Dr. Manuel Rigger from ETH talks about the testing framework that helps find 400+ logic bugs in DBMSs like TiDB, MySQL, PostgreSQL, and SQLite.

1. Finding Logic Bugs in Database
Management Systems
Manuel Rigger
ETH Zurich, Switzerland
13/06/2020
@RiggerManuel @ast_eth https://people.inf.ethz.ch/suz/

2. 2
Goal
Aim: Detect logic bugs in DBMS

3. 3
Logic Bugs
DatabaseDBMS
✓
row1 φ
row2 φ
row1 φ
row2 φ
row3 ¬φ
SELECT *
FROM …
WHERE φ

4. 4
Logic Bugs
DatabaseDBMS
 Logic Bugs are bugs that cause the DBMS
to return an incorrect result set
row1 φ
row2 φ
row3 ¬φ
row1 φ
SELECT *
FROM …
WHERE φ

5. 5
Logic Bugs
DatabaseDBMS
 Might go unnoticed by
users (unlike crash bugs)
row1 φ
row2 φ
row3 ¬φ
row1 φ
SELECT *
FROM …
WHERE φ

6. 6
Is the Problem Solved?
SQLite (~150,000 LOC) has 662 times
as much test code as source code
SQLite is extensively fuzzed (e.g., by
Google’s OS-Fuzz Project)
SQLite’s test cases achieve
100% branch test coverage
Anomaly testing (out-of-memory,
I/O error, power failures)
https://www.sqlite.org/testing.html

7. 7
Tested Database Management Systems
PostgreSQL
Over 400 bugs in popular and
widely-used DBMS!

8. 8
Bug-Hunting Challenge
22 bugs were classified as P1, and
6 as P2 → over 100 T-shirts!
https://pingcap.com/community-cn/tidb-bug-hunting/

9. 9
Automatic Testing Core Challenges
1. Effective test case
Generate a
Database
Generate a
Query
Validate the
Query’s Result

10. 10
Automatic Testing Core Challenges
1. Effective test case
Generate a
Database
Generate a
Query
Validate the
Query’s Result
2. Test oracle

11. 11
Automatic Testing Core Challenges
1. Effective test case
Generate a
Database
Generate a
Query
Validate the
Query’s Result
2. Test oracle
Query and database generation
is not the focus of this talk

12. 12
Heuristic Database Generation
Lower and upper limits
for all statements
CREATE TABLE t0(c0 INT UNIQUE);
CREATE TABLE t1(c0 INT, c1 TEXT);
Generate
Tables
Select Other
Actions

13. 13
Heuristic Database Generation
INSERT INTO t1(c0, c1) VALUES (0, '');
UPDATE t1 SET c0 = 3;
CREATE INDEX i0 ON t1(c0, c1) WHERE c0 > 0;
INSERT INTO t0(c0) VALUES (0), (0);
CREATE TABLE t0(c0 INT UNIQUE);
CREATE TABLE t1(c0 INT, c1 TEXT);
Generate
Tables
Select Other
Actions

14. 14
Heuristic Database Generation
INSERT INTO t1(c0, c1) VALUES (0, '');
UPDATE t1 SET c0 = 3;
CREATE INDEX i0 ON t1(c0, c1) WHERE c0 > 0;
INSERT INTO t0(c0) VALUES (0), (0);
CREATE TABLE t0(c0 INT UNIQUE);
CREATE TABLE t1(c0 INT, c1 TEXT);
Statements can fail or be redundant
Generate
Tables
Select Other
Actions

15. 15
Random Expression Generation
IS
NOT
t0.c0 1
t0.c0 IS NOT 1;
We randomly generate
expressions used in
WHERE and other clauses

16. 16
Automatic Testing Core Challenges
1. Effective test case
Generate a
Database
Generate a
Query
Validate the
Query’s Result
2. Test oracle
The focus of this talk are test
oracles for finding logic bugs!

