SQL Server Reporting Services provides reporting capabilities through traditional and interactive reports. It offers a scalable and manageable server infrastructure that integrates with SharePoint, Office applications, and browsers. The platform supports structured data like relational, hierarchical, and multidimensional data. SQL Server Reporting Services supports the full reporting lifecycle including authoring, management, and delivery of reports.
Recommended
More Related Content
What's hot
What's hot (20)
Viewers also liked
Viewers also liked (10)
Similar to Basics & Intro to SQL Server Reporting Services: Sql Server Ssrs 2008 R2
Similar to Basics & Intro to SQL Server Reporting Services: Sql Server Ssrs 2008 R2 (20)
More from Bala Subra
More from Bala Subra (19)
Basics & Intro to SQL Server Reporting Services: Sql Server Ssrs 2008 R2
- 1. SQL Server Reporting Services Bala Subra @bsubra @bsubra
- 3. BI User Profiles Information Consumers Information Explorers 5-10% of users 15-25% of users 65-80% of users Analysts @bsubra SQL Server Reporting Services SQL Server Analysis Services
- 4. Reporting Services Architecture (2005) SQL Server Catalog Report Server Delivery Delivery Targets (E-mail, File share, Custom) Security Services (NT, Passport, Custom) Security Data Sources (SQL, OLE DB, ODBC, Oracle, Custom) Output Formats (HTML, Excel, PDF, Custom) Report Processing Browser Management Custom App URL WMI Web Service Data Retrieval Rendering @bsubra
- 5. Reporting Services Architecture (2008) @bsubra
- 6. Service Architecture (Reporting Services) @bsubra
- 8. Reporting Services available Web service development options @bsubra
- 10. Reporting Lifecycle SQL Server Reporting Services supports the full reporting lifecycle, including Authoring, Management and Delivery @bsubra Authoring Management Delivery
- 22. @bsubra
- 25. @bsubra
- 44. Why Report Builder? Report Viewer Report Builder Report Designer @bsubra Report Consumers Business Users Power Users Developers
- 46. Report Builder Architecture SQL Server Catalog Web Service / URL interface Report Server Report Builder Client Model Designer Data Sources (SQL Server, Analysis Services) Drill through report generation Query generation Report Manager Report Designer SQL Mgmt Studio @bsubra
- 54. Report Builder vs. Report Designer @bsubra Report Builder Report Designer Targeted at business users Targeted at IT pros and developers Ad hoc reports Managed reports Auto-generates queries using semantic layer on top of the source Native queries (SQL, OLE DB, XML/A, ODBC, Oracle) Reports built on templates Free-form (nested, banded) reports Click-once application, easy to deploy and manage Integrated into Visual Studio Cannot import Report Designer reports Can work with reports built in Report Builder
- 56. Comparing Report Authoring Environments @bsubra
- 57. SQL Server Report Builder @bsubra
- 58. Planning a Deployment Topology @bsubra or
Editor's Notes
- 11/19/11 14:41 © 2004 Microsoft Corporation. All rights reserved. This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary. Microsoft SQL Server 2008 Reporting Services provides a complete server-based platform that is designed to support a wide variety of reporting needs including managed enterprise reporting, ad-hoc reporting, embedded reporting, and web based reporting to enable organizations to deliver relevant information where needed across the entire enterprise. Reporting Services 2008 provides the tools and features necessary to author a variety of richly formatted reports from a wide range of data sources and provides a comprehensive set of familiar tools used to manage and secure an enterprise reporting solution. Reports are processed and delivered quickly and effectively, enabling users to either receive reports automatically through subscriptions, to access reports from a central report repository on an ad-hoc basis, or to consume reports in context of their business processes through reports directly embedded into their business or web applications.
