This document provides information on the lumbosacral plexus and innervation of the lower limb. It discusses the muscles of the thigh and their nerve innervation. It describes the anterior, posterior, and medial compartments of the thigh. It also discusses the formation of the femoral, obturator, and sciatic nerves from the lumbosacral plexus and their cutaneous innervation territories in the lower limb. Additionally, it provides information on the greater and lesser sciatic foramina and their anatomical structures.
rectus sheath, the sheath covering rectus muscle of anterior abdominal wall, formation of the sheath, the muscles involved in ts formation, and the contents the sheath is covering
spinal cord, ascending tracts of the the spinal cord, spinocortical tracts, gray matter of spinal cord, white mater of spinal cord, organization of neuron, first order second order and third order neuron, anterolateral spinal tract anteroposterior spinal tract, spinolivary tract, visceral sensory tract, dorsal column tract, spino cerebellar tract , spinorectal pathway, spino olivary pathway, cerebellar peduncles,
Atlanto occipital and atlanto axial jointShubham Singh
Anatomy:
>Atlas is the topmost vertebra and chief peculiarity of atlas is that it has no body, it is ring like and consist of anterior and posterior arch and two lateral masses.
>Axis, the 2nd cervical vertebra has a concave under side and convex from side to side. The most distinctive characteristic of this bone is strong odontoid process, the dens.
TheJoint:
>Atlanto-occipital joint (articulation between the atlas and the occipital bone) consists of a pair of condyloid joints.
>The atlanto-occipital joints are synovial socket-type joints
Ligaments:
> Posterior atlanto-occipital membrane: extend from anterior arch of atlas to posterior margin of foramen magnum.
>Anterior atlanto-occipital membrane: extend from anterior arch of atlas to anterior margin of foramen magnum.
>The ligamentam flavam join laminae of adjacent vertebral arches.
>The interspinous ligaments expand to form the ligamentum nuchae which inserts along the posterior foramen magnum and external occipital condyle.
> The following four ligaments stabilize these joints:
1.Apical ligament: Connects the dens to the foramen magnum of the occipital bone.
2.Alar ligaments: Connect the dens to the lateral margins of the foramen magnum.
3.Cruciate ligament: Attaches the dens to the anterior arch of the atlas and the body of the axis to the foramen magnum of the occipital bone.
4.Tectorial membrane: Starts at the skull and becomes the posterior longitudinal ligament.
>Atlanto-axial articular capsules are thick and loose, and connect the margins of the lateral masses of the atlas with those of the posterior articular surfaces of the axis.
Muscles:
>Flexion is produced mainly by the action of longis capitis, rectus capitis anterior and sternocleidomastoid (anterior fibres)
>Extension by the rectus capitis posterior major and minor, the obliquus capitis superior, the semispinalis capitis, splenius capitis, longissimus capitis, sternocleidomastoid and upper fibres of the trapezius
>The recti lateralis are concerned in the lateral movement, assisted by the trapezius, splenius capitis, semispinalis capitis, and the sternocleidomastoid of the same side, all acting together.
Movements:
>Flexion and extension in the Sagittal axis, which give rise to the ordinary forward and backward nodding of the head.
>Lateral flexion to one or other side in the Frontal axis(titling of head
>Lateral AAJ Movement: It is a synovial joint which allows only gliding
>Medial AAJ Movement: This joint allows the rotation of the atlas the axis i.e round the dens.
Clinical anatomy:
> Headaches can arise from many different sources including dysfunctional muscles, tears in the ligaments, misalignment of the vertebral bodies, injury to cervical facets and degenerative discs.
>Excessive flexion could rupture the supraspinous ligament.
>Posterior atlanto-occipital membrane ossification cause migraine headaches due to compression of artery.
Lateral ventricle of Brain. By Dr.N.Mugunthan.M.Smgmcri1234
Lateral ventricle of brain. Lecture by Dr.N.Mugunthan.
