Graphene and graphene oxide
•Download as PPTX, PDF•
2 likes•6,830 views
Graphene is an exciting material with many potential applications. It has a large theoretical specific surface area, high intrinsic mobility, high Young's modulus, and high thermal conductivity. Graphene also has good electrical conductivity and optical transmittance of around 97.7%. The properties of graphene include its honeycomb lattice structure composed of carbon atoms bonded together with sigma bonds. Each carbon atom has a pi orbital contributing to a delocalized network of electrons. Graphene also has intrinsic ripples observed through transmission electron microscopy with a lateral dimension of 8-10 nm and height displacement of 0.7-1 nm. These ripples can be induced, suggesting local electrical and optical properties could be altered through 'ripple engineering
Report
Share
Report
Share
![Introduction
Graphene is an exciting material. [ 1 ] It has a large theoretical
specific surface area (2630 m 2 g − 1 ), high intrinsic mobility
(200 000 cm 2 v − 1 s − 1 ), [ 2 , 3 ] high Young’s modulus ( ∼ 1.0 TPa) [
4 ]
and thermal conductivity ( ∼ 5000 Wm − 1 K − 1 ), [ 5 ] and its optical
transmittance ( ∼ 97.7%) and good electrical conductivityamong many
