Needles &
Haystacks:
Machine Learning powered
Threat Detection
Ioan Constantin,
Orange Romania
Text with illustrationHow do you go about finding a
needle in a haystack?
It’s simple, actually.
You bring a magnet.
Agenda
Complex Threats
A brief walk trough
some of the new
challenges most
companies face now
with the advent of
APTs.
Machine Learning
Beyond buzzwords: how
do we improve our
existing detection
methods and
technologies with the
context offered by M.L.?
‘Post-hash’
Context
Threat Intel,
Proactive Security,
Threat Hunting,
SOCMINT, HUMINT,
OSINT
Threat Detection
Are we trying to
replace our existing
SIEMs, FWs and
IPSs? Spoiler: No.
We’re building around
it.
1 2 3 4 5SIEM much?
Are we trying to build
yet another Open
Source SIEM?
Advan
ceduses sophisticated
exploits, 0-Days, Social
Engineering. Stealthy.
Compromised end-points
Can infect multiple end-
points in large networks,
of various type such as
smartphones,
workstations,
applications
Highly Dependant on
Social Engineering,
surveillance, supply
chain-compromise
Persistent
Low-and-slow approach
to attacks
Targeting is conducted
trough continuous
monitoring
Task-specific rather than
opportunistic
The goal is to maintain
long-term access
Complex
Threats
Keep a
door
open
Exfiltrate data
Delete all track
Break stuff
06
Complete
mission
Maintain
presence, use
stealthy
(encrypted)
channels to
communicate
05
Keep a low
profile
Expand control
to other
endpoints,
servers, active
equipment,
harvest data
and configs
04
Lateral
Movement
Look around,
find other
vulnerable
victims, gather
as much intel as
you can
03
Reconnaiss
ance.
Create C2C
controllable
victim end-
points in the
network,
escalate
privileges
02
Establish
foothold
Using social
engineering,
spear phishing,
media infestation
with zero-day
malware
01
Initial
compromise
Works in stages
APTs are a complex species
of threats
And we have no definitive guide
or ‘how-to’ detect it or mitigate it.
We’re constantly learning from
the experience of others and
we’re relying on human
intelligence to better understand
these threats
77%Network Technologies
(FWs, Routers,
Switches)
64 %
Log Monitoring / Event
Correlation / SIEMs / A.I.
/ M.L.
Technical Controls
used to Protect
Against APTs*
*according to a TrendMicro Survey, H1 2017
Mobile Security
Gateways, Mobile Anti-
Malware, Mobile Device
Management
37%
83%Antivirus & Antimalware
66%
Zoning Off (Network
Segregation)
Malware Variety
There are hundreds of
million of malware variations
that can be used in a APT.
This makes it challenging to
detect.
41 2 3
Traditional security is
ineffective
As it needs more than
signature or rule-based
detection. It needs context
and some form of
automated learning method
to expand the context
Log analysis and Log
correlation has its limits
Because, of course, it also
needs context and
‘perspective’.
There’s lots of noise
It’s extremely hard to
separate noise from
legitimate traffic and there’s
lots of noise being ‘ingested’
by security equipment
Challenges in mitigation
The average
company takes 170
days to detect an
advanced threat, 39
days to mitigate and
43 days to recover*
*According to the Ponemon Institute
170
days
39
days
43
days
0%
To Mitigation
For Detection
To Recovery
Challenges in mitigation
Obligatory timeline slide
1998 2003 2009 2010 2011 2018
Moonlight Maze
Some guys in Russia breaks
into systems at the Pentagon,
NASA, U.S. Department of
Energy. Exfiltrates thousands
of docs. Attack lasted 2 years
Ghost Net
Large-scale attack,
initiated from phishing
e-mails, downloaded
trojans
RSA Attack
Adobe Flash exploit +
phishing e-mail =
pwned SecurID
Titan Rain
Attacks on large
defense contractors
from various Chinese
sources.
Stuxnet
Fun fact: there’s
chatter out there
about a not-so-long-
awaited sequel 
Stuxnet 2.0
VPNFilter /
BlackEnergy
And, of course the
youngest of the
bunch…
Proactive
Security
Bug Bounty
Programs
Machine Learning,
maybe?
Threat
Intelligence
OSINT
SOCMINT
HUMINT
Counter
surveillance
Threat
Hunting
Solutions?
Provide
Context.
Machine Learning is the science of getting
computers to act without being explicitly
programmed (Stanford University, Artificial
Intelligence Laboratory)
Machine Learning (…) algorithms can figure out how
to perform important tasks by generalizing from
examples (University of Washington)
Machine Learning
Machine Learning
Learn from available data
Using representation, evaluation
and optimisation. Use training
data
Establish baseline
Define normal behaviour, define
normal data.
Don’t over use the word ‘normal’ 
Find Anomalies
Identify deviations from the
baseline. Correlate deviations
with other input data
Act upon finding
Classify deviations as
anomalies. Notify / Take action
Available data
Network
Devices
Endpoints Applications
Security
Products
Cool stuff
Active network
equipment
Routers, switches,
printers, APs and the
like. They all generate
tons of data
PCs, Laptops,
Smartphones,
Servers
Metrics, Operating
Systems Logs, Hardware
logs, Security logs.
Interesting to say the
least
Software clients
Client-side and server-
side. E-Mail clients, Web
Browsers, VPN clients.
In all shapes and sizes,
from ubiquitous MS
Windows to iOS.
Networked, in the
cloud or on endpoints
Everything from FWs,
IPSs, Sandboxes, AVs /
Anti-Malware, Anti-Spam
& E-Mail security
Gateways, MdM etc.
Our secret sauce
We generate huge
amounts of data from
TELCO-specific
technologies and
equipment. We add it to
the mix to better help
with context.
Sneak &
Peek at our
Analytics & Threat
Detection Platform
Pentest
Results
Infobyte’s Faraday
Vulnerability Scans
We’re keeping an eye on
vulnerable systems that
can be used as entry
points in larger networks
Rapid7 OpenData
Secrepo / Censys / etc.
Threatmap & IoCs
We use data from our
own Threatmap
service to detect
vulnerabilities and
malware in
compromised
websites
Kaggel /
Virustotal / VXHeaven
Malware
analysis
Security Data
We gather anonymized
statistical data about app
usage, website
browsing, detected
attacks and malware
activity from our
Managed Security
Services
Threat intel feeds
IoCs, hashes, tweets and
posts.
Criticalstack / MDL /
Kiran Bandla’s
APTNotes / ISC
Suspicious Domains /
ThreatMiner /
Threat
Crowd
Cellular data
Wi-FiWe operate large Wi-Fi
networks both for
consumer and business
customers.
Architecture
KafkaLogstashElastic SearchKibanaWe
Architecture - II
Logstash Servers
Event Parsing
Event Enrichment
Data Ingestion
Kafka Servers
Load Balancing
Data Collection
Full Packet Data
Endpoints & Servers
Cloud Services
Machine & Equipment Logs
Service Bus
Everything Else
Kafka Servers
Caching
Kibana Servers
Event View
Custom Dashboards
Reporting
Long Term Storage
Hadoop Servers
ElasticSearch Servers
Machine Learning
Analytics
Caching & Short Term
Storage
Alerting
High-level overview
Of our proposed
architecture for our
Threat Detection &
Analytics Platform
Beats
Syslog
Cloud APIs
OSINT
HUMINT
SOCMINT
Machine Learning Algorithms
Sweet spot UnsupervisedSupervised
Supervised Machine
Learning relies on feeding
the machines with labeled
data, be it ‘good’ data or
‘bad’ data.
This helps create a baseline of
expected behaviour, in threat
detection and, in turn, will yield
results in detecting anomalies
On the Unsupervised side
you have to consider several
approaches such as
dimensionality reduction and
association rule learning.
These approaches are useful in
making large data sets easier to
analyse or understand. They can
be used to reduce the complexity
(dimensionality) of fields of data
to look at or group things together
(clustering)
Machine Learning Algorithms
Supervised
Unsupervised
Labeled Data
Unlabeled Data
Malware Identification
Spam Detection
Anomaly Detection
Risk (Reputation) Scoring
Clustering
Association – Rule Learning
Dimensionality Reduction
Entity Classification
Anomaly Detection
Data learning (exploration)
Machine
Learning
(More than) Text Mining
Twitter is a great data source for text mining. This has been done before and
we’re using what we’re learning from both commercial solutions like Sintelix and
Bitext and open source projects.
Twitter
Scrap
Engine /
Text
Mining
Local
Storage
Noise
Removal
Feature
Extraction
Feature
Selection
ElasticSearch
Machine
Learning
Anaylitics
Classification
Circling back to APTs
04
Lateral
Movement
02
Establish
foothold
Noise removal:
Exclude known good
traffic patterns and
legitimate pre-
labeled traffic
Gather Logs:
And traffic
dumps
Known domains:
Ingest data from
known malware
domain lists,
SOCMINT
Look for anomalies:
Large amount of request,
single requests, large
DNS queries etc. Malware
can be noisy
Visualize
Alert
Report
Gather Logs:
Windows
Machines,
mostly
Psexec DCOM QuarkPwD
RDP Logon Scripts WCE
WMIC WinRM MS14-058
mimikatz PWDumpX timestomp
Analyze logs
For specific event IDs,
attribute changes etc.
Visualize
Alert
Report
Expected Output
Dashboards
Configurable dashboard that can be customized to show both live data
and analytics for any number of categories such as Malware
Detections, C2 Server activity, Phishing Attacks reported trough
SOCMINT and our own sensors etc.
Alerting
Customizable alerts per events such as live attacks, threshold
breaking, Social Sentiment Analysis and -possibly- any delta over a
preset baseline
Reporting
Detailed reporting on all incidents, incident categories, sources of
attacks, types of threats etc.
Are we building yet another
Open-Source SIEM?
In short: NO. We’re not looking to
replace existing ones. We’re not
looking into compliance and
automated mitigation.
We’re trying to teach our existing
open-source log management
systems some new tricks so they
can help us in detecting complex
threats.
In closing, some nice stats*:
*From a Ponemon survey conducted in H1 2018
Savings
Companies using M.L. to
detect threats save an
estimate of 2.5 million US$
in operating costs
60%$2.5m 60% 69%
Improves Productivity
Companies are positive that
deploying M.L.-based
security tech improves the
productivity of their security
personnel.
More speed
The most significant benefit
of using M.L. for threat
analysis is increased speed.
64% say that the most
significant advantage is the
acceleration in the
containment of infected
endpoints, devices, hosts.
Identify Vulnerabilities
Sixty percent of the
respondents stated that M.L.
identified their application
security vulnerabilties
Thanks 

