1. Bluetooth Security
Mechanisms
Hochschule der Medien
Computer Science and Media
Mobile Security
Marvin Hoffmann (B.Sc.)
contact@marvin-hoffmann.de 18. April 2011

2. Fun-Facts
1. Bluetooth is anglicised for „Blåtand“
- danish king who was well known for his
communication skills
2. Bluetooth logo is a bind rune merging
Hagall and Bjarkan runes, the initials of
„Harald Blauzahn“

3. Agenda
1. Bluetooth Technology and Standards
2. Security Mechanisms
3. Weaknesses
• exloitation and protection
4. Known Attacks
5. Conclusion

4. 1. Bluetooth Technology
• developed by Ericsson in 1994
• since 1998 managed by „Bluetooth Special Interest
Group“ (over 14.000 companies)
• v1.0a July 1999 // v1.1 in early 2001
• current Version 4.0 (since December 2009)
• fully backward compatible to v1.1
4

5. 1. Bluetooth Technology
• uses 2.5 GHz ISM band (Industrial, Scientific,
Medical) - licence-free worldwide
• frequence spectrum 2402-2480 MHz
- divided into 79 channels, 1 MHz each
• channel changes 1600 times per second
- leads to 625 µs timeslots
- determine hopping sequence on connection
5

6. 1. Bluetooth Technology
• Two types of networks
• Piconet
M S
- 1 master, up to 255 slaves
(max. 8 active devices at a time, incl. master) S
• Scatternet
- consists of two or more Piconets M S
P
S
P
S
M
6

7. 1. Bluetooth Technology
• 3 classes with different permitted power and range
• minimum distance 10cm
permitted power range *
(mW) (m)
not
recommended
Class 1 100 100
recommended Class 2 2.5 10
recommended Class 3 1 1
* ranges under best conditions
7

8. 1. Bluetooth Technology
• evolution of data rates and features
v1.1 v1.2 v2.0 v3.0 v4.0
(02.2001) (11.2003) (11.2004) (04.2009) (12.2009)
up to 24 still 2,1 / 24
data-rate 732,2 KBit/s 1 MBit/s 2,1 MBit/s MBit/s MBit/s
(peer-to-peer)
Adaptive
Received Signal high speed
Frequency- Enhanced Data Bluetooth low
new features Strength
Hopping spread Rate (EDR)
channel on
energy protocol
Indication WLAN basis
spectrum (AFH)
8

9. 1. Bluetooth Technology
• the 4 different states when setting up a connection
Inquiry Page
Standby Connected
9

10. 1. Bluetooth Technology
• Inquiry
- master sending on different frequences (changing all 3.12µs)
- slave scanning on different frequences (changing all 1.28µs)
- synchronisation of channelhops
- switching to „Page“-mode
• Page Inquiry Page
- calculating hopping-sequence
including unique hardware-ID
of the master device
Standby Connected
- switching to „Connected“-mode
10

11. 1. Bluetooth Technology
• Connected
- synchronous frequency-hopping
- using pattern settled in page mode
• Standby
- no communication
Inquiry Page
- energy saving
Standby Connected
11

12. 1. Bluetooth Technology
• pairing process
random number
M S
acknowledgement
M S
random number + PIN +
M masters Bluetooth address S
(simplified)
XOR combination
M and verification S
:) / :(
M session key S
12

13. 2. Security Mechanisms
• frequence hopping
- master and slaves within a Piconet know
the hopping-sequence
- attacker does not
• limited range
- class 2 or class 3 should be used (class 2 most common)
- turn off when in public or connection not required
13

14. 2. Security Mechanisms
• optional pre-shared key authentication and
encryption algorithms
• strength of security relies primarily on length and
randomness of the passkey used for pairing
• discoverability and connectability
- control whether remote Bluetooth devices are able to
find and connect to a local Bluetooth device
• optional user authorization for incoming
14

15. 3. Weaknesses
• hidden phones can be scanned
• PIN authentication is weak (BF attack possible when
PIN too simple)
- save pin -> no PIN authentication required again
- PIN should be more then 8 characters
(16 characters possible / 128bit)
- be careful when reauthentication requested
• fix and often weak PINs in devices without keyboard
15

16. 3. Weaknesses
„According to the Bluetooth specification, PINs can be
8-128 bits long. Unfortunately, most manufacturers have
standardized on a four decimal-digit PIN. This attack can
crack that 4-digit PIN in less than 0.3 sec on an old
Pentium III 450MHz computer, and in 0.06 sec on a
Pentium IV 3Ghz HT computer.“
Bruce Schneier (June 2005)
16

17. 3. Weaknesses
• unit keys: one shared key with all trusted units
- trusted units can impersonate the unit distributing the key
- no protection against trusted units
• not all attacks need to know frequence-sequence
• scanner that listens on all 79 channels can spy
hopping-sequence
17

18. 3. Weaknesses
• 3 security modes
- mode 1: no encryption : (
- mode 2: activated by application - therefore possibly off : (
- mode 3: always on : )
18

19. 4. Known Attacks
• BlueJacking
- sending vCard contact, containing a message as name
• BlueSnarfing
- allows access to calendar, contact list, emails and text-
messages
- patched in newer Bluetooth standards
• BlueBug
- calls, SMS, phonebook, forward calls, www, use provider, ...
19

20. 4. Known Attacks
• CommWarrior
- presented by Jörg last week
• Location Tracking
- can be used for advertising combined with Bluejacking
• DOS attack
- e.g. stop device to switch in energy-saving standby mode
20

21. 5. Conclusion
• most dangerous in crowded, public places due to
limited range of class 2 devices
• hiding the phone does not protect completely, but
increases effort dramatically
• relatively secure technology
- depends highly on implementation of manufacturer
(chosen class, security mode, build in PIN, etc.)
21

22. 5. Recommendations
• pairing process at secure place
• choose strong PIN
• turn off completely when not in use
• at least hide your phone
22
