBean) factory.getBean
(“myBean”);
mybean.methodx():
}

A Web Application may never need to use code such as
the one shown above as the framework does it all for
us.
ApplicationContext
 Extends the BeanFactory
 Adds the following methods:
 getResource()
 getMessage()
Wiring Objects
 Spring provides for declarative wiring of objects
 Declaring a bean
 Declaring beans as singleton or prototype
 Declaring init and destroy methods
 Injecting values into beans properties
 Injecting other beans as properties
 Injecting arrays and collections as properties
Spring book

This book on Spring is marvelous ! Now I am a wiring expert too
!
Declaring beans
<beans>
<bean id=“x” class=“y”/>
</beans>

When using the id attribute, special characters are not
permitted. Spring therefore allows the use of an
alternative attribute: name
<bean name=“x” class=“y”/>
To singleton or not
 Beans are instantiated as Singletons by default. This is how

we can override the default :
<beans>
<bean id=“x” class=“y” singleton=“false”/>
</beans>
Init and destroy
 As Spring manages the bean lifecycle, it allows us to

specify the init and destroy methods declaratively.
<beans>
<bean id=“x” class=“y” init-method=“a”/>
<bean id=“p” class=“q” destroy-method=“b”/>
</beans>
Alternative
 Spring defines the following interfaces
 InitializingBean
 DisposableBean
 Beans implementing these interfaces are assured that

the methods defined in these interfaces are called back
by Spring during initialization and destruction.
 This is thus an alternative to the init and destroy
method declaration in the config.xml
Dependency Injection
 Spring allows for:
 Setter based injection
 Constructor based injection
Setter injection
 Setter based injection allows us to inject values into

bean properties through the setter methods.
 These values may be
 Primitive Types

 Strings
 Beans
 Arrays
 Collections
 Property
Primitive Types
<bean id=“x” class=“y”>
<property name=“age”>
<value>26</value>
</property>
</bean>

This sets “26” to the property age
Strings
<bean id=“x” class=“y”>
<property name=“nm”>
<value>val</value>
</property>
</bean>

This sets “val” to the property nm
<bean id=“x” class=“y”>
<property name=“pq”>
<value></value>
</property>
</bean>

This sets an empty string “” to the property pq
Null values
<bean id=“x” class=“y”>
<property name=“nm”>
<value><null/></value>
</property>
</bean>
Bean
<beans>
<bean id=“myClass” class=“demo.MyClass”>
<property name=“display”>
<ref bean=“a” />
</property>
</bean>
<bean id=“a” class=“util.TestClass”/>
</beans>
Arrays and Lists
<bean id=“x” class=“y”>
<property name=“nm”>
<list>
<value>pqr</value>
<value>xyz</value>
<value>abc</value>
</list>
</property>
</bean>
List of objects
<beans>
<bean id=“x” class=“y”>
<property name=“nm”>
<list>
<ref bean=“a”/>
<ref bean=“b”/>
</list>
</property>
</bean>
<bean id=“a” class=“p”/>
<bean id=“b” class=“q”/>
</beans>
Sets
<bean id=“x” class=“y”>
<property name=“nm”>
<set>
<value>pqr</value>
<value>xyz</value>
<value>abc</value>
</set>
</property>
</bean>

For a set consisting of beans use the <ref bean> tag
Maps
<beans>
<bean id=“x” class=“y”>
<property name=“nm”>
<map>
<entry key=“k1”>
<value>val1</value>
</entry>
<entry key=“k2”>
<ref bean=“a” />
Spring limits the user to declare keys as Strings only
</entry>
</map>
</property>
</bean>
<bean id=“a” class=“p”/>
</beans>
Properties
<beans>
<bean id=“x” class=“y”>
<property name=“nm”>
<props>
<prop key=“k1”>val1</prop>
<prop key=“k2”>val2</prop>
</props>
</property>
</bean>
</beans>
Constructor injection
Spring allows for injection via constructors
Below is example of constructor based injection
<beans>
<bean id=“myClass” class=“demo.MyClass”>
<constructor-arg>
<value>42</value>
</constructor-arg>
</bean>
</beans>
Constructor injection
Spring allows for injection via constructors
Below is example of constructor based injection for setting multiple
arguments
<beans>
<bean id=“myClass” class=“demo.MyClass”>
<constructor-arg index=“1”>
<value>42</value>
</constructor-arg>
<constructor-arg index=“2”>
<ref bean=“testClass”/>
</constructor-arg>
</bean>
</beans>
Constructor injection - Advantage
The data members of the class are set only once at the
time of creation/instantiation of the object. There are
no public setter methods that are exposed to the
outside world and through which the state of an object
can be changed.
Thus the object is immutable.
Constructor injection - Disadvantage
The xml declaration for constructor based injection is
complex and the developer has to ensure that there are
no ambiguities in the parameters
Autowiring
 Spring has autowiring capabilities
<beans>
<bean id=“x” class=“y” autowire=“byName”>
</bean>
</beans>
The dependencies need not be defined in the xml explicitly. With autowire by
Name option if we ensure that the name of id in xml, and name of the
properties in the java class matches then the Spring framework automatically
invokes setter methods.
Note: byName should be used with only setter based injection
Modules
 Seven modules or packages
Spring Core
 Dependency Injection
 BeanFactory and ApplicationContext
Spring Web
 Web utilities

Spring tags for use in html/jsp
 Multipart functionality
 Integration with Struts framework
In one application the struts can be used in web MVC layer and
integrated with other Spring components in the application

bigfile.xml
part1.xml

part2.xml

part3.xml
Spring Web MVC
 Controller
 Validator
Life cycle of a request

Spring Web MVC

Handler Mapping

2

Request

3

1

Dispatcher Servlet

Controller

4
ModelAndView

5

ViewResolver

6

View
Spring Web MVC
2

Request

Handle Mapping

3

1

Dispatcher Servlet

Controller

4
ModelAndView

5

ViewResolver
Life cycle of a Request
1.
2.
3.
4.
5.

6.
7.

The client typically web browser send request (1)
The first component to receive is DispatcherServlet. All the
requests goes through single front controller servlet.
DispacherServlet queries HandlerMapping. This is a mapping
of URLs and Controller objects defined in configuration xml
Dispatcher servlet dispatches request to Controller to perform
business logic
Controller returns the model and the view. The model is the
data that need to be displayed in the view. The view is a logical
name that is mapped to the .jsp file that will render the view.
This is defined in the xml mapping file
Controller send request to ViewResolver to resolve which .jsp
to render for which view
Finally the view is rendered
Configuring the Dispatcher Servlet
Dispatcher servlet is MVC’s front controller. Like any servlet
it must be configured in Spring application context
Example:
<servlet>
<servlet-name>testapp</servlet-name>
<servletclass>org.springframework.web.servlet.DispatcherServl
et</servlet-class>
<load-on-startup>1</load-on-startup>
<servlet>
Since the dispatcher servlet’s name is testapp the servlet will load the application context from a file named
‘testapp-servlet.xml’
Spring Web MVC - Controller
There are following main Controller types
 Abstract Controller
 Simple Form Controller
 Multi Action Controller
All the above are implementation classes for the Controller
Interface
Abstract Controller
 This controller is used when the view/GUI has to be read

only.
 No data is entered in the screen
Example
public class ListCircuitsController extends AbstractController{
public ModelAndView handleRequestInternal(HttpServletRequest
req,HttpServletResponse res){
Collection circuits=circuitService.getAllCircuits();
return new ModelAndView(“circuitList”,”circuits”, circuits);
}
The first argument “circuitList” is the name of the view to which
the controller is associated.
The second argument is the name of the model object which holds the
third argument circuits object.
Declaring View Resolver
View Resolver resolves the logical view name returned by controller to the jsp file that
renders the view. Of the various view resolvers InternalResourceViewResolver is
simplest for rendering jsp
Example
<!-- view-resolver -->
<bean id="viewResolver"
class="org.springframework.web.servlet.view.InternalResource
ViewResolver">
<property name="prefix">
<value>/WEB-INF/ui/</value>
</property>
<property name="suffix">
<value>.jsp</value>
</property>
</bean>
<!-- /view-resolver -->
Mapping requests to Controllers
SimpleUrlHandlerMapping is one of the straight forward Spring’s handler
mapping. This maps the URL patterns to controllers.
Example
<bean id="urlMapping"
class="org.springframework.web.servlet.handler.Simple
UrlHandlerMapping">
<property name="urlMap">
<map>
<entry key="/forum.do">
<ref bean="forumController" />
</entry>
</map>
</property>
</bean>
<!-- /UrlMapping -->
Simple Form Controller
 This controller is used for GUI which have a data entry

form to be filled in and submitted by the user.
 The controller is responsible for –
 Displaying the form for data entry

