1. Auto-Cloning Photonic Crystal
✓ Multi-Domains of Arbitrary Patterns
✓ Muti-Domained Waveplate / Polarizer on a Chip
✓ Realization of Desired Optical Characteristics by Patterning
・Thickness: ~10λ
・Anisotropic multi-layer
・Inorganic material
・Low refractive index : SiO2
・High refractive : Nb2O5, TiO2, …etc
・Working wavelength : UV - Vis - IR
2. Thin Photonic Crystal Waveplate
3dB
Hybrid
✓ 15μmT×0.5mmH×2mm (max.) W (HWP)
✓ Pitch of Array : 20μm to 250μm
✓ Wavelength Range : C or L Band
✓ Insertion loss : Less than 0.1 dB@λ = 1.55μm Application for polarization diversity circuit
(Commercially available)
0.5 mm
8-segmented waveplate
3. Polarization Beam Splitter
Substrate Photonic crystal
thickness ~ 10λ
Surface SEM image of PBS
✓ Left / Right Circular Polarization Output
✓ Ellipticity : ~0.95
✓ Separation Angle : (max.) 20°@λ=1.55μm
✓ Low Insertion Loss : Less than 0.1dB@λ=1.55μm
Left CP
Right CP
Liner Pol.Left CP Right CP
Right CP Left CP
10 μm
