BROWSER SERVING YOUR WEB APPLICATION SECURITY
ALL YOU NEED TO KNOW

ABOUT ME
HI I’M PHILIPPE
I’m a Developer Evangelist for kuzzle.io.
Long-time internet developer, author,
screen caster, podcaster and speaker. I’m
specializes in PHP, Symfony, Kuzzle,
security, code quality, performance, real
time and geolocation.
• Sécurité PHP 5 et MySQL 5
• OWASP Montreal
• PHP Quebec
• Table Top Game Developer
• Pen & Paper RPG Writer

PURPOSE OF THE PRESENTATION
• Improve the code of your website
• Protect your site against certain attacks
• Protect your users from certain attacks
• Protect your development sites
WHY WE ARE TALKING ABOUT THIS?

PROTECT YOUR DEV SITES
• Dev/test/qa/regression servers
• If they are available via the web
• Robots.txt is not enough
• forget
• File compliance
AVOID LEAKS

META NAME=ROBOTS
CODE
<meta name="robots” content="noindex” />

PROTECT YOUR SITES
• name
• robots for all robots
• speciﬁc:
• Googlebot: Googlebot-News, Googlebot-Image, Googlebot-Video, Googlebot-
Mobile, Mediapartners-Google, Mediapartners, AdsBot-Google, AdsBot-
Google-Mobile-Apps
• slurp
• msnbot, bingbot
• teoma
META NAME=ROBOTS

PROTECT YOUR SITES
• content
• all
• index
• follow
META NAME=ROBOTS

PROTECT YOUR SITES
• content
• none
• noindex
• noarchive
• nocache
• nofollow
META NAME=ROBOTS

PROTECT YOUR SITES
• content
• nosnippet
• noodp
• noydir
• notranslate
• noimageindex
• unavailable_after: [RFC-850 date/time]
META NAME=ROBOTS

HEADER : X-ROBOTS-TAG
APACHE EXAMPLE
#apache
<IfModule mod_headers.c>
Header set X-Robots-Tag “noindex, nofollow, noarchive"
<FilesMatch “.(doc|pdf|png|jpe?g|gif)$”>
Header set X-Robots-Tag “noindex, noarchive, nosnippet"
</FilesMatch>
<IfModule>

PHP EXAMPLE
<?php
header(“X-Robots-Tag : noindex”, true);

EXAMPLES
X-Robots-Tag: noarchive
X-Robots-Tag: unavailable_after: 25 Jun 2010 15:00:00 PST
X-Robots-Tag: googlebot: nofollow
X-Robots-Tag: otherbot: noindex, nofollow

IMPROVE YOUR CODE
• Normally, for IE8 +
• Requests IE to use the latest render engines or a particular version.
• Should use the ChromeFrame renderer (for IE6 and IE7)
• Does not validate
• Reduce the display speed of the site if it needs to change mode
• Does not work in a conditional comment ( <!--[if lt IE 7]> )
META/HEADER : X-UA-COMPATIBLE

META: X-UA-COMPATIBLE
CODE
<meta http-equiv="X-UA-Compatible" content="IE=edge,chrome=1">
<meta http-equiv="X-UA-Compatible” content="IE=9">

HEADER: X-UA-COMPATIBLE
CODE PHP
<?php
header (“X-UA-Compatible : IE=Edge,chrome=1”, true);

HEADER: X-UA-COMPATIBLE
APACHE EXAMPLE
#apache
Header set X-UA-Compatible “IE=Edge,chrome=1”
# Mod_headers Does not use the content type,
# but we do not want to send this header
<FilesMatch “.(js|css|gif|png|jpe?g|pdf|xml|oga|ogg|m4a|ogv|mp4|
m4v|webm|svg|svgz|eot|ttf|otf|woff|ico|webp|appcache|manifest|htc|
crx|oex|xpi|safariextz|vcf)$” >
Header unset X-UA-Compatible
</FilesMatch>
</IfModule>

CLICKJACKING PROTECTION
• “Clickjacking” protection
• <frame>
• <iframe>
• <object>
• Value
• DENY
• SAMEORIGIN
• ALLOW-FROM uri
META/HEADER : X-FRAME-OPTIONS