Associate Professor,
Mahatma Gandhi Medical College & Research Institute,
Sri Balaji Vidyapeeth, Pondicherry.
glossopharyngeal nerve, origin an course and termination of glossopharyngeal nerve, functional component of the nerve, sensory and motor component of glossopharyngeal nerve, gag reflex
rectus sheath, the sheath covering rectus muscle of anterior abdominal wall, formation of the sheath, the muscles involved in ts formation, and the contents the sheath is covering
spinal cord, ascending tracts of the the spinal cord, spinocortical tracts, gray matter of spinal cord, white mater of spinal cord, organization of neuron, first order second order and third order neuron, anterolateral spinal tract anteroposterior spinal tract, spinolivary tract, visceral sensory tract, dorsal column tract, spino cerebellar tract , spinorectal pathway, spino olivary pathway, cerebellar peduncles,
Atlanto occipital and atlanto axial jointShubham Singh
Anatomy:
>Atlas is the topmost vertebra and chief peculiarity of atlas is that it has no body, it is ring like and consist of anterior and posterior arch and two lateral masses.
>Axis, the 2nd cervical vertebra has a concave under side and convex from side to side. The most distinctive characteristic of this bone is strong odontoid process, the dens.
TheJoint:
>Atlanto-occipital joint (articulation between the atlas and the occipital bone) consists of a pair of condyloid joints.
>The atlanto-occipital joints are synovial socket-type joints
Ligaments:
> Posterior atlanto-occipital membrane: extend from anterior arch of atlas to posterior margin of foramen magnum.
>Anterior atlanto-occipital membrane: extend from anterior arch of atlas to anterior margin of foramen magnum.
>The ligamentam flavam join laminae of adjacent vertebral arches.
>The interspinous ligaments expand to form the ligamentum nuchae which inserts along the posterior foramen magnum and external occipital condyle.
> The following four ligaments stabilize these joints:
1.Apical ligament: Connects the dens to the foramen magnum of the occipital bone.
2.Alar ligaments: Connect the dens to the lateral margins of the foramen magnum.
3.Cruciate ligament: Attaches the dens to the anterior arch of the atlas and the body of the axis to the foramen magnum of the occipital bone.
4.Tectorial membrane: Starts at the skull and becomes the posterior longitudinal ligament.
>Atlanto-axial articular capsules are thick and loose, and connect the margins of the lateral masses of the atlas with those of the posterior articular surfaces of the axis.
Muscles:
>Flexion is produced mainly by the action of longis capitis, rectus capitis anterior and sternocleidomastoid (anterior fibres)
>Extension by the rectus capitis posterior major and minor, the obliquus capitis superior, the semispinalis capitis, splenius capitis, longissimus capitis, sternocleidomastoid and upper fibres of the trapezius
>The recti lateralis are concerned in the lateral movement, assisted by the trapezius, splenius capitis, semispinalis capitis, and the sternocleidomastoid of the same side, all acting together.
Movements:
>Flexion and extension in the Sagittal axis, which give rise to the ordinary forward and backward nodding of the head.
>Lateral flexion to one or other side in the Frontal axis(titling of head
>Lateral AAJ Movement: It is a synovial joint which allows only gliding
>Medial AAJ Movement: This joint allows the rotation of the atlas the axis i.e round the dens.
Clinical anatomy:
> Headaches can arise from many different sources including dysfunctional muscles, tears in the ligaments, misalignment of the vertebral bodies, injury to cervical facets and degenerative discs.
>Excessive flexion could rupture the supraspinous ligament.
>Posterior atlanto-occipital membrane ossification cause migraine headaches due to compression of artery.
Lateral ventricle of Brain. By Dr.N.Mugunthan.M.Smgmcri1234
Lateral ventricle of brain. Lecture by Dr.N.Mugunthan.
Associate Professor,
Mahatma Gandhi Medical College & Research Institute,
Sri Balaji Vidyapeeth, Pondicherry.
glossopharyngeal nerve, origin an course and termination of glossopharyngeal nerve, functional component of the nerve, sensory and motor component of glossopharyngeal nerve, gag reflex
Above power point wil give detailed explanation aboutthe cubital fossa.knowledge of this cubital fossa is clinically very important for all clinicians.
7. anterior compartment of thigh
• sartorius
• four large quadriceps femoris muscles
(rectus femoris, vastus lateralis, vastus
medialis, and vastus intermedius).
• the terminal ends of the psoas major
• and iliacus muscles pass into the upper
part of the anterior compartment from
sites of origin on the posterior abdominal
wall.
8.
9. • The posterior compartment of thigh
contains three large muscles termed the
'hamstrings'. All are innervated by the
sciatic nerve.
15. 15
.
Anterior rami of
upper 4 lumbar
spinal nerves (+L5)
and from the
contribution of
subcostal nerve
(T12)
in the lumbar
region, within
the psoas major
muscle.