17. 17
Test Oracle
Test oracle: For a given input, determines
whether the system works as expected

18. 18
Fuzzing
DatabaseDBMSSQLsmith
SELECT …
SEGMENTATION FAULT
Fuzzing cannot find logic bugs

19. 19
Differential Testing
Query
Generator
RS1 = RS2 = RS3?
RS1
RS2
RS3

20. 20
Differential Testing: RAGS (Slutz 1998)
“[Differential testing] proved to be extremely useful,
but only for the small set of common SQL”

21. 21
Problem 1: Different SQL Dialects
DBMS-
specific SQL
Common
SQL Core
“We are unable to use Postgres as an
oracle because CockroachDB has slightly
different semantics and SQL support, and
generating queries that execute identically
on both is tricky […].” – Cockroach Labs

22. 22
Problem 2: No Ground Truth
https://github.com/pingcap/tidb/issues/15743
DBMS are affected
by common bugs
https://github.com/pingcap/tidb/issues/15743

23. 23
Other approaches
• Solver-based (Khalek et al. 2008, 2010)
• Performance (Jung et al. 2019)
• Estimated cost accuracy (Gu et al. 2012)

24. 24
Automatic Testing Core Challenges
1. Effective test case
Generate a
Database
Generate a
Query
Validate the
Query’s Result
2. Test oracle
The problem of testing DBMS to find logic
bugs has not yet been well addressed

25. 25
Overview
Pivoted Query
Synthesis (PQS)
Non-optimizing
Reference Engine
Construction
(NoREC)
Ternary Logic
Query Partitioning
(TLP)

26. 26
Overview
Pivoted Query
Synthesis (PQS)
Non-optimizing
Reference Engine
Construction
(NoREC)
Ternary Logic
Query Partitioning
(TLP)
Generate a query for which it is
ensured that a randomly-selected
row, the pivot row, is fetched
~100
bugs

27. 27
Overview
Pivoted Query
Synthesis (PQS)
Non-optimizing
Reference Engine
Construction
(NoREC)
Ternary Logic
Query Partitioning
(TLP)
Detecting optimization bugs by
rewriting the query so that it
cannot be optimized
>150
bugs

28. 28
Overview
Pivoted Query
Synthesis (PQS)
Non-optimizing
Reference Engine
Construction
(NoREC)
Ternary Logic
Query Partitioning
(TLP)
Partition the query into
several partitioning queries,
which are then composed
>150
bugs

29. 29
SQLancer (Synthesized Query Lancer)
https://github.com/sqlancer/

30. 30
go-sqlancer by PingCAP
https://github.com/chaos-mesh/go-sqlancer

31. 31
Non-optimizing
Reference Engine
Construction
(NoREC)
Non-optimizing Reference Engine Construction

32. 32
Goal
Easy-to-realize technique that can
find bugs in the query optimizer

33. 33
Optimization Bugs
Database
row1 φ
Optimizer
row1 φ
row2 φ
row3 ¬φ
SELECT *
FROM …
WHERE φ
DBMS

34. 34
Optimization Bugs

row1
Optimizer
Optimizer
row1
row2
-O3
-O0
DBMS provide limited control
over optimizations
≠
SELECT *
FROM …
WHERE φ
DBMS
DBMS

35. 35
Idea
Idea: Rewrite the query so that
the DBMS cannot optimize it

36. 36
Idea
Query
Generator
Optimizer
Optimizer
Optimized
Query
Translation
Step
Unoptimized
Query

row1
row1
row2
≠
It is unobvious how the
translation step should look like
DBMS
DBMS

37. 37
Idea
Query
Generator
Optimizer
Optimizer
Optimized
Query
Translation
Step
Unoptimized
Query

row1
row1
row2
≠
Insight: Checking the number of rows that are
fetched is sufficient to detect most bugs
DBMS
DBMS

38. 38
Translation Step
SELECT *
FROM …
WHERE φ
row1 φ
row2 φ
SELECT φ
FROM …
TRUE φ
TRUE φ
FALSE ¬φ
φ evaluates
to TRUE for
two rows
φ evaluates
to TRUE for
two rows
=
✓
Optimized
Query
Unoptimized
Query
DBMS
DBMS

39. 39
Translation Step
SELECT *
FROM …
WHERE φ
row1 φ
SELECT φ
FROM …
TRUE φ
TRUE φ
FALSE ¬φ
φ evaluates
to TRUE for
one row
φ evaluates
to TRUE for
two rows
≠