 Validating data entered by the user
 Redisplaying the form on error with error message
 Submitting the data
 Displaying the success page
Command Object
 It holds the data that the user enters in the form/GUI
Simple Form Controller -code
public class EnterCircuitDetailsController extends
SimpleFormController{
public EnterCircuitDetails(){
setCommandClass(Circuit.class);
}
Protected void doSubmitAction(Object command) throws
Exception{
Circuit circuit=(Circuit) command;
circuitService.createCircuit(circuit);
}
Private CircuitService circuitservive;
Public void setCircuitService(CircuitService
circuitservice){
this.circuitService=circuitService;
}
}
Simple Form Controller -Configuration
 The details of configuration of the view is as below:
<bean id=“enterCircuitDetailsController" class="
com.circuit.mvc.CircuitDetailsController">
<property name=“circuitService" ref=“circuitService" />
<property
name="formView"><value>circuitForm</value></property>
<property
name="successView"><value>circuitCreated.do</value></pr
operty>
</bean>
Simple Form Controller -explained
 As per the above example EnterCircuitDetailsController

displays a form for taking the details of the circuit that
need to be created as well as processes the data that is
entered.
 The doSubmitAction() method handles form submission
and takes details of the form from Circuit object
 The doSubmitAction() does not return ModelAndView
object and hence with this we will not be able to send any
data to the view. If a particular view need to be displayed
with some data in it we need to use the onSubmit() method
instead.
Simple Form Controller -explained
 SimpleFormController is designed to keep view details out of

the controller’s code. The formView represents the logical
name of the view that is to be displayed when the Controller
gets a GET request or there are any errors on the form. The
success view represents the logical name of the view to be
displayed when form is submitted successfully. The view
resolver will use this to render the actual view to the user.
Simple Form Controller
 Below is an example of onSubmit method
protected ModelAndView onSubmit(Object command,
BindException errors) throws Exception {
Circuit circuit = (Circuit) command;
circuitService.createCircuit(circuit);
return new ModelAndView(getSuccessView(),“circuit", circuit);
}
Multi Action Controller
 These controllers are used to handle multiple actions in a single

controller. Each action is handled by a different method within
the controller.
 The specific method that needs to be called in the Action
controller based on the type of resolver.
 The below example shows that we are using methodName
Resolver
<bean id="multiactionController"
class="com. mvc.ListCircuitsController">
<property name="methodNameResolver">
<ref bean="methodNameResolver"/>
</property>
</bean>
Multi Action Controller
 There are two types of method name resolvers like

ParameterMethodNameResolver and PropertiesMethodNameResolver.
This will ensure that the appropriate method in the Multiaction
Controller is called based on the parameter name passed in the request.
The parameter name will need to be same as the method name in the
MultiActionForm Controller. Below is the configuration that need to be
done
<bean id="methodNameResolver" class="org.springframework.web.
servlet.mvc.multiaction.ParameterMethodNameResolver">
<property name="paramName">
<value>action</value>
</property>
</bean>
Multi Action Controller
 Example: If we are accessing the URL

“http://…/listCircuits.htm?action=circuitsByDate” the
method name circuitsByDate() is called in the
MultiActionController since we have configured the name
resolver to be based on the parameter passed in the request.
Spring Web MVC-Validator
 Spring provides a Validator Interface that is used for

validating objects
 For Example: In the example of a simple form
controller in previous slides in which there is a
command object “circuit” which needs to be validated
or in other words we need to validate that the circuit
details entered by the user are correct. In that case the
class Circuit should implement the Validator interface
Spring Web MVC-Validator
 Validator Interface has the following methods defined

in it
public interface Validator {
void validate(Object obj, Errors errors);
boolean supports(Class class);
}
Spring Web MVC-Validator Code
 Sample code below explains how Validator Interface is

implemented to perform validations. We write a class
ValidateCktDetails for validating circuit details entered by user

public class CircuitValidator implements Validator {
public boolean supports(Class class) {
return class.equals(Circuit.class);
}
public void validate(Object command, Errors errors) {
Circuit circuit = (Circuit) command;
ValidationUtils.rejectIfEmpty(
errors, “circuitType", "required. circuitType ", “Circuit Type is mandatory
for creating a circuit");
}
Web MVC-Validator Code Explained
 The framework uses support() method to check if the

Validator can be used for a given class
 The validate() methods can validate all the attributes of the
object that is passed into validate() method and reject invalid
values through Errors object
Spring Web MVC-Validator
 The only other thing to do is to use the

CircuitValidator with
EnterCircuitDetailsController which can be
done by wiring the bean
<bean id=“enterCircuitDetailsController" class=
"com.circuit.mvc.CircuitDetailsController">
<property name="validator">
<bean class="com.validate.mvc.CircuitValidator"/>
</property>
</bean>
Spring Web MVC
 When a user enters the circuit details, if all of the

required properties are set and circuit type is not
empty, then EnterCircuitDetailsController’s
doSubmitAction() will be called. However, if
CircuitValidator rejects any of the fields, then the user
will be returned to the form view to correct the errors.
Spring Context
 Resource bundles
 Event propagation
 Bean Lookup
Spring ORM
 Hibernate support- Spring provides integration with

Object Relational mapping frameworks like Hibernate
Spring DAO
 Transaction infrastructure
 JDBC support
 DAO support
Spring DAO-JDBC
 Assuming that the persistence layer in an application is

JDBC. In that case we need to use
DataSourceTrnsactionManger which will manage
transactions on a single JDBC Data Source
 The source code explains the use of Transaction Manager.
The transaction manager takes care of managing the
transactions.
<bean id="transactionManager" class="org.springframework.jdbc.
datasource.DataSourceTransactionManager">
<property name="dataSource">
<ref bean="dataSource"/>
</property>
</bean>
Spring DAO-JDBC
 The dataSource property is set with a reference to a bean named

datasource

<bean id="datasource" class="org.apache.commons.dbcp.BasicDataSource">
<property name="driverClassName">
<value>oracle.jdbc.driver.OracleDriver</value>
</property>
<property name="url">
<value>jdbc:oracle:thin:@111.21.15.234:1521:TESTSID</value>
</property>
<property name="username">
<value>test</value>
</property>
<property name="password">
<value>test</value>
</property>
</bean>
Spring framework in depth

More Related Content

What's hot

Spring introduction
Spring introductionSpring introduction
Spring introduction
Manav Prasad

Spring Framework - Core
Spring Framework - CoreSpring Framework - Core
Spring Framework - Core
Dzmitry Naskou

Spring boot introduction
Spring boot introductionSpring boot introduction
Spring boot introduction
Rasheed Waraich

Spring Framework
Spring Framework  Spring Framework
Spring Framework
tola99

Spring MVC
Spring MVCSpring MVC
Spring MVC
Aaron Schram

Spring MVC Framework
Spring MVC FrameworkSpring MVC Framework
Spring MVC Framework
Hùng Nguyễn Huy

Spring Core
Spring CoreSpring Core
Spring Core
Pushan Bhattacharya

Node.js Tutorial for Beginners | Node.js Web Application Tutorial | Node.js T...
Node.js Tutorial for Beginners | Node.js Web Application Tutorial | Node.js T...Node.js Tutorial for Beginners | Node.js Web Application Tutorial | Node.js T...
Node.js Tutorial for Beginners | Node.js Web Application Tutorial | Node.js T...
Edureka!

