• Designed a Sine Wave Generator Hardware, whose frequency could be controlled using a quadrature encoder.
• Coded the FPGA board in System Verilog to display a count (going from 0 to 9999) on to a seven segment board. This count that was displayed, was same as the frequency of the sine wave generated.
• Incorporated a brightness control feature for all the digits being displayed. This was done by changing the duty cycle using a push button for the PWM control.
• Included an additional feature of increasing the count and the frequency by tens, hundreds or thousands, instead of increasing by just one.