- 11/19/11 14:41 © 2004 Microsoft Corporation. All rights reserved. This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary. Parameterized reports Linked reports Snapshot reports Cached reports Ad hoc reports Clickthrough reports Drilldown reports Drillthrough reports Subreports
- 11/19/11 14:41 © 2004 Microsoft Corporation. All rights reserved. This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary. Managed Reporting. Also often referred to as enterprise reporting - supports the creation of reports that span all aspects of the business and delivers them across the enterprise to provide every employee real time access to information relevant for their business area and enable better decision making Ad-Hoc Reporting. Enables users to create their own reports on an ad-hoc basis and provides them with the flexibility to quickly get the information that they need, in the format that they need it without submitting a request and waiting for a report developer to create the report for them. Embedded Reporting. Enables organizations to embed reports directly into business applications and web portals, enabling users to consume reports within the context of their business process. Deep integration with Microsoft Office SharePoint Server 2007 also enables organizations to deliver reports through a central report library or to use new web parts for thin rendering of reports directly within SharePoint enabling easy creation of dashboards. In this way organizations are able to bring all business critical data, structured as well as unstructured, from across the company together in one central location providing one common experience for information access so that users can see key business performance information at a glance.
- 11/19/11 14:41 © 2004 Microsoft Corporation. All rights reserved. This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.
- 11/19/11 14:41 © 2004 Microsoft Corporation. All rights reserved. This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.
- In Reporting Services, a report server is implemented as a Windows service that consists of distinct feature areas that run in separate application domains. The service hosts Report Manager, the Report Server Web service, and background processing feature areas. 11/19/11 14:41 © 2004 Microsoft Corporation. All rights reserved. This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.
- The following diagram shows the three-tier architecture of a Reporting Services deployment. It shows the report server database and data sources in the data tier, the report server components in the middle tier, and the client applications and built-in or custom tools in the presentation tier. It shows the flow of requests and data among the server components and which components send and retrieve content from a data store. 11/19/11 14:41 © 2004 Microsoft Corporation. All rights reserved. This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.
- 11/19/11 14:41 © 2004 Microsoft Corporation. All rights reserved. This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.
- 11/19/11 14:41 © 2004 Microsoft Corporation. All rights reserved. This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.
- 11/19/11 14:41 © 2004 Microsoft Corporation. All rights reserved. This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary. List . A freeform layout for data. Chart . A graphical format that displays data in the form of a chart. Table . A tabular format in which data is displayed in rows and columns. You can create a hierarchy of rows to reflect groupings in your data and display group totals. Matrix . A format that supports row and column groups, and which can display aggregated summary data in the cells where row groups and column groups intersect one another, similarly to a pivot table or crosstab. Tablix. A hybrid between Table and Matrix, introduced with the release of SQL Server 2008 Reporting Services.
- 11/19/11 14:41 © 2004 Microsoft Corporation. All rights reserved. This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.
- 11/19/11 14:41 © 2004 Microsoft Corporation. All rights reserved. This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.
- 11/19/11 14:41 © 2004 Microsoft Corporation. All rights reserved. This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.
- 11/19/11 14:41 © 2004 Microsoft Corporation. All rights reserved. This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary. Creating a Group • Right-click on left margin of table and select Insert Group • Select a field to group on or enter an expression • Select any options (page break at start, page break at end, etc.) and click OK to create group • SSRS doesn't automatically add the group field to the group header (the wizard does, though) but you can add it easily enough Groups • You can use Sorting tab of Grouping and Sorting Properties dialog to sort groups and detail with groups • To edit group, right-click on left-hand margin of group header or footer and select Edit Group • Groups can be nested many deep Interactive Sorting • Lets users re-sort reports on columns that you pre-specify • Right-click column header, select Properties, & click Interactive Sort tab Creating Drill-Down Reports • Drill Down Reports (rptCustomerHierarchy2) ? Using the Visibility properties of TableRows you can create an interactive drill-down effect ? Printed output will always show the fully expanded data • Document Maps (rptCustomerHierarchy3) ? Use the Document map label property of Grouping and Sorting Properties dialog ? Converts to PDF Bookmarks Displaying Data on a Report • When you drag a field onto a section of a report, SSRS places it within a TextBox • TextBoxes can be bound to a field or to a member of a global collection Expressions • Reporting Services uses VB-like expressions • You can use standard +. -, *, /, mod operators • String concatenation with & (don’t use +) ? =Fields!City.Value & ", " & Fields!Country.Value • Aggregate functions: ? Sum, Count, Avg, Min, Max, First, Last, etc. • Also supported: ? IIf(), Len(), Switch()
- 11/19/11 14:41 © 2004 Microsoft Corporation. All rights reserved. This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.