Optimized
Query
Unoptimized
Query
DBMS
DBMS

40. 40
Translation Step
SELECT *
FROM …
WHERE φ
SELECT φ
FROM …
Optimized
Query
Unoptimized
Query
The result set contains
the original rows
The result set contains
TRUE and FALSE values

41. 41
Translation Step
SELECT *
FROM …
WHERE φ
SELECT φ
FROM …
Optimized
Query
Unoptimized
Query
Most optimization aim to reduce
the amount of data that
is processed (e.g., using indexes)

42. 42
Translation Step
SELECT *
FROM …
WHERE φ
SELECT φ
FROM …
Optimized
Query
Unoptimized
Query
The predicate must be
evaluated on every row

43. 43
Translation Step
The translated query
cannot be efficiently
optimized by the DBMS
SELECT *
FROM …
WHERE φ
SELECT φ
FROM …
Optimized
Query
Unoptimized
Query
The predicate must be
evaluated on every row

44. 44
Counting Implementation
SELECT COUNT(*)
FROM …
WHERE φ
SELECT SUM(count) FROM (
SELECT φ IS TRUE
as count
FROM <tables>
);
Optimized
Query
Unoptimized
Query
1
DBMS
DBMS
2
≠


45. 45
Example SQLite3
Optimized
Query
Unoptimized
Query
CREATE TABLE t0(c0 UNIQUE);
INSERT INTO t0 VALUES (-1) ;
SELECT *
FROM t0
WHERE t0.c0 GLOB '-*';
SELECT t0.c0 GLOB '-*'
FROM t0;
c0
-1
t0
TRUE
{}
Result
should
contain
one row


46. 46
Evaluation: Found Bugs
Closed
DBMS Fixed Verified Intended Duplicate
SQLite 110 0 6 0
MariaDB 1 5 0 1
PostgreSQL 5 2 1 0
CockroachDB 28 7 0 1
We found 159 bugs, 141 of
which have been fixed!

47. 47
Evaluation: Found Bugs
Closed
DBMS Fixed Verified Intended Duplicate
SQLite 110 0 6 0
MariaDB 1 5 0 1
PostgreSQL 5 2 1 0
CockroachDB 28 7 0 1
We concentrated on testing SQLite

48. 48
Evaluation: Test Oracles
Crash
DBMS Logic Error Release Debug
SQLite 39 30 15 26
MariaDB 5 0 1 0
PostgreSQL 0 4 2 1
CockroachDB 7 24 4 0

49. 49
Evaluation: Test Oracles
Crash
DBMS Logic Error Release Debug
SQLite 39 30 15 26
MariaDB 5 0 1 0
PostgreSQL 0 4 2 1
CockroachDB 7 24 4 0
We found 51 optimization bugs!

50. 50
Evaluation: Test Oracles
Crash
DBMS Logic Error Release Debug
SQLite 39 30 15 26
MariaDB 5 0 1 0
PostgreSQL 0 4 2 1
CockroachDB 7 24 4 0
Error and crash bugs seem to be
more common/easier to find

51. 51
Discussion and Questions

52. 52
Ternary Logic
Partitioning (TLP)
Ternary Logic Partitioning (TLP)

53. 53
Challenge
NoREC is mostly limited to testing
WHERE clauses

54. 54
Query Partitioning
Query
Generator
Q
RS(Q)

55. 55
Query Partitioning
Query
Generator
Q
RS(Q)
Q denotes the (randomly-generated) original query

56. 56
Query Partitioning
Query
Generator
Q
RS(Q)
RS(Q) denotes the original query’s result set

57. 57
Query Partitioning
Query
Generator
Q
RS(Q)
RS(Q’1)
RS(Q’2)
RS(Q’3)
RS(Q’n)
Q’1
Q’2
Q’3
Q’n
Partition the result set

58. 58
Query Partitioning
Query
Generator
Q
RS(Q) RS(Q’)
RS(Q’1)
RS(Q’2)
RS(Q’3)
RS(Q’n)
Q’1
Q’2
Q’3
Q’n
♢
Q’
Combine the results so that
RS(Q)=RS(Q’)

59. 59
Query Partitioning
Query
Generator
Q
RS(Q) RS(Q’)
RS(Q’1)
RS(Q’2)
RS(Q’3)
RS(Q’n)
Q’1
Q’2
Q’3
Q’n
♢
Q’
✓
=