More Related Content

What's hot

TACTiCS_WP Security_Addressing Security in SDN Environment
TACTiCS_WP Security_Addressing Security in SDN EnvironmentTACTiCS_WP Security_Addressing Security in SDN Environment
TACTiCS_WP Security_Addressing Security in SDN Environment
Saikat Chaudhuri

01_Metasploit - The Elixir of Network Security
01_Metasploit - The Elixir of Network Security01_Metasploit - The Elixir of Network Security
01_Metasploit - The Elixir of Network Security
Harish Chaudhary

Designing Security Assessment of Client Server System using Attack Tree Modeling
Designing Security Assessment of Client Server System using Attack Tree ModelingDesigning Security Assessment of Client Server System using Attack Tree Modeling
Designing Security Assessment of Client Server System using Attack Tree Modeling
ijtsrd


What's hot (20)

Ceis 9 padeep kumar_final_paper
Ceis 9 padeep kumar_final_paperCeis 9 padeep kumar_final_paper
Ceis 9 padeep kumar_final_paper

Antigena Overview
Antigena OverviewAntigena Overview
Antigena Overview

IJET-V3I2P16
IJET-V3I2P16IJET-V3I2P16
IJET-V3I2P16

Virus detection based on virus throttle technology
Virus detection based on virus throttle technologyVirus detection based on virus throttle technology
Virus detection based on virus throttle technology

Security Intelligence: Advanced Persistent Threats
Security Intelligence: Advanced Persistent ThreatsSecurity Intelligence: Advanced Persistent Threats
Security Intelligence: Advanced Persistent Threats

An overview of network penetration testing
An overview of network penetration testingAn overview of network penetration testing
An overview of network penetration testing

REAL-TIME THREAT INTELLIGENCE FOR TRUSTED RELATIONSHIPS
REAL-TIME THREAT INTELLIGENCE FOR TRUSTED RELATIONSHIPSREAL-TIME THREAT INTELLIGENCE FOR TRUSTED RELATIONSHIPS
REAL-TIME THREAT INTELLIGENCE FOR TRUSTED RELATIONSHIPS

Advanced persistent threats(APT)
Advanced persistent threats(APT)Advanced persistent threats(APT)
Advanced persistent threats(APT)

Hvordan stopper du CryptoLocker?
Hvordan stopper du CryptoLocker?Hvordan stopper du CryptoLocker?
Hvordan stopper du CryptoLocker?