- 11/19/11 14:41 © 2004 Microsoft Corporation. All rights reserved. This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary. • =Globals!TotalPages • =Globals!ExecutionTime, etc. Group Calculations rptEmployeeSales2 report • You can use standard aggregate functions ? Sum, Count, Avg, Min, Max, etc. ? e.g. =Sum(Fields!Cost.Value) • Calculating Percentages ? Trick is to give the textbox containing the denominator a name (e.g., txtTotalCost) and use it in expression,referencing it using ReportItems collection ? e.g., • =Sum(Fields!Cost.Value)/ReportItems!txtTotalCost.Value
- 11/19/11 14:41 © 2004 Microsoft Corporation. All rights reserved. This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.
- 11/19/11 14:41 © 2004 Microsoft Corporation. All rights reserved. This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.
- 11/19/11 14:41 © 2004 Microsoft Corporation. All rights reserved. This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary. =iif(code.ColumnSel(Parameters!Column_Sel,3)= true,false,true) Public Function GetColumnColor(ByVal parameter as Parameter) as string Public Function p(ByVal something as String) as String MsgBox(something) Return something End Function Public Function GetFontWeight(ByVal parameter as Parameter) as string
- 11/19/11 14:41 © 2004 Microsoft Corporation. All rights reserved. This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary. Formatting Numbers/Dates ? Right-click on textbox and select Properties ? Enter a .NET format string or click on […] • Styles (Font, FontSize, Color, etc.) ? Use property sheet
- 11/19/11 14:41 © 2004 Microsoft Corporation. All rights reserved. This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary. Creating a Report • A number of ways to create a new report, including ? Right click on the Reports node in Solution Explorer and select • Add New Report – starts report wizard • Add|Add New Item – to create a blank report • Import Reports – to import all of the reports from an Access database
- Read/Write Report Variable Combining Data from More Than One Dataset Conditional Rendering Expressions Let’s say that you want to simplify the report layout when a user exports a report to Microsoft Excel. Sometimes other report items in the report can cause a text box in a data region to render as a set of merged cells when you are unable to get everything to align perfectly. The usual reason that users export a report to Excel is to filter and sort the data, and they are not very interested in the information contained in the other report items. Rather than fussing with the report layout to get each report item positioned and aligned just right, you can use an expression in the Hidden property to keep those report items visible in every export format except Excel. Simply reference the name of the extension as found in the RSReportServer.config file in an expression like this: =iif(RenderFormat.Name="EXCEL", True, False) 11/19/11 14:41 © 2004 Microsoft Corporation. All rights reserved. This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.
- 11/19/11 14:41 © 2004 Microsoft Corporation. All rights reserved. This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.
- 11/19/11 14:41 © 2004 Microsoft Corporation. All rights reserved. This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.
- 11/19/11 14:41 © 2004 Microsoft Corporation. All rights reserved. This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.
- The single server deployment configuration is recommended in the following circumstances: For small to moderate report volumes where demand for report processing is evenly spaced throughout the day and the number of concurrent sessions is easily handled by the processing capability of the computer. When you are a developer and need to develop custom solutions that integrate with Reporting Services. When you are evaluating the software. A scale-out server deployment configuration is recommended in the following circumstances: For high-volume reporting, where activity is measured in concurrent users or in the complexity of reports that take a long time to process or render. For high-availability scenarios, where it is important that the reporting environment does not encounter unplanned downtime or become unavailable. When you want to improve the performance of scheduled operations and subscription delivery. 11/19/11 14:41 © 2004 Microsoft Corporation. All rights reserved. This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.
- 11/19/11 14:41 © 2004 Microsoft Corporation. All rights reserved. This presentation is for informational purposes only. Microsoft makes no warranties, express or implied, in this summary.