Introduction to Spring Boot!
Introduction to Spring Boot!Introduction to Spring Boot!
Introduction to Spring Boot!
Jakub Kubrynski

Spring boot Introduction
Spring boot IntroductionSpring boot Introduction
Spring boot Introduction
Jeevesh Pandey

Introduction to Spring Boot
Introduction to Spring BootIntroduction to Spring Boot
Introduction to Spring Boot
Purbarun Chakrabarti

Spring boot
Spring bootSpring boot
Spring boot
sdeeg

Java Spring Framework
Java Spring FrameworkJava Spring Framework
Java Spring Framework
Mehul Jariwala

Introduction to Spring Framework
Introduction to Spring FrameworkIntroduction to Spring Framework
Introduction to Spring Framework
Hùng Nguyễn Huy

Java Spring framework, Dependency Injection, DI, IoC, Inversion of Control
Java Spring framework, Dependency Injection, DI, IoC, Inversion of ControlJava Spring framework, Dependency Injection, DI, IoC, Inversion of Control
Java Spring framework, Dependency Injection, DI, IoC, Inversion of Control
Arjun Thakur

Spring - Part 1 - IoC, Di and Beans
Spring - Part 1 - IoC, Di and Beans Spring - Part 1 - IoC, Di and Beans
Spring - Part 1 - IoC, Di and Beans
Hitesh-Java

jQuery
jQueryjQuery
Spring Boot
Spring BootSpring Boot
Spring Boot
Pei-Tang Huang

Spring Boot
Spring BootSpring Boot
Spring Boot
Jiayun Zhou

Spring beans
Spring beansSpring beans
Spring beans
Roman Dovgan


What's hot (20)

Spring introduction
Spring introductionSpring introduction
Spring introduction

Spring Framework - Core
Spring Framework - CoreSpring Framework - Core
Spring Framework - Core

Spring boot introduction
Spring boot introductionSpring boot introduction
Spring boot introduction

Spring Framework
Spring Framework  Spring Framework
Spring Framework

Spring MVC
Spring MVCSpring MVC
Spring MVC

Spring MVC Framework
Spring MVC FrameworkSpring MVC Framework
Spring MVC Framework

Spring Core
Spring CoreSpring Core
Spring Core

Node.js Tutorial for Beginners | Node.js Web Application Tutorial | Node.js T...
Node.js Tutorial for Beginners | Node.js Web Application Tutorial | Node.js T...Node.js Tutorial for Beginners | Node.js Web Application Tutorial | Node.js T...
Node.js Tutorial for Beginners | Node.js Web Application Tutorial | Node.js T...

Introduction to Spring Boot!
Introduction to Spring Boot!Introduction to Spring Boot!
Introduction to Spring Boot!

Spring boot Introduction
Spring boot IntroductionSpring boot Introduction
Spring boot Introduction

Introduction to Spring Boot
Introduction to Spring BootIntroduction to Spring Boot
Introduction to Spring Boot

Spring boot
Spring bootSpring boot
Spring boot

Java Spring Framework
Java Spring FrameworkJava Spring Framework
Java Spring Framework

Introduction to Spring Framework
Introduction to Spring FrameworkIntroduction to Spring Framework
Introduction to Spring Framework

Java Spring framework, Dependency Injection, DI, IoC, Inversion of Control
Java Spring framework, Dependency Injection, DI, IoC, Inversion of ControlJava Spring framework, Dependency Injection, DI, IoC, Inversion of Control
Java Spring framework, Dependency Injection, DI, IoC, Inversion of Control

Spring - Part 1 - IoC, Di and Beans
Spring - Part 1 - IoC, Di and Beans Spring - Part 1 - IoC, Di and Beans
Spring - Part 1 - IoC, Di and Beans

jQuery
jQueryjQuery
jQuery

Spring Boot
Spring BootSpring Boot
Spring Boot

Spring Boot
Spring BootSpring Boot
Spring Boot

Spring beans
Spring beansSpring beans
Spring beans


Viewers also liked

Spring framework
Spring frameworkSpring framework
Spring framework
Rajkumar Singh

Spring orm notes_by_soma_sekhar_reddy_javabynataraj
Spring orm notes_by_soma_sekhar_reddy_javabynatarajSpring orm notes_by_soma_sekhar_reddy_javabynataraj
Spring orm notes_by_soma_sekhar_reddy_javabynataraj
Satya Johnny

JSR 168 Portal - Overview
JSR 168 Portal - OverviewJSR 168 Portal - Overview
JSR 168 Portal - Overview
Vinay Kumar

Spring framework part 2
Spring framework  part 2Spring framework  part 2
Spring framework part 2
Skillwise Group

Spring core module
Spring core moduleSpring core module
Spring core module
Raj Tomar

Getting Started with Spring Framework
Getting Started with Spring FrameworkGetting Started with Spring Framework
Getting Started with Spring Framework
Edureka!

Introduction to Spring Framework
Introduction to Spring FrameworkIntroduction to Spring Framework
Introduction to Spring Framework
Dineesha Suraweera

Introduction to Spring Framework
Introduction to Spring FrameworkIntroduction to Spring Framework
Introduction to Spring Framework
Serhat Can

Spring notes
Spring notesSpring notes
Spring notes
Rajeev Uppala


Viewers also liked (9)

Spring framework
Spring frameworkSpring framework
Spring framework

Spring orm notes_by_soma_sekhar_reddy_javabynataraj
Spring orm notes_by_soma_sekhar_reddy_javabynatarajSpring orm notes_by_soma_sekhar_reddy_javabynataraj
Spring orm notes_by_soma_sekhar_reddy_javabynataraj

JSR 168 Portal - Overview
JSR 168 Portal - OverviewJSR 168 Portal - Overview
JSR 168 Portal - Overview

Spring framework part 2
Spring framework  part 2Spring framework  part 2
Spring framework part 2

Spring core module
Spring core moduleSpring core module
Spring core module

Getting Started with Spring Framework
Getting Started with Spring FrameworkGetting Started with Spring Framework
Getting Started with Spring Framework

Introduction to Spring Framework
Introduction to Spring FrameworkIntroduction to Spring Framework
Introduction to Spring Framework

Introduction to Spring Framework
Introduction to Spring FrameworkIntroduction to Spring Framework
Introduction to Spring Framework

Spring notes
Spring notesSpring notes
Spring notes


Similar to Spring framework in depth

Spring talk111204
Spring talk111204Spring talk111204
Spring talk111204
ealio

Integration of Backbone.js with Spring 3.1
Integration of Backbone.js with Spring 3.1Integration of Backbone.js with Spring 3.1
Integration of Backbone.js with Spring 3.1
Michał Orman

Skillwise-Spring framework 1
Skillwise-Spring framework 1Skillwise-Spring framework 1
Skillwise-Spring framework 1
Skillwise Group

Spring
SpringSpring
Spring
s4al_com

Spring talk111204
Spring talk111204Spring talk111204
Spring talk111204
s4al_com

Toms introtospring mvc
Toms introtospring mvcToms introtospring mvc
Toms introtospring mvc
Guo Albert

Spring review_for Semester II of Year 4
Spring review_for Semester II of Year 4Spring review_for Semester II of Year 4
Spring review_for Semester II of Year 4
than sare

