Seminar presentation On Femtocell Technology
•Download as PPTX, PDF•
1 like•393 views
Femtocell technology provides improved cellular coverage for indoor spaces. A femtocell is a small cellular base station that connects to a service provider's network via broadband to improve coverage for mobile phones within a home or business. Femtocells can support a few mobile phones within a range of 10-50 meters and help alleviate capacity constraints on the macro network by shifting traffic indoors. They provide benefits like improved coverage, capacity, and battery life for users along with increased revenue and customer satisfaction for providers. However femtocells require a broadband connection and don't support outdoor coverage. Future research aims to develop femtocells that can support 4G/5G networks and integrate with other home devices.