META/HEADER : X-FRAME-OPTIONS
BROWSER SUPPORT
Android Chrome Edge Firefox Internet Explorer Opera Safari
X-Frame-Option 4+ 4+ 12+ 4+ 8+ 10.5+ 4.0+
Allow-from N/A N/A* N/A* 18+ 9+ N/A N/A*
*Use CSP frame-ancestors directive instead

HEADER : X-FRAME-OPTIONS
APACHE EXAMPLE
#apache
Header set X-Frame-Options “deny”
</IfModule>

HEADER : X-FRAME-OPTIONS
PHP CODE
<?php
header(“X-Frame-Options: deny”, true);

META : X-FRAME-OPTIONS
CODE
<meta http-equiv="X-Frame-Options” content="deny">

PROTECT AGAINS DRIVE-BY ATTAQUE
• Only one value: nosniﬀ
HEADER : X-CONTENT-TYPE-OPTIONS
nosniﬀ 3+ 1.0+* 11+ 50+** 8+ 13+ N/A
* during download
** or with NoScript

APACHE EXAMPLE
#apache
Header set X-Content-Type-Options “nosniff”
</IfModule>

PHP CODE
<?php
header(“X-Content-Type-Options: nosniff”, true);

XSS PROTECTION
• Automatic protection against XSS
• mode=block
• report=<reporting-URI>
META/HEADER : X-XSS-PROTECTION
X-XSS-Protection (Yes) 4+ 11+ N/A* 8+ Yes 4+
report No Chromium No No No No No
* yes with NoScript

HEADER : X-XSS-PROTECTION
APACHE EXAMPLE
#apache
Header set X-XSS-Protection “1; mode=block”
</IfModule>

HEADER : X-XSS-PROTECTION
PHP CODE
<?php
header(“X-XSS-Protection: 0”, true);

META : X-XSS-PROTECTION
EXAMPLE
<meta http-equiv="X-XSS-Protection" content="1">
<meta http-equiv="X-XSS-Protection" content="1; mode=block">
<meta http-equiv="X-XSS-Protection” content="0">

<meta http-equiv="X-XSS-Protection” content="1; report=<url>">

SUPER PROTECTION
• 3 level of specification
• Specification 1.0 Recommendation
• http://w3c.org/TR/CSP1
• Specification 2.0 Recommendation
• Specification 3.0 Working Draft
META/HEADER : CONTENT-SECURITY-POLICY

SUPER PROTECTION
Recommendation 1 4.4+ 25+ 12+ 23+ 11+ 7+
X-Content-Security-Policy 12+* 4+ 10+
X-WebKit-CSP 14+ 5.1+
Recommendation 2 53+ 40+ 15+ 31+** 27+ 10+
Working Draft 3
* Limited
** Partial

• default-src (csp 1, 2, 3)
• child-src (csp 2, 3)
• connect-src (csp 1, 2, 3)
• font-src (csp 1, 2, 3)
• frame-src (csp 1, 3)
• img-src (csp 1, 2, 3)
• manifest-src (csp 3)
• media-src (csp 1, 2)
• object-src (csp 1, 2)
• script-src (csp 1, 2)
• style-src (csp 1, 2)
• worker-src (csp 3)
FETCH DIRECTIVES

• * (csp 1, 2, 3)
• 'self' (csp 1, 2, 3)
• 'none' (csp 1, 2, 3)
• uri (csp 1, 2, 3)
• media1.example.com
• *.cdn.example.com
• protocol
• https: (csp 1, 2, 3)
• http: (csp 1, 2, 3)
• data: (csp 1, 2, 3)
• mediastream: (csp 2, 3)
• blob: (csp 2, 3)
• ﬁlesystem: (csp 2, 3)
• unsafe-inline (csp 1, 2, 3)
• unsafe-eval (csp 1, 2, 3)
• 'nonce-<base64-value>' (csp 2, 3)
• <hash-source> (csp 2, 3)
• 'strict-dynamic' (csp 2, 3)
FETCH DIRECTIVES VALUES