Introduction to Spring Framework
Introduction to Spring FrameworkIntroduction to Spring Framework
Introduction to Spring Framework
Rajind Ruparathna

Jinal desai .net
Jinal desai .netJinal desai .net
Jinal desai .net
rohitkumar1987in

Java Spring MVC Framework with AngularJS by Google and HTML5
Java Spring MVC Framework with AngularJS by Google and HTML5Java Spring MVC Framework with AngularJS by Google and HTML5
Java Spring MVC Framework with AngularJS by Google and HTML5
Tuna Tore

springmvc-150923124312-lva1-app6892
springmvc-150923124312-lva1-app6892springmvc-150923124312-lva1-app6892
springmvc-150923124312-lva1-app6892
Tuna Tore

Sel study notes
Sel study notesSel study notes
Sel study notes
Lalit Singh

SpringBootCompleteBootcamp.pptx
SpringBootCompleteBootcamp.pptxSpringBootCompleteBootcamp.pptx
SpringBootCompleteBootcamp.pptx
SUFYAN SATTAR

Spring Framework - III
Spring Framework - IIISpring Framework - III
Spring Framework - III
People Strategists

Java J2EE Interview Question Part 2
Java J2EE Interview Question Part 2Java J2EE Interview Question Part 2
Java J2EE Interview Question Part 2
Mindsmapped Consulting

Java J2EE Interview Questions Part 2
Java J2EE Interview Questions Part 2Java J2EE Interview Questions Part 2
Java J2EE Interview Questions Part 2
javatrainingonline

Spring tutorial
Spring tutorialSpring tutorial
Spring tutorial
Sanjoy Kumer Deb

Spring training
Spring trainingSpring training
Spring training
TechFerry

Spring MVC 5 & Hibernate 5 Integration
Spring MVC 5 & Hibernate 5 IntegrationSpring MVC 5 & Hibernate 5 Integration
Spring MVC 5 & Hibernate 5 Integration
Majurageerthan Arumugathasan

Jsf
JsfJsf

Similar to Spring framework in depth (20)

Spring talk111204
Spring talk111204Spring talk111204
Spring talk111204

Integration of Backbone.js with Spring 3.1
Integration of Backbone.js with Spring 3.1Integration of Backbone.js with Spring 3.1
Integration of Backbone.js with Spring 3.1

Skillwise-Spring framework 1
Skillwise-Spring framework 1Skillwise-Spring framework 1
Skillwise-Spring framework 1

Spring
SpringSpring
Spring

Spring talk111204
Spring talk111204Spring talk111204
Spring talk111204

Toms introtospring mvc
Toms introtospring mvcToms introtospring mvc
Toms introtospring mvc

Spring review_for Semester II of Year 4
Spring review_for Semester II of Year 4Spring review_for Semester II of Year 4
Spring review_for Semester II of Year 4

Introduction to Spring Framework
Introduction to Spring FrameworkIntroduction to Spring Framework
Introduction to Spring Framework

Jinal desai .net
Jinal desai .netJinal desai .net
Jinal desai .net

Java Spring MVC Framework with AngularJS by Google and HTML5
Java Spring MVC Framework with AngularJS by Google and HTML5Java Spring MVC Framework with AngularJS by Google and HTML5
Java Spring MVC Framework with AngularJS by Google and HTML5

springmvc-150923124312-lva1-app6892
springmvc-150923124312-lva1-app6892springmvc-150923124312-lva1-app6892
springmvc-150923124312-lva1-app6892

Sel study notes
Sel study notesSel study notes
Sel study notes

SpringBootCompleteBootcamp.pptx
SpringBootCompleteBootcamp.pptxSpringBootCompleteBootcamp.pptx
SpringBootCompleteBootcamp.pptx

Spring Framework - III
Spring Framework - IIISpring Framework - III
Spring Framework - III

Java J2EE Interview Question Part 2
Java J2EE Interview Question Part 2Java J2EE Interview Question Part 2
Java J2EE Interview Question Part 2

Java J2EE Interview Questions Part 2
Java J2EE Interview Questions Part 2Java J2EE Interview Questions Part 2
Java J2EE Interview Questions Part 2

Spring tutorial
Spring tutorialSpring tutorial
Spring tutorial

Spring training
Spring trainingSpring training
Spring training

Spring MVC 5 & Hibernate 5 Integration
Spring MVC 5 & Hibernate 5 IntegrationSpring MVC 5 & Hibernate 5 Integration
Spring MVC 5 & Hibernate 5 Integration

Jsf
JsfJsf
Jsf


More from Vinay Kumar

Modernizing the monolithic architecture to container based architecture apaco...
Modernizing the monolithic architecture to container based architecture apaco...Modernizing the monolithic architecture to container based architecture apaco...
Modernizing the monolithic architecture to container based architecture apaco...
Vinay Kumar

Kafka and event driven architecture -apacoug20
Kafka and event driven architecture -apacoug20Kafka and event driven architecture -apacoug20
Kafka and event driven architecture -apacoug20
Vinay Kumar

Kafka and event driven architecture -og yatra20
Kafka and event driven architecture -og yatra20Kafka and event driven architecture -og yatra20
Kafka and event driven architecture -og yatra20
Vinay Kumar

Extend soa with api management Sangam18
Extend soa with api management Sangam18Extend soa with api management Sangam18
Extend soa with api management Sangam18
Vinay Kumar

Extend soa with api management Doag18
Extend soa with api management Doag18Extend soa with api management Doag18
Extend soa with api management Doag18
Vinay Kumar

Roaring with elastic search sangam2018
Roaring with elastic search sangam2018Roaring with elastic search sangam2018
Roaring with elastic search sangam2018
Vinay Kumar

Extend soa with api management spoug- Madrid
Extend soa with api management   spoug- MadridExtend soa with api management   spoug- Madrid
Extend soa with api management spoug- Madrid
Vinay Kumar

Expose your data as an api is with oracle rest data services -spoug Madrid
Expose your data as an api is with oracle rest data services -spoug MadridExpose your data as an api is with oracle rest data services -spoug Madrid
Expose your data as an api is with oracle rest data services -spoug Madrid
Vinay Kumar

Modern application development with oracle cloud sangam17
Modern application development with oracle cloud sangam17Modern application development with oracle cloud sangam17
Modern application development with oracle cloud sangam17
Vinay Kumar

award-3b07c32b-b116-3a75-8974-d814d37026ca
award-3b07c32b-b116-3a75-8974-d814d37026caaward-3b07c32b-b116-3a75-8974-d814d37026ca
award-3b07c32b-b116-3a75-8974-d814d37026ca
Vinay Kumar

award-3b07c32b-b116-3a75-8974-d814d37026ca
award-3b07c32b-b116-3a75-8974-d814d37026caaward-3b07c32b-b116-3a75-8974-d814d37026ca
award-3b07c32b-b116-3a75-8974-d814d37026ca
Vinay Kumar

Adf spotlight-webcenter task flow-customzation
Adf spotlight-webcenter task flow-customzationAdf spotlight-webcenter task flow-customzation
Adf spotlight-webcenter task flow-customzation
Vinay Kumar

Personalization in webcenter portal
Personalization in webcenter portalPersonalization in webcenter portal
Personalization in webcenter portal
Vinay Kumar

Custom audit rules in Jdeveloper extension
Custom audit rules in Jdeveloper extensionCustom audit rules in Jdeveloper extension
Custom audit rules in Jdeveloper extension
Vinay Kumar

File upload in oracle adf mobile
File upload in oracle adf mobileFile upload in oracle adf mobile
File upload in oracle adf mobile
Vinay Kumar

Webcenter application performance tuning guide
Webcenter application performance tuning guideWebcenter application performance tuning guide
Webcenter application performance tuning guide
Vinay Kumar

Tuning and optimizing webcenter spaces application white paper
Tuning and optimizing webcenter spaces application white paperTuning and optimizing webcenter spaces application white paper
Tuning and optimizing webcenter spaces application white paper
Vinay Kumar

Oracle adf performance tips
Oracle adf performance tipsOracle adf performance tips
Oracle adf performance tips
Vinay Kumar

Oracle Fusion Architecture
Oracle Fusion ArchitectureOracle Fusion Architecture
Oracle Fusion Architecture
Vinay Kumar

Incentive compensation in fusion CRM
Incentive compensation in fusion CRMIncentive compensation in fusion CRM
Incentive compensation in fusion CRM
Vinay Kumar


More from Vinay Kumar (20)

Modernizing the monolithic architecture to container based architecture apaco...
Modernizing the monolithic architecture to container based architecture apaco...Modernizing the monolithic architecture to container based architecture apaco...
Modernizing the monolithic architecture to container based architecture apaco...