60. 60
Query Partitioning
Query
Generator
Q
RS(Q) RS(Q’)
RS(Q’1)
RS(Q’2)
RS(Q’3)
RS(Q’n)
Q’1
Q’2
Q’3
Q’n
♢
Q’
≠


61. 61
Query Partitioning
Query
Generator
Q
RS(Q) RS(Q’)
RS(Q’1)
RS(Q’2)
RS(Q’3)
RS(Q’n)
Q’1
Q’2
Q’3
Q’n
♢
Q’
Partitioning queries

62. 62
Query Partitioning
Query
Generator
Q
RS(Q) RS(Q’)
RS(Q’1)
RS(Q’2)
RS(Q’3)
RS(Q’n)
Q’1
Q’2
Q’3
Q’n
♢
Q’
Partitions

63. 63
Query Partitioning
Query
Generator
Q
RS(Q) RS(Q’)
RS(Q’1)
RS(Q’2)
RS(Q’3)
RS(Q’n)
Q’1
Q’2
Q’3
Q’n
♢
Q’
Composition operator

64. 64
How to Realize This Idea?
Key challenge: find a valid partitioning
strategy that stresses the DBMS

65. 65
Ternary Logic
Consider a predicate φ and a given row r. Exactly one of the following
must hold:
• φ
• NOT φ
• φ IS NULL
ternary predicate variants

66. 66
Ternary Logic
Consider a predicate φ and a given row r. Exactly one of the following
must hold:
• φ
• NOT φ
• φ IS NULL
φ
NOT φ
φ IS NULL

67. 67
Example: MySQL
c0
0
c0
-0
t0 t1
SELECT * FROM t0, t1
WHERE t0.c0 = t1.c0;

How did we find
this bug using TLP? t0.c0 t0.c1

68. 68
Example: MySQL
t0.c0 t0.c1
0 -0
SELECT * FROM t0, t1 WHERE t0.c0=t1.c0
UNION ALL
SELECT * FROM t0, t1 WHERE NOT (t0.c0=t1.c0)
UNION ALL
SELECT * FROM t0, t1 WHERE (t0.c0=t1.c0) IS NULL;
SELECT * FROM t0, t1;
t0.c0 t0.c1
≠

69. 69
Ternary Logic Partitioning
Query
Generator
Q
RS(Q) RS(Q’)
Q’p
Q’p IS NULL
♢
Q’
Q ¬p
RS(Q’p)
RS(Q ¬p)
RS(Q’p IS NULL)
SELECT * FROM t0, t1;

70. 70
Ternary Logic Partitioning
Query
Generator
Q
RS(Q) RS(Q’)
Q’p
Q’p IS NULL
♢
Q’
Q ¬p
RS(Q’p)
RS(Q ¬p)
RS(Q’p IS NULL)
SELECT * FROM t0, t1 WHERE t0.c0=t1.c0

71. 71
Ternary Logic Partitioning
Query
Generator
Q
RS(Q) RS(Q’)
Q’p
Q’p IS NULL
♢
Q’
Q ¬p
RS(Q’p)
RS(Q ¬p)
RS(Q’p IS NULL)
SELECT * FROM t0, t1 WHERE NOT (t0.c0=t1.c0)

72. 72
Ternary Logic Partitioning
Query
Generator
Q
RS(Q) RS(Q’)
Q’p
Q’p IS NULL
♢
Q’
Q ¬p
RS(Q’p)
RS(Q ¬p)
RS(Q’p IS NULL)
SELECT * FROM t0, t1 WHERE (t0.c0=t1.c0) IS NULL;

73. 73
Ternary Logic Partitioning
Query
Generator
Q
RS(Q) RS(Q’)
Q’p
Q’p IS NULL
♢
Q’
Q ¬p
RS(Q’p)
RS(Q ¬p)
RS(Q’p IS NULL)
UNION ALL

74. 74
Scope
• WHERE
• GROUP BY
• HAVING
• DISTINCT queries
• Aggregate functions

75. 75
Testing WHERE Clauses
Q Q’ptern ♢(Q’p, Q’¬p, Q’p IS NULL)
SELECT <columns>
FROM <tables>
[<joins>]
SELECT <columns>
FROM <tables>
[<joins>]
WHERE ptern
Q′p ⊎ Q′¬p ⊎ Q′p IS NULL