TACTiCS_WP Security_Addressing Security in SDN Environment
TACTiCS_WP Security_Addressing Security in SDN EnvironmentTACTiCS_WP Security_Addressing Security in SDN Environment
TACTiCS_WP Security_Addressing Security in SDN Environment

Common Techniques To Identify Advanced Persistent Threat (APT)
Common Techniques To Identify Advanced Persistent Threat (APT)Common Techniques To Identify Advanced Persistent Threat (APT)
Common Techniques To Identify Advanced Persistent Threat (APT)

WLAN Penetration Examination of The University of Pembangunan Panca Budi
WLAN Penetration Examination of The University of Pembangunan Panca BudiWLAN Penetration Examination of The University of Pembangunan Panca Budi
WLAN Penetration Examination of The University of Pembangunan Panca Budi

01_Metasploit - The Elixir of Network Security
01_Metasploit - The Elixir of Network Security01_Metasploit - The Elixir of Network Security
01_Metasploit - The Elixir of Network Security

Designing Security Assessment of Client Server System using Attack Tree Modeling
Designing Security Assessment of Client Server System using Attack Tree ModelingDesigning Security Assessment of Client Server System using Attack Tree Modeling
Designing Security Assessment of Client Server System using Attack Tree Modeling

Network security
Network securityNetwork security
Network security

Meletis Belsis - Wireless Security: Common Protocols and Vulnerabilities
Meletis Belsis - Wireless Security: Common Protocols and VulnerabilitiesMeletis Belsis - Wireless Security: Common Protocols and Vulnerabilities
Meletis Belsis - Wireless Security: Common Protocols and Vulnerabilities

Peripheral Review and Analysis of Internet Network Security
Peripheral Review and Analysis of Internet Network SecurityPeripheral Review and Analysis of Internet Network Security
Peripheral Review and Analysis of Internet Network Security

Network Security
Network  SecurityNetwork  Security
Network Security

UN Presentation - 10-17-2018 - Maccaglia
UN Presentation - 10-17-2018 - MaccagliaUN Presentation - 10-17-2018 - Maccaglia
UN Presentation - 10-17-2018 - Maccaglia

Network Attack and Intrusion Prevention System
Network Attack and  Intrusion Prevention System Network Attack and  Intrusion Prevention System
Network Attack and Intrusion Prevention System


Similar to Needles, Haystacks and Algorithms: Using Machine Learning to detect complex threats

Trends in network security feinstein - informatica64
Trends in network security   feinstein - informatica64Trends in network security   feinstein - informatica64
Trends in network security feinstein - informatica64
Chema Alonso

Attackers May Depend On Social Engineering To Gain...
Attackers May Depend On Social Engineering To Gain...Attackers May Depend On Social Engineering To Gain...
Attackers May Depend On Social Engineering To Gain...
Tiffany Sandoval


Similar to Needles, Haystacks and Algorithms: Using Machine Learning to detect complex threats (20)

The Role of Application Control in a Zero-Day Reality
The Role of Application Control in a Zero-Day RealityThe Role of Application Control in a Zero-Day Reality
The Role of Application Control in a Zero-Day Reality

NetWitness
NetWitnessNetWitness
NetWitness

How to protect your corporate from advanced attacks
How to protect your corporate from advanced attacksHow to protect your corporate from advanced attacks
How to protect your corporate from advanced attacks

Introduction To Information Security
Introduction To Information SecurityIntroduction To Information Security
Introduction To Information Security

Trends in network security feinstein - informatica64
Trends in network security   feinstein - informatica64Trends in network security   feinstein - informatica64
Trends in network security feinstein - informatica64

Attackers May Depend On Social Engineering To Gain...
Attackers May Depend On Social Engineering To Gain...Attackers May Depend On Social Engineering To Gain...
Attackers May Depend On Social Engineering To Gain...

NTXISSACSC2 - The Role of Threat Intelligence and Layered Security for Intrus...
NTXISSACSC2 - The Role of Threat Intelligence and Layered Security for Intrus...NTXISSACSC2 - The Role of Threat Intelligence and Layered Security for Intrus...
NTXISSACSC2 - The Role of Threat Intelligence and Layered Security for Intrus...

4777.team c.final
4777.team c.final4777.team c.final
4777.team c.final

The next generation of IT security
The next generation of IT securityThe next generation of IT security
The next generation of IT security

Event - Internet Thailand - Total Security Perimeters
Event - Internet Thailand - Total Security PerimetersEvent - Internet Thailand - Total Security Perimeters
Event - Internet Thailand - Total Security Perimeters

Emerging Threats to Infrastructure
Emerging Threats to InfrastructureEmerging Threats to Infrastructure
Emerging Threats to Infrastructure

Modern Malware and Threats
Modern Malware and ThreatsModern Malware and Threats
Modern Malware and Threats

Cyber Defense - How to be prepared to APT
Cyber Defense - How to be prepared to APTCyber Defense - How to be prepared to APT
Cyber Defense - How to be prepared to APT

Cisco Security Presentation
Cisco Security PresentationCisco Security Presentation
Cisco Security Presentation

Corporate threat vector and landscape
Corporate threat vector and landscapeCorporate threat vector and landscape
Corporate threat vector and landscape

The Role of Threat Intelligence and Layered Securiy for Intrusion Prevention ...
The Role of Threat Intelligence and Layered Securiy for Intrusion Prevention ...The Role of Threat Intelligence and Layered Securiy for Intrusion Prevention ...
The Role of Threat Intelligence and Layered Securiy for Intrusion Prevention ...

Network monitoring white paper
Network monitoring white paperNetwork monitoring white paper
Network monitoring white paper

Esteban Próspero
Esteban PrósperoEsteban Próspero
Esteban Próspero

Insight Brief: Security Analytics to Identify the 12 Indicators of Compromise
Insight Brief: Security Analytics to Identify the 12 Indicators of CompromiseInsight Brief: Security Analytics to Identify the 12 Indicators of Compromise
Insight Brief: Security Analytics to Identify the 12 Indicators of Compromise

Cyber Attack Methodologies
Cyber Attack MethodologiesCyber Attack Methodologies
Cyber Attack Methodologies


More from DefCamp

More from DefCamp (20)

Remote Yacht Hacking
Remote Yacht HackingRemote Yacht Hacking
Remote Yacht Hacking

Mobile, IoT, Clouds… It’s time to hire your own risk manager!
Mobile, IoT, Clouds… It’s time to hire your own risk manager!Mobile, IoT, Clouds… It’s time to hire your own risk manager!
Mobile, IoT, Clouds… It’s time to hire your own risk manager!

The Charter of Trust
The Charter of TrustThe Charter of Trust
The Charter of Trust

Internet Balkanization: Why Are We Raising Borders Online?
Internet Balkanization: Why Are We Raising Borders Online?Internet Balkanization: Why Are We Raising Borders Online?
Internet Balkanization: Why Are We Raising Borders Online?