Kafka and event driven architecture -apacoug20
Kafka and event driven architecture -apacoug20Kafka and event driven architecture -apacoug20
Kafka and event driven architecture -apacoug20

Kafka and event driven architecture -og yatra20
Kafka and event driven architecture -og yatra20Kafka and event driven architecture -og yatra20
Kafka and event driven architecture -og yatra20

Extend soa with api management Sangam18
Extend soa with api management Sangam18Extend soa with api management Sangam18
Extend soa with api management Sangam18

Extend soa with api management Doag18
Extend soa with api management Doag18Extend soa with api management Doag18
Extend soa with api management Doag18

Roaring with elastic search sangam2018
Roaring with elastic search sangam2018Roaring with elastic search sangam2018
Roaring with elastic search sangam2018

Extend soa with api management spoug- Madrid
Extend soa with api management   spoug- MadridExtend soa with api management   spoug- Madrid
Extend soa with api management spoug- Madrid

Expose your data as an api is with oracle rest data services -spoug Madrid
Expose your data as an api is with oracle rest data services -spoug MadridExpose your data as an api is with oracle rest data services -spoug Madrid
Expose your data as an api is with oracle rest data services -spoug Madrid

Modern application development with oracle cloud sangam17
Modern application development with oracle cloud sangam17Modern application development with oracle cloud sangam17
Modern application development with oracle cloud sangam17

award-3b07c32b-b116-3a75-8974-d814d37026ca
award-3b07c32b-b116-3a75-8974-d814d37026caaward-3b07c32b-b116-3a75-8974-d814d37026ca
award-3b07c32b-b116-3a75-8974-d814d37026ca

award-3b07c32b-b116-3a75-8974-d814d37026ca
award-3b07c32b-b116-3a75-8974-d814d37026caaward-3b07c32b-b116-3a75-8974-d814d37026ca
award-3b07c32b-b116-3a75-8974-d814d37026ca

Adf spotlight-webcenter task flow-customzation
Adf spotlight-webcenter task flow-customzationAdf spotlight-webcenter task flow-customzation
Adf spotlight-webcenter task flow-customzation

Personalization in webcenter portal
Personalization in webcenter portalPersonalization in webcenter portal
Personalization in webcenter portal

Custom audit rules in Jdeveloper extension
Custom audit rules in Jdeveloper extensionCustom audit rules in Jdeveloper extension
Custom audit rules in Jdeveloper extension

File upload in oracle adf mobile
File upload in oracle adf mobileFile upload in oracle adf mobile
File upload in oracle adf mobile

Webcenter application performance tuning guide
Webcenter application performance tuning guideWebcenter application performance tuning guide
Webcenter application performance tuning guide

Tuning and optimizing webcenter spaces application white paper
Tuning and optimizing webcenter spaces application white paperTuning and optimizing webcenter spaces application white paper
Tuning and optimizing webcenter spaces application white paper

Oracle adf performance tips
Oracle adf performance tipsOracle adf performance tips
Oracle adf performance tips

Oracle Fusion Architecture
Oracle Fusion ArchitectureOracle Fusion Architecture
Oracle Fusion Architecture

Incentive compensation in fusion CRM
Incentive compensation in fusion CRMIncentive compensation in fusion CRM
Incentive compensation in fusion CRM


Recently uploaded

JavaLand 2024: Application Development Green Masterplan
JavaLand 2024: Application Development Green MasterplanJavaLand 2024: Application Development Green Masterplan
JavaLand 2024: Application Development Green Masterplan
Miro Wengner

GraphRAG for LifeSciences Hands-On with the Clinical Knowledge Graph
GraphRAG for LifeSciences Hands-On with the Clinical Knowledge GraphGraphRAG for LifeSciences Hands-On with the Clinical Knowledge Graph
GraphRAG for LifeSciences Hands-On with the Clinical Knowledge Graph
Neo4j

Nordic Marketo Engage User Group_June 13_ 2024.pptx
Nordic Marketo Engage User Group_June 13_ 2024.pptxNordic Marketo Engage User Group_June 13_ 2024.pptx
Nordic Marketo Engage User Group_June 13_ 2024.pptx
MichaelKnudsen27

Christine's Supplier Sourcing Presentaion.pptx
Christine's Supplier Sourcing Presentaion.pptxChristine's Supplier Sourcing Presentaion.pptx
Christine's Supplier Sourcing Presentaion.pptx
christinelarrosa

Mutation Testing for Task-Oriented Chatbots
Mutation Testing for Task-Oriented ChatbotsMutation Testing for Task-Oriented Chatbots
Mutation Testing for Task-Oriented Chatbots
Pablo Gómez Abajo

Y-Combinator seed pitch deck template PP
Y-Combinator seed pitch deck template PPY-Combinator seed pitch deck template PP
Y-Combinator seed pitch deck template PP
c5vrf27qcz

How to Interpret Trends in the Kalyan Rajdhani Mix Chart.pdf
How to Interpret Trends in the Kalyan Rajdhani Mix Chart.pdfHow to Interpret Trends in the Kalyan Rajdhani Mix Chart.pdf
How to Interpret Trends in the Kalyan Rajdhani Mix Chart.pdf
Chart Kalyan

High performance Serverless Java on AWS- GoTo Amsterdam 2024
High performance Serverless Java on AWS- GoTo Amsterdam 2024High performance Serverless Java on AWS- GoTo Amsterdam 2024
High performance Serverless Java on AWS- GoTo Amsterdam 2024
Vadym Kazulkin

Northern Engraving | Modern Metal Trim, Nameplates and Appliance Panels
Northern Engraving | Modern Metal Trim, Nameplates and Appliance PanelsNorthern Engraving | Modern Metal Trim, Nameplates and Appliance Panels
Northern Engraving | Modern Metal Trim, Nameplates and Appliance Panels
Northern Engraving

Session 1 - Intro to Robotic Process Automation.pdf
Session 1 - Intro to Robotic Process Automation.pdfSession 1 - Intro to Robotic Process Automation.pdf
Session 1 - Intro to Robotic Process Automation.pdf
UiPathCommunity

"$10 thousand per minute of downtime: architecture, queues, streaming and fin...
"$10 thousand per minute of downtime: architecture, queues, streaming and fin..."$10 thousand per minute of downtime: architecture, queues, streaming and fin...
"$10 thousand per minute of downtime: architecture, queues, streaming and fin...
Fwdays

What is an RPA CoE? Session 1 – CoE Vision
What is an RPA CoE?  Session 1 – CoE VisionWhat is an RPA CoE?  Session 1 – CoE Vision
What is an RPA CoE? Session 1 – CoE Vision
DianaGray10

Freshworks Rethinks NoSQL for Rapid Scaling & Cost-Efficiency
Freshworks Rethinks NoSQL for Rapid Scaling & Cost-EfficiencyFreshworks Rethinks NoSQL for Rapid Scaling & Cost-Efficiency
Freshworks Rethinks NoSQL for Rapid Scaling & Cost-Efficiency
ScyllaDB