76. 76
Testing WHERE Clauses
Q Q’ptern ♢(Q’p, Q’¬p, Q’p IS NULL)
SELECT <columns>
FROM <tables>
[<joins>]
SELECT <columns>
FROM <tables>
[<joins>]
WHERE ptern
Q′p ⊎ Q′¬p ⊎ Q′p IS NULL
The multiset addition can be
implemented using UNION ALL

77. 77
Testing HAVING Clauses
Q Q’ptern ♢(Q’p, Q’¬p, Q’p IS NULL)
SELECT <columns>
FROM <tables>
[<joins>]
[WHERE …]
[GROUP BY …]
SELECT <columns>
FROM <tables>
[<joins>]
[WHERE …]
[GROUP BY …]
HAVING ptern
Q′p ⊎ Q′¬p ⊎ Q′p IS NULL

78. 78
Testing DISTINCT Clauses
Q Q’ptern ♢(Q’p, Q’¬p, Q’p IS NULL)
SELECT DISTINCT
<columns>
FROM <tables>
[<joins>]
SELECT [DISTINCT]
<columns>
FROM <tables>
[<joins>]
WHERE ptern
Q′p ∪ Q′¬p ∪ Q′p IS NULL

79. 79
Testing DISTINCT Clauses
Q Q’ptern ♢(Q’p, Q’¬p, Q’p IS NULL)
SELECT DISTINCT
<columns>
FROM <tables>
[<joins>]
SELECT [DISTINCT]
<columns>
FROM <tables>
[<joins>]
WHERE ptern;
Q′p ∪ Q′¬p ∪ Q′p IS NULL
The set union can be
implemented using UNION

80. 80
Testing GROUP BY Clauses
Q Q’ptern ♢(Q’p, Q’¬p, Q’p IS NULL)
SELECT <columns>
FROM <tables>
[<joins>]
GROUP BY <columns>
SELECT <columns>
FROM <tables>
[<joins>]
WHERE ptern
GROUP BY <columns>
Q′p ∪ Q′¬p ∪ Q′p IS NULL

81. 81
Testing Self-decomposable Aggregate Functions
Q Q’ptern ♢(Q’p, Q’¬p, Q’p IS NULL)
SELECT MAX(<e>)
FROM <tables>
[<joins>]
SELECT MAX(<e>)
FROM <tables>
[<joins>]
WHERE ptern;
MAX(Q′p ⊎ Q′¬p ⊎ Q′p IS NULL)
A partition is an intermediate
result, rather than
a subset of the result set

82. 82
Bug Example: CockroachDB
SET vectorize=experimental_on;
CREATE TABLE t0(c0 INT);
CREATE TABLE t1(c0 BOOL) INTERLEAVE IN PARENT t0(rowid);
INSERT INTO t0(c0) VALUES (0);
INSERT INTO t1(rowid, c0) VALUES(0, TRUE);
NULL 0
SELECT MAX(aggr) FROM (
SELECT MAX(t1.rowid) as aggr FROM t1 WHERE '+' >= t1.c0 UNION ALL
SELECT MAX(t1.rowid) as aggr FROM t1 WHERE NOT('+' >= t1.c0) UNION ALL
SELECT MAX(t1.rowid) as aggr FROM t1 WHERE ('+' >= t1.c0) IS NULL
);
SELECT MAX(t1.rowid)
FROM t1;
≠

83. 83
Testing Decomposable Aggregate Functions
Q Q’ptern ♢(Q’p, Q’¬p, Q’p IS NULL)
SELECT AVG(<e>)
FROM <tables>
[<joins>];
SELECT SUM(<e>) as s,
COUNT(<e>) as s
FROM <tables>
[<joins>];
SUM(s(Q′p ⊎ Q′¬p ⊎ Q′p IS NULL))
SUM(c(Q′p ⊎ Q′¬p ⊎ Q′p IS NULL))
We did not consider non-decomposable
aggregate functions (e.g., GROUP_CONCAT())

84. 84
Evaluation: Found Bugs
Closed
DBMS Fixed Verified Intended Duplicate
SQLite 4 0 0 0
MySQL 1 6 3 0
CockroachDB 22 9 0 0
TiDB 26 35 0 1
DuckDB 71 1 0 2
We found 175 bugs, 123 of
which have been fixed!