20. 20
.
(L2-L4)
largest branch
both motor and sensory.
Emerges from the lateral
border of the psoas major
Flexors of the hip and
extensors of the knee
Skin of the anterior and
lateral thigh, medial leg
and foot
22. 22
.
Emerges from the medial
border of the psoas
major
Leaves the lesser
pelvis through
the obturator canal
Skin on the superior
medial thigh
Adductor muscles of the
leg
23.
24.
25.
26.
27.
28. Gluteal region
deep group of small muscles,
• piriformis, obturator internus, gemellus
superior, gemellus inferior, and quadratus
femoris;
superficial group
gluteus minimus, gluteus medius, and
gluteus maximus-
• the tensor fasciae latae,
31. 31
.
Sensory and motor innervation of the whole
lower limb
arises from the spinal roots L1-S4
Lumbal plexus
Sacral plexus
32. 32
.
Descending part of
the L4 nerve unites
with the anterior
ramus of the L5
nerve to form the
lumbosacral trunk.
Participates in the
formation of the
sacral plexus with
the anterior rami
of S1-S4 nerves.
44. 44
.
o Leaves the
gluteal region by
passing deep to
the long head of
the biceps
femoris,at the
lower margin of
the quadratus
femoris muscle
o Divides into the
common peroneal
and tibial
nerves, at a
variable site
above the
popliteal fossa
49. Greater sciatic foramen
• The greater sciatic foramen is formed on the posterolateral pelvic wall and is the major route for
structures to pass between the pelvis and the gluteal region of the lower limb . The margins of the
foramen are formed by:
• the greater sciatic notch;
• parts of the upper borders of the sacrospinous and sacrotuberous ligaments;
• the lateral border of the sacrum.
•
•
• The piriformis muscle passes out of the pelvis into the gluteal region through the greater sciatic
foramen and separates the foramen into two parts, a part above the muscle and a part below:
• the superior gluteal nerve and vessels pass through the greater sciatic foramen above the
piriformis;
• the sciatic nerve, inferior gluteal nerves and vessels, pudendal nerve and internal pudendal vessels,
posterior cutaneous nerve of thigh, nerve to the obturator internus and gemellus superior and the
nerve to the quadratus femoris and gemellus inferior pass through the greater sciatic foramen
below the muscle.
•
49
51. Lesser sciatic foramen
• The lesser sciatic foramen is inferior to the greater sciatic foramen
on the posterolateral pelvic wall .It is also inferior to the lateral
attachment of the pelvic floor to the pelvic wall and therefore
connects the gluteal region with the perineum:
• the tendon of obturator internus passes from the lateral pelvic wall
through the lesser sciatic foramen into the gluteal region to insert
on the femur;
• the pudendal nerve and internal pudendal vessels, which first exit
the pelvis by passing through the greater sciatic foramen below the
piriformis muscle, enter the perineum below the pelvic floor by
passing around the ischial spine and sacrospinous ligament and
medially through the lesser sciatic foramen.
•
51
53. Trendelenburg's Test
• – assesses functioning of hip abductors
• Stand behind patient and ask to stand on
one leg for 30 seconds
• Pelvis should tilt up on side of unsupported
leg = Trendelenburg negative (normal)
• If pelvis tilts down towards unsupported leg =
Trendelenburg positive (pathological)
• Repeat for other leg
53
54. A 51-year-old man experiences a loss of
skin sensation along the medial
compartment of the thigh. No other
areas of skin are affected. Which of the
following best describes the area of deficit?
A. L2 dermatome
B. L3dermatome
C. L4 dermatome
D. Cutaneous field of the femoral nerve
E. Cutaneous field of the obturator nerve
F. Cutaneous field of the saphenous nerve
55.
56. 27. A 55-year-old man has difficulty
extending his hip while walking up a flight
of stairs.He experiences no cutaneous
deficits. Which damaged nerve is most
likely responsible
for causing this man’s symptoms?
A. Inferior gluteal nerve
B. S1 nerve root
C. S2 nerve root
D. Superior gluteal nerve
57. 28. A 33-year-old man’s pelvis drops on
the right side when
he steps with his right foot. He has no
cutaneous deficits.
Which nerve lesion is most likely causing
this problem?
A. Femoral nerve
B. Inferior gluteal nerve
C. Obturator nerve
D. Superior gluteal nerve
E. Tibial nerve