QA or the Highway - Component Testing: Bridging the gap between frontend appl...
QA or the Highway - Component Testing: Bridging the gap between frontend appl...QA or the Highway - Component Testing: Bridging the gap between frontend appl...
QA or the Highway - Component Testing: Bridging the gap between frontend appl...
zjhamm304

AppSec PNW: Android and iOS Application Security with MobSF
AppSec PNW: Android and iOS Application Security with MobSFAppSec PNW: Android and iOS Application Security with MobSF
AppSec PNW: Android and iOS Application Security with MobSF
Ajin Abraham

Must Know Postgres Extension for DBA and Developer during Migration
Must Know Postgres Extension for DBA and Developer during MigrationMust Know Postgres Extension for DBA and Developer during Migration
Must Know Postgres Extension for DBA and Developer during Migration
Mydbops

What is an RPA CoE? Session 2 – CoE Roles
What is an RPA CoE?  Session 2 – CoE RolesWhat is an RPA CoE?  Session 2 – CoE Roles
What is an RPA CoE? Session 2 – CoE Roles
DianaGray10

Leveraging the Graph for Clinical Trials and Standards
Leveraging the Graph for Clinical Trials and StandardsLeveraging the Graph for Clinical Trials and Standards
Leveraging the Graph for Clinical Trials and Standards
Neo4j

[OReilly Superstream] Occupy the Space: A grassroots guide to engineering (an...
[OReilly Superstream] Occupy the Space: A grassroots guide to engineering (an...[OReilly Superstream] Occupy the Space: A grassroots guide to engineering (an...
[OReilly Superstream] Occupy the Space: A grassroots guide to engineering (an...
Jason Yip

The Microsoft 365 Migration Tutorial For Beginner.pptx
The Microsoft 365 Migration Tutorial For Beginner.pptxThe Microsoft 365 Migration Tutorial For Beginner.pptx
The Microsoft 365 Migration Tutorial For Beginner.pptx
operationspcvita


Recently uploaded (20)

JavaLand 2024: Application Development Green Masterplan
JavaLand 2024: Application Development Green MasterplanJavaLand 2024: Application Development Green Masterplan
JavaLand 2024: Application Development Green Masterplan

GraphRAG for LifeSciences Hands-On with the Clinical Knowledge Graph
GraphRAG for LifeSciences Hands-On with the Clinical Knowledge GraphGraphRAG for LifeSciences Hands-On with the Clinical Knowledge Graph
GraphRAG for LifeSciences Hands-On with the Clinical Knowledge Graph

Nordic Marketo Engage User Group_June 13_ 2024.pptx
Nordic Marketo Engage User Group_June 13_ 2024.pptxNordic Marketo Engage User Group_June 13_ 2024.pptx
Nordic Marketo Engage User Group_June 13_ 2024.pptx

Christine's Supplier Sourcing Presentaion.pptx
Christine's Supplier Sourcing Presentaion.pptxChristine's Supplier Sourcing Presentaion.pptx
Christine's Supplier Sourcing Presentaion.pptx

Mutation Testing for Task-Oriented Chatbots
Mutation Testing for Task-Oriented ChatbotsMutation Testing for Task-Oriented Chatbots
Mutation Testing for Task-Oriented Chatbots

Y-Combinator seed pitch deck template PP
Y-Combinator seed pitch deck template PPY-Combinator seed pitch deck template PP
Y-Combinator seed pitch deck template PP

How to Interpret Trends in the Kalyan Rajdhani Mix Chart.pdf
How to Interpret Trends in the Kalyan Rajdhani Mix Chart.pdfHow to Interpret Trends in the Kalyan Rajdhani Mix Chart.pdf
How to Interpret Trends in the Kalyan Rajdhani Mix Chart.pdf

High performance Serverless Java on AWS- GoTo Amsterdam 2024
High performance Serverless Java on AWS- GoTo Amsterdam 2024High performance Serverless Java on AWS- GoTo Amsterdam 2024
High performance Serverless Java on AWS- GoTo Amsterdam 2024

Northern Engraving | Modern Metal Trim, Nameplates and Appliance Panels
Northern Engraving | Modern Metal Trim, Nameplates and Appliance PanelsNorthern Engraving | Modern Metal Trim, Nameplates and Appliance Panels
Northern Engraving | Modern Metal Trim, Nameplates and Appliance Panels

Session 1 - Intro to Robotic Process Automation.pdf
Session 1 - Intro to Robotic Process Automation.pdfSession 1 - Intro to Robotic Process Automation.pdf
Session 1 - Intro to Robotic Process Automation.pdf

"$10 thousand per minute of downtime: architecture, queues, streaming and fin...
"$10 thousand per minute of downtime: architecture, queues, streaming and fin..."$10 thousand per minute of downtime: architecture, queues, streaming and fin...
"$10 thousand per minute of downtime: architecture, queues, streaming and fin...

What is an RPA CoE? Session 1 – CoE Vision
What is an RPA CoE?  Session 1 – CoE VisionWhat is an RPA CoE?  Session 1 – CoE Vision
What is an RPA CoE? Session 1 – CoE Vision

Freshworks Rethinks NoSQL for Rapid Scaling & Cost-Efficiency
Freshworks Rethinks NoSQL for Rapid Scaling & Cost-EfficiencyFreshworks Rethinks NoSQL for Rapid Scaling & Cost-Efficiency
Freshworks Rethinks NoSQL for Rapid Scaling & Cost-Efficiency

QA or the Highway - Component Testing: Bridging the gap between frontend appl...
QA or the Highway - Component Testing: Bridging the gap between frontend appl...QA or the Highway - Component Testing: Bridging the gap between frontend appl...
QA or the Highway - Component Testing: Bridging the gap between frontend appl...

AppSec PNW: Android and iOS Application Security with MobSF
AppSec PNW: Android and iOS Application Security with MobSFAppSec PNW: Android and iOS Application Security with MobSF
AppSec PNW: Android and iOS Application Security with MobSF

Must Know Postgres Extension for DBA and Developer during Migration
Must Know Postgres Extension for DBA and Developer during MigrationMust Know Postgres Extension for DBA and Developer during Migration
Must Know Postgres Extension for DBA and Developer during Migration

What is an RPA CoE? Session 2 – CoE Roles
What is an RPA CoE?  Session 2 – CoE RolesWhat is an RPA CoE?  Session 2 – CoE Roles
What is an RPA CoE? Session 2 – CoE Roles

Leveraging the Graph for Clinical Trials and Standards
Leveraging the Graph for Clinical Trials and StandardsLeveraging the Graph for Clinical Trials and Standards
Leveraging the Graph for Clinical Trials and Standards

[OReilly Superstream] Occupy the Space: A grassroots guide to engineering (an...
[OReilly Superstream] Occupy the Space: A grassroots guide to engineering (an...[OReilly Superstream] Occupy the Space: A grassroots guide to engineering (an...
[OReilly Superstream] Occupy the Space: A grassroots guide to engineering (an...