Bridging the gap between CyberSecurity R&D and UX
Bridging the gap between CyberSecurity R&D and UXBridging the gap between CyberSecurity R&D and UX
Bridging the gap between CyberSecurity R&D and UX

Secure and privacy-preserving data transmission and processing using homomorp...
Secure and privacy-preserving data transmission and processing using homomorp...Secure and privacy-preserving data transmission and processing using homomorp...
Secure and privacy-preserving data transmission and processing using homomorp...

Drupalgeddon 2 – Yet Another Weapon for the Attacker
Drupalgeddon 2 – Yet Another Weapon for the AttackerDrupalgeddon 2 – Yet Another Weapon for the Attacker
Drupalgeddon 2 – Yet Another Weapon for the Attacker

Economical Denial of Sustainability in the Cloud (EDOS)
Economical Denial of Sustainability in the Cloud (EDOS)Economical Denial of Sustainability in the Cloud (EDOS)
Economical Denial of Sustainability in the Cloud (EDOS)

Trust, but verify – Bypassing MFA
Trust, but verify – Bypassing MFATrust, but verify – Bypassing MFA
Trust, but verify – Bypassing MFA

Threat Hunting: From Platitudes to Practical Application
Threat Hunting: From Platitudes to Practical ApplicationThreat Hunting: From Platitudes to Practical Application
Threat Hunting: From Platitudes to Practical Application

Building application security with 0 money down
Building application security with 0 money downBuilding application security with 0 money down
Building application security with 0 money down

Implementation of information security techniques on modern android based Kio...
Implementation of information security techniques on modern android based Kio...Implementation of information security techniques on modern android based Kio...
Implementation of information security techniques on modern android based Kio...

Lattice based Merkle for post-quantum epoch
Lattice based Merkle for post-quantum epochLattice based Merkle for post-quantum epoch
Lattice based Merkle for post-quantum epoch

The challenge of building a secure and safe digital environment in healthcare
The challenge of building a secure and safe digital environment in healthcareThe challenge of building a secure and safe digital environment in healthcare
The challenge of building a secure and safe digital environment in healthcare

Timing attacks against web applications: Are they still practical?
Timing attacks against web applications: Are they still practical?Timing attacks against web applications: Are they still practical?
Timing attacks against web applications: Are they still practical?

Tor .onions: The Good, The Rotten and The Misconfigured
Tor .onions: The Good, The Rotten and The Misconfigured Tor .onions: The Good, The Rotten and The Misconfigured
Tor .onions: The Good, The Rotten and The Misconfigured

We will charge you. How to [b]reach vendor’s network using EV charging station.
We will charge you. How to [b]reach vendor’s network using EV charging station.We will charge you. How to [b]reach vendor’s network using EV charging station.
We will charge you. How to [b]reach vendor’s network using EV charging station.

Connect & Inspire Cyber Security
Connect & Inspire Cyber SecurityConnect & Inspire Cyber Security
Connect & Inspire Cyber Security

The lions and the watering hole
The lions and the watering holeThe lions and the watering hole
The lions and the watering hole

Catch Me If You Can - Finding APTs in your network
Catch Me If You Can - Finding APTs in your networkCatch Me If You Can - Finding APTs in your network
Catch Me If You Can - Finding APTs in your network


Recently uploaded

Future Visions: Predictions to Guide and Time Tech Innovation, Peter Udo Diehl
Future Visions: Predictions to Guide and Time Tech Innovation, Peter Udo DiehlFuture Visions: Predictions to Guide and Time Tech Innovation, Peter Udo Diehl
Future Visions: Predictions to Guide and Time Tech Innovation, Peter Udo Diehl
Peter Udo Diehl

Structuring Teams and Portfolios for Success
Structuring Teams and Portfolios for SuccessStructuring Teams and Portfolios for Success
Structuring Teams and Portfolios for Success
UXDXConf


Recently uploaded (20)

WSO2CONMay2024OpenSourceConferenceDebrief.pptx
WSO2CONMay2024OpenSourceConferenceDebrief.pptxWSO2CONMay2024OpenSourceConferenceDebrief.pptx
WSO2CONMay2024OpenSourceConferenceDebrief.pptx

Connecting the Dots in Product Design at KAYAK
Connecting the Dots in Product Design at KAYAKConnecting the Dots in Product Design at KAYAK
Connecting the Dots in Product Design at KAYAK

Demystifying gRPC in .Net by John Staveley
Demystifying gRPC in .Net by John StaveleyDemystifying gRPC in .Net by John Staveley
Demystifying gRPC in .Net by John Staveley

Unpacking Value Delivery - Agile Oxford Meetup - May 2024.pptx
Unpacking Value Delivery - Agile Oxford Meetup - May 2024.pptxUnpacking Value Delivery - Agile Oxford Meetup - May 2024.pptx
Unpacking Value Delivery - Agile Oxford Meetup - May 2024.pptx

Introduction to FDO and How It works Applications _ Richard at FIDO Alliance.pdf
Introduction to FDO and How It works Applications _ Richard at FIDO Alliance.pdfIntroduction to FDO and How It works Applications _ Richard at FIDO Alliance.pdf
Introduction to FDO and How It works Applications _ Richard at FIDO Alliance.pdf

Simplified FDO Manufacturing Flow with TPMs _ Liam at Infineon.pdf
Simplified FDO Manufacturing Flow with TPMs _ Liam at Infineon.pdfSimplified FDO Manufacturing Flow with TPMs _ Liam at Infineon.pdf
Simplified FDO Manufacturing Flow with TPMs _ Liam at Infineon.pdf

Future Visions: Predictions to Guide and Time Tech Innovation, Peter Udo Diehl
Future Visions: Predictions to Guide and Time Tech Innovation, Peter Udo DiehlFuture Visions: Predictions to Guide and Time Tech Innovation, Peter Udo Diehl
Future Visions: Predictions to Guide and Time Tech Innovation, Peter Udo Diehl

A Business-Centric Approach to Design System Strategy
A Business-Centric Approach to Design System StrategyA Business-Centric Approach to Design System Strategy
A Business-Centric Approach to Design System Strategy

The UX of Automation by AJ King, Senior UX Researcher, Ocado
The UX of Automation by AJ King, Senior UX Researcher, OcadoThe UX of Automation by AJ King, Senior UX Researcher, Ocado
The UX of Automation by AJ King, Senior UX Researcher, Ocado

The Value of Certifying Products for FDO _ Paul at FIDO Alliance.pdf
The Value of Certifying Products for FDO _ Paul at FIDO Alliance.pdfThe Value of Certifying Products for FDO _ Paul at FIDO Alliance.pdf
The Value of Certifying Products for FDO _ Paul at FIDO Alliance.pdf

UiPath Test Automation using UiPath Test Suite series, part 1
UiPath Test Automation using UiPath Test Suite series, part 1UiPath Test Automation using UiPath Test Suite series, part 1
UiPath Test Automation using UiPath Test Suite series, part 1

Buy Epson EcoTank L3210 Colour Printer Online.pdf
Buy Epson EcoTank L3210 Colour Printer Online.pdfBuy Epson EcoTank L3210 Colour Printer Online.pdf
Buy Epson EcoTank L3210 Colour Printer Online.pdf

Integrating Telephony Systems with Salesforce: Insights and Considerations, B...
Integrating Telephony Systems with Salesforce: Insights and Considerations, B...Integrating Telephony Systems with Salesforce: Insights and Considerations, B...
Integrating Telephony Systems with Salesforce: Insights and Considerations, B...

