A breakpoint makes a program stop at a specific point so it can be debugged. Breakpoints are implemented by setting an "int 3" instruction at the target memory address using ptrace calls. When the instruction pointer hits this address, it triggers an interrupt that notifies the debugger. The debugger then reverts the "int 3" instruction, advances the instruction pointer, and allows the user to inspect the program state at the breakpoint.

1. Breakpoints
The secrets behind them

2. A breakpoint makes your program stop whenever a certain point in the program is
reached
What’s a breakpoint?

3. How are they implemented?
Using the following steps...

4. What’s a debugger?
A debugger or debugging tool is a computer program that is used to test and debug
other programs (the "target" program).
Before that….

5. A basic debugger
Fork the debugee process in run_child function by calling “exec”
Now the debugger is the parent process and the debugee the child

6. Step - 1
Identify the memory address you want to set a breakpoint at.
Access that memory address
Set the instruction “int 3” at the first byte of that memory address

7. Ooh! What do they even mean?
Identify the memory address you want to set a breakpoint at

8. Identify the memory address
Here’s a sample program I want to debug -

9. Identify the memory address
And here’s the objdump result -

10. And what about?
Access the memory address

11. Access the memory address
Using ptrace calls
The ptrace() system call provides a means by which one process (the "tracer") may
observe and control the execution of another process (the "tracee"), and examine and
change the tracee's memory and registers. It is primarily used to implement breakpoint
debugging and system call tracing.

12. I don’t even...
Set the instruction “int 3” at the first byte of the memory address

13. int 3
Assembly language instruction for generating software interrupt
int 3 is used by the debuggers
The opcode for int 3 is - 0xCC

14. Set the “int 3” at the first byte

15. What happens now?
The child process is modified and is now being executed.
The instruction pointer loads the memory address at 0x80483e9
And it gets an interrupt
And the parent process (which is the debugger) gets an interrupt.
What does the parent process do?
Handle the breakpoint

16. Step 2
Revert the value that we modified at the first byte of the address on which the
breakpoint is set
Back the instruction pointer one address up

17. Revert the value
Remember we had put “int 3” opcode at the first byte of the address 0x80483e9
Let’s change it back to original instructions

18. Back the IP one step up
We haven’t actually executed the original instruction at the address 0x80483e9
Let’s execute it by setting the EIP/RIP register to the memory address

19. Step 3
Let the user do what she wants to do once the breakpoint has been hit
