This document provides instructions for analyzing particle images using ImageJ software. It discusses downloading and running ImageJ, processing images through thresholding, erosion, and dilation, analyzing particles to obtain size data and distribution statistics, and setting the measurement scale. The summary also acknowledges the students who provided feedback on the homework instructions.

1. Analyze Particlesby using imageJ http://rsb.info.nih.gov/ij/docs/menus/analyze.html#ap By Nguyen Hoang Viet, PhD.

2. Content Where to download How to run ImageJ Image Processing & Calculation

3. Visit this link: http://rsbweb.nih.gov/ij/download.html Note: please check your window first, 32- or 64-bit system Where to download

4. First – Run ImageJ program and Load the your image file. How to run ImageJ

5. Open Image File Run ImageJ: Start/All Programs/ImageJ/ Open Image File: File/Open…, choose the file and click OK

6. Image Processing & Calculation

7. Step 1 – Convert to 8-bit & Crop Open Image File: File/Open…, choose the file and click OK - Grain Size Calculation.jpg Convert to 8-bit: Image/Type/8-bit. Crop: Draw a rectangular shape then Image/Type/Crop. Save the cropped file: File/Save as/Jpeg… - Grain Size Calculation-Crop.tif

9. Measurement scale unit Draw a rectangular shape fits on scale bar. You will see its width to be 237 px. So, 1 m equals 79px.

12. How to set new scale bar Analyze/Set Scale Then, the unit in imageJwill be µm (micrometer)

13. Step 4: Analyze data Based on two data files in Excel format, you should find a software for doing further analysis. Such software like: Excel, MatLab, Origin, SciLab*, SciDAVis* … *: free software

14. Step 4: Analyze data (2) On the “Results” dialog. Choose Results/Distribution… the set bin number for ‘specify bins’ field: 10, 50 and 100. Based on Histogram dialogClick on List to get data list,then you should use other software to draw the graph.

15. Terms: What is bin(s)? In a particle size distribution measurement, typically each distribution, whether is displayed cumulatively or differentially, is composed of a few hundred data points in a pre-set size range. Each data points is called a bin. Since every particle is measured, each bin is a collection of particles in the size range that bin represents. Depending on the distribution broadness, the total size range can be reset to a finer division, therefore showing the distribution details, i.e., each bin can be pre-set to cover a smaller size range. Other advantages include fine differential between two particles and more accurate statistic values calculated from the distribution. More at http://www.spectrex.com/html_files/practanl.html

16. Histograms of the grain sizes

17. Grain sizes of cropped images

18. Acknowledgement Thank my students, ATP k52 (Fall 2010), for doing well this homework and have good suggestion for further processing.

19. Any questions? Please email me at viet4777@gmail.com for further information Discussion time!
