The document describes a proposed online library management system. It includes sections on methodology, scope, requirements, design diagrams, screenshots and future scope. The key points are: 1. The proposed system will manage book and member records, transactions, and generate reports to provide an efficient service for librarians and members. 2. The system will allow librarians to add, issue, and return books and update member information. Members can check book availability and status. 3. Entity relationship, use case, sequence, and activity diagrams were designed to model the system's functions and interactions between librarians and members.

1. SUBMITTED BY-
1. POULAMEE CHATTOPADHYAY (1005102)
2. SIDDHARTH SHANKAR (1005185)
3. SUMAN DAS (1005206)
4. VARSHA SRAKAR (1005221)

2. INTRODUCTION
1.1 METHODOLOGY
A software development methodology engineering is a framework that is used to structure,
plan, and control the process of developing an information system. A software development
process also known as software development life-cycle (SDLC), is a structure imposed on the
development of a software product. The main idea of the SDLC has been to pursue the
development of information systems in a very deliberate, structured and methodical way,
requiring each stage of the life cycle from inception of the idea to delivery of the final system, to
be carried out rigidly and sequentially within the context of the framework being applied.
As a noun, a software development methodology is a framework that is used to structure, plan,
and control the process of developing an information system - this includes pre-definition of
specific deliverables and artifacts that are created and completed by a project team to develop or
maintain an application. Specific software development methodologies include:
· Rational Unified Process (RUP , IBM) since 1998
· Agile Unified Process (AUP) since 2005 by Scott Ambler

3. Every software development methodology approach acts as a basis for applying
specific frameworks to develop and maintain software. Several software development
approaches have been used since the origin of information technology. These are:
• Waterfall: a linear framework
• Prototyping: an iterative framework
• Evolutionary: a combined linear iterative framework
• Spiral: a combined linear framework
• Rapid application development (RAD): an iterative framework
• Extreme Programming

4. Purpose of ONLINE MANAGEMENT SYSTEM project -
The purpose of this application are as follows :
• The software is for automation of library work
• It provides following facilities to
1) Librarian:
• Can enter details related to a particular book.
• Can provide membership to members and update as required.
2) Member:
• Can request for issue, return book and check for any existing fine by
asking the librarian.
• Can pay his fine and the details are updated accordingly by the librarian.

5. SCOPE
The different areas where we can use this application are :
• Any education institute can make use of it for providing information about
author, content of the available books in its library.
• Modifications can be easily done according to requirements as and when
necessary.

6. REQUIREMENT SPECIFICATION
Functional Requirements :
• Librarian Login: Librarian can login and access the required information.
• Security: No normal user should be able to login except the librarian
• Update member information: Librarian can update the bill for payment of
fine, the number of books issued ,any change in personal details.
• Update book details: Librarian can add new book details and also change
the status of the book (whether available or not available).

7. Non-Functional Requirements :
• Secure access of confidential data (user’s details).
• Better component design to get better performance at peak time
• Flexible service based architecture will be highly desirable for future
extension.

8. System Requirements :
Hardware Requirements :
To develop or implement this project we need different types of hardware
configuration for server and client.
The Client Machines: -
The Server Machines: -
Processor RAM Hard Disk
Intel Pentium III or
AMD-800 MHz
128 MB 100 MB
Processor RAM Hard Disk
Intel Pentium III or
AMD-800 MHz
512 MB 300 MB

9. Software Requirements :
Front End:
• Client on Internet: Web Browser, Operating System (any)
• Client on Intranet: Web Browser, Operating System (any)
Back End:
• JSP,CSS
• Web Server: Apache Tomcat
• Database Server: MSAccess
• Operating System: Any (preferably Linux)

10. Communication Interface
• Students on Internet will be using HTTP/HTTPS protocol.
• Admin on Internet will be using HTTP/HTTPS protocol.
Constraints:
• Not more than 3 books can be issued by any member at a time.
• The librarian cannot go back to the login page after he signs in unless he
logs out.
• User name of librarian has to be unique.

11. HTML :
Hypertext Markup Language is used for creating web pages and other information
that can be displayed in a web browser.
JAVA SERVER PAGES :
It is a technology that helps software developers create dynamically generated web
pages based on HTML, XML, or other document types. To deploy and run Java
Server Pages, a compatible web server with a servlet container, such as Apache
Tomcat is required.
MS ACCESS:
It is a database management tool from Microsoft which combines Relational
Microsoft Jet Database Graphical User Interface and software development tools.
APACHE TOMCAT SERVER :
Apache Tomcat is an open source web server and servlet container developed by
the Apache Software Foundation (ASF). Tomcat implements the Java Servlet and
the Java Server Pages (JSP) and provides a "pure Java" HTTP web server
environment for Java code to run in.

