Network delay
•Download as PPTX, PDF•
5 likes•4,841 views
This document discusses different types of network delay. It defines network delay as the time it takes for data to travel from one node to another across the network, measured in fractions of seconds. The main types of delay are transmission delay, which is the time to transmit a packet onto an outgoing link; propagation delay, the time for a bit to move from one end of a wire to another; processing delay, the time for a router to process a packet; and queuing delay, the time a packet spends waiting in a queue before being processed. Formulas are provided for calculating transmission delay based on packet length and bandwidth, and propagation delay based on wire length and velocity.
