Recommended
More Related Content
What's hot
What's hot (20)
Viewers also liked
Viewers also liked (11)
Similar to Introduction to Seismology Analysis Saudi Arabia
Similar to Introduction to Seismology Analysis Saudi Arabia (20)
More from Ali Osman Öncel
More from Ali Osman Öncel (20)
Recently uploaded
Recently uploaded (20)
Introduction to Seismology Analysis Saudi Arabia
- 1. Introduction to Seismology Seismic Hazard Analysis 1 (pp.455-460) Department of Earth Sciences KFUPM Ali Oncel [email_address] Introduction to Seismology-KFUPM
- 3. Introduction to Seismology-KFUPM Oncel, 2006
- 4. Depth=0-20km Time Interval: 1973-2005 Log (N)= 8.06 – 1.12 M Frequency-Magnitude Model Mc=4.6 Introduction to Seismology-KFUPM Oncel, 2006
- 5. Zoning : Spatial mapping of the variations in seismicity or earthquake strong ground motion (and identification of similar zones) Parameters to map: Occurrence of damaging earthquakes (Mallett 1858) Number of felt earthquakes (e.g. Balloré 1896) I o Macrozoning on the regional scale Microzoning takes into account localised conditions e.g. rock and soil type Recall: Seismic Zonation Introduction to Seismology-KFUPM
- 6. Microzoning for Saudi Arabia Introduction to Seismology-KFUPM Al-Amri (2005)
- 7. Al-Amri (2005) Introduction to Seismology-KFUPM
- 8. Introduction to Seismology-KFUPM Oncel, 2006 after Al-Amri, 2005 What about the M max ?
- 9. Magnitude prediction equations • Best known: Wells and Coppersmith (1994). – Distributed to the class. – Recommendation: read the article, and learn how to use these relations. Introduction to Seismology-KFUPM See pp. 437 of Bullen and Bolt
- 12. Adams, 2006 Macro-/Microzoning for Saudi Arabia Introduction to Seismology-KFUPM Al-Amri, 2005
- 13. Abdalla and Al- Homoud (2004 ) Al-Amri (2005) Compared Models of Seismic Hazard Introduction to Seismology-KFUPM
- 16. Abdalla and Al- Homoud (2004) Case Work: Eastern Arabia Introduction to Seismology-KFUPM
- 17. Seismic Zones on Eastern Arabia Introduction to Seismology-KFUPM Abdalla and Al- Homoud (2004)
- 18. Seismic Sources for Eastern Arabia Introduction to Seismology-KFUPM Abdalla and Al- Homoud (2004)
- 19. Maximum Expected Earthquakes for Seismic Sources Introduction to Seismology-KFUPM Abdalla and Al- Homoud (2004)
- 20. Hazard Parameters for Seismic Sources of Eastern Arabia Could you write Magnitude-Frequency Relations for Regions 1 and 2? Log N= 10.17 – 1.22 M Region 1 Log N= 6.99 - 0.94 M Region 2 What is the number of M7 for regions 1 and 2? Introduction to Seismology-KFUPM Abdalla and Al- Homoud (2004) 1008-2002
- 21. What is the Frequency? Log (N/T obs )= 10.17 – 1.22 M Region 1 Log (N/T obs )= 6.99 - 0.94 M Region 2 T obs = 995 years What is the number of M7 for regions 1 and 2? (N/T obs ) = 10 10.17-1.22* 7 (N/T obs )= 10 6.99-0.94* 7 0.043 for Region 1 0.03 for Region 2 Introduction to Seismology-KFUPM
- 22. What is the Recurrence Time? What is the recurrence period for M7 events? T(1)= 1/ (N/T obs )= T(2)=1/ (N/T obs )= 23.33 yrs 387.10 yrs Which of those regions has large hazard? Region 1? Or Region 2? Introduction to Seismology-KFUPM
- 23. Probability is given by formula as: P(t)= 1-e -t/T Recall T is recurrence time while t is years Then calculate the M=7 probability for 30 years? P(t)= 0.72 or % 72 for Region 1 P(t)= 0.07 or % 7 for Region 2 Introduction to Seismology-KFUPM What is the Earthquake Probability?