12. OVERVIEW
Project is related to library management which provides reading
services to its members. Any person can become a member of the
library by filling a prescribed form. They can get the book issued,
so that they can take home and return them.

13. PROPOSED SYSTEM
There will be three major components :
1. Stock maintenance.
2. Transaction entry.
3. Reports.
Proposed system provides with following solutions :
1. It provides efficient service to members.
2. Reduces the workload of employee.
3. Fast retrieval of information about the desired book.
4. Provides facility for proper monitoring reduce paper work and provide
data security.
5. All details will be available on a click.

15. S.No. Column Name Data Type Length Description
1 MemberId Text 50 Unique
identification of
members
2 Name Text 70 Name of
Members
3 Address Text 70 Location of
Members
4 DateOfMember
ship
Date/Time Date of
Registration
5 Status Text 50 Temporary/Per
manent
1.TABLE : MemberRecord

16. 2.TABLE :Books
S.No Column Name Data Type Description
1 BookID Text Book identification
number
2 Name Text Title of the book
3 Author Text Author of books
4 Status Text Whether book is
available or not
5 Price Text Cost of books
6 Rack_no Text Location of book
7 No of Books Number Quantity of books

17. 3.TABLE : Transaction
S.No. Column Name Data Type Description
1 TransactionId Text Unique identification of
transaction type and
number
2 MemberId Text User identification
number
3 DateOfIssue Date/Time Date on which book was
issued
4 Due_Date Date/Time Due date on which book
is to be returned
5 BookId Text Unique identification
number of book

18. 4.Table:Librarian
S.No Column Name Data Type Description
1 Name Text Name of the
librarian
2 Password Password Login Password of
the librarian

19. USE CASE DIAGRAM

20. CLASS DIAGRAM

21. Activity diagram for issuing book in library

22. Activity diagram for returning book in library

23. Sequence diagram for issuing book

24. Sequence diagram for returning book

25. E-R DIAGRAM
It is clear that the physical objects from the previous section – the member, books,
library – correspond to entities in the Entity-Relationship model, and the operations
to be done on those entities – holds, checkouts, and so on – correspond to
relationships. However, a good design will minimize redundancy and attempt to
store all the required information in as small a space as possible.

27. :Screenshots:
1. LIBRARIAN LOGIN PAGE

28. 2. LIBRARIAN HOME PAGE

29. 3. BOOK ISSUE FORM

30. 4. Book Issued

31. 5.BOOK RETURN FORM 1

32. 6.BOOK RETURN FORM 2

33. 7.BOOK RETURNED FORM

34. 8.BOOK ADD FORM

35. 9.BOOK ADDED

36. 10.ISSUE STATUS PAGE

37. 11.BOOK ISSUED

38. 12.ADD MEMBER

39. 13.MEMBER ADDED

40. Future Scope
This application can be easily implemented under various situations.
We can add new features as and when we require. Reusability is possible as and when require
in this application. There is flexibility in all the modules.
• Extensibility:
This software is extendable in ways that its original developers may not expect. The following
principles enhances extensibility like hide data structure, avoid traversing multiple links or
methods, avoid case statements on object type and distinguish public and private operations.
•Reusability:
Reusability is possible as and when require in this application. We can update it next version.
Reusable software reduces design, coding and testing cost by amortizing effort over several
designs. Reducing the amount of code also simplifies understanding, which increases the
likelihood that the code is correct. We follow up both types of reusability: Sharing of newly
written code within a project and reuse of previously written code on new projects.

41. • Understandability:
A method is understandable if someone other than the creator of the method can understand the code
(as well as the creator after a time lapse). We use the method, which small and coherent helps to
accomplish this.
• Cost-effectiveness:
Its cost is under the budget and make within given time period. It is desirable to aim for a system with
a minimum cost subject to the condition that it must satisfy the entire requirement.Scope of this
document is to put down the requirements, clearly identifying the information needed by the user, the
source of the information and outputs expected from the system.

42. Conclusion
From a proper analysis of positive points and constraints on the component, it
can be safely concluded that the product is a highly efficient GUI based
component. This application is working properly and meeting to all user
requirements. This component can be easily plugged in many other systems.