The Microsoft 365 Migration Tutorial For Beginner.pptx
The Microsoft 365 Migration Tutorial For Beginner.pptxThe Microsoft 365 Migration Tutorial For Beginner.pptx
The Microsoft 365 Migration Tutorial For Beginner.pptx


Spring framework in depth

  • 2.  Introduction  Injection  Aspect Dependency Oriented Programming  Bean Factory  Wiring Objects  Spring MVC  Spring DAO
  • 3. Introduction  Spring Framework  is a J2EE Framework  that provides a lightweight container  for dependency injection  and Aspect oriented Programming (AOP) Now what was that, again?
  • 4. DI or IOC  Dependency injection or Inversion of control  Alternative to Service Locator Locate your own dependencies Let the framework do the dirty job for you
  • 5. AOP  Aspect oriented programming  Cross cutting concerns  Transaction, Security and Logging requirements
  • 6. BeanFactory      Interface BeanFactory BeanFactory creates beans getBean() method Implementation classes like the XmlBeanFactory Methods:  getBean()  isSingleton()  getType()  getAliases()  containsBean() This is how a BeanFactory looks like
  • 7. Using BeanFactory public static void main (String args []){ BeanFactory factory = new XmlBeanFactory (new FileInputStream (“bean-config.xml”)); MyBean mybean = (MyBean) factory.getBean (“myBean”); mybean.methodx(): } A Web Application may never need to use code such as the one shown above as the framework does it all for us.
  • 8. ApplicationContext  Extends the BeanFactory  Adds the following methods:  getResource()  getMessage()
  • 9. Wiring Objects  Spring provides for declarative wiring of objects  Declaring a bean  Declaring beans as singleton or prototype  Declaring init and destroy methods  Injecting values into beans properties  Injecting other beans as properties  Injecting arrays and collections as properties Spring book This book on Spring is marvelous ! Now I am a wiring expert too !
  • 10. Declaring beans <beans> <bean id=“x” class=“y”/> </beans> When using the id attribute, special characters are not permitted. Spring therefore allows the use of an alternative attribute: name <bean name=“x” class=“y”/>
  • 11. To singleton or not  Beans are instantiated as Singletons by default. This is how we can override the default : <beans> <bean id=“x” class=“y” singleton=“false”/> </beans>
  • 12. Init and destroy  As Spring manages the bean lifecycle, it allows us to specify the init and destroy methods declaratively. <beans> <bean id=“x” class=“y” init-method=“a”/> <bean id=“p” class=“q” destroy-method=“b”/> </beans>
  • 13. Alternative  Spring defines the following interfaces  InitializingBean  DisposableBean  Beans implementing these interfaces are assured that the methods defined in these interfaces are called back by Spring during initialization and destruction.  This is thus an alternative to the init and destroy method declaration in the config.xml
  • 14. Dependency Injection  Spring allows for:  Setter based injection  Constructor based injection
  • 15. Setter injection  Setter based injection allows us to inject values into bean properties through the setter methods.  These values may be  Primitive Types  Strings  Beans  Arrays  Collections  Property
  • 16. Primitive Types <bean id=“x” class=“y”> <property name=“age”> <value>26</value> </property> </bean> This sets “26” to the property age
  • 17. Strings <bean id=“x” class=“y”> <property name=“nm”> <value>val</value> </property> </bean> This sets “val” to the property nm <bean id=“x” class=“y”> <property name=“pq”> <value></value> </property> </bean> This sets an empty string “” to the property pq
  • 18. Null values <bean id=“x” class=“y”> <property name=“nm”> <value><null/></value> </property> </bean>
  • 19. Bean <beans> <bean id=“myClass” class=“demo.MyClass”> <property name=“display”> <ref bean=“a” /> </property> </bean> <bean id=“a” class=“util.TestClass”/> </beans>
  • 20. Arrays and Lists <bean id=“x” class=“y”> <property name=“nm”> <list> <value>pqr</value> <value>xyz</value> <value>abc</value> </list> </property> </bean>
  • 21. List of objects <beans> <bean id=“x” class=“y”> <property name=“nm”> <list> <ref bean=“a”/> <ref bean=“b”/> </list> </property> </bean> <bean id=“a” class=“p”/> <bean id=“b” class=“q”/> </beans>
  • 22. Sets <bean id=“x” class=“y”> <property name=“nm”> <set> <value>pqr</value> <value>xyz</value> <value>abc</value> </set> </property> </bean> For a set consisting of beans use the <ref bean> tag
  • 23. Maps <beans> <bean id=“x” class=“y”> <property name=“nm”> <map> <entry key=“k1”> <value>val1</value> </entry> <entry key=“k2”> <ref bean=“a” /> Spring limits the user to declare keys as Strings only </entry> </map> </property> </bean> <bean id=“a” class=“p”/> </beans>
  • 24. Properties <beans> <bean id=“x” class=“y”> <property name=“nm”> <props> <prop key=“k1”>val1</prop> <prop key=“k2”>val2</prop> </props> </property> </bean> </beans>
  • 25. Constructor injection Spring allows for injection via constructors Below is example of constructor based injection <beans> <bean id=“myClass” class=“demo.MyClass”> <constructor-arg> <value>42</value> </constructor-arg> </bean> </beans>
  • 26. Constructor injection Spring allows for injection via constructors Below is example of constructor based injection for setting multiple arguments <beans> <bean id=“myClass” class=“demo.MyClass”> <constructor-arg index=“1”> <value>42</value> </constructor-arg> <constructor-arg index=“2”> <ref bean=“testClass”/> </constructor-arg> </bean> </beans>
  • 27. Constructor injection - Advantage The data members of the class are set only once at the time of creation/instantiation of the object. There are no public setter methods that are exposed to the outside world and through which the state of an object can be changed. Thus the object is immutable.
  • 28. Constructor injection - Disadvantage The xml declaration for constructor based injection is complex and the developer has to ensure that there are no ambiguities in the parameters
  • 29. Autowiring  Spring has autowiring capabilities <beans> <bean id=“x” class=“y” autowire=“byName”> </bean> </beans> The dependencies need not be defined in the xml explicitly. With autowire by Name option if we ensure that the name of id in xml, and name of the properties in the java class matches then the Spring framework automatically invokes setter methods. Note: byName should be used with only setter based injection
  • 31. Spring Core  Dependency Injection  BeanFactory and ApplicationContext
  • 32. Spring Web  Web utilities Spring tags for use in html/jsp  Multipart functionality  Integration with Struts framework In one application the struts can be used in web MVC layer and integrated with other Spring components in the application bigfile.xml part1.xml part2.xml part3.xml
  • 33. Spring Web MVC  Controller  Validator
  • 34. Life cycle of a request Spring Web MVC Handler Mapping 2 Request 3 1 Dispatcher Servlet Controller 4 ModelAndView 5 ViewResolver 6 View
  • 35. Spring Web MVC 2 Request Handle Mapping 3 1 Dispatcher Servlet Controller 4 ModelAndView 5 ViewResolver
  • 36. Life cycle of a Request 1. 2. 3. 4. 5. 6. 7. The client typically web browser send request (1) The first component to receive is DispatcherServlet. All the requests goes through single front controller servlet. DispacherServlet queries HandlerMapping. This is a mapping of URLs and Controller objects defined in configuration xml Dispatcher servlet dispatches request to Controller to perform business logic Controller returns the model and the view. The model is the data that need to be displayed in the view. The view is a logical name that is mapped to the .jsp file that will render the view. This is defined in the xml mapping file Controller send request to ViewResolver to resolve which .jsp to render for which view Finally the view is rendered
  • 37. Configuring the Dispatcher Servlet Dispatcher servlet is MVC’s front controller. Like any servlet it must be configured in Spring application context Example: <servlet> <servlet-name>testapp</servlet-name> <servletclass>org.springframework.web.servlet.DispatcherServl et</servlet-class> <load-on-startup>1</load-on-startup> <servlet> Since the dispatcher servlet’s name is testapp the servlet will load the application context from a file named ‘testapp-servlet.xml’
  • 38. Spring Web MVC - Controller There are following main Controller types  Abstract Controller  Simple Form Controller  Multi Action Controller All the above are implementation classes for the Controller Interface
  • 39. Abstract Controller  This controller is used when the view/GUI has to be read only.  No data is entered in the screen Example public class ListCircuitsController extends AbstractController{ public ModelAndView handleRequestInternal(HttpServletRequest req,HttpServletResponse res){ Collection circuits=circuitService.getAllCircuits(); return new ModelAndView(“circuitList”,”circuits”, circuits); } The first argument “circuitList” is the name of the view to which the controller is associated. The second argument is the name of the model object which holds the third argument circuits object.