AI revolution and Salesforce, Jiří Karpíšek
AI revolution and Salesforce, Jiří KarpíšekAI revolution and Salesforce, Jiří Karpíšek
AI revolution and Salesforce, Jiří Karpíšek

Structuring Teams and Portfolios for Success
Structuring Teams and Portfolios for SuccessStructuring Teams and Portfolios for Success
Structuring Teams and Portfolios for Success

10 Differences between Sales Cloud and CPQ, Blanka Doktorová
10 Differences between Sales Cloud and CPQ, Blanka Doktorová10 Differences between Sales Cloud and CPQ, Blanka Doktorová
10 Differences between Sales Cloud and CPQ, Blanka Doktorová

THE BEST IPTV in GERMANY for 2024: IPTVreel
THE BEST IPTV in  GERMANY for 2024: IPTVreelTHE BEST IPTV in  GERMANY for 2024: IPTVreel
THE BEST IPTV in GERMANY for 2024: IPTVreel

Intro in Product Management - Коротко про професію продакт менеджера
Intro in Product Management - Коротко про професію продакт менеджераIntro in Product Management - Коротко про професію продакт менеджера
Intro in Product Management - Коротко про професію продакт менеджера

What's New in Teams Calling, Meetings and Devices April 2024
What's New in Teams Calling, Meetings and Devices April 2024What's New in Teams Calling, Meetings and Devices April 2024
What's New in Teams Calling, Meetings and Devices April 2024

Speed Wins: From Kafka to APIs in Minutes
Speed Wins: From Kafka to APIs in MinutesSpeed Wins: From Kafka to APIs in Minutes
Speed Wins: From Kafka to APIs in Minutes


Needles, Haystacks and Algorithms: Using Machine Learning to detect complex threats