85. 85
Evaluation: Found Bugs
Closed
DBMS Fixed Verified Intended Duplicate
SQLite 4 0 0 0
MySQL 1 6 3 0
CockroachDB 22 9 0 0
TiDB 26 35 0 1
DuckDB 71 1 0 2
The total number of bugs
reflects our testing focus

86. 86
Evaluation: Found Bugs
Query Partitioning Oracle
DBMS WHERE Aggregate GROUP BY HAVING DISTINCT Error Crash
SQLite 0 3 0 0 1 0 0
CockroachDB 3 3 0 1 0 22 2
TiDB 29 0 1 0 0 27 4
MySQL 7 0 0 0 0 0 0
DuckDB 21 4 1 2 1 13 19

87. 87
Evaluation: Found Bugs
Query Partitioning Oracle
DBMS WHERE Aggregate GROUP BY HAVING DISTINCT Error Crash
SQLite 0 3 0 0 1 0 0
CockroachDB 3 3 0 1 0 22 2
TiDB 29 0 1 0 0 27 4
MySQL 7 0 0 0 0 0 0
DuckDB 21 4 1 2 1 13 19
The WHERE oracle is the simplest, but most effective oracle

88. 88
Evaluation: Found Bugs
Query Partitioning Oracle
DBMS WHERE Aggregate GROUP BY HAVING DISTINCT Error Crash
SQLite 0 3 0 0 1 0 0
CockroachDB 3 3 0 1 0 22 2
TiDB 29 0 1 0 0 27 4
MySQL 7 0 0 0 0 0 0
DuckDB 21 4 1 2 1 13 19
The other oracles found interesting, but fewer bugs

89. 89
Evaluation: Found Bugs
Query Partitioning Oracle
DBMS WHERE Aggregate GROUP BY HAVING DISTINCT Error Crash
SQLite 0 3 0 0 1 0 0
CockroachDB 3 3 0 1 0 22 2
TiDB 29 0 1 0 0 27 4
MySQL 7 0 0 0 0 0 0
DuckDB 21 4 1 2 1 13 19
We implemented these oracles only for DBMS
for which our bug-finding efforts saturated

90. 90
Comparison to NoREC
TLP
• Aggregate functions,
DISTINCT, GROUP BY,
HAVING, WHERE clauses
• UNION, UNION ALL
• Bugs in (unoptimized)
JOINs and operators
NoREC
• Bugs in the unoptimized
query

91. 91
Discussion and Questions

92. 92
Pivoted Query
Synthesis (PQS)
Pivoted Query Synthesis (PQS)

93. 93
Inherent Limitation of Metamorphic Testing
SQL Query Result Set
Execute
Derived SQL
Query
Derive
Metamorphic approaches cannot establish a ground truth

94. 94
Idea: PQS
Idea: Divide-and-conquer
approach for testing DBMS
that provides a ground truth

95. 95
Idea: PQS Automatic testing approach
considering only a single row
Column0 Column1 Column2
… … …
Valuei,0 Valuei,1 Valuei,2
… … …
Pivot Row

96. 96
Idea: PQS
Generate a
Database
Generate a
Query
Validate the
Query’s Result
Generate query that is
guaranteed to fetch the pivot row

97. 97
Idea: PQS
Generate a
Database
Generate a
Query
Validate the
Query’s Result
Validate that the pivot row is
contained in the result set

98. 98
Intuition
• Simpler conceptually and implementation-wise
• Similar effectiveness as checking all rows
Column0 Column1 Column2
… … …
Valuei,0 Valuei,1 Valuei,2
… … …
✓
✓
✓
SELECT * FROM <tables>
WHERE φ

99. 99
Approach
Randomly
Generate
Database
Select
Pivot Row
Generate
Query for the
Pivot Row
Verify that
the Pivot Row
is contained

100. 100
Approach
Randomly
Generate
Database
Select
Pivot Row
Generate
Query for the
Pivot Row
Verify that
the Pivot Row
is contained