• Document Directives
• base-uri (csp 2, 3)
• disown-opener (csp 3)
• plugin-types (csp 2, 3)
• sandbox (csp 1, 2, 3)
• Navigation Directives
• form-action (csp 2, 3)
• frame-ancestors (csp 2, 3)
• Directives Deﬁned in Other
Documents
• block-all-mixed-content (csp 3)
• require-sri-for (csp 3)
• upgrade-insecure-requests (csp 3)
DIRECTIVES

META/HEADER: CONTENT-SECURITY-POLICY
• allow-forms
• allow-modals
• allow-orientation-lock
• allow-pointer-lock
• allow-popups
• allow-popups-to-escape-sandbox
• allow-presentation
• allow-same-origin
• allow-scripts
• allow-top-navigation
SANDBOX VALUE

HEADER: CONTENT-SECURITY-POLICY
APACHE EXAMPLE
#apache
Header set Content-Security-Policy “default-src ‘self’;”
</IfModule>

HEADER: CONTENT-SECURITY-POLICY
PHP CODE
<?php
header(“Content-Security-Policy: default-src ‘self’;”, true);

META: CONTENT-SECURITY-POLICY
CODE
<meta http-equiv="Content-Security-Policy" content="default-src https:">

EXAMPLES
default-src 'self';
script-src 'self';
script-src 'self' www.google-analytics.com ajax.googleapis.com;
default-src 'none'; script-src 'self'; connect-src 'self'; img-src 'self'; style-src 'self';
default-src 'self'; img-src *; object-src media1.example.com media2.example.com
*.cdn.example.com; script-src trustedscripts.example.com
default-src https: 'unsafe-inline' 'unsafe-eval'
default-src *; script-src https://example.com/js/;”
default-src *; sandbox allow-scripts

EXAMPLES
default-src 'self'; frame-ancestors 'none'
base-uri 'self'
object-src 'none'
plugin-types application/x-shockwave-flash
plugin-types application/x-java-applet
form-action 'none'
default-src 'self'; require-sri-for script style
block-all-mixed-content
upgrade-insecure-requests; default-src https:

• Reporting Directives
• report-uri (CSP 1, 2, 3)
• report-to (CSP 3)
• Meta/Header
• Content-Security-Policy-Report-Only
REPORT

HEADER : CONTENT-SECURITY-POLICY
APACHE EXAMPLE REPORT
Content-Security-Policy “default-src ‘self’; report-uri http://example.org/csp-report.php”
http://evil.example.com/image.png

RESPONSE
{
“csp-report”: {
“document-uri”: “http://example.org/page.html",
“referrer”: “http://evil.example.com/haxor.html",
“blocked-uri”: “http://evil.example.com/image.png",
“violated-directive”: “default-src ‘self’”,
“original-policy”: “default-src ‘self’; report-uri http://example.org/csp-report.cgi”
}
}

CROSS-ORIGIN RESOURCE SHARING
• Access-Control-Allow-Credentials
• Access-Control-Allow-Headers
• Access-Control-Allow-Methods
• Access-Control-Allow-Origin
• Access-Control-Expose-Headers
• Access-Control-Max-Age
• Access-Control-Request-Headers
• Access-Control-Request-Method
META/HEADER: ACCESS-CONTROL-*

CROSS-ORIGIN RESOURCE SHARING
META/HEADER: ACCESS-CONTROL-*
Access-Control-* 2.1+ 4+ 12+ 3.5+ 10+ 12+ 4+

META: ACCESS-CONTROL-*
CODE
<meta http-equiv="Access-Control-Allow-Origin” content="*">
<meta http-equiv="Access-Control-Allow-Origin” content="http://kuzzle.io">
<meta http-equiv="Access-Control-Allow-Credentials” content="true">
<meta http-equiv="Access-Control-Allow-Headers” content="Content-Length, X-Powered-By">
<meta http-equiv="Access-Control-Allow-Methods” content="POST, GET, OPTIONS">
<meta http-equiv="Access-Control-Expose-Headers” content="Content-Length, X-Powered-By">
<meta http-equiv="Access-Control-Max-Age” content="600">
<meta http-equiv="Access-Control-Request-Headers” content="Content-Length, X-Powered-By">
<meta http-equiv="Access-Control-Request-Methods” content="POST">