  • 40. Declaring View Resolver View Resolver resolves the logical view name returned by controller to the jsp file that renders the view. Of the various view resolvers InternalResourceViewResolver is simplest for rendering jsp Example <!-- view-resolver --> <bean id="viewResolver" class="org.springframework.web.servlet.view.InternalResource ViewResolver"> <property name="prefix"> <value>/WEB-INF/ui/</value> </property> <property name="suffix"> <value>.jsp</value> </property> </bean> <!-- /view-resolver -->
  • 41. Mapping requests to Controllers SimpleUrlHandlerMapping is one of the straight forward Spring’s handler mapping. This maps the URL patterns to controllers. Example <bean id="urlMapping" class="org.springframework.web.servlet.handler.Simple UrlHandlerMapping"> <property name="urlMap"> <map> <entry key="/forum.do"> <ref bean="forumController" /> </entry> </map> </property> </bean> <!-- /UrlMapping -->
  • 42. Simple Form Controller  This controller is used for GUI which have a data entry form to be filled in and submitted by the user.  The controller is responsible for –  Displaying the form for data entry  Validating data entered by the user  Redisplaying the form on error with error message  Submitting the data  Displaying the success page
  • 43. Command Object  It holds the data that the user enters in the form/GUI
  • 44. Simple Form Controller -code public class EnterCircuitDetailsController extends SimpleFormController{ public EnterCircuitDetails(){ setCommandClass(Circuit.class); } Protected void doSubmitAction(Object command) throws Exception{ Circuit circuit=(Circuit) command; circuitService.createCircuit(circuit); } Private CircuitService circuitservive; Public void setCircuitService(CircuitService circuitservice){ this.circuitService=circuitService; } }
  • 45. Simple Form Controller -Configuration  The details of configuration of the view is as below: <bean id=“enterCircuitDetailsController" class=" com.circuit.mvc.CircuitDetailsController"> <property name=“circuitService" ref=“circuitService" /> <property name="formView"><value>circuitForm</value></property> <property name="successView"><value>circuitCreated.do</value></pr operty> </bean>
  • 46. Simple Form Controller -explained  As per the above example EnterCircuitDetailsController displays a form for taking the details of the circuit that need to be created as well as processes the data that is entered.  The doSubmitAction() method handles form submission and takes details of the form from Circuit object  The doSubmitAction() does not return ModelAndView object and hence with this we will not be able to send any data to the view. If a particular view need to be displayed with some data in it we need to use the onSubmit() method instead.
  • 47. Simple Form Controller -explained  SimpleFormController is designed to keep view details out of the controller’s code. The formView represents the logical name of the view that is to be displayed when the Controller gets a GET request or there are any errors on the form. The success view represents the logical name of the view to be displayed when form is submitted successfully. The view resolver will use this to render the actual view to the user.
  • 48. Simple Form Controller  Below is an example of onSubmit method protected ModelAndView onSubmit(Object command, BindException errors) throws Exception { Circuit circuit = (Circuit) command; circuitService.createCircuit(circuit); return new ModelAndView(getSuccessView(),“circuit", circuit); }
  • 49. Multi Action Controller  These controllers are used to handle multiple actions in a single controller. Each action is handled by a different method within the controller.  The specific method that needs to be called in the Action controller based on the type of resolver.  The below example shows that we are using methodName Resolver <bean id="multiactionController" class="com. mvc.ListCircuitsController"> <property name="methodNameResolver"> <ref bean="methodNameResolver"/> </property> </bean>
  • 50. Multi Action Controller  There are two types of method name resolvers like ParameterMethodNameResolver and PropertiesMethodNameResolver. This will ensure that the appropriate method in the Multiaction Controller is called based on the parameter name passed in the request. The parameter name will need to be same as the method name in the MultiActionForm Controller. Below is the configuration that need to be done <bean id="methodNameResolver" class="org.springframework.web. servlet.mvc.multiaction.ParameterMethodNameResolver"> <property name="paramName"> <value>action</value> </property> </bean>
  • 51. Multi Action Controller  Example: If we are accessing the URL “http://…/listCircuits.htm?action=circuitsByDate” the method name circuitsByDate() is called in the MultiActionController since we have configured the name resolver to be based on the parameter passed in the request.
  • 52. Spring Web MVC-Validator  Spring provides a Validator Interface that is used for validating objects  For Example: In the example of a simple form controller in previous slides in which there is a command object “circuit” which needs to be validated or in other words we need to validate that the circuit details entered by the user are correct. In that case the class Circuit should implement the Validator interface
  • 53. Spring Web MVC-Validator  Validator Interface has the following methods defined in it public interface Validator { void validate(Object obj, Errors errors); boolean supports(Class class); }
  • 54. Spring Web MVC-Validator Code  Sample code below explains how Validator Interface is implemented to perform validations. We write a class ValidateCktDetails for validating circuit details entered by user public class CircuitValidator implements Validator { public boolean supports(Class class) { return class.equals(Circuit.class); } public void validate(Object command, Errors errors) { Circuit circuit = (Circuit) command; ValidationUtils.rejectIfEmpty( errors, “circuitType", "required. circuitType ", “Circuit Type is mandatory for creating a circuit"); }
  • 55. Web MVC-Validator Code Explained  The framework uses support() method to check if the Validator can be used for a given class  The validate() methods can validate all the attributes of the object that is passed into validate() method and reject invalid values through Errors object
  • 56. Spring Web MVC-Validator  The only other thing to do is to use the CircuitValidator with EnterCircuitDetailsController which can be done by wiring the bean <bean id=“enterCircuitDetailsController" class= "com.circuit.mvc.CircuitDetailsController"> <property name="validator"> <bean class="com.validate.mvc.CircuitValidator"/> </property> </bean>
  • 57. Spring Web MVC  When a user enters the circuit details, if all of the required properties are set and circuit type is not empty, then EnterCircuitDetailsController’s doSubmitAction() will be called. However, if CircuitValidator rejects any of the fields, then the user will be returned to the form view to correct the errors.
  • 58. Spring Context  Resource bundles  Event propagation  Bean Lookup
  • 59. Spring ORM  Hibernate support- Spring provides integration with Object Relational mapping frameworks like Hibernate
  • 60. Spring DAO  Transaction infrastructure  JDBC support  DAO support
  • 61. Spring DAO-JDBC  Assuming that the persistence layer in an application is JDBC. In that case we need to use DataSourceTrnsactionManger which will manage transactions on a single JDBC Data Source  The source code explains the use of Transaction Manager. The transaction manager takes care of managing the transactions. <bean id="transactionManager" class="org.springframework.jdbc. datasource.DataSourceTransactionManager"> <property name="dataSource"> <ref bean="dataSource"/> </property> </bean>
  • 62. Spring DAO-JDBC  The dataSource property is set with a reference to a bean named datasource <bean id="datasource" class="org.apache.commons.dbcp.BasicDataSource"> <property name="driverClassName"> <value>oracle.jdbc.driver.OracleDriver</value> </property> <property name="url"> <value>jdbc:oracle:thin:@111.21.15.234:1521:TESTSID</value> </property> <property name="username"> <value>test</value> </property> <property name="password"> <value>test</value> </property> </bean>

Editor's Notes

  1. Life cycle of a RequestThe client typically web browser send request (1)The first component to receive is DispatcherServlet. All the requests goes through single front controller servlet.DispacherServlet queries HandlerMapping. This is a mapping of URLs and Controller objects defined in configuration xmlDispatcher servlet dispatches request to Controller to perform business logicController returns the model and the view. The model is the data that need to be displayed in the view. The view is a logical name that is mapped to the .jsp file that will render the view. This is defined in the xml mapping fileController send request to ViewResolver to resolve which .jsp to render for which viewFinally the view is rendered
