Mogas Industries manufactures a line of industrial ball valves specifically designed for the most demanding applications, including extremes of temperature, pressure, abrasive particulates, acidic products, heavy solids build-up, and large pressure differential. The Mogas valves are designed to provide sufficient levels of safety and performance where the results of failure can be catastrophic. Specialty modifications also provide noise reduction and velocity control. The presentation illustrates and explains the special features needed to accommodate the world's most demanding valve applications, as well as providing process schematics for numerous industrial applications that show how the valves are used.