HEADER: ACCESS-CONTROL-*
APACHE EXAMPLE
#apache
Header set Access-Control-Allow-Origin “http://kuzzle.io”
Header set Access-Control-Allow-Credentials “true”
Header set Access-Control-Allow-Headers “Content-Length, X-Powered-By”
Header set Access-Control-Allow-Methods “POST, GET, OPTIONS”
Header set Access-Control-Expose-Headers “Content-Length, X-Powered-By”
Header set Access-Control-Max-Age “60”
Header set Access-Control-Request-Headers “Content-Length, X-Powered-By”
Header set Access-Control-Request-Methods “POST”
</IfModule>

HEADER: ACCESS-CONTROL-*
PHP CODE
<?php
header(“Access-Control-Allow-Origin: http://kuzzle.io”, true);
header(“Access-Control-Allow-Credentials: true”, true);
header(“Access-Control-Allow-Headers: Content-Length, X-Powered-By”, true);
header(“Access-Control-Allow-Methods: POST, GET, OPTIONS”, true);
header(“Access-Control-Expose-Headers: Content-Length, X-Powered-By”, true);
header(“Access-Control-Max-Age: 60”, true);
header(“Access-Control-Request-Headers: Content-Length, X-Powered-By”, true);
header(“Access-Control-Request-Methods: POST”, true);

PROTECT YOUR SESSIONS
• Stealing session (session cookie) is quite simple.
• Use HTTPS on your server if you use sessions.
• But it is not enough...
PHP CONFIGURATION

PROTECT YOUR SESSIONS
PHP CONFIGURATION
session.use_cookies “1”
session.use_only_cookies “1”
session.cookie_secure “1”
session.cookie_httponly “1”

PROTECT YOUR COOKIES
• Secure
• HttpOnly
• SameSite
SETCOOKIE
Secure 1+ 1+ 10+ 3+ 9+ 11+ 5+
HttpOnly 1+ 1+ 10+ 3+ 9+ 11+ 5+
SameSite 51+ 51+ N/A N/A N/A 39+ N/A

PROTECT YOUR COOKIES
PHP CODE
bool setcookie ( string $name [, string $value = "" [, int $expire = 0 [, string $path = ""
[, string $domain = "" [, bool $secure = false [, bool $httponly = false ]]]]]] )

PROTECT IN TRANSIT DATA
• Require the browser to use a site in SSL (and retains the information)
HTTP STRICT TRANSPORT SECURITY
Strict-Transport-
Security
4.4+ 4+ 12+ 4+ 11+ 12+ 7+

EXAMPLES
Strict-Transport-Security: max-age=<expire-time>
Strict-Transport-Security: max-age=<expire-time>; includeSubDomains
Strict-Transport-Security: max-age=<expire-time>; preload
Strict-Transport-Security: max-age=<expire-time>; includeSubDomains; preload

APACHE EXAMPLE
#apache
<VirtualHost *:80>
ServerAlias *
RewriteEngine On
RewriteRule ^(.*)$ https://%{HTTP_HOST}$1 [redirect=301]
</VirtualHost>
<VirtualHost *:443>
ServerAlias *
...
Header set Strict-Transport-Security “max-age=16070400; preload"
</IfModule>
</VirtualHost>

PHP EXAMPLE
<?php
// IIS defines the HTTPS protocol to be “off” for non-SSL requests
if (isset($_SERVER['HTTPS']) && $_SERVER['HTTPS'] != 'off') {
header(’Strict-Transport-Security: max-age=16070400’);
} else {
header('Location: https://’.$_SERVER[’HTTP_HOST'] .
$_SERVER['REQUEST_URI'], true, 301);
exit;
}

PROTECT IN TRANSIT DATA
• Tells a Web client to associate a specific public cryptographic public key
to a Web server to reduce the risk of MITM attacks with falsified
certificates.
HTTP PUBLIC KEY PINNING (HPKP)
Public-Key-Pins 38+ 38+ N/A 35+ N/A 25+ N/A
Report-uri 46+ 46+ N/A N/A N/A 33+ N/A

