The proposed home monitoring system uses sensors to monitor temperature and humidity in a home. The sensor data is sent to a web server and stored in the cloud. This allows users to access the sensor data from anywhere using a mobile phone or computer. The system also allows users to remotely control electric appliances in the home through the web server. When temperature or humidity thresholds are exceeded, the system can send alerts to users.