  • 1. Needles & Haystacks: Machine Learning powered Threat Detection Ioan Constantin, Orange Romania
  • 2. Text with illustrationHow do you go about finding a needle in a haystack? It’s simple, actually. You bring a magnet.
  • 3. Agenda Complex Threats A brief walk trough some of the new challenges most companies face now with the advent of APTs. Machine Learning Beyond buzzwords: how do we improve our existing detection methods and technologies with the context offered by M.L.? ‘Post-hash’ Context Threat Intel, Proactive Security, Threat Hunting, SOCMINT, HUMINT, OSINT Threat Detection Are we trying to replace our existing SIEMs, FWs and IPSs? Spoiler: No. We’re building around it. 1 2 3 4 5SIEM much? Are we trying to build yet another Open Source SIEM?
  • 4. Advan ceduses sophisticated exploits, 0-Days, Social Engineering. Stealthy. Compromised end-points Can infect multiple end- points in large networks, of various type such as smartphones, workstations, applications Highly Dependant on Social Engineering, surveillance, supply chain-compromise Persistent Low-and-slow approach to attacks Targeting is conducted trough continuous monitoring Task-specific rather than opportunistic The goal is to maintain long-term access Complex Threats
  • 5. Keep a door open Exfiltrate data Delete all track Break stuff 06 Complete mission Maintain presence, use stealthy (encrypted) channels to communicate 05 Keep a low profile Expand control to other endpoints, servers, active equipment, harvest data and configs 04 Lateral Movement Look around, find other vulnerable victims, gather as much intel as you can 03 Reconnaiss ance. Create C2C controllable victim end- points in the network, escalate privileges 02 Establish foothold Using social engineering, spear phishing, media infestation with zero-day malware 01 Initial compromise Works in stages APTs are a complex species of threats And we have no definitive guide or ‘how-to’ detect it or mitigate it. We’re constantly learning from the experience of others and we’re relying on human intelligence to better understand these threats
  • 6. 77%Network Technologies (FWs, Routers, Switches) 64 % Log Monitoring / Event Correlation / SIEMs / A.I. / M.L. Technical Controls used to Protect Against APTs* *according to a TrendMicro Survey, H1 2017 Mobile Security Gateways, Mobile Anti- Malware, Mobile Device Management 37% 83%Antivirus & Antimalware 66% Zoning Off (Network Segregation)
  • 7. Malware Variety There are hundreds of million of malware variations that can be used in a APT. This makes it challenging to detect. 41 2 3 Traditional security is ineffective As it needs more than signature or rule-based detection. It needs context and some form of automated learning method to expand the context Log analysis and Log correlation has its limits Because, of course, it also needs context and ‘perspective’. There’s lots of noise It’s extremely hard to separate noise from legitimate traffic and there’s lots of noise being ‘ingested’ by security equipment Challenges in mitigation
  • 8. The average company takes 170 days to detect an advanced threat, 39 days to mitigate and 43 days to recover* *According to the Ponemon Institute 170 days 39 days 43 days 0% To Mitigation For Detection To Recovery Challenges in mitigation
  • 9. Obligatory timeline slide 1998 2003 2009 2010 2011 2018 Moonlight Maze Some guys in Russia breaks into systems at the Pentagon, NASA, U.S. Department of Energy. Exfiltrates thousands of docs. Attack lasted 2 years Ghost Net Large-scale attack, initiated from phishing e-mails, downloaded trojans RSA Attack Adobe Flash exploit + phishing e-mail = pwned SecurID Titan Rain Attacks on large defense contractors from various Chinese sources. Stuxnet Fun fact: there’s chatter out there about a not-so-long- awaited sequel  Stuxnet 2.0 VPNFilter / BlackEnergy And, of course the youngest of the bunch…
  • 11. Machine Learning is the science of getting computers to act without being explicitly programmed (Stanford University, Artificial Intelligence Laboratory) Machine Learning (…) algorithms can figure out how to perform important tasks by generalizing from examples (University of Washington) Machine Learning
  • 12. Machine Learning Learn from available data Using representation, evaluation and optimisation. Use training data Establish baseline Define normal behaviour, define normal data. Don’t over use the word ‘normal’  Find Anomalies Identify deviations from the baseline. Correlate deviations with other input data Act upon finding Classify deviations as anomalies. Notify / Take action
  • 13. Available data Network Devices Endpoints Applications Security Products Cool stuff Active network equipment Routers, switches, printers, APs and the like. They all generate tons of data PCs, Laptops, Smartphones, Servers Metrics, Operating Systems Logs, Hardware logs, Security logs. Interesting to say the least Software clients Client-side and server- side. E-Mail clients, Web Browsers, VPN clients. In all shapes and sizes, from ubiquitous MS Windows to iOS. Networked, in the cloud or on endpoints Everything from FWs, IPSs, Sandboxes, AVs / Anti-Malware, Anti-Spam & E-Mail security Gateways, MdM etc. Our secret sauce We generate huge amounts of data from TELCO-specific technologies and equipment. We add it to the mix to better help with context.
  • 14. Sneak & Peek at our Analytics & Threat Detection Platform
  • 15. Pentest Results Infobyte’s Faraday Vulnerability Scans We’re keeping an eye on vulnerable systems that can be used as entry points in larger networks Rapid7 OpenData Secrepo / Censys / etc. Threatmap & IoCs We use data from our own Threatmap service to detect vulnerabilities and malware in compromised websites Kaggel / Virustotal / VXHeaven Malware analysis Security Data We gather anonymized statistical data about app usage, website browsing, detected attacks and malware activity from our Managed Security Services Threat intel feeds IoCs, hashes, tweets and posts. Criticalstack / MDL / Kiran Bandla’s APTNotes / ISC Suspicious Domains / ThreatMiner / Threat Crowd Cellular data Wi-FiWe operate large Wi-Fi networks both for consumer and business customers.
  • 17. Architecture - II Logstash Servers Event Parsing Event Enrichment Data Ingestion Kafka Servers Load Balancing Data Collection Full Packet Data Endpoints & Servers Cloud Services Machine & Equipment Logs Service Bus Everything Else Kafka Servers Caching Kibana Servers Event View Custom Dashboards Reporting Long Term Storage Hadoop Servers ElasticSearch Servers Machine Learning Analytics Caching & Short Term Storage Alerting High-level overview Of our proposed architecture for our Threat Detection & Analytics Platform Beats Syslog Cloud APIs OSINT HUMINT SOCMINT
  • 18. Machine Learning Algorithms Sweet spot UnsupervisedSupervised Supervised Machine Learning relies on feeding the machines with labeled data, be it ‘good’ data or ‘bad’ data. This helps create a baseline of expected behaviour, in threat detection and, in turn, will yield results in detecting anomalies On the Unsupervised side you have to consider several approaches such as dimensionality reduction and association rule learning. These approaches are useful in making large data sets easier to analyse or understand. They can be used to reduce the complexity (dimensionality) of fields of data to look at or group things together (clustering)
  • 19. Machine Learning Algorithms Supervised Unsupervised Labeled Data Unlabeled Data Malware Identification Spam Detection Anomaly Detection Risk (Reputation) Scoring Clustering Association – Rule Learning Dimensionality Reduction Entity Classification Anomaly Detection Data learning (exploration) Machine Learning
  • 20. (More than) Text Mining Twitter is a great data source for text mining. This has been done before and we’re using what we’re learning from both commercial solutions like Sintelix and Bitext and open source projects. Twitter Scrap Engine / Text Mining Local Storage Noise Removal Feature Extraction Feature Selection ElasticSearch Machine Learning Anaylitics Classification
  • 21. Circling back to APTs 04 Lateral Movement 02 Establish foothold Noise removal: Exclude known good traffic patterns and legitimate pre- labeled traffic Gather Logs: And traffic dumps Known domains: Ingest data from known malware domain lists, SOCMINT Look for anomalies: Large amount of request, single requests, large DNS queries etc. Malware can be noisy Visualize Alert Report Gather Logs: Windows Machines, mostly Psexec DCOM QuarkPwD RDP Logon Scripts WCE WMIC WinRM MS14-058 mimikatz PWDumpX timestomp Analyze logs For specific event IDs, attribute changes etc. Visualize Alert Report
  • 22. Expected Output Dashboards Configurable dashboard that can be customized to show both live data and analytics for any number of categories such as Malware Detections, C2 Server activity, Phishing Attacks reported trough SOCMINT and our own sensors etc. Alerting Customizable alerts per events such as live attacks, threshold breaking, Social Sentiment Analysis and -possibly- any delta over a preset baseline Reporting Detailed reporting on all incidents, incident categories, sources of attacks, types of threats etc.
  • 23. Are we building yet another Open-Source SIEM? In short: NO. We’re not looking to replace existing ones. We’re not looking into compliance and automated mitigation. We’re trying to teach our existing open-source log management systems some new tricks so they can help us in detecting complex threats.
  • 24. In closing, some nice stats*: *From a Ponemon survey conducted in H1 2018 Savings Companies using M.L. to detect threats save an estimate of 2.5 million US$ in operating costs 60%$2.5m 60% 69% Improves Productivity Companies are positive that deploying M.L.-based security tech improves the productivity of their security personnel. More speed The most significant benefit of using M.L. for threat analysis is increased speed. 64% say that the most significant advantage is the acceleration in the containment of infected endpoints, devices, hosts. Identify Vulnerabilities Sixty percent of the respondents stated that M.L. identified their application security vulnerabilties