HTTP PUBLIC KEY PINNING (HPKP)
EXAMPLES
Public-Key-Pins: pin-sha256=<base64==>; max-age=<expireTime>;
Public-Key-Pins: pin-sha256=<base64==>; max-age=<expireTime>; includeSubDomains
Public-Key-Pins: pin-sha256=<base64==>; max-age=<expireTime>; report-uri=<reportURI>
Public-Key-Pins-Report-Only: pin-sha256=<base64==>; max-age=<expireTime>; report-
uri=<reportURI>

PROTECT IMPORTED FILES INTEGRITIES
• Verify extracted ﬁles are delivered without unexpected manipulation.
• Uses a cryptographic hash.
• <script>, <link>
• Base64 of
• sha256
• sha384
• sha512
SUBRESOURCE INTEGRITY

SUBRESOURCE INTEGRITY
EXAMPLES
<script src="https://example.com/example-framework.js"
integrity="sha384-oqVuAfXRKap7fdgcCY5uykM6+R9GqQ8K/uxy9rx7HNQlGYl1kPzQho1wx4JwY8wC"
crossorigin="anonymous"></script>
<link rel="stylesheet” href="https://site53.example.net/style.css"
integrity="sha384-+/M6kredJcxdsqkczBUjMLvqyHb1K/JThDXWsBVxMEeZHEaMKEOEct339VItX1zB"
crossorigin="anonymous">
cat example-framework.js | openssl dgst -sha384 -binary | openssl enc -base64 -A

PROTECT YOUR
• Allows you to specify when the browser will deﬁne a Referer header.no-
referrer
• no-referrer
• no-referrer-when-downgrade
• origin
• origin-when-cross-origin
• same-origin
• strict-origin
• strict-origin-when-cross-origin
• unsafe-url
HEADER: REFERRER-POLICY

HEADER: REFERRER-POLICY
COMPATIBILITY
Referrer-Policy 56+ 56+ N/A 50+ N/A 43+ N/A
same-origin N/A N/A N/A 52+ N/A N/A N/A
strict-origin N/A N/A N/A 52+ N/A N/A N/A
strict-origin-
when-cross-
origin
N/A N/A N/A 52+ N/A N/A N/A

MISSING IN THIS TALK
• Meta/Header : X-UA-Compatible
• Meta/Header : X-Frame-Options
• Protect your session
• Protect your cookie
CAN BE FOUND IN THE DOWNLOAD VERSION

ANY QUESTIONS?
THANK YOU!
If you want to talk more,
feel free to contact me.
http://kuzzle.io
This presentation was created using Keynote. The text
is set in Oswald and Ubuntu. The source code is set in
Ubuntu Mono. The iconography is provided by Keynote,
kuzzle.io and Font Awesome.
Unless otherwise noted, all photographs are used by
permission under a Creative Commons license. Please
refer to the Photo Credits slide for more information.
Copyright ©
This work is licensed under Creative Commons
Attribution-ShareAlike 4.0 International. For uses not
covered under this license, please contact the author.
hello@kuzzle.io
@kuzzleio
Kuzzle
kuzzleio
http://kuzzle.io
Browser Serving Your Web Application Security
2014-2017 Philippe Gamache
GAMACHE, Philippe. “Browser Serving Your Web
Application Security” NorthEast PHP Conference.
August 10, 2017. Conference presentation.
pgamache@kuzzle.io
@philoupedia
philippegamache
joind.in/talk/8d346
Please visit us at:

Browser Serving Your We Application Security - ZendCon 2017

Recommended

Recommended

More Related Content

What's hot

What's hot (20)

Similar to Browser Serving Your We Application Security - ZendCon 2017

Similar to Browser Serving Your We Application Security - ZendCon 2017 (20)

More from Philippe Gamache

More from Philippe Gamache (17)

Recently uploaded

Recently uploaded (20)

Browser Serving Your We Application Security - ZendCon 2017