101. 101
Approach
Randomly
Generate
Database
Select
Pivot Row
Generate
Query for the
Pivot Row
Verify that
the Pivot Row
is contained

102. 102
Approach
Randomly
Generate
Database
Select
Pivot Row
Generate
Query for the
Pivot Row
Verify that
the Pivot Row
is contained

103. 103
Example: SQLite3 Bug
c0
0
1
2
3
NULL
t0
CREATE TABLE t0(c0);
CREATE INDEX i0 ON t0(1) WHERE c0 NOT NULL;
INSERT INTO t0 (c0) VALUES (0), (1), (2), (3), (NULL);
Pivot row

104. 104
Example: SQLite3 Bug
c0
0
1
2
3
NULL
t0
CREATE TABLE t0(c0);
CREATE INDEX i0 ON t0(1) WHERE c0 NOT NULL;
INSERT INTO t0 (c0) VALUES (0), (1), (2), (3), (NULL);
SELECT c0 FROM t0
WHERE t0.c0 IS NOT 1;
Expected to fetch the pivot row

105. 105
Example: SQLite3 Bug
c0
0
1
2
3
NULL
t0
CREATE TABLE t0(c0);
CREATE INDEX i0 ON t0(1) WHERE c0 NOT NULL;
INSERT INTO t0 (c0) VALUES (0), (1), (2), (3), (NULL);
SELECT c0 FROM t0
WHERE t0.c0 IS NOT 1;
0
2
3
The pivot row is not contained in the result set!


106. 106
Approach
Randomly
Generate
Database
Select
Pivot Row
Generate
Query for the
Pivot Row
Verify that
the Pivot Row
is contained
How do we generate this query?

107. 107
How do we Generate Queries?
Generate a predicate that yields
TRUE for the pivot row
SELECT c0 FROM t0
WHERE

108. 108
Random Expression Generation
IS
NOT
t0.c0 1
t0.c0 IS NOT 1;
We implemented an
expression evaluator for
each node!

109. 109
Random Expression Generation
IS
NOT
t0.c0 1
c0
0
1
2
3
NULL
t0
Evaluate the tree based
on the pivot row

110. 110
Random Expression Generation
IS
NOT
t0.c0 1
c0
0
1
2
3
NULL
t0
Column references return the
values from the pivot row
NULL

111. 111
Random Expression Generation
IS
NOT
t0.c0 1
c0
0
1
2
3
NULL
t0
Constant nodes return their
assigned literal values
NULL 1

112. 112
Random Expression Generation
IS
NOT
t0.c0 1
c0
0
1
2
3
NULL
t0
NULL 1 Compound nodes
compute their result
based on their children
TRUE

113. 113
t0.c0 IS NOT 1;
Query Synthesis
SELECT c0 FROM t0
WHERE
What if the expression does
not evaluate to TRUE?

114. 114
Random Expression Rectification
switch (result) {
case TRUE:
result = randexpr;
case FALSE:
result = NOT randexpr;
case NULL:
result = randexpr IS NULL;
}

115. 115
Implementation Effort
• Literal evaluator
• Simpler than PL AST Interpreters → No mutable state
• Simpler than query engines → only a single row needs to be considered
• Operators are implemented naively
• The performance of the DBMS is the bottleneck
• Higher implementation effort for functions (e.g. printf) and
complex operators

116. 116
Bugs Overview
DBMS Fixed Verified
SQLite 65 0
MySQL 15 10
PostgreSQL 5 4
99 bugs!

117. 117
Oracles
DBMS Logic Error Crash
SQLite 46 17 2
MySQL 14 10 1
PostgreSQL 1 7 1
61 logic bugs

118. 118
Discussion and Questions

119. 119
Comparison
Property PQS NoREC TLP
WHERE ✓ ✓ ✓
Aggregates, HAVING, …   ✓
Ground truth ✓  
Implementation effort Moderate Very Low Low

120. 120
Discussion: Industry Adoption
https://github.com/chaos-mesh/go-sqlancer

121. 121
@RiggerManuel @ast_eth @sqlancer_dbmsSummary
Goal: Logic Bugs NoREC: Derive Unoptimized Query TLP: Partition Result Set
PQS: Check Pivot Row Containment Evaluation: Over 400 bugs in DBMS