Editor's Notes

  1. Are robots taking over? If John Connor was right, Skynet is hiding somewhere in a docker container hosting logstash  -We’ll skip the buzzwords and see if and how Machine Learning and Log and Event Correlation can prove helpful in detecting APTs
  2. :Funny quote from a funny movie: -Identifying the challenge: -We generate a large amount of log data, telemetry, samples and captures; -Shifting towards cloud-based infrastructure & virtualization means that the sheer volume of data sources is increasing; -SIEM solutions are great at finding correlation between events, assuring compliance and automating response; -They do a good job at pointing out the breadcrumbs -We’re looking into improving this response with open-source technology that can point out the entire trail  -We’re not looking into building cvasi-SIEMs and replacing our existing ones; -We’re simply moving forward on using advanced machine learning as a means of putting together all the puzzle pieces that can lead to better detecting persistent threats. -…and we’re doing this using Open Source and free software
  3. Our agenda for today focuses on 5 points and covers in a high-level presentation our quest for better resilience; 1. We’ll discuss the new threats that large companies face, such as APTs; Yes, there’s a timeline of well-know APTs some where in here  2. What’s beyond signatures, hashes, IoCs and rules? We’ll talk Proactive Security 3. Machine Learning is such a overused buzzword, right up there together with Artificial Intelligence and Blockchain. We’re not trying to match our smartphone camera’s settings to various pets. We’re trying to teach some new tricks to a computer. 4. We’ll see how this implementation improves the detection of cyber threats beyond the capabilities of ‘traditional’ signature-based detection tools; 5. We’ll discuss shortly the possibility of automation, thus closing the circle, from detection to mitigation and prevention. Are robots going to steal the hard-working firewalls’ jobs? 
  4. APT usually refers to a group, such as a government, with both the capability and the intent to target, persistently and effectively, a specific entity. The term is commonly used to refer to cyber threats, in particular that of Internet-enabled espionage using a variety of intelligence gathering techniques to access sensitive information, but applies equally to other threats such as that of traditional espionage or attacks. Other recognized attack vectors include infected media, supply chain compromise, and social engineering. The purpose of these attacks is to place custom malicious code on one or multiple computers for specific tasks and to remain undetected for the longest possible period. Knowing the attacker artifacts, such as file names, can help a professional make a network-wide search to gather all affected systems. Individuals, such as an individual hacker, are not usually referred to as an APT, as they rarely have the resources to be both advanced and persistent even if they are intent on gaining access to, or attacking, a specific target. Some defining characteristics of these threats: Highly targeted; Highly resourceful actors with expert knowledge; Specific motivation – political or business (economical) reasons; Targets private organizations, government institutions at state-level; Actors have access to exploits and backdoors that are ‘zero-day’ or unbeknown to the general public; Highly reliant on social engineering; As per boundaries it can be considered as a attack from inside and outside; This endeavor usually lasts for months on; It is extremely hard to detect with conventional, signature-based solutions;
  5. APTs are a new species of threats and there’s no definitive guide or ‘how-to” Never the less, there are specific activities and tools usually in-use to successfully run such an attack. By studying high-profile APTs such as Stuxnet, we identified six main stages for this new type of threat: The initial compromise usually relies on highly targeted social engineering campaigns, with victims most commonly being able to provide access to within the targeted network(s). The initial vector could be a spear phishing e-mail or a media-infestation (this was the case for the Stuxnet APT). The initial driver could be malware derived from zero-day vulnerabilities with a high degree of targeting. The attacker can – for once- find out what kind of business apps the victim is using, research that software, dependencies and plugins, write (or buy) an exploit for a unkown (zero-day) vulnerability and somehow insert that malware into the target network Gaining ground: once the malicious code is copied on an endpoint (laptop, desktop computer, smartphone, tablet) that belongs to a business network the attacker will ‘listen’ for covert connections, appearing as legitimate traffic to most signature-based detection tools. In some cases, the ‘agent’ that runs on the endpoint will communicate with the Command and Control Server over port 53, legitimately used for DNS. Most firewalls will ‘see’ this traffic as being legitimate as they don’t posses the required intelligence to discern as to why is a computer creating outbound DNS connection when it DOES NOT receive any DNS Queries? The same applies to traffic ‘hidden’ over HTTP on ports 80, 8080, 443 etc. If the attacker adds encryption to the mix, most firewalls will simply ignore this traffic, per policy Reconnaissance: Once installed on an endpoint, the malicious software can perform several discovery – type functions: it can map the network, it can silently audit the computers on the network for installed software and open ports, etc. Lateral movement: based on the findings from the Reconnaissance stage and the commands it receives from the C2 server, the malware can ‘move laterally’ and expand to other systems on the same network or on servers, active equipment such as routers, switches (using something like the payload in MiraiBot or VPNFilter) Keep a low profile – in all stages, the malware will not alert to it’s presence, will use system functionality where available to disguise as legitimate software or as a OS process. In all stages, the malware will usually use encrypted communications to ‘talk’ to other instances of itself or the C2 server, oblivious to Firewalls, IDS/IPSs etc. This is not a stage in the process, per-se but rather a general requirement encompassing all other stages. Complete mission: in this final stage, the malware will actually deliver the results expected by the attacker: exfiltrate information, delete information, disable devices, encrypt disks etc. Usually this is accompanied by a final process of deleting it’s own tracks – all data on disk, all relevant logs etc. There’s a lot of specificity to each APT, as it happens. Some attacks lasts for years on (Stuxnet), others take days to compromise, act and deliver.
  6. Key takeaway is that 83% of responders are betting on AV in fighting APTs. Not exclusively by as a first line of protection. What about BYOD, fileless malware, zero-days & vaults?
  7. 170 days – . Mars One estimates their mission’s travel time from Earth to Mars in the 6 to 8 months region. That’s 180 days to 240 days. This is anecdotal evidence that it takes less time to get to Mars than to detect and APT in your perimeter.
  8. What great diversity, isn’t it? You have everything in one graph, from Russian hackers to Chinese spies, Adobe Flash and nukes. Quite the James Bond on steroids movie, right?
  9. It’s quite the mix: your large datasets and
  10. Machine Learning is not necessarily a new topic of discussion among data scientist and CyberSec / InfoSec people. Various ideas and implementations have been tried and in-place for the last couple of decades. Back then, the data sets that machines had to use to learn from was usually low in volume and diversity. The game changer happened maybe 10 years ago when smartphones, social media and apps become the norm. This drove a increase in data at least SEVERAL orders of magnitude greater that before it as internet providers and service providers adapted to a new content-model where data was GENERATED by its users rather then CONSUMED. Large volumes of distributed data constitutes larger surfaces of attack that drives upwards the number and complexity of cyber attacks. Numerous and complex cyber attacks become more diverse as technology progresses. There’s direct causality between the complexity, numbers and diversity of cyber threats and the increasing volume of data. From a security standpoint, each category feeds on the other. As there’s no school of thought reg. Machine Learning, various institutions, researchers and professionals tried to define the concept. We’ll focus on the two definitions from the previous slide and extract key points from it. Machine Learning will: -find patterns in large pools of data -will establish a baseline, a ‘normal’ environment where events happen predictably -will identify deviations from the baseline -will correlate such deviations to find patterns that can be labeled as anomalies -(it can) automatize processes and act upon finding.
  11. There’s a challenge: Design, Build and Operate a large Telco Infrastructure, deliver powerful various services in a secure, reliable way by using custom built, state-of-the-art technologies, equipment and software. Oh, and try keeping it legacy-compliant for those customers who still love their 2G phone and don’t like spending too much time on the internet. Unfortunately, this is utopic. The reality is that we rely on multiple vendors, various technologies, both commercial and developed in-house. Most of these adhere to some kind of standardization for things like communications protocols. They all like the OSI Layer when it comes to ‘being talkative’ but unfortunately for security gals and guys, they talk different languages when it comes to security logs and feeds. Our equipment, software, hardware, firmware and middleware generates a HUGE amount of data relevant to security in various forms. Some like HTTP Restful APIs and JSON. Others like Schemes and XML, there’s the ones that will send you CEF and then there’s those that only ‘speak’ encrypted. Then there’s our language. We mostly speak Romanian when discussing threats. Some speak English or French. And then there’s the Internet. You have Social Intelligence where people write things in forums, on facebook, on twitter, on reddit. Some use sarcasm, others use abbreviations. Some LOL, some are L33t. Ever browsed virustotal.com? Imagine making business sense from virus samples and md5 hashes. You’ll probably end up with a headache. How about reverse engineered exploits? Memory dumps? You can figure out how easy is to get lost in such an avalanche of information, generated, written or spoken in different languages, using different constructs and schemas.
  12. It’s only a sneak and peek. It’s work in progress. It’s high-level. I hope it’s not boring.
  13. We’re a Telecommunications Operator. We anonymize all the data we gather, into datasets: Cellular data: Location data, Radio information, Device data; Data usage; Voice usage; Wireless data: SSIDs used, Radio information, Cellular to WiFi Roaming info; Security data: Website and applications usage monitoring, malware activity, attack activity We collaborate with other actors and we rely on proven sources: Threat intelligence feeds: Open, free and paid (such as OTX, Virustotal) Malware analysis: Threat hunting activity: We use Threatmap as a scanning engine for compromised websites (OWASP Vulnerability Scanning, CMS-Specific Scanning, Malware Scanning) We’re white hats & pen-testers: Vulnerability assessment information: We use up-to-date vulnerability scanners (mostly open-sourced, free) to identify potential targets for current threats CVEs feeds and zero-day info: We input feed data about the latest reported vulnerabilities and affected systems & software and we use social intelligence feeds, with info gathered from discussion forums, reddit, twitter. Pentest results: we use info gathered from pentest to better understand the baseline of the current threat model
  14. Modern IT systems are built from larger numbers of individual systems interconnected to satisfy the desired end goal. These systems generate logs and events which can provide valuable insight into the system’s current state and internal workings. The more data ingested and analyzed, the better the decision. Currently, given the reduced costs of storage, we target massive collection of useful data from across the entire IT infrastructure and application environments. Over the years, as the data has grown to Petabyte level, the technologies capable of storing and manipulating these amounts of data has shifted from a traditional file based approach to unstructured no-sql databases, capable of adapting to any type of data and volumes of ingestion. Currently Elasticsearch and Hadoop are amongst technologies capable of handling large volumes of data, while at the same time providing for fast searching capabilities and customized visualizations and dashboards. With the new addition of Machine Learning and Alerting, we can now provide fast analytics and anomaly detection as well as generating alerts concerning threat-related events identified within the client’s infrastructure We are using leading industry no-sql, hdfs and in-memory technologies and consists of: Data Collection - Open Source and commercial technologies are being installed and customized for collecting data from any source (device, application, sensor, etc.) across the client’s environment (cloud and/or on premise) using standard, broadly used, protocols such as syslog, nslog, ftp, smtp, snmp, https or using stand-alone light software agents or API’s, if/when available. Kafka nodes - To ensure high availability for the collection of information within the data ingestion pipeline, we use Apache Kafka therefore being able to sustain longer periods of downtime in case of disasters. Logstash/other log shippers nodes - Logstash is the heart of data enrichment, providing abundant capabilities in parsing events from any data source by enriching the data with geo-IP information, customer internal DNS information, threat intelligence and other custom enrichment. Hadoop cluster: Used for long term storage, and custom post-event enrichment; also stores an unaltered version of your raw data which may be needed for other purposes such as compliance. Network Load Balancer – Component acts as a one-point collector for the data sources that are trying to send events into the solution; the NLB forwards events to the Kafka servers. NLB is configured with one or more virtual IPs for HA reasons. Elasticsearch cluster: This is a no-sql database technology, capable of ingesting, storing and searching any amounts of data. Build around a standard cluster design, it provides integrated high availability and can horizontally scale automatically, allowing it to store from tens of GB to hundreds of TB of data. With its new addition of Machine Learning (Prelert), we are currently capable of detecting anomalies within hundreds of GB of events in seconds, alerting you about a potential infrastructure or security issue. Visualization nodes: Allows SOC personnel as well as the customer’s security team to easily visualize and interact with the data and create custom dashboards. Summary: We are using a highly scalable containerized deployment of Elastics Search, Logstash, Kafka, Beats and Kibana We have pipelines that run across the VMs, with one machine’s output becoming the next machine’s input. We wrote APIs for custom-built things. We used the provided APIs for proprietary things. We ingest syslog where we need it We capture netflow where needed. We ingest, store, normalize, anonymize and finally analyze data. We present it via custom dashboards, in single-pane-of-glass style We generate reports
  15. On the supervised side we have the two poster-use-cases: Malware identification and spam detection On the unsupervised size we’re dealing with classification and feature selection for better understanding the data itself. We’re not bound to one method so we can run both types of algorithms on different data sets. We can use the output of our unsupervised algorithms as input for our supervised algorithms, for once.
  16. We’re mainly using Text Mining for classification of alerts, newly reported vulnerabilities and reported attacks.
  17. Okay. What about practical uses? M.L. algorithms and SOCMINT can prove helpful in detecting APTs and its associated activity like establishing a foothold in the target network(s) and move laterally. For the first activity, we’ll focus on analysing logs and traffic dumps. We’ll start by excluding legitimate ‘labeled’ traffic and we’ll continue with feeding our training algorithm with ‘good’ traffic patterns. We’ll use public-open data sets such as those indexed by Kaggle or UCI ML Repo and we’ll eventually recycle or own data sets that provide a high-enough level of certainty on their safety. We then compare outgoing connections to known malware domain lists such as C2 server domains. We ingest these lists from public indexes and from internets chatter (reading tweets) We’re adding an additional loop where we’re writing algorithms that correlate seemingly unrelated events to possible threats, such as failed login attempts, keyboard interactive or over VPN-remote, for a given period of time, with repetition or large DNS queries that might hide malicious traffic. Once our training algorithms have a good grasp on what is ‘ok’ they can point out what’s above or below the baseline – anomalies. Add the second loop in the mix and there you have it, a possible correlation between seemingly unrelated events that in turn will alert the security guys to take action. How about lateral movement? There A LOT we can learn from logs, event IDs and Sysmon logs, specially from Windows machines. The tools used by an malicious actor to move laterally in a network can be either Microsoft-made, signed and trusted by the OS on other machines or custom tools made by 3rd parties. What they all have in common is that they generate enough ‘breadcrumbs’ that – when pieced together – will tell us if their use was legitimate or illegitimate. We can elaborate a training set for our ML that cycles trough various events gathered from logs and matches those to malicious activities such as privilege escalation by use of *bullets – mimikatz. Once the training set is in place, the machines can monitor seemingly ‘normal’ activity from the logs gathered and tell if the succession of recognized events had a legitimate outcome or a malicious one.
